Monoprice 38295 Manuel utilisateur

2-Port USB and HDMI® KVM Switch

P/N 38295

User's Manual

SAFETY WARNINGS AND GUIDELINES

Please read this entire manual before using this device, paying extra

attention to these safety warnings and guidelines. Please keep this

manual in a safe place for future reference.

This device is intended for indoor use only.

Do not expose this device to water or moisture of any kind. Do not

place drinks or other containers with moisture on or near the device.

If moisture does get in or on the device, immediately unplug it from

the power outlet and allow it to fully dry before reapplying power.

Do not touch the device, the power cord, or any other connected

cables with wet hands.

Do not expose this device to excessive vibration.

Do not subject the product to extreme force, shock, or fluctuations

in temperature or humidity.

Do not expose this device to excessively high temperatures. Do not

place it in, on, or near a heat source, such as a fireplace, stove,

radiator, etc. Do not leave it in direct sunlight.

Ensure that power is turned off and disconnected before making

any electrical connections.

Clean using a soft, dry cloth only. Do not use chemical cleaners,

solvents, or detergents. For stubborn deposits, moisten the cloth

with warm water.

This device has no user serviceable parts. Do not attempt to open,

service, or modify this device.

INTRODUCTION

This 2-Port USB and HDMI® KVM Switch allows you to use a single HDMI

monitor, USB keyboard, USB mouse, microphone, and headset/speakers

with two desktop or laptop computers. You can easily switch computers

using the built-in Port Selector, keyboard hotkeys, or with a simple

double-click of the mouse wheel. It supports HDMI video resolutions up

to 1900x1200 and is compatible with Windows®, Mac®, Linux®, UNIX®,

Novell® NetWare®, and DOS PCs. It features Video DynaSync™

technology, which eliminates boot-up display problems and optimizes

the video resolution when switching ports. The KVM and audio focus can

be separated, so one computer can have the KVM focus and the other

the audio focus. If one of the connected computers is powered off, the

switch will automatically select the other computer.

FEATURES

Includes two sets of 3.9-foot USB, HDMI®, and audio cables built-in

for connecting the two computers

Allows computer selection using the dedicated Remote Port

Selector button, keyboard hotkey, or with the simple double-click

of the mouse wheel

Supports independent KVM and audio selection, one computer can

have the KVM focus, while the other has the audio focus

Supports HDMI resolutions up to 1900x1200

Features Video DynaSync™ technology, which eliminates boot-up

display problems and optimizes the video resolution when

switching ports

Compatible with Windows®, Mac®, Linux®, UNIX®, Novell®

NetWare®, and DOS PCs

Features independent KVM and audio computer selection

Supports gaming and multimedia keyboards

Supports multifunction and wireless keyboards and mice

The console mouse port emulation/bypass feature supports most

mouse drivers

Features Mac keyboard support and emulation

Supports US English, French, and Japanese keyboard layouts

Supports firmware upgrading

Requires no external power connection

CUSTOMER SERVICE

The Monoprice Customer Service department is dedicated to ensuring

that your ordering, purchasing, and delivery experience is second to

none. If you have any problem with your order, please give us an

opportunity to make it right. You can contact a Monoprice Customer

Service representative through the Live Chat link on our website

www.monoprice.com or via email at suppo[email protected]. Check the

website for support times and links.

PACKAGE CONTENTS

Please take an inventory of the package contents to ensure you have all

the items listed below. If anything is missing or damaged, please contact

Monoprice Customer Service for a replacement.

1x 2-Port KVM Switch

2x Hotkey Stickers

1x User's Manual

1x Quick Start Guide

PRODUCT OVERVIEW

1. Port LEDs: Two LEDs to indicate the selected computer and its

status. The LED illuminates solid when the corresponding computer

is selected. The LED flashes when the corresponding computer is

being scanned by the Auto Scan function. The LED is off when the

corresponding computer is not selected.

2. Console Keyboard Port: Plug your USB keyboard into this port.

3. Console Monitor Port: Plug your HDMI® display into this port.

4. Console Mouse Port: Plug your USB mouse into this port.

5. KVM Cables: Two sets of USB, HDMI, and audio cables for

connecting the two computers.

6. Console Audio Ports: 3.5mm jacks for connecting a microphone and

headphones/speakers. Note that if your HDMI display has speakers,

you do not need to connect headphones/speakers, unless you want

to use separate the KVM and audio focus feature.

7. Remote Port Selector: Momentarily press the button to switch

computer selection. Press and hold the button for 3 seconds to

swap the default Hotkey Prefix between Scroll Lock and Ctrl.

OPERATING SYSTEM COMPATIBILITY

The following table details the specific operating system versions

supported by the KVM.

Version

Windows®

2000 / XP / 2003 / 2008 / Vista® / 7

Linux®

RedHat

9.0 / Fedora and higher

SuSE

10 / 11.1 and higher

Ubuntu

7.04 / 7.10

UNIX®

FreeBSD

5.5 / 6.1 / 6.2

Novell®

NetWare®

6.0 / 6.5

Mac®

OS 9 and higher

DOS

6.2 and higher

INSTALLATION

Perform the following steps to install this KVM switch.

1. Ensure that all equipment to be connected is powered off and

unplugged from its power source. This is especially true for

computers that have the Keyboard Power On feature.

2. Plug your USB keyboard into the Console Keyboard Port on the

switch.

3. Plug your HDMI® display into the Console Monitor Port on the

switch.

4. Plug your USB mouse or graphics tablet into the Console Mouse

Port on the switch.

5. (Optional) Plug a microphone into the 3.5mm Console Audio Port

with the pink plastic ring.

6. (Optional) Plug a pair of headphones or powered speakers into the

3.5mm Console Audio Port with the green plastic ring. Note that if

your HDMI display has speakers, you do not need to use external

headphones/speakers, unless you want to use the separate KVM

and audio focus feature.

7. Plug the two USB, one HDMI®, and two audio cables on one of the

KVM Cables into the appropriate ports on the first computer.

8. Repeat step 7 for the second KVM Cable and second computer.

9. Plug in and power on both computers. By default, the switch will

select the first computer that is powered on.

Note: The USB ports are standard USB 2.0 ports and can accept any USB

peripheral. If you want to use additional peripherals, plug a USB hub into

one of the two USB ports, then plug the keyboard, mouse, and additional

peripheral(s) into the hub.

OPERATION

This KVM switch supports three different methods of switching the

selected computer, which are detailed in the following sections.

Important Note: Do not switch focus when a USB peripheral, other than

the keyboard and mouse, is in active operation. Doing so could result in

data loss and/or file corruption.

Manual Switching

Momentarily press the button on the Remote Port Selector to manually

switch the KVM and audio focus from one computer to the other.

Mouse Switching

Double-click the mouse wheel button to swap the KVM and audio focus

from one computer to the other.

Notes:

1. This method is only supported by USB 3-button mice with a scroll

wheel.

2. The function is not available by default. It must be enabled by first

enabling Mouse Emulation with the hotkey command ([m] [Enter]),

then turning on the Scroll Wheel Switching function ([w] [Enter]).

Hotkey Switching

The hotkey method of switching offers the most flexibility in that you can

independently switch the KVM and audio focus. All hotkey commands

are prefaced with the Hotkey Prefix, which by default is two presses of

the [Scroll Lock] key. To swap the KVM and audio focus from one

computer to the other, type:

[Scroll Lock] [Scroll Lock] [Enter]
