ML Accessories LSPIKEA Mode d’emploi

INSTALLATION & MAINTENANCE MANUAL

LSPIKEA

These instructions should be read carefully and retained by the end-user after

installation for future reference and maintenance.

These instructions should be used to aid the installation of the following product:

LSPIKEA

GENERAL INSTRUCTIONS

SAFETY

• This product must be installed in accordance with the latest edition of the IEE Wiring

Regulations (BS7671) and current Building Regulations. If in any doubt, consult a

qualiﬁed electrician

• Please isolate mains prior to installation or maintenance

• Check the total load on the circuit (including when this luminaire is ﬁtted) does not exceed

the rating of the circuit cable, fuse or circuit breaker

• Please note the IP (Ingress Protection) rating of this luminaire when deciding the location

for installation

• This product is Class I and must be earthed

• This product is IP65 rated

INSTALLATION

Note - If this luminaire is being used in conjunction with an external PIR or sensor, please

conﬁrm with the manufacturer of the sensors that they are compatible with LED luminaires

• Provide power to the required point of installation (refer to BS7671 for correct

cabling methods). Suitable IP rated junction boxes should be used where required

• The power source connections should be local and accessible via a suitable IP rated

enclosure

• Choose a position for the luminaire ensuring that the ground is suitable to ﬁrmly hold the

spike and luminaire in position. Check the ground is not liable to ﬂooding and the spike

does not infringe with any underground pipes or cables (see Fig. 1)

Fig. 1

• The body of the product should not rest directly on the ground

• The pre-installed cable supplied is for above-ground use only. Cables that are to be

routed within walls or below ground must be protected by means of a suitable conduit or

trunking (see Fig. 2)

• Connect the luminaire to the mains supply ensuring that correct polarity is observed:

Live (brown), Earth (green/yellow), Neutral (blue)

• Switch on and check for correct operation

Fig. 2

•Connect the luminaire to the mains supply ensuring that correct polarity is observed: Live (brown),

Earth (green/yellow), Neutral (blue)

•Switch on and check for correct operation

WARNING

This luminaire must be disconnected from the circuit if subjected to any high voltage or insulation resistance

testing. Irreparable damage will occur if this instruction is not followed.

GENERAL

The LED lamps fitted in this product are non-replaceable. The product should be recycled in the correct manner

when it reaches the end of its life. Check local authorities for where facilities exist.

Clean the external surfaces with a damp cloth using a mild solution of detergent and warm water only, do not use

aggressive cleaning products or solvents which may damage the product.

Do not use any source of high-pressure washers to maintain or clean this product.

This product is not suitable for installation in or near a coastal or marine environment.

This product is non-dimmable.

WARRANTY

This product has a warranty of 2 years from the date of purchase. Failure to install this product in accordance

with the current edition of the IEE Wiring Regulations (BS7671), improper use, or removal of the batch code will

invalidate the warranty. If this product should fail within its warranty period it should be returned to the place of

purchase for a free of charge replacement. ML Accessories does not accept responsibility for any installation

costs associated with the replacement product. Your statutory rights are not affected. ML Accessories reserve the

right to alter product specification without prior notice.

AVAUG20_V1

WARNING

This luminaire must be disconnected from the circuit if subjected to any high voltage or

insulation resistance testing. Irreparable damage will occur if this instruction is not followed.

WARRANTY

GENERAL

This product has a warranty of 2 years from date of purchase. Failure to install this product

in accordance with the current edition of the IEE Wiring Regulations (BS7671), improper

use, or removal of the batch code will invalidate the warranty. If this product should fail

within its warranty period it should be returned to the place of purchase for a free of

charge replacement. ML Accessories does not accept responsibility for any installation

costs associated with the replacement product. Your statutory rights are not affected. ML

Accessories reserve the right to alter product speciﬁcation without prior notice.

The LED lamps ﬁtted in this product are non-replaceable. The product should be recycled

in the correct manner when it reaches the end of its life. Check local authorities for where

facilities exist.

Clean the external surfaces with a damp cloth using a mild solution of detergent and warm

water only, do not use aggressive cleaning products or solvents which may damage the

product.

Do not use any source of high-pressure washers to maintain or clean this luminaire.

This product is not suitable for installation in or near a coastal or marine environment.

This product is non-dimmable.

ML Accessories Limited LU5 4LT

www.mlaccessories.co.uk

AVAUG20_V1
