INSTALLATION & MAINTENANCE MANUAL

E27PR

These instructions should be read carefully and retained after installation by the end user for

future reference and maintenance.

These instructions should be used to aid installation of the following product:

E27PR

GENERAL INSTRUCTIONS

• This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671)

and current Building Regulations. If in any doubt, consult a qualiﬁed electrician

• Please isolate mains prior to installation or maintenance

• Check the total load on the circuit (including when this luminaire is ﬁtted) does not exceed the rating of the

circuit cable, fuse, or circuit breaker

• Please note the IP (Ingress Protection) rating of this luminaire when deciding the location for installation

• This product is Class I and must be earthed

• This product is IP65 rated

SAFETY

INSTALLATION

• Provide power to the required point of installation (refer to BS7671 for correct cabling methods). Suitable IP

rated junction boxes should be used where required

• Round cable should be used for the mains supply. The use of ﬂat cable will cause water ingress to the ﬁtting

• Remove the diffuser by removing the two screws on the top and bottom of the diffuser

• Drill out one of the 20mm drilling guides on the ﬁtting, and ﬁt a grommet (included) or compression gland

(not included)

• Using the back plate as a template, mark the location for, and drill the ﬁxing holes ensuring not to infringe

with any gas/water pipes or electrical cables

• Feed the mains cable through the rubber grommet to retain IP rating

• Fix the base to a suitable solid surface using the screws provided. Rubber washers or sealant should be

applied around the screw heads to prevent water ingress

• Connect the luminaire to the mains supply ensuring the correct polarity is observed: L - Live (brown),

E - Earth (green/yellow), N - Neutral (blue)

• Add a suitable max. 100W E27 lamp

• Replace the diffuser

• Switch on and check for correct operation

WARNING

This product is not suitable for installation in or near a coastal or marine environment.

GENERAL

Clean the external surfaces with a damp cloth using a mild solution of detergent and warm water only, do not

use aggressive cleaning products or solvents which may damage the product.

This product is dimmable dependent on lamp type

This product should be recycled in the correct manner when it reaches the end of its life. Check local authorities

for where facilities exist.

AVJUN21_V2

ML Accessories Limited LU5 4LT

www.mlaccessories.co.uk

INTERNATIONAL

CONTACT DETAILS

INTERNATIONAL

CONTACT DETAILS

INTERNATIONAL

CONTACT DETAILS

WARRANTY

This product has a warranty of 1 year from date of purchase. Failure to install this product in accordance with

the current edition of the IEE Wiring Regulations (BS7671), improper use, or removal of the batch code will

invalidate the warranty. If this product should fail within its warranty period, it should be returned to the place

of purchase for a free of charge replacement. ML Accessories does not accept responsibility for any installation

costs associated with the replacement product. Your statutory rights are not affected. ML Accessories reserve

the right to alter product speciﬁcation without prior notice.
