MIMAKI JV400-LX Manuel utilisateur

MIMAKI ENGINEERING CO., LTD.

URL:http://eng.mimaki.co.jp

Service Documents

D500698-22

JV400-130LX / 160LX

INSTALLATION GUIDE

Service Documents > Change Tracking

Change Tracking

Date 2013.04.30 Manual Ver. 2.2 Remark

Status Index Rev. Changes

Revised 5.1-P.1

-P.2

1.5 Illustrations of jointing are changed.

Revised 5.1-P.5 1.1 Work procedure for W ink using is changed.

Date 2013.10.10 Manual Ver. 2.1 Remark

Status Index Rev. Changes

Revised 2 1.3 Weight is changed..

Revised 4.2 1.1

1.2

Screw type is changed..

Revised 4.3 1.3 Screw type is changed..

Revised 4.4 1.3 Screw type is changed..

Added 5 1.3 6 color is added.

Added 5.1 1.4 6 color is added.

Revised 7.3 1.5 Work procedure is changed.Important is added.

Revised 7.6 1.2 Work procedure is changed.

Date 2013.04.15 Manual Ver. 2.0 Remark

Status Index Rev. Changes

Revised 3 1.2 Illustration is changed in accordance with heater change.

Revised 4 1.2 Illustration is changed in accordance with heater change.

Revised 4.2-P.6

4.2-P.7

4.2-P.9

1.1 Drying heater is changed and Finger guard is added.

Revised 4.3 1.2 Work procedure is changed in accordance with heater change.

Revised 4.4 1.2 Drying heater is changed and Finger guard is added.

Revised 4.5 1.2 Finger guard is added.

Added 4.6 1.0 New page is added.

Added 5 1.2 6 color is added.

Added 5.1 1.3 6 color is added.

Added 5.2 1.3 6 color is added.

Revised 6.1 1.2 Drying heater is changed and Finger guard is added.

Revised 7.3 1.4 Ink set is changed.

Revised 7.6 1.1 Work procedure is changed.

Date 2013.01.20 Manual Ver. 1.8 Remark

Status Index Rev. Changes

Revised 2 1.1 Specification for power supply is changed.

Revised 4 1.1 Caution for environmental of installation is added.

Revised 6.2 1.1 Caution is added.

Service Documents > Change Tracking

Change Tracking

Date 2012.10.15 Manual Ver. 1.7 Remark

Status Index Rev. Changes

Revised 4.5-P.14 1.1 The illustration is changed.

Revised 7.2-P.1

7.2-P.2

1.1

1.3

Page is deleted.

Revised 7.3-P.1

7.3-P.2

7.3-P.3

1.3

1.2

Entire change according to the work for air purge was added.

Date 2012.06.07 Manual Ver. 1.6 Remark

Status Index Rev. Changes

Revised 7.2-P.4 1.2 "Target value" is changed.

Date 2012.05.29 Manual Ver. 1.5 Remark

Status Index Rev. Changes

Revised 5 1.1 6c and 6c+W ink set are deleted, and 4c+W is added.

Revised 5.1-P.2 1.2 The illustration of the coupling is changed.

Ink set 6c and 6c+W are deleted, and 4c+W is added.

Revised 5.1-P.3 1.2 An important item of step 2 is changed.

Revised 5.2 1.2 The ink label illustration is changed.

Revised 7.2-P.4 1.2 Step 6 is deleted (The following numbers advance).

Date 2012.05.15 Manual Ver. 1.4 Remark

Status Index Rev. Changes

Revised 4.3-P.11 1.1 Deleted:Step6)

Revised 4.3-P.12 1.1 Step number advances.

Date 2012.03.16 Manual Ver. 1.3 Remark

Status Index Rev. Changes

Revised 4.3 1.1 3) of Step 3 was added.

Date 2012.02.07 Manual Ver. 1.20 Remark

Status Index Rev. Changes

Revised 3 1.1 Installation Space was revised.

Revised 7.3 1.1 The procedure of the air purge was changed.

Date 2012.01.11 Manual Ver. 1.10 Remark

Status Index Rev. Changes

Revised 4.4 1.1 Step4 was added.

Revised 5.1 1.1 The connection of the ink tube was changed.

Revised 5.2 1.1 Hint was added.

Label of accessories was changed.

Service Documents > Change Tracking

Change Tracking

Date 2011.12.19 Manual Ver. 1.00 Remark

Status Index Rev. Changes

Released New issued

Contents

1. About the Installation Guide . . . . . . . . . . . . . . . . . . . . . . 1-1

1.1 Description of the Ink Used . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

2. Main Unit Specifications . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

3. Installation Space . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

4. Printer Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

4.1 Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

4.2 Assembling the Stands and the Device . . . . . . . . . . . . . . . . . . 4-3

4.3 Mounting the Drying heater Assy . . . . . . . . . . . . . . . . . . . . . . 4-10

4.4 Mounting the Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-14

4.5 Removing the Stopper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-15

4.6 Removing the Fitting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-16

5. Ink Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

5.1 Changing the Joints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2

5.2 Pasting label on eco case . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6

6. Power Supply Related . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1

6.1 Setting the Voltage Selector . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2

6.2 Connecting the Power Cable . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

6.3 Turning the Power On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4

6.4 Turning the Power Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5

7. Outputting Plots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1

7.1 Setting at Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2

7.2 Pressure Adjustment (Deleted) . . . . . . . . . . . . . . . . . . . . . . . . 7-3

7.3 Performing the Initial Ink Fill . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4

7.4 Performing a Test Print . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7

7.5 Cleaning the Heads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8

7.6 Image Quality Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-9

R.1.0

INSTALLATION GUIDE > About the Installation Guide

Model

JV400-130/160LX

Issued 2011.02.15

Revised F/W ver. Remark

1.0

Rev.

1. About the Installation Guide

Outline

This document is a collection of information for service engineers when setting up JV400-130/160LX inkjet printers.

During the setup, proceed with the work by referring to this document and the following related documents.

Documents related to this unit

Documents other than this document which describe the JV400-130/160LX are listed below. Refer to these as

required.

Operation Manual (included with product)

Mechanical Drawing

Maintenance Manual

Accessories List

R.1.0

INSTALLATION GUIDE > About the Installation Guide > Description of the Ink Used

Model

JV400-130/160LX

Issued 2011.02.15

Revised F/W ver. Remark

1.0

Rev.

1.1 Description of the Ink Used

Outline

Hand the "Material Safety Data Sheet (MSDS)" over to the user who will actually use this unit.

Furthermore, explain about the following items with regards to using the product safely.

Usage environment

Emergency measures

R.1.3

INSTALLATION GUIDE > Main Unit Specifications

Model

JV400-130/160LX

Issued 2011.02.15

Revised

2013.10.10

F/W ver. Remark

1.3

Rev.

2. Main Unit Specifications

List of main unit specifications

Item Specifications Remarks

JV400-130/160LX

Power supply specifications Single phase AC100V to 120V : 1440W x 2

Single phase AC220V to 240V : 1800W x 2

Power consumption 2120VA or less x2 lines Main unit including heater

Installation

environment

Usable

temperature 20



C ~ 35



In environments outside of the

range shown on the left, the ink

ejection stability may deteriorate

Relative

humidity 35 to 65% Rh (no condensation)

Precision

guaranteed

temperature



C to 25



Temperature

gradient





C/h or less

Dust Office equivalent

Weight Main unit 198kg(130LX), 235kg(160LX)

External dimensions (W) 2885 mm or less

R.1.2

INSTALLATION GUIDE > Installation Space

Model

JV400-130/160LX

Issued 2011.02.15

Revised

2013.04.15

F/W ver. Remark

1.2

Rev.

3. Installation Space

1,000 mm or more

2854 mm

or more

500 mm or more

JV400-130LX : 3634mm

or more

JV400-160LX : 3879mm

or more

1,000 mm or more

500 mm or more

R.1.2

INSTALLATION GUIDE > Printer Assembly

Model

JV400-130/160LX

Issued 2011.02.15

Revised

2013.04.15

F/W ver. Remark

1.2

Rev.

4. Printer Assembly

List of work procedures

Work operation Description Refer to

1

Unpacking Unpack the product. 4.1 (p.2)

2

Assembling the leg with the main

body

Assemble the leg with the main body. 4.2 (p.3)

3

Mounting the Drying heater Assy Mount the Drying heater Assy. 4.3 (p.10)

4

Mounting the Accessories Carry out the work to attach the accessories. 4.4 (p.14)

5

Removing the Stopper Remove the stopper. 4.5 (p.15)

In order to prevent accidental cuts, always wear gloves when performing disassembly and assembly

work.

When carrying out the work, ensure that there is sufficient surrounding space, and install in a stable

location.

This product is extremely heavy. Take great care when handling the product.

Do not install the machine in the room or area using (photographic) fixing solution or acid solution

(acetic acid, hydrochloric acid). An irrecoverable deflection or nozzles missing occur the machine

by chemical effect of above solution.

Main unit
