MELICONI GUMBODY UNIVERSAL 6 LIGHT Manuel utilisateur

USING THE KEYS AND FUNCTIONS

The functions described below are only available

if they are already foreseen by your TV.

Keep your Instruction Booklet and Code Booklet for future reference.

For anyone with internet, via the website www.gumbodylight.com, it is even easier and quicker

to programme the remote control and discover all the potential of the

UNIVERSAL 6 Light thanks to the on-line guide.

SET-UP

Read these instructions carefully before programming your remote control!

Thanks to its large database and numerous functions the U N I V E R S A L 6 L i g h t remote control is

ideal for replacing up to 6 remote controls of any brands for TV - VCR - DVD - SAT - AUX - TER

(Digital

Terrestrial)

Its ergonomic form and casing in soft rubber make it easy to grip and protect it against falls and bumps.

Thanks to the LIGHT button, the keys light up so you can use the remote control even in the dark. Thanks to

the LEARN function, the U N I V E R S A L 6 L i g h t can also learn the signals of any original remote

controls issued in the future and thus not yet included in its database. It can also learn and memorize secondary

functions on the function keys F1 - F2 - F3 - F4 or on any other key on the keypad.

Thank you for choosing a MELICONI remote control.

U N I V E R S A L 6 L i g h t

Keys for selecting which appliance

you want to use.

They light up whenever a command

is sent to the selected appliance.

Key to activate

the LEARN functions.

This lights up while the commands

are being memorized and during

their transmission.

Specific area for SET TOP BOX

Control the volume using +/–

To move around within the MENU

or to control BRIGHTNESS and

COLOUR

Number keys

Keys that the user can customize

to memorize and access additional

commands

Impact-proof rubber casing

ON/OFF key to turn the

selected appliance

on and off

TELETEXT keys

Turns the volume on and off

FORWARD / REWIND

functions for VCR and DVD

VCR/DVD function keys: RECORD

PAUSE - STOP - PLAY

To select the next (P+) or previous

(P-) channel or programme

Confirm button

To select an external

input terminal

TV functions always active

LIGHT button

to light up the keys

To programme the

U N I V E R S A L 6 L i g h t

remote control,

follow the indications in paragraph

The quickest and easiest way to programme the remote control is by

consulting the website www.gumbodylight.com.

Warning: programme one appliance at a time!

BRAND SEARCH PROGRAMMING MODE

FITTING THE BATTERIES

Before programming and using

the remote control, fit the batteries.

The remote control requires 2 new AA/LR06 batteries. Insert the batteries as shown:

• Change the batteries if the light indicator starts to flash

during use. The batteries are low.

• Make a note of the codes for your appliances on the

adhesive label inside the battery cover in case you have

to reprogramme your remote control.

• This remote control has a permanent memory and does

not lose the programmed codes or functions when the

batteries are removed.

To display and make a note of the code memorized by means of the search,

follow the instructions described in the paragraph CURRENT CODE DISPLAY.

ADDITIONAL CHECK

Check that some of the other functions used on your original remote control are working correctly. If the

commands function incorrectly or erratically, you have probably entered a code for a similar remote control

but not the right one. In this case, repeat the search procedure starting from point 3, entering the code

previously used (e.g. 0025).

+++

1. Turn on the appliance to be programmed:

- if a VCR, insert a cassette

- if a SAT or TER select a programme

- if a DVD insert a DVD.

2. Look for the brand of the appliance you want to programme

in the code book and make a note of the code indicated

alongside (

e.g. PHILIPS 0025

) or the code for the brand

indicated by the arrow.

3. Hold down the selection key for the appliance to be

programmed for 5 seconds.

4. When the key is released, it will start to flash. Enter the

brand code previously identified (

e.g. 0025

). The selection

key flashes more quickly to indicate that the remote

control is ready for the search.

5. Point the remote control at the appliance. Press and slowly

release the ON/OFF key or PLAY for the VCR and DVD

several times, stopping when the appliance responds

correctly to the command.

6. When the appliance responds correctly, press OK to

confirm. Three flashes indicate that the search operation

has been completed correctly.

PHILIPS 0025

PHONOLA

PHILIPS

5 SEC.

or or or or or

1. Turn on the appliance to be programmed:

- if a VCR, insert a cassette

- if SAT or TER select a programme

- if a DVD insert a DVD.

2. Look for the brand of the appliance you want to programme

in the code book and make a note of the first code in

the list (

e.g. Philips TV 1000 - VCR 5070

3. Hold down the selection key for the appliance to be

programmed for 5 seconds.

4. When the key is released, it will start to flash. Enter the

previously identified code (

e.g. 1000

). Three flashes

indicate that the code has been memorized correctly. If

not, try the code entry procedure again from point 3.

PHILIPS 0025

TV 1000 1006 1007 1008

1009 1010 1011 1012 1013

1014 1015 1016 1017 1018

VCR 5070 5072 5073 5076

N.B. THE LIGHT INDICATOR STOPS FLASHING.

The remote control exits programming mode and the light indicator stops flashing:

• if no keys are pressed for 14 seconds

• if an invalid brand code is entered

• if a key other than ON/OFF or PLAY is accidentally pressed

• if the end of the code search list has been reached. In this case, go back to point or switch

to programming mode .

DIRECT CODE ENTRY

The quickest and easiest way to programme the remote control is by

consulting the website www.gumbodylight.com.

Warning: programme one appliance at a time!

GLOBAL SEARCH REMOTE CONTROL PROGRAMMING

This operation can take up to 20 minutes and should be carried out if you have not

succeeded in programming the remote control by means of the other methods.

The quickest and easiest way to programme the remote control is

by consulting the website www.gumbodylight.com.

Warning: programme one appliance at a time!

Remember to make a note of the codes used to programme the remote control on the adhesive

label inside the battery cover for quick and easy reprogramming.

N.B. THE LIGHT INDICATOR STOPS FLASHING.

The remote control exits programming mode and the light indicator stops flashing:

• if no keys are pressed for 14 seconds

• if an invalid code is entered

• if the wrong keys are accidentally pressed.

ADDITIONAL CHECK

Check that some of the other functions used on your original remote control are working correctly. If the

commands function incorrectly or erratically, you have probably used the wrong code. In this case, repeat

the procedure starting from point 3. This time, however, use the NEXT CODE in the list (e.g. Philips TV

1006 – VCR 5072).

+++

1000

1. Turn on the appliance to be programmed:

- if a VCR, insert a cassette

- if SAT or TER select a programme

- if a DVD insert a DVD.

5 SEC.

or or or or or

2. Hold down the selection key for the appliance to be

programmed for 5 seconds.

3. When the key is released, it will start to flash. Enter the

code 0000; the selection key flashes more quickly to

indicate that the remote control is ready for the search.

4. Point the remote control at the appliance. Press and slowly

release the ON/OFF key or PLAY for the VCR and DVD

several times, stopping when the appliance responds

correctly to the command.

5. When the appliance responds correctly, press OK to

confirm. Three flashes indicate that the search operation

has been completed correctly.

+++

0000

ADDITIONAL CHECK

Check that some of the other functions used on your original remote control are working correctly.

If the commands function incorrectly or erratically, you have probably entered a code for a similar remote

control but not the right one. In this case, repeat the search procedure starting from point 2.

To display and make a note of the code memorized by means of the search,

follow the instructions described in the paragraph CURRENT CODE DISPLAY.

N.B. THE LIGHT INDICATOR STOPS FLASHING.

The remote control exits programming mode and the light indicator stops flashing:

• if no keys are pressed for 14 seconds

• if a key other than ON/OFF or PLAY is accidentally pressed

• if the end of the code search list has been reached. In this case, start again from point 2 or

consult our website www.gumbodylight.com.

CURRENT CODE DISPLAY

In addition to what is described above, you can assign the selection keys to appliances other than those

indicated; for example, you can use the SAT key to control the TV. This allows every possible combination

according to your requirements; ust programme the remote control by means of procedure direct code

entry. To find out the appliance code if you have used procedure or , proceed as described in the

paragraph CURRENT CODE DISPLAY.

USING THE REMOTE CONTROL WITH MORE THAN ONE APPLIANCE OF THE SAME TYPE

A C

N.B. this operation cannot be interrupted and the remote control cannot

therefore be used until the end of the 4 series of flashes.

1. Hold down the selection key of the appliance whose code

you want to know for 5 seconds.

2. When the key is released it will start to flash; press and

release the 1-/-- key within 8 seconds.

3. After a few seconds, the light indicator produces 4 series

of flashes, with a pause between each series, correspon-

ding to the current code. Count the number of flashes;

each series of flashes corresponds to one figure in the

code. 10 flashes correspond to 0.

4. Make a note of the code on the adhesive label inside the

battery cover for quick and easy future reprogramming.

........................................................ = 1

............................................ = 3

= 0

.......................... = 6

Code obtained = 1306

To find out the code of your remote control, follow this procedure:

5 SEC.

or or or or or

5 SEC.

or or or or or

LIGHT FUNCTION: Lights up the keys on the remote control

Press the LIGHT button the remote control keys will light up immediately. This is very useful in the

dark to find which key to press. The light goes out when the LIGHT button is pressed again or after about

10 seconds if no keys are pressed.

TV FUNCTIONS ALWAYS ACTIVE

The TV functions VOLUME + / VOLUME – / MUTE and AV are always available, regardless of which appliance

is being used.

To use this function the remote control

you want to copy the signal from must still work.

LEARN FUNCTION

This function allows the remote control to:

Learn the missing functions of an original remote control and memorize them on the keys F1 -

F2 -F3 - F4 or on any other key and thus replace the original remote control

Learn all the functions of a new remote control issued in the future and thus not yet included

in the database of the universal remote control.

This indicates the maximum distance for data exchange between the two remote controls. In order

to copy the signals the remote controls must be positioned at half this distance, taking care not to move

them until the process is completed.

L1 Learn the missing functions of an original remote control and

memorize them on any key of the

U N I V E R S A L 6 L i g h t

To copy the signals it is first of all necessary to position

the remote controls at the correct distance from each other:

1. Position the original remote control in front of the universal

remote control, so that the areas that emit the infrared

signals are in front of each other and about 5 cm apart.

2. Press the LEARN key briefly and then, within five seconds,

press and hold down any key on the original remote

control. The yellow light under the LEARN key should

start to flash; if not, the remote controls should be moved

closer together.

3. Gradually increase the distance between the two remote

controls, making sure they are still in line with each other,

until the yellow light under the LEARN key stops flashing.

5 cm

Max dist

4. Press the selection key of the required appliance.

5. Briefly press the LEARN key together with one of the keys

F1 - F2 - F3 - F4, or any other key on which you want to

memorize the function to be copied.

6. The yellow light of the LEARN key will light up and stay

lit while waiting to receive a signal from the original remote

control.

7. Press the key on the original remote control corresponding

to the signal to be copied and hold it down until the

yellow light of the LEARN key goes out.

+or …

or or

or or or or or

N.B.: if the light of the LEARN key lights up again when the key is released, the same key on the original

remote control must be pressed again until the light goes out again.

L2 Learn all the functions of a new remote control

not yet included in the

U N I V E R S A L 6

L i g h t database

With the

U N I V E R S A L 6 L i g h t

it is possible to create

up to 6 completely empty keypads so that a total of 96 new commands

can be copied with the LEARN function.

HOW TO USE THE ADDITIONAL COMMANDS WHICH DO NOT APPEAR ON THE KEYPAD

Although not indicated on the keypad,

some keys can be used for additional commands.

Find them on your

U N I V E R S A L 6 L i g h t

remote control by pressing the buttons one by one and

discovering the commands that interest you.

In particular, the additional functions most frequently used, such as NORMALIZATION, COLOUR and

BRIGHTNESS, can be found on the following keys:

After setting up one of these keypads with LEARN commands, it can be disabled by programming another

code on the appliance selection key and subsequently reactivated, ust as it was before, by re-entering

the code 800x on the same appliance selection key or on another key.

1. Programme an appliance selection key following procedure

entering one of the following codes: 8000, 8001,

8002, 8003, 8004 or 8005.

2. To copy and memorize the signals from one or more

original remote controls, follow the procedure .

For less frequently used functions look for the additional commands on our website www.gumbodylight.com.

As well as easily finding the code to programme your remote control, the on-line guide will help you to

find which keys on the

U N I V E R S A L 6 L i g h t

remote control correspond to the additional

commands. You can memorize the additional commands on the function keys F1 - F2 - F3 - F4.

After programming the

U N I V E R S A L 6 L i g h t

, whenever a key that has been assigned a

LEARN command is pressed, not only will the light of the key relative to the appliance being used light

up, but also the light of the LEARN key.

8. The procedure is complete when the green light of the

selected appliance emits three long flashes. Only then

will the remote control be ready to copy other signals to

be assigned to other keys.

Normalization:

Brightness (+): or

Brightness (-): or

Colour (+): or

Colour (-): or

CANCELLING ALL THE LEARN COMMANDS

All the signals copied with the LEARN function can be cancelled

by entering the code 9000 on any appliance selection key,

thus resetting the original commands on the keys.

+++

800x

(x = 0, 1, 2, 3, 4, 5)

PROBLEM SOLVING

INFO-LINE

If you have any queries about your

U N I V E R S A L 6 L i g h t

remote control:

• read this Instruction Booklet carefully - you will find an answer to most of your questions

• consult our website www.gumbodylight.com where you will find the answers you need easily and

quickly.

WARRANTY: 2 years

The warranty ceases to be valid if the product

is tampered with or used incorrectly.

Type of remote control GumBody Light

Model UNIVERSAL 6 Light

Purchase date / /

Dealer’s stamp

The symbol of the crossed trash can shown on the remote control indicates that once the product has reached the end of its working life it

should be disposed of separately from other waste. The user should, therefore, take the remote control to a specialised collection centre

for electronic and electrical waste, or hand it over to the dealer when purchasing a new similar remote control, on a one to one basis. Correct

separated collection for subsequent recycling, processing and environmentally compatible disposal contributes in preventing possible

negative effects on the environment and on health and favours the recycling of the materials used in producing the remote control. Improper

disposal of the product by the user leads to application of the penalties as per legislative decree no. 22/1997 (article 50 and following of

decree no. 22/1997).

SOLUTION

Try some of the other frequently-used buttons. If

the problem persists, check that the batteries are

fitted correctly. If necessary, replace them with 2

new 1.5 V AA/LR06 batteries.

Check that the batteries are new and that the remote

control is pointing at the TV without any obstacles

in the way. If necessary, re-programme the remote

control, following the programming procedure A

or Bor C.

The batteries are low. Change them.

You may have used the wrong code. Re-enter the

remote control code, following the programming

procedure Aor Bor C.

Programme the remote control following the global

search procedure Cor consult the on-line guide

on the website www.gumbodylight.com to find

the code with which to programme your remote

control.

PROBLEM

The appliance does not respond and the

TV - VCR - SAT- AUX - TER - DVD selection

keys do not light up when a key is pressed.

The appliance does not respond but the

selection keys do light up.

The selection keys flash.

The remote control commands are not all

working correcting.

The code for your appliance is not in the

Code Book.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels MELICONI Télécommande

MELICONI

MELICONI TLC04 Manuel utilisateur

MELICONI

MELICONI MYCRO Manuel utilisateur

MELICONI

MELICONI personal 4 Manuel utilisateur

MELICONI

MELICONI personal 4 Manuel utilisateur

MELICONI

MELICONI CONTROL 4 Plus Manuel utilisateur

MELICONI

MELICONI GUMBODY FACILE 100 Manuel utilisateur

MELICONI

MELICONI GumBody DIGITAL 2 SMART Manuel utilisateur

MELICONI

MELICONI GumBody Personal 1 Manuel utilisateur

MELICONI

MELICONI Colibri 2 Manuel utilisateur

MELICONI

MELICONI Personal 5+ Manuel utilisateur

MELICONI

MELICONI Algo 2.1 Manuel utilisateur

MELICONI

MELICONI EASY 300 Manuel utilisateur

MELICONI

MELICONI GUMBODY UNIVERSAL 3-300 Manuel utilisateur

MELICONI

MELICONI pratico 6 Manuel d'installation et d'exploitation

MELICONI

MELICONI Pratico 2 Manuel utilisateur

MELICONI

MELICONI CONTROL TV 100 Manuel utilisateur

MELICONI

MELICONI Personal 4+ Manuel utilisateur

MELICONI

MELICONI Speedy 210 combo Guide d'installation

MELICONI

MELICONI Control 5 500 PLUS Manuel utilisateur

MELICONI

MELICONI Speedy 210 combo Manuel utilisateur

MELICONI

MELICONI LOGIC12 Manuel utilisateur

MELICONI

MELICONI Speedy 2.1 BIG Manuel utilisateur

MELICONI

MELICONI SPEEDY 110 Plus Manuel utilisateur

MELICONI

MELICONI Facile 5.1 LED Manuel utilisateur

Manuels Télécommande populaires d'autres marques

Panasonic

Panasonic EUR7622KB0 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen Beo4 Manuel utilisateur

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuel utilisateur

Multiplex

Multiplex PROFI TX 9 Manuel utilisateur

One Remote

One Remote RMB4 Manuel utilisateur

FUTABA

FUTABA 9ZAP - PART2 Manuel utilisateur

HR Matic

HR Matic HR MULTI 3 Manuel utilisateur

Yamaha

Yamaha ACC-GNRST-30-20 Manuel utilisateur

EisSound

EisSound KBSOUND Manuel utilisateur

Marantz

Marantz RC101 Manuel utilisateur

Conrad

Conrad FS20 TC6 Manuel utilisateur

Anritsu

Anritsu MP1777A Manuel utilisateur

Niles

Niles WVC100 Guide de dépannage

RCA

RCA RCU1300 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen BEO6 Manuel utilisateur

GE 94901 Manuel utilisateur

Onbon

Onbon YQ1-75 Manuel utilisateur

FUTABA

FUTABA R7108SB Instructions d'installation
