MELICONI Speedy 210 combo Guide d'installation

Keep this booklet for future reference.

Thank you for choosing a Meliconi remote control.

The Speedy 210 combo remote control can control a TV (analogue or digital) and can also simultaneously control a

decoder if one is connected to it (terrestrial or satellite).

Thanks to its combined keypad, there is no need to manually select the device to be controlled. Using Speedy 210

combo to control both devices (TV + DECODER), the light blue buttons automatically control the TV, and the dark

blue buttons control the DECODER, but it is also possible, with suitable settings, to make all of the buttons control a

single device.

The remote control has a permanent memory, so it does not lose its settings even if there are no batteries in it.

Its ergonomic shape and soft rubber body make it easy to grip and protect the remote control if it is knocked and

dropped.

IMPORTANT: The remote control must not be exposed to excessive heat sources.

USE OF THE BUTTONS AND FUNCTIONS

The functions of the buttons described below are available only if they are on your original device.

COMBO

Selects the next programme.

Menu options confirm button

Turns down the TV volume.

Numeric keypad.

Indicator light.

Button for exiting Teletext and

returning to normal screen.

TV ON button, sometimes needed to switch on the TV.

Turns up the TV volume.

For selecting an external input sourcefor the TV.

Teletext button.

Selects the previous programme.

ON/OFF switches the TV OFF and in some cases ON.

OFF for switching off the decoder (STB).

Before using the remote control, insert the batteries and programme it.

INSERTING THE BATTERIES

The remote control requires 2 new 1.5V alkaline AAA/LR03 batteries.

Insert them as illustrated.

Try pressing a number button and check that the red light remains lit continuously

until you release the button. If the light ﬂashes, the batteries inserted are not charged

and are about to go ﬂat, therefore you must substitute them.

Menu options exit button

Selects digital TV and radio

Do not leave ﬂat batteries inserted, as liquid may leak and damage the remote control

The Speedy 210 combo remote control is a universal remote, so its memory contains data relating to numerous

devices of various brands available on the market.

Each original device has a speciﬁc code which must be used to set up the remote control.

Therefore, to use Speedy 210 combo you must enter the speciﬁc code for each device you want to control.

Use one of the following methods to identify the correct code and set it in your remote control:

A) - INTERNET (recommended)

B) - MOBILE PHONE (SMS)

C) - MANUAL SEARCH

SETTING THE CODE

If you have an Internet connection available, follow the on-line guide on the www.meliconi.com/guida website to

identify the speciﬁc codes for the devices you want to control. Then set the codes manually in your MELICONI remote

control as described in the ENTERING THE CODE DIRECTLY procedure.

SETTING CODES USING INTERNET

From today, MELICONI gives customers who don’t have internet access the chance to receive the codes for

programming their remote control directly on their mobile phone.

SETTING CODES USING A MOBILE PHONE

(the service is fee, the only cost being that of sending the SMS, which depends on your service operator tariffs)

Send an SMS as follows: 2C, Type, Brand, Model

Indicate the type of device to be controlled using only one of the following

abbreviations: TV

SAT (satellite decoder)

TER (terrestrial decoder)

indicate the brand of the device to be controlled

indicate the model of the device to be controlled, usually shown on a label

on the back of the device (if you don’t know the model, don’t write anything

after the brand)

2C, TV, PHILIPS,

32PFL3614

EXAMPLE:

2C, TV, PHILIPS, 32PFL3614

Fixed text which must always be included

MANUAL CODE SEARCH

(only to be performed if the speciﬁc code could not be found)

IMPORTANT - separate the information with a comma, and be as precise as possible so that the IT system can

search the data and respond correctly.

Send the SMS to the number 0039 345 7518893 and wait for an SMS reply.

Once you have received the SMS with the list of codes, set the ﬁrst code in the remote control as described in the

ENTERING THE CODE DIRECTLY section.

Place the MELICONI remote control in front of the device, which should already be ON, and press the TV or ON/OFF

STB button (depending on the device being operated). If the device does NOT switch off, try setting the next code in

the SMS list on the remote control. When the device reacts, check whether the other buttons are operating correctly

too. If they do, the remote control is ready to use. If they don’t, you are probably using an incorrect code intended

for a very similar device. At this point, ignore the SMS list and consult the MANUAL CODE SEARCH section to ﬁnd a

more suitable code.

Check that the other buttons (light blue) correspond to the functions of the original remote control; if not, it is

likely that the code found is incorrect, but is used for a very similar device, therefore repeat the procedure

from point 2

C1. MANUAL SEARCH (TV)

If you want to use the Speedy 210 combo to simultaneously control two different devices (TV + DECODER) follow

procedure C1 then procedure C2.

To control a single device (DECODER), follow only procedure C2.

To control a single device (DIGITAL/ANALOGUE TV), follow procedure C3.

If the manual search for the code is successful, obtain the code in use by following the DISPLAY CODE IN USE

procedure and make a note of it inside the battery cover.

NOTE: If you don’t receive an SMS on your mobile phone or if the message says ERROR / NO CODE, it means the system

was not able to process the data you sent. Do not try sending another SMS, instead set the code using the MANUAL

CODE SEARCH procedure

1. Switch on the TV and select a programme

2. Simultaneously hold down the VOL + and VOL - buttons.

3. When the indicator light starts ﬂashing, release the buttons

and brieﬂy press the ON/OFF TV button.

4. The indicator light ﬂashes faster; the remote control is ready

for the search.

5. Point the remote control at the TV. Slowly press and release

the ON/OFF TV button several times, stopping when the TV

is switched off (you may need to press the button several

dozen times).

6. When the device has switched off press the OK button.

Three long ﬂashes indicate that the operation was completed

correctly.

C2. MANUAL SEARCH (DECODER)

Check that the other buttons (dark blue) correspond to the functions of the original remote control; if not,it is

likely that the code found is incorrect, but is used for a very similar device, therefore repeat the procedure

from point 2.

1. Switch on the device and select a programme.

2. Simultaneously hold down the P+ and P- buttons.

3. When the indicator light starts ﬂashing, release the

buttons and brieﬂy press the ON/OFF STB button.

4. The indicator light ﬂashes faster; the remote control is

ready for the search.

5. Point the remote control at the device. Slowly press and

release the ON/OFF STB button several times, stopping

when the decoder is switched off (you may need to press

the button several dozen times).

6. When the device has switched off press the OK button.

Three long ﬂashes indicate that the operation was

completed correctly.

STB

C3. MANUAL SEARCH (DIGITAL/ANALOGUE TV)

1. Switch on the TV and select a programme.

2. Simultaneously hold down the VOL + and P+ buttons.

3. When the indicator light starts ﬂashing, release the

buttons and brieﬂy press the ON/OFF TV button.

4. The indicator light ﬂashes faster; the remote control is

ready for the search.

5. Point the remote control at the TV. Slowly press and

release the ON/OFF TV button several times, stopping

when the TV is switched off (you may need to press the

button several dozen times).

6. When the TV has switched off press the OK button. Three

long ﬂashes indicate that the operation was completed

correctly.

STB

Check that the other buttons correspond to the functions of the original remote control; if not, it is likely that the code

found is incorrect, but is used for a very similar device, therefore repeat the procedure from point 2.

NOTE: During the search the indicator stops ﬂashing and the remote control exits the programming mode in

the following cases:

• if for 12 seconds the button indicated is not pressed or if another button is pressed

• if the list of codes to ﬁnd is terminated. If this happens, go to the www.meliconi.com website

To go to the programming mode, according to requirements, use one of the following pairs of buttons:

VOL

and VOL - to set the code for the TV part only - (light blue buttons)

and P - to set the code for the DECODER part only - (dark blue buttons)

VOL

and P

to set a single code and control only one device - (whole keypad)

Three long ﬂashes indicate a correct setting. If they do not appear, repeat the procedure.

ENTERING THE CODE DIRECTLY

(only to be performed if you know the speciﬁc code to be set)

1. Switch to the programming mode by simultaneously

holding down the appropriate pair of buttons.

2. When the indicator light starts ﬂashing, release the

buttons and immediately enter the speciﬁc code

previously found.(e.g.: 1306)

Example of TV code

If you set up the remote control using the MANUAL SEARCH procedure, obtain and make a note of the code in use

as follows:

DISPLAY CODE IN USE

1. Simultaneously hold down the VOL+ and VOL- buttons (if

you want to ﬁnd the codes of analogue or digital TVs), or

P+ and P- (to ﬁnd the decoder code).

2. When the indicator light starts ﬂashing, release the

buttons and brieﬂy press the TV/RADIO button.

3. After a pause of several seconds, the indicator light

produces four sets of ﬂashes, spaced out, corresponding

to the code to be obtained. Count the number of ﬂashes.

Each set of ﬂashes corresponds to one ﬁgure in the code.

Ten ﬂashes correspond to the ﬁgure 0. For example, for

the code 1306 the following ﬂashes will be obtained:

TV Code Decoder Code

Make a note of the code obtained on the label on the inside of the battery cover. You may need it in future.

Code obtained = 1306

2 year WARRANTY

The warranty is voided if the product is tampered with or used improperly.

The symbol showing a wheelie bin with a cross through it which appears on the device indicates that at the end of its useful life the product must

be collected separately from other waste. Therefore, at the end of the device’s life, you must take it to appropriate centres for the differentiated

collection of electrical and electronic waste, or return it to the retailer when purchasing a new device of equivalent type, on a one-for-one basis. Suitable

differentiated collection to allow subsequent recycling of the decommissioned device, with environmentally-compatible treatment and disposal, help

to prevent any negative effects on the environment and health and to promote the recycling of the materials of which the device is made. Improper

disposal of the product by the user will be subject to the sanctions in Legislative Decree No. 22/1997 (article 50 and subsequent articles of Legislative

Decree No. 22/1997).

Retailer stamp

Purchase date

Remote control model Speedy 210 combo

PROBLEM

The device does not respond and the indicator light

does not come on when a button is pressed

The device does not respond but the indicator light

comes on.

When you press a button the indicator light ﬂashes

and the device does not respond to commands.

The remote control does not execute all commands

correctly.

SOLUTION

Make sure that the batteries are inserted correctly,

or substitute them with 2 new 1.5V alkaline AAA/

LR03 batteries.

Make sure that the batteries are new and that the

remote control is pointing at the device without any

obstacles between them.

If necessary, enter the remote control code again by

repeating the programming procedure.

Substitute the batteries, which are about to go ﬂat.

You may be using the wrong code.

Enter the remote control settings again by repeating

the programming procedure.

TROUBLESHOOTING

If you have any questions about the new Speedy 210 combo remote control:

• carefully read this Instructions Booklet which will allow you to solve most problems

• consult our website www.meliconi.com where you will ﬁnd the answers you need in the fastest, easiest way.

INFO-LINE

Autres manuels pour Speedy 210 combo

Table des matières

Autres manuels MELICONI Télécommande

MELICONI

MELICONI Algo 2.1 Manuel utilisateur

MELICONI

MELICONI GUMBODY UNIVERSAL 5-500 - WINDOWS Manuel utilisateur

MELICONI

MELICONI SPEEDY 110 Plus Manuel utilisateur

MELICONI

MELICONI Control TV.1 Manuel utilisateur

MELICONI

MELICONI Speedy 210 combo Manuel utilisateur

MELICONI

MELICONI CONTROL 4 Plus Manuel utilisateur

MELICONI

MELICONI Speedy Mode d'emploi

MELICONI

MELICONI GUMBODY UNIVERSAL 6 LIGHT Manuel utilisateur

MELICONI

MELICONI TLC04 Manuel utilisateur

MELICONI

MELICONI pratico 6 Manuel d'installation et d'exploitation

MELICONI

MELICONI Colibri 2 Manuel utilisateur

MELICONI

MELICONI TLC02 Manuel utilisateur

MELICONI

MELICONI GumBody Personal 1 Manuel utilisateur

MELICONI

MELICONI PRATICO 2 Light Manuel utilisateur

MELICONI

MELICONI GumBody Personal 1 Manuel utilisateur

MELICONI

MELICONI Control 5 500 PLUS Manuel utilisateur

MELICONI

MELICONI MYCRO Manuel utilisateur

MELICONI

MELICONI Speedy 210 combo Manuel utilisateur

MELICONI

MELICONI TLC04 Manuel utilisateur

MELICONI

MELICONI Smart4 Manuel utilisateur

MELICONI

MELICONI TLC03+ Manuel utilisateur

MELICONI

MELICONI Personal 4+ Manuel utilisateur

MELICONI

MELICONI CONTROL 2 Simple Manuel utilisateur

MELICONI

MELICONI EASY 300 Manuel utilisateur

Manuels Télécommande populaires d'autres marques

Panasonic

Panasonic EUR7622KB0 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen Beo4 Manuel utilisateur

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuel utilisateur

Multiplex

Multiplex PROFI TX 9 Manuel utilisateur

One Remote

One Remote RMB4 Manuel utilisateur

FUTABA

FUTABA 9ZAP - PART2 Manuel utilisateur

HR Matic

HR Matic HR MULTI 3 Manuel utilisateur

Yamaha

Yamaha ACC-GNRST-30-20 Manuel utilisateur

EisSound

EisSound KBSOUND Manuel utilisateur

Marantz

Marantz RC101 Manuel utilisateur

Conrad

Conrad FS20 TC6 Manuel utilisateur

Anritsu

Anritsu MP1777A Manuel utilisateur

Niles

Niles WVC100 Guide de dépannage

RCA

RCA RCU1300 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen BEO6 Manuel utilisateur

GE 94901 Manuel utilisateur

Onbon

Onbon YQ1-75 Manuel utilisateur

FUTABA

FUTABA R7108SB Instructions d'installation
