MELICONI FACILE 1 RC Manuel utilisateur

MELICONI remote control - FACILE 1 RC

TASTO

BUTTON

SAMSUNG

SONY

PANASONIC

SHARP

PHILIPS

TELEFUNKEN

MIVAR / UNITED

TOSHIBA

ALTRE MARCHE

OTHER BRANDS

Meliconi SpA,

Via Minghetti 10,

40057 Cadriano di Granarolo Emilia, (BO) Italy

web: www.meliconi.com

email: telecomandi@meliconi.com

The symbol showing a wheelie bin with a cross through it which appears on the device indicates that at the

end of its useful life the product must be collected separately from other waste. Therefore, at the end of the

device’s life, you must take it to appropriate centres for the differentiated collection of electrical and

electronic waste, or return it to the retailer when purchasing a new device of equivalent type, on a one-for-

one basis. Suitable differentiated collection to allow subsequent recycling of the decommissioned device,

with environmentally-compatible treatment and disposal, help to prevent any negative effects on the

environment and health and to promote the recycling of the materials of which the device is made.

MANUAL SEARCH REFERENCE TABLE

Thank you for choosing a Meliconi remote control.

The FACILE 1 RC remote control is designed to command a television.

Its ergonomic shape and soft rubber body make it easy to grip and protect it from shocks and drops.

It is also designed to be connected to the PC via MELICONI audiocable (included in the package) in order to download the

latest information to its configuration.

The remote control has a permanent memory, so it does not lose its settings even if there are no batteries in it.

The remote control requires 2 new 1.5V AAA/LR03 alkaline batteries, not included in the

package. Insert with the correct polarity as shown in figure.

DO NOT use rechargeable batteries.

BATTERIES TEST: Press and hold the ON/OFF [ ] button and check that the indicator light

remains on continuously until the button is released. If the light is off or blinks, the inserted

batteries are low, therefore they need replacement.

Before using the remote control, for each device you wish to control, it is essential to set a specific code, it matched.

Identify the specific code and set it into the remote control using one of the following ways:

www.meliconi.com/guide

Go to the website listed above, or use the qr-code on the side, to access online tool SEARCH

ACTIVATION CODE.

Once you have found the specifi c code for your device, set it in the remote control as described

in the ENTERING THE CODE DIRECTLY chapter.

SETTING VIA INTERNET

MANUAL SEARCH

MOBILE (SMS)

INTERNET

ACTIVATION OF REMOTE CONTROL

Do not leave exhausted batteries inserted, as liquid may leak and damage the remote control

INSERTING THE BATTERIES

SAFETY WARNINGS

The remote control must not be exposed to excessive heat sources or fire.

The product is not a toy. Keep out of reach of children or domestic animals.

Keep this booklet for future reference

(only to be performed if you know the specific code to be set)

•Press and hold on the MELICONI remote control for at least 6 seconds both ON/OFF [ ] and

MUTE [ ] buttons.

•When the indicator light flashes, release and immediately enter the previously identified code.

(4 digits)

•Three final flashes indicate that the operation has been completed successfully.

(the service is free, the only cost being that of sending the SMS, which depends on your service operator fees)

Send an SMS as follows: 1J, TV, Brand, Model EXAMPLE

ATTENTION - separate the information with a comma and be as precise as possible so that the information system can

search for data and answer correctly.

Send the SMS to 0039 345 7518893 and wait for a reply by SMS.

Once you have received the SMS with the list of codes, set the first code (4 digits) in the remote control as described in the

ENTERING THE CODE DIRECTLY chapter.

After entering the code stand in front of the device already turned on press ON/OFF [ ] button on the MELICONI remote

control. If the device does NOT switch off, set the next code in the SMS list on the remote control and try switching the device

off again. Repeat the operation until the device switches off. When the device switches off, check that the other buttons are

also operating correctly. If they do, the remote control is ready to use.

If certain buttons do not work correctly, you are probably using an incorrect code destined for a very similar device; at this

point ignore the SMS list and consult the SETTING VIA MANUAL SEARCH chapter to find a more suitable code.

Indicate the model of the device to be controlled, usually

shown on a label on the back of the device (if the model

is unknown, do not write anything after the brand)

Indicate the brand of the device to be controlled

Fixed text which must always be included

SETTING VIA MOBILE (SMS)

If the remote control does NOT carry out the three final flashes, the setting is NOT successful; repeat the procedure.

If still unsuccessful, it means that the code is not included in the remote control, contact the customer service.

ENTERING THE CODE DIRECTLY

1J, TV, PHILIPS,

32PFL3614

(only to be performed if the specific code could not be found)

CAUTION: the search procedure could take several minutes.

A) Look in the table at the beginning of the booklet, referring to the column relating to the type,

the brand of device which you wish to control, and note the corresponding number in the

BUTTON column. If the brand is not present using zero “0”. (example: TV SONY = 3)

B) Stand in front of the device to be controlled and make sure it is ON (not in stand-by).

If necessary, switch it on using the original remote control (if this is still working) or the

buttons present on the device itself. (on TVs they can be on the side or the top).

C) Press and hold on the MELICONI remote control for at least 6 seconds both ON/OFF [ ]and

MUTE [ ] buttons.

D) When the indicator light flashes, release and immediately press the numeric button identified in

the table for a moment. EXAMPLE: 3

E) Pointing the remote control towards the device to be controlled, press and hold on the

MELICONI remote control the ON/OFF [ ] button.

CAUTION: you may have to keep the button pressed for a few minutes before the device

switches off.

F) When the device switches off, IMMEDIATELY RELEASE the button and press the [OK] button.

G) Three final flashes indicate that the operation has been completed successfully.

NOTE: During the search the indicator stops flashing and the remote control exits the search mode in the following

cases:

•if for 30 seconds the indicated button is not pressed or if another button is pressed.

•if the list of codes to find is terminated. In this case consult the www.meliconi.com/guide website or contact the

customer service.

ADDITIONAL CHECK

Check that the MELICONI remote control operates your device also with the other main functions; if it does not,

REPEAT the procedure from step B using the same brand number.

If, after various attempts, do not get a satisfactory result REPEAT the procedure from step B, using 0 (zero) as brand

number.

SETTING VIA MANUAL SEARCH

NOTE: If you don’t receive an SMS on your mobile phone or if the message says ERROR or NO CODE, it means the

system has not been able to process the data you have sent. Do not send another SMS, only use the SETTING VIA

MANUAL SEARCH procedure or contact the customer service.

Sometimes some functions of the original remote control are not directly present on the MELICONI remote control keypad.

To enable them proceed as described in chapter ADDITIONAL FUNCTIONS.

The functions of the buttons described below are available only if they are also present on the original device

BUTTONS AND FUNCTIONS USE

Indicator light

Numeric keypad

Selects digital TV

and radio

Volume control +/ –

MENU control

Arrows used to move

around the MENU

FASTEXT functions

or for selecting

submenus using colours

Displays the list

of programmes

MUTE - turns

sound OFF and ON

TELETEXT control

For selecting an

external input source

For selecting

the next programm P+or

the previous programm P–

Selects

analogue / digital

Confirm selection

ON / OFF -switches

the device OFF and

in some cases ON

Use the online tool FIND THE CODE FOR YOUR REMOTE and continue until you see the list matching buttons between the

original remote control and the MELICONI remote control. After identified the function you want to achieve, note the 3-digit

number in amber to it combined and operate as follows:

•Simultaneously press on the MELICONI remote control the [OK]button and the ON/OFF [ ]

button; release, the indicator light flashes.

•Point the remote control at the device to be controlled and dial the 3-digit number corresponding to the function you want to

get. (with the pressure of the third digit the remote control already transmits such function)

•To match the function obtained to a MELICONI remote control button, within 5 seconds, press and hold the desired button.

•Wait three flashes indicate that storage; release the button. (the used button loses the original

function that will be called by setting again the activation code)

If for remote control setup has been used the MANUAL SEARCH procedure, obtain and make a note of the code in use as

follows:

•Press and hold on the MELICONI remote control for at least 6 seconds both ON/OFF [ ] and

MUTE [ ] buttons.

•When the indicator light starts flashing, release and immediately briefly press the [TV / ]

button.

•After a pause of several seconds, the indicator light produces four sets of flashes, spaced out,

corresponding to the code to be obtained. Count the number of flashes. Each set of flashes

corresponds to one digit in the code. Ten flashes correspond to the digit zero “0”.

(example code obtained = 1701)

•Make a note of the code obtained on the label on the inside of the battery cover. You may need it

in future.

Connect the MELICONI remote control to a Personal Computer with Internet access through the appropriate audio cable

(included in the package) as shown in figure.

Proceed as follows:

•Make sure the remote control is equipped with charged batteries.

•Open the battery cover on the remote control and connect the flat end of the cable to three

contacts connector.

•Connect the jack of the cable to the audio / headphone output PC (green jack socket).

•Consult the www.meliconi.com/guide website and use the tool FIND THE CODE FOR

YOUR REMOTE and follow the signs.

UPDATE VIA AUDIOCABLE

DISPLAY CODE IN USE

ADDITIONAL FUNCTIONS

●IF THE REMOTE CONTROL IS NEW AND YOU CAN NOT MAKE IT WORK

Check that you have carried out all the settings procedures correctly. If necessary repeat them, following all the steps

indicated carefully.

The code set in the remote control is incorrect for the device that you want to control. Consult the www.meliconi.com/guide

website to fi nd the correct code for your device. Or try entering all the codes for the same brand shown on the website or

received via SMS one by one and check which one works.

●IF THE REMOTE CONTROL STOPS WORKING

Remove the batteries, press some buttons and insert NEW batteries. Make sure that the remote control is pointing at the

device without any obstacles between them.

Also try entering the code used to set the remote control again.

●IF SOME FUNCTIONS ARE NOT AVAILABLE ON THE REMOTE CONTROL

Usually the MELICONI remote control makes available only the present functions on his keyboard, provided they are

available also on the original remote control.

If some of the MAIN functions are not available, you are probably using an incorrect code. Find and set a more suitable code

as described earlier.

Some secondary functions are not present on the MELICONI remote control keypad, to obtained them proceed as described

in chapter ADDITIONAL FUNCTIONS.

●HOW TO CHECK IF THE REMOTE CONTROL SENDS INFRARED SIGNALS

The human eye is not able to detect infrared signals; use a camera (even that of the mobile phone).

Aim the infrared LED located in front of the remote control (not the red LED above) and press and hold on the remote control

the ON/OFF [ ]button.

If you see through the camera, the LED light with short white / light blue flashes means that the remote control works and

emits infrared.

Consult the www.meliconi.com/guide website for more detailed information on the product and for the on-line tools to

activate the remote control quickly and easily.

IMPORTANT! When contacting technical support it is INDISPENSABLE that you communicate the BRAND and

MODEL of the device that you want to control and which MELICONI remote control you are using.

To contact an operator to call number +39 02 66012766 or send an e-mail to: telecomandi@meliconi.com

WARRANTY: 2 year

Always keep your sales receipt as proof of the validity of the product’s warranty. The warranty is voided if the product is

tampered with or used improperly.

CUSTOMER SERVICE

ATTENTION!

Most problems are caused by using insufficiently charged batteries.

We recommend checking them and, if necessary, replace them as shown in the INSERTING THE

BATTERIES chapter.

TROUBLESHOOTING

Table des matières

Autres manuels MELICONI Télécommande

MELICONI

MELICONI CONTROL TV 100 Manuel utilisateur

MELICONI

MELICONI SPEEDY 2 Manuel utilisateur

MELICONI

MELICONI MYCRO Manuel utilisateur

MELICONI

MELICONI LOGIC12 Manuel utilisateur

MELICONI

MELICONI Personal 4+ Manuel utilisateur

MELICONI

MELICONI easytel 2+ Manuel utilisateur

MELICONI

MELICONI PERSONAL 3 Manuel utilisateur

MELICONI

MELICONI pratico 6 Manuel d'installation et d'exploitation

MELICONI

MELICONI FACILE Manuel utilisateur

MELICONI

MELICONI Speedy 210 combo Manuel utilisateur

MELICONI

MELICONI Control 5 500 PLUS Manuel utilisateur

MELICONI

MELICONI TLC01 Manuel utilisateur

MELICONI

MELICONI Speedy 100 plus Manuel utilisateur

MELICONI

MELICONI EASY 300 Manuel utilisateur

MELICONI

MELICONI GUMBODY FACILE 100 Manuel utilisateur

MELICONI

MELICONI GUMBODY UNIVERSAL 6 LIGHT Manuel utilisateur

MELICONI

MELICONI TLC03 Manuel utilisateur

MELICONI

MELICONI SPEEDY 110 Manuel utilisateur

MELICONI

MELICONI TLC04 Manuel utilisateur

MELICONI

MELICONI GUMBODY UNIVERSAL 3-300 Manuel utilisateur

MELICONI

MELICONI easytel TV+ Manuel utilisateur

MELICONI

MELICONI CONTROL 3-300 PLUS - WINDOWS Manuel utilisateur

MELICONI

MELICONI Speedy Mode d'emploi

MELICONI

MELICONI GumBody Personal 1 Manuel utilisateur

Manuels Télécommande populaires d'autres marques

Panasonic

Panasonic EUR7622KB0 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen Beo4 Manuel utilisateur

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuel utilisateur

Multiplex

Multiplex PROFI TX 9 Manuel utilisateur

One Remote

One Remote RMB4 Manuel utilisateur

FUTABA

FUTABA 9ZAP - PART2 Manuel utilisateur

HR Matic

HR Matic HR MULTI 3 Manuel utilisateur

Yamaha

Yamaha ACC-GNRST-30-20 Manuel utilisateur

EisSound

EisSound KBSOUND Manuel utilisateur

Marantz

Marantz RC101 Manuel utilisateur

Conrad

Conrad FS20 TC6 Manuel utilisateur

Anritsu

Anritsu MP1777A Manuel utilisateur

Niles

Niles WVC100 Guide de dépannage

RCA

RCA RCU1300 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen BEO6 Manuel utilisateur

GE 94901 Manuel utilisateur

Onbon

Onbon YQ1-75 Manuel utilisateur

FUTABA

FUTABA R7108SB Instructions d'installation
