Assembly Instructions

MODEL

TP100Y23012

This product is covered by a limited warranty that is effective for 90 days from the date of purchase. If, during the limited

warranty period, a part is found to be defective or breaks, we will offer replacement parts at no cost to you, the customer.

The only exceptions to the warranty include mainframes, table tops, playing surfaces, batteries or tools.

The above warranty will not apply in cases of damages due to improper usage, alteration, misuse, abuse, accidental

damage or neglect.

This Limited Warranty gives you speciﬁc legal rights and you may also have other rights vary from one State (province) to

another.

A PURCHASE RECEIPT (or other proof of purchase) will be required before any warranty service is initiated. For all

requests for warranty service, please feel free to contact our Consumer Service Department.

Please be aware of your product’s Limited Warranty for the return/refund policy from the store, We, at Medal Sports,

cannot handle the product which is out of product’s limited warranty since we only provide available parts. Thank you!

PLEASE CONTACT US BEFORE RETURNING THE PRODUCT TO THE STORE!

MD SPORTS

877-472-4296

www.medalsports.com

Customer Service Toll Free

Please Contact

Mon.-Fri., 9:00 a.m. to 5:00 p.m. EST

For additional resources and Frequently Asked Questions, please visit us at

DO NOT RETURN TO STORE

WE ARE READY TO HELP

TP100Y23012 1(Continued on the next page.) www.medalsports.com

English

LIMITED 90 DAYS WARRANTY

RECOMMENDED

Electric Screwdrivers may be helpful during assembly; however, please set a low torque and

use extreme caution.

Power Tools: Set to Low Torque

High Torque Over Tightened

This product is intended for INDOOR use only.

Wipe with a clean cloth wrung in water or in a solution of water and a neutral detergent.

Adult supervision is required for children playing this game.

IMPORTANT NOTICE

Adult assembly required.

CHOKING HAZARD - This item contains small parts. Not suitable for children under 3 years.

WARNING

No children in assembly

area

Keep away from pets in

assembly area Do not use or keep

product outdoors. For

indoor use only. No

wet/humid conditions.

- Not Included

- Included

Phillips Screwdriver

Standard (Flat Head

Screwdriver)

Allen Key

TP100Y23012 2(Continued on the next page.) www.medalsports.com

English

TOOLS REQUIRED

Pusher

Puck

Felt Pad

FOR FIG. 1

Apron Corner

ACCESSORIES

FOR FIG. 2

M3x8mm Screw

HARDWARE

PRE-INSTALLED PARTS

Allen Key

FOR FIG. 2

Goal Box

PART NUMBER FIG. NUMBER

QUANTITY

PART

PART NAME Mainframe

FOR FIG. 1

Find a clean, level place to begin the play of your product.

Verify that you have all listed parts as shown on the part list page. If any parts are missing, call our customer service.

BEFORE PLAY

TP100Y23012 3(Continued on the next page.) www.medalsports.com

English

PARTS IDENTIFIER

Motor

Led

Battery Box

FIG. 2

4x2

A2 x1

FIG. 1

Pre-installed

TP100Y23012 4(Continued on the next page.) www.medalsports.com

English

ASSEMBLY

Note: Tear off the backside papers of the felt

pads (5) and stick them onto the bottom of the

pushers (3).

1P1

ELECTRONIC CONNECTIONS DIAGRAM

(BOTTOM OF TABLE)

A1 2

Requires 3 pcs 1.5V “AA” batteries (not included).

Do not mix old and new batteries.

Do not mix alkaline, standard (carbon-zinc), or rechargeable (ni-cad, ni-mh, etc.) batteries.

WARNING

The batteries must be installed according to their correct polarization (+ and -).

Please clean the battery contacts and also those of the device prior to battery installation.

If the game will not be used for a long period of time, we recommend removing the batteries.

REMINDING

Battery Box: Unscrew the bolt using a screwdriver and open the battery box. Insert 3 pcs 1.5V “AA” batteries (not included)

in the sequence of polarity as shown on the inside cover. Then close the cover using a screwdriver.

Turn the power ON using the ON/OFF switch.

TP100Y23012 5(Continued on the next page.) www.medalsports.com

English

BATTERY INSTALLATION

“ON/OFF” SWITCH

TIP

Plip the “ON/OFF” switch to turn the led lights on.

TP100Y23012 6(The last page) www.medalsports.com

English

DISCLAIMER

WARNING

Changes or modiﬁcations not expressly approved by the party responsible for compliance could void the user’s authority

to operate the equipment. NOTA
