MakerBot Replicator 2 Manuel utilisateur

USER MANUAL | SINGLE EXTRUSION

AWELCOME. LET’S GET STARTED 04

Speciﬁcations 06

How It Works 07

Terminology 08

BSETTING UP YOUR MAKERBOT REPLICATOR 2 DESKTOP 3D PRINTER 10

What’s in The Box 12

MakerBot Replicator 2 Desktop 3D Printer Diagram 13

Unpacking Your MakerBot Replicator 2 Desktop 3D Printer 14

Installing Build Plate 16

Installing Filament Guide Tube and Spool Holder 17

Mounting Filament Spool and Attaching USB Cable 18

Attaching Power Supply and Powering On 19

CSTARTUP PROCESS: LEVELING, LOADING, TESTING 20

Leveling the Build Platform 22

Loading MakerBot PLA Filament 27

Making a Test Object from the SD Card 32

DMAKING AN OBJECT WITH MAKERBOT MAKERWARE 34

ETROUBLESHOOTING, DIAGNOSTICS, AND MAINTENANCE 44

Troubleshooting 46

Diagnostics 47

LCD Panel | Top-Level Menu 47

LCD Panel | Utilities Menu 48

LCD Panel | Info and Settings Menu 49

Maintenance 50

Unloading MakerBot PLA Filament 50

Lubricating the Threaded Rod and the X-Axis Idler Pulley 50

Cleaning the Drive Gear 52

Adjusting the Plunger 54

FTERMS OF SERVICE 56

03TABLE OF CONTENTSV1

TABLE OF CONTENTS

Welcome.

Let’s get started.

WARNING: The MakerBot Replicator 2 Desktop 3D Printer generates high temperatures and includes

moving parts that can cause injury. Never reach inside the MakerBot Replicator 2 while it is in operation.

Always allow the MakerBot Replicator 2 to cool down before reaching inside.

CAUTION: If opening the MakerBot Replicator 2 for service, ensure that the power supply is turned o and

the cord is disconnected.

This User Guide is designed to start your journey

with the MakerBot®Replicator™2 Desktop 3D Printer

o in the right direction. Even if you are familiar

with earlier MakerBot machines, it is essential that

you read through this guide, as there are several

important and exciting updates with the MakerBot

Replicator 2 Desktop 3D Printer.

In chapters A and B, you will learn the basics of

the MakerBot Replicator 2 Desktop 3D Printer, how

to unbox safely, and how to get set up. Chapters

C–E will take you through leveling, printing,

maintenance, and troubleshooting.

MakerBot is excited to welcome you to the world

of the MakerBot Replicator 2 Desktop 3D Printer.

Following this guide will help ensure that you are

getting the most out of your machine, and that you

continue to make amazing things.

AWELCOME, LET’S GET STARTED

06 A WELCOME, LET’S GET STARTED

PRINTING

Print Technology: Fused Filament Fabrication

Build Volume: 11.2 L x 6.0 W x 6.1 H in

[28.5 x 15.3 x 15.5 cm]

Print Quality: High 100 microns [0.0039 in]

Medium 270 microns [0.0106 in]

Low 340 microns [0.0133 in]

Positioning Precision: XY: 11 microns [0.0004 in];

Z: 2.5 microns [0.0001 in]

Filament Diameter: 1.75 mm [0.069 in]

Nozzle Diameter: 0.4 mm [0.015 in]

SOFTWARE

Soware Bundle: MakerBot MakerWare™

File Types: .stl, .obj, .thing

Supports: Windows 7,

Linux [Ubuntu 12.04+],

Mac OS X [10.6/ 10.7/10.8]

PHYSICAL DIMENSIONS

Without Spool: 19.1 x 12.8 x 14.7 in [49 x 32 x 38 cm]

With Spool: 19.1 x 16.5 x 14.7 in [49 x 42 x 38 cm]

Shipping Box: 23 x 21.5 x 17 in [59 x 55 x 43 cm]

Weight: 25.4 lbs [11.5 kg]

Shipping Weight: 32.0 lbs [14.5 kg]

TEMPERATURE

Ambient Operating 15° – 32° C [60° – 90° F]

Temperature:

Storage Temperature: 0° – 32° C [32° – 90° F]

ELECTRICAL

AC Input: 100 – 240 V, ~2 amps, 50 – 60 Hz

Power Requirements: 24 V DC @ 6.25 amps

Connectivity: USB, SD card [included]

MECHANICAL

Chassis: Powder-coated steel

Body: PVC Panels

Build Platform: Acrylic

XYZ Bearings: Wear-resistant,

oil-infused bronze

Stepper Motors: 1.8° step angle with

1/16 micro-stepping

SPECIFICATIONS

07AWELCOME, LET’S GET STARTED

The MakerBot Replicator 2 Desktop 3D Printer makes solid, three-dimensional objects

out of melted MakerBot PLA Filament. Your 3D design ﬁles are translated into instructions

for the MakerBot Replicator 2 and sent to the machine via USB cable or SD Card. Then

the MakerBot Replicator 2 heats the MakerBot PLA Filament and squeezes it out through

an extruder to make a solid object layer by layer. This method is called Fused Filament

Fabrication [FFF].

HOW DOES IT WORK?

ACTIVE COOLING FAN: The fan that

cools the MakerBot PLA Filament as

it extrudes.

BUILD PLATE: The surface on which the

MakerBot Replicator 2 makes an object.

BUILD PLATFORM: The support for the

build plate. The build platform includes

knobs for manual leveling.

PLUNGER: A part of the extruder

assembly. The Delrin plunger pushes the

MakerBot PLA Filament against

the drive gear.

DRIVE GEAR: The gear that drives the

MakerBot PLA Filament into the heater.

EXTRUDER: Draws MakerBot PLA

Filament from the spool and pushes it

into the nozzle, where it is heated and

squeezed onto the build plate

EXTRUDER FAN: The fan that keeps the

MakerBot Replicator 2 motor cool and

disperses heat from the heat sink.

FAN GUARD: A grill that protects the

extruder fan and protects the user

from the fan.

FILAMENT GUIDE TUBE: A plastic tube

that guides the MakerBot PLA Filament

from the ﬁlament spool to the extruder.

GCODE: A computer language used to

describe the toolpath your MakerBot

Replicator 2 will use to build an object.

GCode is converted to S3G before being

sent to your machine.

HEAT SINK: An active heat sink that

dissipates heat from the cartridge heater.

It looks like an aluminum plate with ﬁns.

LCD CONTROL PANEL: The liquid-

crystal display in the front lower right

corner of the MakerBot Replicator 2. This

control panel provides status information

about the MakerBot Replicator 2 and

includes control menus and diagnostics.

MAKERBOT PLA FILAMENT: Polylactic

acid ﬁlament. PLA is a renewable

bioplastic. MakerBot PLA Filament is the

source material from which you make

objects on the MakerBot Replicator 2.

MAKERBOT REPLICATOR 2: The

MakerBot Replicator 2 Desktop 3D Printer.

MAKERWARE: Free soware created

by MakerBot that allows you to load 3D

model ﬁles, manipulate and edit those

ﬁles, and send them to the MakerBot

Replicator 2 for building.

MOTOR ASSEMBLY: The stepper motor

and the drive block that push ﬁlament

into the extruder.

08 A WELCOME, LET’S GET STARTED

TERMINOLOGY

MOTOR WIRES: The bundle of electrical

wires that provide power to the motor.

NOZZLE: The opening on the end of the

extruder from which heated MakerBot PLA

Filament emerges to be spread onto the

build plate.

POWER SUPPLY: An A/C power supply

for the MakerBot Replicator 2 that

includes a block and two plugs.

REPLICATOR G: Free, open source

soware that allows you to manipulate

and edit .stl ﬁles and GCode ﬁles and

send them to the MakerBot Replicator 2.

S3G: A compact format for describing

the toolpath your MakerBot Replicator 2

will use to build an object.

SD CARD: Secure Digital memory card

that can store digital data and be read by

the MakerBot Replicator 2.

SPACERS: Plastic pieces that keep the

extruder fan and heat sink secure and

in place.

SPOOL HOLDER: A part that attaches

to the back of the MakerBot Replicator

2 and holds the spool of MakerBot PLA

Filament. The spool holder ensures that

the MakerBot PLA Filament is fed evenly

to the MakerBot Replicator 2.

.THING: A ﬁle format used by MakerWare

that allows you to print multiple 3D

models on the same plate.

THINGIVERSE: A website for uploading

and downloading 3D model ﬁles for use

with the MakerBot Replicator 2.

THREADED ROD: A long rod that is

threaded along its entire length. This

rod allows the build platform to move

up and down.

.STL: A widely used ﬁle format for

3D models.

USB CABLE: A cable that allows the

MakerBot Replicator 2 to communicate

with a computer using the USB interface

on the computer.

09AWELCOME, LET’S GET STARTED

TERMINOLOGY CONTINUED
