M-system R3Y-SS8N Manuel utilisateur

R3Y-SS8N

P. 1 / 3 EM-8957 Rev.2

BEFORE USE ....

Thank you for choosing M-System. Before use, please check

the contents of the package you received as outlined below.

If you have any problems or questions with the product,

please contact M-System’s Sales Office or representatives.

■ PACKAGE INCLUDES:

DC current input module ........................................... (1)

■ MODEL NO.

Check that model No. described on the specification label is

exactly what you ordered.

■ INSTRUCTION MANUAL

This manual describes necessary points of caution when you

use this product, including installation, connection and basic

maintenance procedures.

INSTRUCTION MANUAL

MODEL R3Y-SS8N

DC CURRENT INPUT MODULE

(8 points, non-isolated)

POINTS OF CAUTION

■ CONFORMITY WITH EC DIRECTIVES

• The equipment must be mounted inside the instrument

panel of a metal enclosure.

• The actual installation environments such as panel con-

figurations, connected devices and connected wires may

affect the protection level of this unit when it is integrated in

a panel system. The user may have to review the CE

requirements in regard to the whole system and employ

additional protective measures to ensure CE conformity.

■ HOT INSERTION/REMOVAL OF MODULES

Removing or replacing modules does not affect other modules

on the same backplane. It is possible to replace them without

removing the power supply. However, replacing multiple

modules at once may greatly change line voltage levels. We

recommend that you replace them one by one.

■ ENVIRONMENT

• Indoor use

• When heavy dust or metal particles are present in the air,

install the unit inside proper housing with sufficient ventila-

tion.

• Do not install the unit where it is subjected to continuous

vibration. Do not subject the unit to physical impact.

• Environmental temperature must be within -10 to +55°C

(14 to 131°F) with relative humidity within 30 to 90% RH in

order to ensure adequate life span and operation.

■ WIRING

• Do not install cables (power supply, input and output) close

to noise sources (relay drive cable, high frequency line, etc.).

• Do not bind these cables together with those in which noises

are present. Do not install them in the same duct.

■ UNUSED INPUT CHANNELS

• Unused channels can be specified and set so on the PC

Configurator Software (model: R3CON).

■ AND ....

• The unit is designed to function as soon as power is

supplied, however, a warm up for 10 minutes is required for

satisfying complete performance described in the data sheet.

INSTALLATION

Use the Installation Base (model: R3-BSx).

R3Y-SS8N

P. 2 / 3 EM-8957 Rev.2

COMPONENT IDENTIFICATION

■ DIMENSIONS mm (inch)

TERMINAL CONNECTIONS

Connect the unit as in the diagrams below and the next page.

SW CONVERSION RATE

160 ms (*)80 ms 40 ms 20 ms

SW3-1 OFF ON OFF ON

SW3-2 OFF OFF ON ON

(*) Factory setting

■SIDE DIP SW

•Conversion Rate: SW3

20 A

RUN LED

ERR LED

Input Connector

■ FRONT VIEW

• Pin Assignment

■ SIDE VIEW

SW3

1Conv.

Rate

130 (5.12)

27.5 (1.08) 110 (4.33) POSITIONING

GUIDE

■STATUS INDICATOR LED

RUN indicator: Bi-color (red/green) LED;

Red when the bus A operates normally;

Green when the bus B operates normally;

Amber when both buses operate normally.

ERR indicator: Bi-color (red/green) LED;

Red with the input circuit abnormality (AD

converter response failure);

Green in normal operating conditions.

R3Y-SS8N

P. 3 / 3 EM-8957 Rev.2

M-SYSTEM WARRANTY

M-System warrants such new M-System product which it manufactures to be free from defects in materials and workmanship during the 36-month period following the date that such

productwasoriginallypurchasedifsuchproducthasbeenusedundernormaloperatingconditionsandproperlymaintained,M-System'ssoleliability,andpurchaser'sexclusiveremedies,

under this warranty are, at M-System's option, the repair, replacement or refund of the purchase price of any M-System product which is defective under the terms of this warranty. To

submit a claim under this warranty, the purchaser must return, at its expense, the defective M-System product to the below address together with a copy of its original sales invoice.

THIS IS THE ONLY WARRANTY APPLICABLE TO M-SYSTEM PRODUCT AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY IMPLIED

WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. M-SYSTEM SHALL HAVE NO LIABILITY FOR CONSEQUENTIAL, INCIDENTAL OR

SPECIAL DAMAGES OF ANY KIND WHATSOEVER.

M-System Co., Ltd., 5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN, Phone: (06) 6659-8201, Fax: (06) 6659-8510, E-mail: [email protected]

INTERNAL POWER

BUS A

BUS B*

*For dual redundant communication.

BUS CONNECTOR

20A / 20B

18A / 18B

–

INPUT 1

16A / 16B

14A / 14B

–

INPUT 2

12A / 12B

10A / 10B

–

INPUT 3

8A / 8B

6A / 6B

–

INPUT 4

19A / 19B

17A / 17B

–

INPUT 5

15A / 15B

13A / 13B

–

INPUT 6

11A / 11B

9A / 9B

–

INPUT 7

7A / 7B

5A / 5B

–

INPUT 8

■ CONNECTION DIAGRAM ■ INPUT CONNECTOR (40-pin)

PIN NO. ASSIGNMENT PIN NO. ASSIGNMENT

1A NC 1B NC

2A NC 2B NC

3A NC 3B NC

4A NC 4B NC

5A – IN8 5B – IN8

6A – IN4 6B – IN4

7A + IN8 7B + IN8

8A + IN4 8B + IN4

9A – IN7 9B – IN7

10A – IN3 10B – IN3

11A + IN7 11B + IN7

12A + IN3 12B + IN3

13A – IN6 13B – IN6

14A – IN2 14B – IN2

15A + IN6 15B + IN6

16A + IN2 16B + IN2

17A – IN5 17B – IN5

18A – IN1 18B – IN1

19A + IN5 19B + IN5

20A + IN1 20B + IN1
