Lutron Electronics MS-7011 Manuel utilisateur
Your purchase of this HUMIDITY CONTENT METER marks a
step forward for you into the field of precision measurement.
Although this HUMIDITY CONTENT METER is a complex and
delicate instrument, its durable structure developed. Please
read the following instructions carefully and always keep this
manual within easy reach.
OPERATION MANUAL
Heavy duty probe, Dew point, Type K Temp.
RS232/USB computer interface
HUMIDITY CONTENT
METER
Model : MS-7011
3, Hagavish st. Israel 58817 Tel: 972 3 5595252, Fax: 972 35594529
MRC. 2.20
TABLE OF CONTENTS
1. FEATURES.............................................................1
2. SPECIFICATIONS................................................... 2
3. FRONT PANEL DESCRIPTION.................................
.
6
3-1 Display............................................................
.
6
3-2 Power Button................................................... 6
3-3 REC. Button.....................................................
.
6
3-4 Hold Button.....................................................
.
6
3-5 , Button....................................................
.
℃℉ 6
3-6 Function Button ...............................................6
3-7 Battery Compartment/Cover..............................6
3-8 Temp. Probe input Socket ................................6
3-9 Humidity Probe input Socket ............................
.
6
3-10 RS-232 Output Terminal.................................
.
6
3-11 Stand.............................................................6
3-12 Probe Plug ....................................................
.
6
3-13 Probe handle..................................................6
3-14 Probe main body............................................
.
6
3-15 Sensing head with inner filter.......................... 6
3-16 Protection cover for Sensing head....................6
4. MEASURING PROCEDURE....................................
.
7
4-1 Humidity content measurement.........................7
4-2 Dew point measurement...................................8
4-3 Type K thermometer measurement...................
.
8
4-4 Data Hold........................................................
.
8
4-5 Data Record (Max, Min reading)........................ 9
5. OFFSET TEMPERATURE ADJUSTMENT for
Type K THERMOMETER......................................... 10
6. AUTO POWER OFF DISABLE...................................12
7. RS232 PC SERIAL INTERFACE................................
.
12
8. BATTERY REPLACEMENT........................................13
9. OPTIONAL PROBES & ACCESSORIES......................
.
14
1. FEATURES
* Professional Humidity content probe, used to measure
the humidity content value for the materials of Grain,
Corn, Rice. Cotton, Paper...
* Stainless probe body, Heavy duty.
* Humidity content + Dew point + Type K Thermometer
are combined into one meter, intelligent.
* Thin-film capacitance sensor for humidity content
measurement, high precision.
* Dew point measurement.
* Type K thermometer build in temperature linearity
and precision cold junction compensation circuit, high
accuracy.
*Microprocessor circuit assures maximum possible
accuracy, provides special functions and features.
* Large LCD with two display, show the humidity
content & temperature values at same time.
* Heavy duty & compact housing case, designed
for easy carry out & operation.
* Records Maximum and Minimum readings with Recall.
* Auto shut off saves battery life.
* Data hold function for freezing the desired value
on display.
* RS232/USB computer interface.
* , conversion is selected by push button on front℃℉
panel easily.
* Built-in low battery indicator.
1
2. SPECIFICATIONS
2-1 General Specifications
Circuit Custom one-chip of microprocessor LSI
circuit.
Display 51 mm x 32 mm, 15 mm ( 0.6" ) digit size.
dual function LCD display,
Measurement
Humidity
%RH ( Relative Humidity )
content
Temperature - , .℃℉
Dew point
, .℃℉
Type K
, .℃℉
thermometer
Sensor
Humidity
Humidity :
Content
High precision thin-film
capacitance sensor.
Temperature :
Thermistor.
Type K
Thermocouple probe.
thermometer
Data Hold Freeze the display reading by push button.
Memory Maximum & Minimum value.
Recall
Sampling Approx. 0.8 second.
Time
Power off Auto shut off saves battery life or manual
off by push button.
Data Output RS 232/USB PC computer interface.
* Connect the optional RS232 cable
UPCB-02 will get the RS232 plug.
* Connect the optional USB cable
USB-01 will get the USB plug.
2
Operating 0 to 50 .℃
Temperature
Operating Main instrument : Less than 80 %RH.
Humidity Probe : Less than 95 %RH.
Power 006P DC 9V battery
Supply
( Alkaline or Heavy duty type ).
Power Approx. DC 7 mA.
Current
Weight
Meter
245 g/0.54 LB
Probe
461 g/1.01 LB
Dimension
Meter
195 x 68 x 30 mm
( 7.6 x 2.6 x 1.2 inch )
Humidity
Probe length : 600 mm
Content
Probe head diameter : 10 mm
Probe:
Cable length : 1.5 meters
Accessories Instruction manual.........................1 PC
Included Humidity content probe, MS-71P.....1 Set
Soft carrying case, CA-05A..............1 PC
Optional * Probe sensing head with inner filter,
Accessories MS71HEAD
* RS232 cable, UPCB-02
*USBcable,USB-01
* Data Acquisition software, SW-U801-WIN
*
Type k thermocouple Probe :
Model : TP-01, TP-02A, TP-03, TP-04.
3
2-2 Electrical Specifications ( 23±5 )℃
Humidity Content
Range 10 to 95 %RH
Humidity Resolution 0.1 %RH.
content Accuracy
70 %RH :≧
± ( 3 % reading + 1 %RH)
< 70 %RH. :
± 3 %RH.
Range 0 to 50 , 32 to 122 .℃℃℉ ℉
Temp. Resolution 0.1 degree
Accuracy : ± 0.8 .℃℃
: ± 1.5 .℉℉
Dew Point
℃Range -25.3 to 48.9℃℃
Resolution 0.1 ℃
℉Range -13.5 to 120.1℉℉
Resolution 0.1 ℉
Remark :
*
Dew Point display value is calculated from the
Humidity/Temp. measurement automatically.
*
The Dew Point accuracy is sum accuracy value of
Humidity & Temperature measurement..
4
Type K Thermometer
℃Range -100.0 to 1300.0 ℃
Resolution 0.1 ℃
Accuracy
-50.0 to 1300.0 :℃
± ( 0.2 % + 0.5 )℃
-50.1 to -100.0 :℃
± ( 0.2 % + 1 )℃
℉Range -148.0 to 2372.0 ℉
Resolution 0.1 .℉
Accuracy
-58.0 to 2372.0 :℉
± ( 0.2 % + 1 )℉
-58.1 to -148.0 :℉
± ( 0.2 % + 1.8 )℉
5
3. FRONT PANEL DESCRIPTION
Fig. 1
3-1 Display
3-2 Power Button
3-3 REC. Button
3-4 Hold Button
3-5 , Button℃℉
3-6 Function Button
3-7 Battery Compartment/Cover
3-8 Temp. Probe input Socket
3-9 Humidity Probe input Socket
3-10 RS-232 Output Terminal
3-11 Stand
3-12 Probe Plug
3-13 Probe handle
3-14 Probe main body
3-15 Sensing head with inner filter
3-16 Protection cover for Sensing head
6
4. MEASURING PROCEDURE
4-1 Humidity content measurement
1)Plug the " Probe Plug " ( 3-12, Fig. 1 ) into the
" Humidity Probe Input Socket " ( 3-9, Fig. 1 ) of the
meter.
2)Power on the meter by pressing the Power Button ( 3-2,
Fig. 1 ).
3)Take the " Protection cover " ( 3-16, Fig. 1 ) away from
" Sensing head " ( 3-15, Fig. 1 ).
4)Penetrate the " Sensing head " ( 3-15, Fig. 1 ) along with
" Probe main body " ( 3-14, Fig. 1 ) into the
measurement materials ( such as Grain, Corn, Rice.
Cotton, Paper...), refer to Fig. 2. The meter's
display will show the Humidity content and the Temp.
value of the inner testing material.
Remark :
During the measurement Press the " , Button " ( 3-5,℃℉
Fig. 1 ) to select the temperature unit.
5)After finish the measurement, slide the " Protection
cover " ( 3-16, Fig. 1 ) into the " Sensing head " ( 3-15,
Fig. 1 ).
Fig. 2
7
Remark :
There is built the " Filter " on inner of the " Sensing
head " ( 3-15, Fig. 1 ). After the probe is used for a long
period and find the humidity response time change to
long time, it should change the unit of " Sensing head
with inner filter " ( optional accessory, Model ; MS-71HEAD ).
4-2 Dew point measurement
The procedures of " Dew point measurement " are same
as the " Hygrometer measurement ", except select the
" Dew point " function by pressing the " Function Button
"(3-6, Fig. 1), the LCD will show the unit " DEW " & " ℃
( or ).℉
4-3 Type K thermometer measurement
1)Take out the humidity probe away from the " Humidity
Probe input Socket " ( 3-9, Fig. 1 ).
*
If not take out the humidity probe, the type K
measurement will be still available.
2)Plug the optional type K temperature probe into the
" Temp. Probe input Socket " ( 3-8, Fig. 1 ). Press the
" Function Button " ( 3-6, Fig. 1 ) once a while until the
display showing the unit of " " ( or ) only.℃℉
4-4 Data Hold
During the measurement, press the " Hold Button " ( 3-4,
Fig. 1 ) will hold the measured value & the LCD will
indicate a " HOLD " symbol on the display.
* Press the " Hold Button " again to release the data hold
function.
8
