Logitech Ultimate Ears 9000 Manuel utilisateur

ULTIMATE

EARS 9000

WIRELESS

HEADPHONES

USER

GUIDE

WIRELESS HEADPHONES

GUIDE DE L’UTILISATEUR

ENGLISH . . . . . . . . . . . . . . . . . . 4

FRANÇAIS . . . . . . . . . . . . . . . . . 16

POWER

UP. SYNC

UP. PRESS

PLAY.

Turn on the UE 9000

Wireless Headphones.

Turn on your Ultimate Ears 9000

Wireless Headphones.

The Bluetooth® LED should blink blue rapidly,

indicating that the headphones are discoverable.

Pair your headphones with your Bluetooth-enabled device.

Apple iOS®

Go to Settings > General > Bluetooth.

Turn on Bluetooth.

Select “UE 9000” from “Devices.”

Optional: Pair additional Bluetooth-enabled devices.

You can pair your headphones with up to eight devices. To do so:

1. Move the slider to the “Bluetooth” position and hold it there until the Bluetooth LED

blinks rapidly blue, indicating that the headphones are discoverable.

2. Complete pairing according to the instructions on the previous page.

3. Press play on the device you’ve just paired.

When you’ve successfully paired a device, the Bluetooth LED will turn solid blue.

If pairing times out (the LED will blink slowly), move the slider to the “Bluetooth”

position and hold it there until the LED starts rapidly blinking again.

Press play on your media device.

GET TO KNOW YOUR

UE 9000 WIRELESS

HEADPHONES.

UE 9000 Wireless Headphones

Molded travel case

Optional audio cable with on-cord mic and controls

USB charging cable

AC adapter

¼-inch (6.35 mm) adapter

Microﬁber polishing cloth

WHAT’S IN

THE BOX:

Volume up

Play/Pause

Call answer/hang up

Next track

Previous track

Volume down

Listen Through button

Micro USB charging port

3.5 mm input (Interrupts Bluetooth connection when connected)

On/O/Bluetooth connection slider

Bluetooth LED

Battery level LED

Click, or press and hold

Single click

Single click to answer/

press and hold to hang up

Double click

Triple click

Click, or press and hold

Music/Calling

On-ear controls On-cord controls

FEATURES:

BASIC BEHAVIOR.

Bluetooth LED Battery Level LED

O

Headphones o or connected to

an audio source via the 3.5 mm jack

Blue (blinking rapidly):

Discoverable/pairing mode

Blue (blinking slowly): Connecting

Blue (solid): Connected

O

Headphone o

Green (pulsing slowly): Charging

Green (solid): Power on; fully charged

Red: Low battery

Move the On/O slider to the ‘On’ position to activate Bluetooth, active noise cancellation,

and ampliﬁcation.

When in wireless mode, all LEDs turn o automatically. However, the LEDs will illuminate

when there is a pairing change or a control is activated.

To use the “listen through” feature, press the Listen Through button once. Your music will be

muted and environmental sounds will be ampliﬁed into your headphones. To resume listening

to music, simply press the Listen Through button again.

The “listen through” feature is only available in wireless mode while listening to music.

Itisnot available in wired mode or during phone calls.

FEATURES:

CHARGING.

Typically a three-hour charge through an AC outlet provides up to 10 hours of power,

andyoucan use your headphones while they’re charging.

When the battery level LED turns red, you should recharge your headphones. To do so:

1. Charge the headphones via the supplied AC adapter or USB. The battery level LED

will pulse green.

2. When your headphones are fully charged, the battery level LED will glow

solid green.

Micro USB charging port USB charging cable

Computer USB port

AC power adapter

ENGLISH - 9

FEATURES:

TRAVEL STORAGE.

To safely store your headphones while you’re on the go:

1. Swivel the ear cups until they “click”.

2. Place the headphones ﬂat in their case.

3. Place the AC adapter in the top pocket.

4. Place all cables and accessories in the bottom pocket.

PRODUCT CENTRAL.

There’s more information and support available for your product online.

Visit Product Central, where you can:

• Browseonlinearticlesandtutorials.

• Findtipsaboutusageandinformationaboutadditionalfeatures.

• Gethelptroubleshootingaproblem.

• Downloadthelatestsoftwareforyourproduct.

• Findonlinedocumentationandwarrantyinformation.

• ConnectwithotherusersinourCommunityForumstogetadvice,

askquestionsandshare solutions.

• Orderspareparts(whenavailable).

Go to www.logitech.com/support/ue9000

ENGLISH - 11

TROUBLESHOOTING.

If your headphones are not working or pairing/connecting properly, try the following:

•Move closer. The range of the Bluetooth wireless connection is up to 10 meters

or30feet.

•Recharge, particularly if the battery level LED is red. See “Charging.”

• Tryincreasingthevolumeontheheadphones,onyourdeviceor

inyourmediaapplication. And if you’re connected to a computer,

checkthevolumesettings for your operating system.

• EnableBluetoothonyourdevice,andthenselect“UE9000”

fromtheBluetoothdevice list.

• ToxaBluetoothconnectionbyrepairing:

1. On your device: Delete “UE 9000” from the Bluetooth device list

2. On the headphones: Move the slider to “Bluetooth” and hold until

theBluetoothLED blinks blue

3. On your device: Select “UE 9000” from the Bluetooth device list

4.FromthemediaplayeronyourBluetoothdevice:Select“UE9000”

• Forcomputers,youmayneedtospecifytheheadphoneastheinput/output

device for your operating system.

Forhelp,gotowww.logitech.com/support/ue9000

WHAT DO YOU THINK?

PRODUCT SUPPORT.

Please take a minute to tell us.

www.logitech.com/ithink

www.logitech.com/support/ue9000

ENGLISH - 13

BATTERY REMOVAL

AND RECYCLING

1. Peel and remove the ear pad from the left ear cup.

2. Remove screws to disassemble the speaker chamber.

3. Unplug the old battery.

4. Dispose of old battery at an authorized

battery recycling center.

HEADPHONE

DISASSEMBLY

Remove screws

LEFT EAR CUP

Peel and remove

earpad

Unplug battery

ENGLISH - 15

APPUYEZ

SUR

LECTURE.

Couplez votre casque avec un dispositif

compatibleBluetooth.

Apple iOS®

Accédez à Paramètres> Général> Bluetooth.

Activez Bluetooth.

Sélectionnez UE9000 dans Périphériques.

Facultatif: couplez des dispositifs compatibles Bluetooth

supplémentaires.

Vous pouvez coupler votre casque avec huit dispositifs au maximum.

Procédezcommesuit:

1. Déplacez le curseur sur Bluetooth et maintenez-le jusqu'à ce que le témoin

Bluetooth clignote rapidement en bleu, indiquant que le casque est détectable.

2. Terminez le couplage en suivant les instructions de la page précédente.

3. Appuyez sur la touche Lecture du dispositif couplé.

Lorsque le dispositif est détecté, le témoin Bluetooth reste allumé en bleu.

En cas d'expiration du délai de couplage (le témoin clignote lentement),

déplacezlecurseur sur Bluetooth et maintenez-le jusqu'à ce que le témoin clignote

ànouveau rapidement.

Appuyez sur la touche Lecture de votre

dispositif multimédia.

METTEZ-

LE SOUS

TENSION.

Mettez sous tension le casque UE9000

Wireless Headphones.

Mettez sous tension votre casque

Ultimate Ears9000 Wireless Headphones.

Le témoin Bluetooth® clignote rapidement en bleu,

indiquant que le casque est détectable.

SYNCHRO-

NISEZ-LE.

DECOUVREZ

VOTRECASQUE UE9000

WIRELESS HEADPHONES.

UE9000 Wireless Headphones

Etui de transport moulé

Câble audio facultatif avec micro et commandes intégrés

Câble de charge USB

Adaptateur secteur

Adaptateur 6,35mm

Chion nettoyant en microﬁbres

CONTENU

DU COFFRET:

Bouton Sons extérieurs

Câble de charge micro USB

Entrée 3,5mm (la connexion du câble interrompt la connexion Bluetooth)

Curseur de connexion Marche/Arrêt/Bluetooth

Témoin Bluetooth

Témoin de charge de la batterie

Musique/Appel

Commandes placées sur

l'écouteur Commandes ﬁlaires

Volume+

Lecture/Pause

Prised'appel/Find'appel

Piste suivante

Piste précédente

Volume-

Cliquez ou maintenez le bouton enfoncé

Cliquez une seule fois

Cliquez une seule fois pour décrocher/

maintenez le bouton enfoncé pour raccrocher

Cliquez deux fois

Cliquez trois fois

Cliquez ou maintenez le bouton enfoncé
