LINSHANG LS131 Manuel utilisateur

Shenzhen Linshang Technology Co., Ltd.

2019-7-25 Page 1 of 9

LS131

UV Energy Meter

User Manual V2.0

Please read this manual carefully before using and reserve it for reference.

Shenzhen Linshang Technology Co., Ltd.

2019-7-25 Page 2 of 9

I. Product Introduction

UV Energy meter can measure the UV energy, UV irradiance simultaneously and record UV power data

as well as the power curve. It can be used to measure the UV irradiance and energy of the machine which

using UV LED light source, such as UV drying machine, exposure machine and printing machine.

II. Parameters

1. Spectral range: 340nm-420nm, calibrated at 395nm

2. Irradiance measuring range: 0-40000mW/cm²

3. Irradiance resolution: 1mW/cm²

4. Energy measuring range: 0-999999mJ/cm²

5. Energy measuring accuracy: ±10%，±5% (typical)

6. Sampling speed: 2048 times/second

7. Irradiance data storage interval: 32 times/second

8. Recording period: 32 minutes

9. Power supply: 4 AAA alkaline dry batteries

10. Display: 240*160 Dot matrix LCD

11. Dimension: 160mm×75mm×13mm (L*W*H)

12. Weight: 303 g

Shenzhen Linshang Technology Co., Ltd.

2019-7-25 Page 3 of 9

III. Spectral response curve

IV. Characteristics

1. It is the real smart UV energy meter with a large LCD to display.

2. It is equipped with a USB port, and the detailed record data can be read through PC software,

generating data curve and print out test reports.

3. Equipped with metal shell, high temperature resistant design can operate at 100℃ for long time.

4. Equipped with large-capacity memory, which can record up to 60,000 pieces of power data.

5. The stored data will not be lost when the power is off and the last test data will be displayed

automatically when power is on; the test data can only be deleted manually.

6. It is with a built-in timer, and can record the UV curing time accurately.

V. Operation

1. Parameter setting

In OFF mode, long press the “POWER” button for 3 s and enter into the setting mode:

Shenzhen Linshang Technology Co., Ltd.

2019-7-25 Page 4 of 9

A. Trigger mode: (the measurement mode of Auto and Manual)

Short press “▲” or “▼”to choose Auto/Manual

Choose “Auto”-the auto trigger mode, the meter will start and stop automatically.

Choose “Manual”-the measurement will start and stop manually.

Short press the “ENTER” key and enter into the next setting interface. If Auto mode is selected, next

setting interface is trigger threshold value. If manual mode is selected, next setting interface is the smooth

process.

Note: For the recording time is only 32 minutes, if the production line is very long and need a long time to

reach the UV Lamp position, the “AUTO” mode must be selected.

B. Trigger threshold (Trigger power: 1-50mW/cm² can be set)

Short press “▲” or “▼” to set the trigger threshold.

Short press the “ENTER” button and enter into the smooth process.

C. Smooth Processing (Smooth: OFF/50HZ/60HZ)

If the UV lamp is powered with alternating current, the frequency of alternating current will influence the

accuracy of the irradiance measurement. Short press “▲” or “▼”to select the power supply frequency of

the light source.

OFF: this option can be selected if no smooth processing will be performed and the UV lamp is

powered with direct current

50HZ: this option must be selected if frequency of the alternating current is 50HZ

60HZ: this option must be selected if frequency of the alternating current is 60HZ

Short press the “ENTER” button to confirm the setting and the meter enters the “Standard Selection”

interface.

D. Standard Selection

Short press the “ ” button or “ ” button to select the standard.

LS-STD (Enterprise standard): The meter is calibrated according to enterprise standard.

JJG 879-2015 (Chinese standard): The meter is calibrated according to Chinese standard.

Short press the “ENTER” button to confirm the setting and the meter enters the “STOP” interface.

Shenzhen Linshang Technology Co., Ltd.

2019-7-25 Page 5 of 9

E. Factory default settings:

 Trigger mode: Manual

 Smooth: 50HZ

 Standard Selection: LS-STD (Enterprise standard)

2. ON/OFF

 In POWER OFF state, short press “POWER” button to power on the meter. Information such as

calibration date, production date, version number, serial number will be showed on the meter after

powering on and enter into the last measurement interface -STOP Interface. In the STOP interface,

long press the “POWER “button to power off the meter.

 In the STOP interface, the meter will power off without any operation in 3 minutes.

 In the state of “READY”, the longest waiting time is 50 minutes .If the measurement cannot be

triggered after 50 minutes, the meter will shut down automatically.

3. Measurement

In the measurement mode, three operation states exist:

READY: In the auto trigger mode, this means the meter is waiting for triggering to begin a measurement.

RUN: The meter is in the process of measurement.

STOP: The data measurement is over.

In measurement interface:

M: Manual Measurement

A: Automatic Measurement

1) Manual Measurement：Short press the "POWER" key, Press "ENTER" to confirm the new

measurement and clear last measured data(show-----)and enters into the measurement state after 1

Shenzhen Linshang Technology Co., Ltd.

2019-7-25 Page 6 of 9

second(RUN state).Short press the “POWER” key or when the measurement time reaches 32

minutes, the measurement ends and enters into the STOP interface.

2) Automatic measurement：Press the button to start the new measurement then enter into the

“READY” state and clear last measured data ,（show"-----"and flash）,When the power value is greater

than the set value of trigger power, the trigger condition is satisfied then enter into the measurement

state (RUN state) .If the recording time reaches 40 minutes or the power value is less than the set

value of trigger power, the measurement will be automatically ended and enters into the STOP

interface.

4. The last measurement data view

After power on, the meter enters into the STOP interface, which displays the real-time value, maximum

power, energy, measurement time and power curve measured last time.

In the STOP interface, short press the "ENTER" key to toggle between the measurement result and

power curve.

In the stop status, long press the "ENTER" key to clear the current test data.

5. Low Power Alarm

When the battery power is low, the battery symbol " " on the bottom right of the screen will flash,

indicating that the battery needs to be replaced.

Shenzhen Linshang Technology Co., Ltd.

2019-7-25 Page 7 of 9

VI. PC Software Instruction

In the STOP interface (other interfaces cannot be connected to the PC software ), plug in the USB cable,

open "UV Energy meter Vx.x" software then the meter can be connected to the computer for you to read

the data .The software has various functions,

Such as parameter configuration, data reading, UV irradiance curve, report printing and power data

saving to EXCEL.

The report generation and printing function should be specially explained. For test data, the software can

generate a report automatically and print, and if a PDF printer is installed, the electronic version report

can be printed in PDF format. This is convenient for the recording and archiving of test data.

Record data can be read by connecting USB cable with computer directly (when the meter is connected

to the computer USB port for the first time, the computer needs to be restarted so as to load the driver

automatically). Currently, the software supports Windows operating system.

Shenzhen Linshang Technology Co., Ltd.

2019-7-25 Page 8 of 9

VII. Precautions

1. The meter sensor needs to be facing towards the UV light source.

2. When not in use, please turn off the meter

3. Avoid contact with corrosive materials and keep away from high humidity.

4. Please put it in the plastic case after power-off and keep properly.

5. The suggested calibrating period is one year, and our company has the standard light source and

provides calibration service. (The previous calibration time “Cal date: year/month/day” will be

displayed on the boot screen.)

Shenzhen Linshang Technology Co., Ltd.

2019-7-25 Page 9 of 9

6. For the UV sensor is very sensitive to humidity, the storage environment is very important. For long

time storage, please be sure to keep the meter in dry environment.

VIII. Standard packing list

No. Description Quantity Unit

1 UV Energy Meter 1 pcs

2 USB Cable 1 pcs

3 Software USB flash disk 1 pcs

4 AAA battery 4 pcs

5 Small cross screwdriver 1 pcs

6 User Manual 1 pcs

7 Certificate/Warranty card 1 pcs

8 Plastic Case 1 pcs

IX. Service

1. The meter has one-year warranty. If the meter works abnormally, please send the whole set of meter

to our company for maintenance.

2. Provide users with spare parts and lifelong maintenance services.

3. Provide the users with the meter calibration service.

4. Free technical support for long term.

Manufacturer: Shenzhen Linshang Technology Co., Ltd.

Website: www.linshangtech.com

Service hotline: +86-755-86263411

Email: sales@linshangtech.com
