Linksys SFE2010 Manuel

ADMIN GUIDE

BUSINESS SERIES

48-port 10/100 Ethernet Switch

Model: SFE2010/SFE2010P

SFE2010/SFE2010P Administration Guide i

Table of Contents

1Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Welcome 1

What’s in this User Guide? 1

2Getting to Know the SFE2010/SFE2010P . . . . . . . . . . . . . . 2

SFE2010/P Front Panel 2

SFE2010/P Back Panel 4

3Connecting Devices . . . . . . . . . . . . . . . . . . . . . . . . 5

Sample Network Configuration 5

Maximum Cabling Distances 5

Before You Install the Switch... 6

Placement Options 6

Desktop Placement 6

Rack-Mount Placement 7

Wall-Mount Placement 8

Connecting the Cables 8

4Web Utility Configuration . . . . . . . . . . . . . . . . . . . . 10

Connecting to the Switch with the Web-Based Utility 10

Using Menus in the Web-Based Utility 10

Viewing On-line Help 11

5Using the Console . . . . . . . . . . . . . . . . . . . . . . . . 12

Connecting to Your Switch with HyperTerminal 12

Connecting to the Switch with Telnet 15

Logging On to the Console 15

Selecting Menu Options and Actions 15

Using the Switch Main Menu 16

System Configuration 16

System Information 17

Management Settings 19

Username & Password Settings 24

Security Settings 25

VLAN Management 28

IP Configuration 29

File Management 43

Restore System Default Settings 46

Reset to Factory Settings 46

Reboot System 46

Stack Configuration 47

Port Status 47

Port Status 48

PoE Status 48

Port Configuration 49

Port Settings 49

PoE Settings 50

System Mode (Layer 2 / Layer 3) Selection 51

Help 52

Logout 53

SFE2010/SFE2010P Administration Guide ii

Table of Contents

AContacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

US/Canada Contacts 54

BCustomer Site Survey. . . . . . . . . . . . . . . . . . . . . . . 55

CWarranty Information . . . . . . . . . . . . . . . . . . . . . . 57

Limited Warranty 57

Exclusions and Limitations 57

Obtaining Warranty Service 58

Technical Support 58

DFederal Communication Commission Interference Statement . . 59

Industry Canada Statement 59

EC Declaration of Conformity (Europe) 59

ESpecifications . . . . . . . . . . . . . . . . . . . . . . . . . . 60

SFE2010/SFE2010P Administration Guide 1

Welcome

Introduction

Welcome

Thank you for choosing a Linksys Switch. This Switch will allow you to quickly and economically

expand your Linksys system.

This new Linksys rack mount Switch delivers non-blocking, wire speed switching for your

network clients, plus multiple options for connecting to your network backbone. Forty eight

ports wire up your workstations or connect to other Linksys switches or devices.

The Switch features monitoring and configuration via your web browser, making it easy to

manage your Switch. Or if you prefer, you can use the console interface to configure the Switch.

Use the instructions in this guide to help you connect the switch, set it up, and configure it to

bridge your different networks. These instructions should be all you need to get the most out of

the Switch.

What’s in this User Guide?

This user guide covers the steps for setting up and using the Switch.

•Chapter 2, "Getting to Know the SFE2010/SFE2010P"

This chapter describes the ports, LEDs, and other features on the front and back panels of

the switch.

•Chapter 3, "Connecting Devices "

This chapter explains how to physically connect your network devices to the switch.

•Chapter 4, "Web Utility Configuration "

This chapter provides an introduction to the features of the web-based configuration utility.

•Chapter 5, "Using the Console"

This chapter describes the use of the switch console, which allows you to perform basic

configuration of the switch.

•Appendix A, "Contacts"

•Appendix B, "Customer Site Survey"

•Appendix C, "Warranty Information"

•Appendix D, "Federal Communication Commission Interference Statement"

•Appendix E, "Specifications"

SFE2010/SFE2010P Administration Guide 2

Getting to Know the SFE2010/SFE2010P

This chapter describes the ports, LEDs, and other features on the front and back panels of the

switch.

The SFE2010 and SFE2010P are 48-port, layer-2 Ethernet switches that affordably expand the

capability of the Linksys system. These two versions are functionally identical except the

SFE2010P model offers Power-over-Ethernet (PoE) which can be used to supply power to

various Linksys products over Ethernet cable.

SFE2010/P Front Panel

Feature Description

Reset The Switch can be reset by inserting a pin or paper clip into the RESET

opening.

CAUTION: If the RESET switch is pressed for more than 10 seconds, the

Switch will reset to its default settings. All customized user settings will be

lost.

LEDs The Switch uses Light Emitting Diodes (LEDs) to indicate the status of

numerous functions. These functions are listed below.

PWR A green PWR LED lights up to indicate that the Switch is powered on.

FAN A green FAN LED lights up to indicate that the cooling fan is operating

properly. A blinking red FAN LED indicates that the cooling fan has failed.

RPS A green RPS LED lights up to indicate that RPS is connected and operating

properly. A blinking red RPS LED indicates an RPS fault.

MST A green MST LED indicates that this Switch is a stack master.

Stack ID A green Stack ID LED indicates that this Switch is stacked and the

corresponding number indicates its stack ID.

Act/Link The green Act/Link LEDs light up to indicate a functional network link

through the corresponding port with an attached device. The Act

(Activity) LEDs flash to indicate that the Switch is actively sending or

receiving data over that port.

Speed On the SFE2010, a green Speed LED indicates that the port is linked to a

100Mbps device.

PoE On the SFE2010P, a green PoE LED indicates that PoE is active on that port.

Gigabit The Gigabit LED lights up to indicate a Gigabit connection on the

corresponding port.

SFE2010/SFE2010P Administration Guide 3

Getting to Know the SFE2010/SFE2010P

1-48 The Switch is equipped with 48 auto-sensing, Ethernet (802.3) network

ports, which use RJ-45 connectors. The Fast Ethernet ports support

network speeds of 10Mbps or 100Mbps. They can operate in half and full-

duplex modes. Auto-sensing technology enables each port to

automatically detect the speed of the device connected to it, and adjust

its speed and duplex accordingly.

The switch can deliver a maximum of 15.4W to a PoE port. With regular AC

power supply, there is 360W available to all PoE ports, and 280W available

with redundant power supply.

G1-G2 Ports G1-G2 are Ethernet (802.3ab) uplink ports which support network

speeds of 10Mbps, 100Mbps, and 1000Mbps.

NOTE: A switch is in stacking mode by default. In stacking mode, ports G1

and G2 are reserved for use as stacking ports.

miniGBIC1/2 The Switch provides two mini-GBIC ports. The mini-GBIC (gigabit interface

converter) port is a connection point for a mini-GBIC expansion module,

so the Switch can be uplinked via fiber to another switch. Each mini-GBIC

port provides a link to a high-speed network segment or individual

workstation at speeds of up to 1000Mbps.

Use the Linksys MGBT1, MGBSX1, or MGBLH1 mini-GBIC modules with the

Switch. The MGBSX1 and the MGBLH1 require fiber cabling with LC

connectors, while the MGBT1 requires a Category 5e Ethernet cable with

an RJ-45 connector.

Feature Description

SFE2010/SFE2010P Administration Guide 4

Getting to Know the SFE2010/SFE2010P

SFE2010/P Back Panel

Feature Description

Power The Power port is where you will connect the power cord.

Console The Console port is where you can connect a serial cable to a PC’s serial

port for configuration using your PC’s HyperTerminal program. Refer to

Chapter 4: Using the Console Interface for Configuration for more

information.

RPS Redundant Power Supply (Linksys RPS1000)

SFE2010/SFE2010P Administration Guide 5

Sample Network Configuration

Connecting Devices

This chapter explains how to physically connect your network devices to the switch.

•”Sample Network Configuration,” on page 5

•”Maximum Cabling Distances,” on page 5

•”Before You Install the Switch... ,” on page 6

•”Placement Options,” on page 6

•”Connecting the Cables,” on page 8

Sample Network Configuration

For an example of a possible network configuration, see the application diagrams shown

below.

Maximum Cabling Distances

When you connect your network devices, make sure you don’t exceed the maximum cabling

distances, which are listed in the following table:

*A hub refers to any type of 100Mbps hub, including regular hubs and stackable hubs. A

10Mbps hub connected to another 10Mbps hub can span up to 100 meters (328 feet).

From To Maximum Distance

Switch Switch or Hub* 100 meters (328 feet)

Hub Hub 5 meters (16.4 feet)

Switch or Hub Computer 100 meters (328 feet)

SFE2010/SFE2010P Administration Guide 6

Before You Install the Switch...

Connecting Devices

Before You Install the Switch...

When you choose a location for the switch, observe the following guidelines:

• Make sure that the switch will be accessible and that the cables can be easily connected.

• Keep cabling away from sources of electrical noise, power lines, and fluorescent lighting

fixtures.

• Position the switch away from water and moisture sources.

• To ensure adequate air flow around the switch, be sure to provide a minimum clearance of

two inches (50 mm).

• Connect the supplied power cord to the switch’s power port, and plug the other end into an

electrical outlet.

CAUTION: Make sure you use the power cord that is supplied with the switch. Use of a

different power cord could damage the switch.

Placement Options

Before connecting cables to the Ethernet switch, first you will physically install the Ethernet

switch. Either set the Ethernet switch on its four rubber feet for desktop placement, mount it in

a standard-sized, 19-inch wide for rack-mount placement, or mount it on a wall with the wall-

mount brackets provided.

NOTE: The four supplied mounting brackets can be used for either wall mount or rack

mount installations.

Desktop Placement

1. Attach the rubber feet to the recessed areas on the bottom of the Ethernet switch.

2. Place the Ethernet switch on a desktop near an AC power source.

SFE2010/SFE2010P Administration Guide 7

Placement Options

Connecting Devices

CAUTION: Keep enough ventilation space for the Ethernet switch so it does not exceed the

environmental restrictions mentioned in the specifications.

Rack-Mount Placement

To mount the Ethernet switch in any standard-sized, 19-inch wide, (each Ethernet switch

requires 1RU of space in the rack), follow these instructions:

1. Remove the four front screws on one side of the Ethernet switch. Retain the screws for re-

installation.

2. Place one of the supplied spacers on the side of the Ethernet switch so the four holes align

to the screw holes.

3. Place a rack mount bracket next to the spacer and reinstall the four screws (removed in step

1).

4. Repeat steps 2 through 3 for the other side of the Ethernet switch.

5. Attach the Ethernet switch to the rack using the supplied screws.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Linksys Routeur réseau

Linksys

Linksys BEFN2PS4 - EtherFast Cable/DSL And Voice... Manuel utilisateur

Linksys

Linksys WET54GS5 - Wireless-G EN Bridge Manuel utilisateur

Linksys

Linksys VELOP LN1100 Series Manuel utilisateur

Linksys

Linksys Hydra 6 Manuel utilisateur

Linksys

Linksys QuickVPN - PC Manuel utilisateur

Linksys

Linksys WET54GS5 - Wireless-G EN Bridge Instructions d'utilisation d'origine

Linksys

Linksys RV016 Manuel utilisateur

Linksys

Linksys BEFSR11 - EtherFast Cable/DSL Router Manuel utilisateur

Linksys

Linksys BEFSR41 - EtherFast Cable/DSL Router Manuel utilisateur

Linksys

Linksys WRT320N - Wireless-N Gigabit Router Wireless Manuel utilisateur

Linksys

Linksys WET11 - Instant Wireless EN Bridge Network... Manuel utilisateur

Linksys

Linksys NR041 Instructions d'utilisation d'origine

Linksys

Linksys RV082 Manuel d'utilisation

Linksys

Linksys WET200 - Wireless-G Business Ethernet Bridge Manuel d'utilisation

Linksys

Linksys WRT160N - Wireless-N Broadband Router... Manuel utilisateur

Linksys

Linksys BEFSR41W Manuel utilisateur

Linksys

Linksys SLM2008 Manuel d'utilisation

Linksys

Linksys BEFSR41 - EtherFast Cable/DSL Router Manuel d'utilisation

Linksys

Linksys WRT54G - Wireless-G Broadband Router... Manuel utilisateur

Linksys

Linksys MAX-STREAM EA 7300 Manuel utilisateur

Linksys

Linksys SVR3000 - One Services Router Manuel utilisateur

Linksys

Linksys RTP300 - Broadband Router With 2 Phone Ports Mode d’emploi

Linksys

Linksys Instant PowerLine PLEBR10 Manuel utilisateur

Linksys

Linksys EA-Series Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
