ProConnect II 2604

Layer 2 Management 4-Port

Gigabit Ethernet Switch

igrate your network to Gigabit speed with the

ProConnect®II 2604 Gigabit Ethernet Switch. Perfect for

today’s high-speed network demands, this switch from

Linksys delivers non-blocking wire speed switching and

blazing Gigabit transfer speeds for all your network applications.

With the ProConnect II 2604 Switch as your network's backbone,

you'll connect your servers at Gigabit speeds. The four built-in

auto MDI/MDI-X ports deliver 8Gbps of non-blocking switching

performance. And as your needs grow, add Gigabit Ethernet or

Gigabit Fiber ports using the four available expansion slots. Three

Port Trunking groups eliminate bottlenecks, and you can stack up

to 8 switches and manage them as one.

The ProConnect II 2604 provides broadcast storm suppression,

has hardware MAC and IP address learning, and supports packet

filtering and port security. Partition your network into up to 256

VLANs, using port-based 802.1q tagging. Use the 802.1p packet

prioritization support to put time-sensitive data at the head of the

line. Configuration and monitoring your network performance is

a snap using the Web management interface, console, telnet, or

SNMP/RMON.

This expandable, managed switch is the perfect solution for your

Gigabit backbone.

• 4 RJ-45 ports for 10Base-T/100Base-TX/1000Base-TX con-

nections

• 4 Expansion slots for optional Gigabit Fiber or Gigabit Copper

modules

• Support for stacking up to 8 switches in one stack

• Port trunking support for up to 3 Port trunk groups

• Provides 8Gps non-blocking switching performance

• Supports Packet filtering and port security based on source or

destination MAC address

• Supports 802.1p/q Quality of Service, and VLAN tagging

• Traffic classification based on Port#, VLAN, and UDP/TCP logi-

cal port

• Optional expansion modules including EFPC2GE, and EFPC2SC

• Supports port mirroring for traffic analysis

• Manageable via Console, Telnet, Web, and SNMP

ProConnect II 2604 Layer 2 Management

4-Port Gigabit Ethernet Switch

Model No.: PC22604

Wire-Speed Gigabit Switching,

Manageability, and Stackability

Features

Benefits

• Four non-blocking, wire-speed Gigabit

(10/100/1000BaseTX) auto MDI/MDI-X ports

• Four Expansion slots for optional Gigabit

Ethernet (TX) or Gigabit Fiber (SX) Modules

• Supports 802.1p traffic prioritization, 802.1q

port-based VLAN tagging support, eight-high

stacking, and port trunking

• Manageable via console, telnet, web browser,

and SNMP/RMON

ProConnect®II Series

Package ContentsSpecifications

Model Number PC22604

Standards IEEE 802.3, 802.1d, 802.1p, 802.1q,

802.3ab, 802.3u, 802.3x, 802.1ad

Ports 4 10/100/1000 Mbps Ethernet Ports

4 Expansion Slots

Cabling Type Category 5 Ethernet Cables

LEDs Power, Heat, Fan, 1000M, 100M, 10M,

Link/ACT, FDX/COL

Environmental

Dimensions 16.93" x 1.75" x 13.78"

(430 mm x 44 mm x 350 mm)

Unit Weight 11.7 lbs. (5.3 kg)

Power 100~240V AC 60Hz, 240V/50Hz

Certification FCC Class A

Operating Temp. 32ºF to 122ºF (0ºC to 50ºC)

Storage Temp. -40ºF to 158ºF (-40ºC to 70ºC)

Operating Humidity 20% to 95%, Non-Condensing

Storage Humidity 5% to 90%, Non-Condensing

• One ProConnect®II 2604 Layer 2 Management

4-Port Gigabit Ethernet Switch

• One Setup CD with User Guide in PDF format

• One set of mounting brackets and screws

• One Power Cord

• One Registration Card

• 200Mhz or Faster Processor

• 64MB RAM

• CD-ROM Drive

• Ethernet Adapter

• Windows 95/98/Me/NT 4.0/2000/XP

Minimum Requirements

DS-PC22604-30218NC KL

Linksys

World Headquarters:

17401 Armstrong Ave.

Irvine, CA 92614 USA

E-mail: [email protected]

[email protected]

Web: http://www.linksys.com

Linksys products are available in more than 50

countries, supported by 12 Linksys Regional

Offices throughout the world. For a complete

list of local Linksys Sales and Technical

Support contacts, visit our Worldwide Web Site

www.linksys.com
