Linksys WUSB11 ver. 2.6 Instructions d'utilisation d'origine

A Division of Cisco Systems, Inc.

Model No.

Quick Installation for Windows XP

Model No.

Wireless

APower on your PC.

BThe Adapter comes with the

USB cable you will use to

connect the Adapter to your

PC.

Connect one end of then

included USB cable to the USB

port of the Adapter.

CConnect the other end of the

USB cable to one of the USB

ports on your computer.

The Power LED should light up

when the Adapter is plugged

in.

DRaise the antenna. Make sure

the antenna is positioned

straight up into the air, at a 90°

angle from the Adapter. This

will ensure optimum wireless

operating range and

performance.

After connecting the Adapter to your

computer, you will install the driver

and configure the Adapter.

AWindows XP will automatically

detect the Adapter. Insert the

Setup CD-ROM into your

computer’s CD-ROM drive.

Click the radio button next to

Install the software

automatically

(Recommended). Then click

Next.

BThe Hardware Installation

screen may appear and

indicate that the Adapter has

not passed Windows Logo

testing. This Adapter has been

tested and found to work with

Windows XP. Click Continue

Anyway to proceed with the

installation.

CWhen Windows has finished

installing the driver, click Finish.

Connect the Wireless-B USB

Network Adapter

WUSB11

USB Network Adapter

Package Contents

• Wireless-B USB Network Adapter

• USB Cable

• Wall Mount

• Setup CD-ROM with User Guide

• Quick Installation

• Registration Card

Wireless-B

GHz

2.4

802.11b

2Install the Driver

Model No.

CEnter the network’s WEP key in

the Network key field, and re-

enter it in the Confirm network

key field. Click Connect, and

go to step D.

DThe Zero Configuration icon will

indicate a wireless connection

when your connection is

active.

Congratulations! The installation of

the Wireless-B USB Network Adapter

is complete.

AThe Windows XP Wireless Zero

Configuration icon will appear

in your computer’s system tray.

Double-click the icon.

BThe screen that appears will

show any available wireless

network. Select the network you

want.

If your network uses a wireless

security feature called Wired

Equivalent Privacy (WEP)

encryption, go to

step C.

If this network does not have

WEP encryption enabled,

make sure the box next to

Allow me to connect to the

selected wireless network,

even though it is not secure is

checked. Click Connect, and

go to step D.

For additional information or troubleshooting

help, refer to the User Guide on the Setup CD-

ROM. You can also call or e-mail for further

support.

24-hour Technical Support

800-326-7114

(toll-free from US or Canada)

E-mail Support

[email protected]

Website

http://www.linksys.com or

http://support.linksys.com

RMA (Return Merchandise Authorization)

http://www.linksys.com/support

FTP Site

ftp://ftp.linksys.com

Sales Information

800-546-5797 (800-LINKSYS)

A Division of Cisco Systems, Inc.

Linksys is a registered trademark or trademark of

Cisco Systems, Inc. and/or its affiliates in the U.S.

WUSB11_V4-XP_QI-40712NC JL

3Configure the Wireless-B USB

Network Adapters
