EtherFast®10/100

Compact USB

Network Adapter

ow you can connect to any 10, 100, or

10/100Mbps hub or switch without having

to open your PC.The EtherFast®10/100

Compact USB Network Adapter from Linksys allows

you to instantly connect to a network from a USB-

enabled desktop or notebook PC running any ver-

sion of Windows that supports USB. The Plug-and-

Play compatible device attaches to your PC’s or

hub’s USB port via a USB Type A connector. Simply

connect a standard UTP Category 5 network cable

into the EtherFast®10/100 Compact USB Network

Adapter’s RJ-45 port, install the included network

software drivers,and you are networked.

The EtherFast®10/100 Compact USB Network

Adapter is bus-powered, drawing power from the

host PC and requires no external power cords.The

10/100 Compact USB Network Adapter features the

maximum throughput supported by USB, easy-to-

read LEDs, compact design, a 1-year limited war-

ranty, and free world-class technical support.

• One A-type USB Port

• One RJ-45 10/100BaseTX Port For

Connecting to a Network

• 18K Memory Buffer

• Powered by the Host PC So No External

Power Supply Is Needed

• Compact Design-Perfect for Use with

Notebook PCs

• RJ-45 Network Port Connects to Any 10, 100,

or 10/100Mbps Hub or Switch

• Easy-to-Read LED Indicators

• Plug-and-Play Compatible with Windows 98,

2000, Millennium, and XP for Easy Installation

• Free Technical Support—24 Hours a Day,

7 Days a Week for North America Only

• 1-Year Limited Warranty

• Compact Size Allows for Greater Flexibility

• Connect to Any Ethernet or Fast Ethernet

Network from Your Computer’s USB Port

• Perfect Solution for Desktop or Notebook

Computers

•Plug-and-Play Compatible with Windows

98, 2000, Millennium, and XP

• Free Technical Support—24 Hours a Day,

7 Days a Week for North America Only

• 1-Year Limited Warranty

EtherFast®10/100 Compact USB Network Adapter

(USB100M)

Use your PC’s USB Port to Connect to

Any 10/100 Network

NNeettwwoorrkkWWiitthhUUSSBB!!

Features

Benefits

Specifications

Model Number: USB100M

Standards IEEE 802.3, IEEE 802.3u, USB Spec. v1.1

Protocol CSMA/CD

Ports 1 10BaseT/100BaseTX RJ-45 Port

1 USB Type A Connector

Connection Speed 10Mbps or 100Mbps Auto-Sensing

Transfer Rate Up to 12Mbps

Memory Buffer 32KB

Cabling Network: UTP Category 5 or better

100 meters (328 feet) Maximum

USB: Standard Shielded USB Cable

5 meters (16.4 feet) Maximum

Topology Star

LEDs 100,Act, 10

Environmental

Dimensions 2.6” x .87” x .39” (67mm x 22mm x 10mm)

Unit Weight .5 oz. (14 gm)

Power Input 5V Bus Power from USB Host Controller

or Hub

Certifications FCC Class B, CE Mark, Commercial,VCCI and

CSA Listed

Operating Temp. 32ºF to 104ºF (0ºC to 55ºC)

Storage Temp. -4ºF to 158ºF (-20ºC to 65ºC)

Operating Hum. 10% to 90% Non-Condensing

Storage Hum. 10% to 90% Non-Condensing

Package Contents

EtherFast®10/100 Compact USB

Network Adapter

• One EtherFast®10/100 Compact

USB Network Adapter

• One USB Coupler

• One Driver CD-ROM

• One User Guide and Registration

Card

Linksys

17401 Armstrong Ave.

Irvine, CA 92614 USA

Sales Information (800) 546-5797

World Wide Web* http://www.linksys.com

China (10) 6432 1923

Japan (03) 5259-5139

Philippines (632) 638 5580

Singapore 552-8998

Thailand 717-0770

United Kingdom 01245 352403

*Visit our website for the most current contact information.

DS-USB100M-010827NC KL
