Linksys USBBT100 Manuel utilisateur

A Division of Cisco Systems, Inc.

Model No.

Wireless

Quick Installation Guide

USBBT100 (EU/UK/LA)

USB Adapter

Bluetooth

Package Contents

• Bluetooth USB Adapter

• USB Extension Cable

• Setup CD-ROM with User Guide

• Quick Installation

Before connecting the Adapter to

your PC’s USB port, you must install

the Bluetooth Software, which will

install everything your system needs

to use the Adapter. Once this Setup

Wizard is installed, you will be able to

connect the Adapter to your PC.

AInsert the Adapter’s Setup Wiz-

ard CD into your PC’s CD-ROM.

It should start up automatically.

If it does not, click Start and

choose Run. In the field that

appears, enter D:\setup.exe (if

“D” is the letter of your CD-ROM

drive). Once the CD starts, the

Wizard’s Welcome screen

should appear.

Click the Install button to install

the Bluetooth Software. Click-

ing the User Guide button will

open up the User Guide’s pdf

file.

BAfter clicking the Install button,

the InstallShield Wizard’s Wel-

come screen will appear. Click

the Next button to continue.

IMPORTANT: You must install the Blue-

tooth Software from the CD included

with the Adapter before connecting the

Adapter to your PC.

Installing The Bluetooth Software

CThe next screen is the License

Agreement screen. Read the

License Agreement and click

the radio button for I accept

the terms in the license agree-

ment. Then, click the Next but-

ton. You may not click the Next

button unless you click the but-

ton showing that you accept

the terms.

DYou will next be asked for a

Destination folder. This is where

the Bluetooth Software will be

installed. A default directory will

be displayed but, if you wish to

change that, you can click the

Change button and select a

different folder. Then, click the

Next button.

ENow, the Bluetooth Software

will be ready to begin installing

all of the necessary files. Click

the Install button to begin.

The files will then install.

FDuring installation, you may

see a Driver Signature Notice.

This product has been tested

for use with Windows. Click the

OK button to continue.

GAt this point, you should con-

nect the Adapter to your PC’s

USB port. (See the description in

the next step for details.) After

connecting it, click the OK but-

ton.

HThe Wizard, along with all you

need to install the Adapter, has

been successfully installed.

Click the Finish button to close

the final window.

NOTE: Restart your PC if requested by

Windows.

AAfter a moment, a Bluetooth

icon will appear in your system

tray.

BTo connect the Adapter to your

PC, simply plug it into any

unused USB port.

Congratulations! The installa-

tion of the Adapter is com-

plete.

Connecting the Adapter

NOTE: Before you can start using the

Adapter, you must run the Bluetooth Setup

Wizard by right-clicking the Bluetooth icon

and selecting the Wizard, described in

Step 3. For more advanced setup options,

please refer to the User Guide (English

Only).

Before you can begin using the Adapter, you must run the Bluetooth

Setup Wizard. Right-click the Bluetooth System Tray Icon and select

Bluetooth Setup Wizard from the menu that appears. This will open

the Bluetooth Setup Wizard.

The Wizard gives you four choices:

I know the service I want to use and I want to find a Bluetooth device

that provides that service.

Bluetooth devices provide many services. Select this option when you

wish to find a device for a specific service.

I want to find a specific Bluetooth device and configure how this

computer will use its services.

Already know the device you wish to select? Chose this option when

you wish to find a service for a specific device. This option is recom-

mended for users who are not familiar with Bluetooth devices.

I want to configure the Bluetooth services that this computer will pro-

vide to remote devices.

As the Adapter communicates with other Bluetooth devices, so are

they communicating with the Adapter. Select this option to configure

the services the Adapter provides for other devices.

For information on Applications and Services, see Appendix B: Blue-

tooth Applications and Services.

I want to change the name and/or device type that this computer

displays to other Bluetooth devices.

Personalize how the Adapter appears to other Bluetooth devices.

From this screen (not shown), you can click Next to proceed with the

Wizard or Cancel to exit the Wizard.

Use the Wizard to configure those options you must. Not all options

must be configured. These options are provided in detail on the fol-

lowing pages.

Using The Bluetooth Setup Wizard

I know the service I want to use and I want

to find a Bluetooth device that provides

that service.

After you select this option from the Wizard’s

menu and click

, the

Bluetooth Service

Selection

screen will appear. Select the ser-

vice that you need and click

Next, the

Bluetooth Device Selection

screen

will appear. This screen will list those devices

that provide the service you’ve requested.

Chose the device to which you wish to con-

nect and click

to continue.

The

Setup Wizard Completion Screen

will

appear next. The name of the service will

appear at the top of the screen and you

can personalize this if you wish. If you wish

to further configure the service you’ve

selected, click

Configure

. In most cases,

further configuration is not required. To start

the connection upon completing the Wiz-

ard, select

Start the Connection

. A shortcut

to this device will be placed in the

My Blue-

tooth Places

folder. To create more short-

cuts in addition to the one created by

default and restart the Wizard, select

Cre-

ate a shortcut and then restart this wizard so

that I can create additional shortcuts

. Click

Back

if you with to go back a step,

Cancel

if you wish to leave the Wizard without sav-

ing your changes, or

Finish

to complete the

Wizard.

The Adapter will then try to connect to

that device. If a PIN code is required

for security, you will be notified. At this

point, you will be asked for your PIN

code as well as the PIN code for the

other Bluetooth device before the con-

nection can be completed.

The Bluetooth Service

Selection Screen

The Bluetooth Device

Selection Screen

The Setup Wizard

Completion Screen

NOTE: For descriptions of services

provided by Bluetooth devices, see

that device’s documentation.

I want to find a specific Bluetooth

device and configure how this com-

puter will use its services.

After you select this option from the

Wizard’s menu and click the Next but-

ton, the Bluetooth Device Selection

screen will appear. This screen will list

those devices that provide the service

you’ve requested. Chose the device

to which you wish to connect and click

Next to continue.

The Bluetooth Security Setup screen will

appear next. Select the pairing options

for that device, including the PIN code

if required, and click Next. If the PIN

code is required, you will be asked for

your PIN code as well as the PIN code

for the other Bluetooth device before

the connection can be completed.

Last, the Bluetooth Service Selection

screen will appear. Select the service

you wish to use for the device you

selected. If you wish to further config-

ure the service you’ve selected, click

Configure. In most cases, further con-

figuration is not required. Click Back if

you with to go back a step, Cancel if

you wish to leave the Wizard without

saving your changes, or Finish to com-

plete the Wizard.

The Bluetooth Device

Selection Screen

The Bluetooth Security

Setup Screen

The Bluetooth Service

Selection Screen

I want to configure the Bluetooth ser-

vices that this computer will provide to

remote devices.

What services do you wish the Adapter

to provide to your other Bluetooth

devices? Select these from the screen

that appears, the Bluetooth Service

Selection screen. If you wish to further

configure the service you’ve selected,

click Configure. In most cases, further

configuration is not required. Click

Back if you with to go back a step,

Cancel if you wish to leave the Wizard

without saving your changes, or Finish

to complete the Wizard.

I want to change the name and/or

device type that this computer dis-

plays to other Bluetooth devices.

If you wish to personalize the Computer

name as shown on other Bluetooth

devices or change the type of com-

puter, select this option. Type in a new

Computer name and select the type

of computer on which the Adapter is

connected. Then, click Back if you with

to go back a step, Cancel if you wish

to leave the Wizard without saving your

changes, or Finish to complete the Wiz-

ard.

The Bluetooth Service

Selection Screen

Changing Computer

Name and Type

Linksys is a registered trademark or trademark of

Cisco Systems, Inc. and/or its affiliates in the U.S.

usbbt100-qig-50618 KL

For additional information or troubleshooting help, refer

to the User Guide on the Setup CD-ROM. You can also

email for further support.

Website

http://www.linksys.com/international

Product Registration

http://www.linksys.com/registration

Autres manuels pour USBBT100

Table des matières

Langues :

Autres manuels Linksys Adaptateur

Linksys

Linksys WUSB54GP Instructions d'utilisation d'origine

Linksys

Linksys PCMLM56 - EtherFast - 56 Kbps Network Manuel utilisateur

Linksys

Linksys SPA2002 Manuel d'utilisation

Linksys

Linksys WPC54GX Manuel utilisateur

Linksys

Linksys PAP2-VU Mode d’emploi

Linksys

Linksys LNE100M Instructions d'utilisation d'origine

Linksys

Linksys WUSB54GS EU Manuel utilisateur

Linksys

Linksys WPC55AG Manuel d'utilisation

Linksys

Linksys Small Business SPA2102 Instructions d'utilisation d'origine

Linksys

Linksys WUSB54G Manuel utilisateur

Linksys

Linksys SPA1 Series Manuel utilisateur

Linksys

Linksys WGA600N - Wireless-N Gaming Adapter Bridge Manuel utilisateur

Linksys

Linksys WPC4400N Manuel utilisateur

Linksys

Linksys WUSB54GS EU Manuel utilisateur

Linksys

Linksys Instant PowerLine PLUSB10 Instructions d'utilisation d'origine

Linksys

Linksys WPC55AG Instructions d'utilisation d'origine

Linksys

Linksys WUSB54G Manuel utilisateur

Linksys

Linksys WGA54AG Manuel utilisateur

Linksys

Linksys WPC54GR (DE) Instructions d'utilisation d'origine

Linksys

Linksys WPC54G EU Manuel utilisateur

Linksys

Linksys WPC54G EU Instructions d'utilisation d'origine

Linksys

Linksys WPC54G EU Manuel utilisateur

Linksys

Linksys WUSB54AG Manuel utilisateur

Linksys

Linksys PAP2-T Manuel d'utilisation

Manuels Adaptateur populaires d'autres marques

PCB Piezotronics

PCB Piezotronics 090B274 Manuel utilisateur

Auvidea

Auvidea J20 Manuel du produit

Gossen MetraWatt

Gossen MetraWatt AT3-III E Manuel utilisateur

Akribis

Akribis ITF-21-BISS-MIT Manuel utilisateur

Tenda

Tenda W54U Manuel utilisateur

ROHO

ROHO AGILITY Manuel utilisateur

PROLiNK

PROLiNK WN2001 Manuel utilisateur

Hawking

Hawking HUF2 Manuel utilisateur

Airlink101

Airlink101 AWLC4030 Manuel utilisateur

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Manuel utilisateur

Philips

Philips SWA4554S/10 Manuel utilisateur

JVC

JVC TS-C9D2B Manuel d'instructions

NETGEAR

NETGEAR A6100 Manuel utilisateur

D-Link

D-Link DWA-121 Manuel utilisateur

Philips

Philips SWA2037 Manuel utilisateur

Basalte

Basalte 0610-20 Manuel utilisateur

Yealink

Yealink EHS40 Manuel utilisateur

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Manuel utilisateur
