Linksys WPC55AG Instructions d'utilisation d'origine

A Division of Cisco Systems, Inc.

Model No.

Quick Installation

Model No.

Wireless

WPC55AG

Notebook Adapter

Package Contents

• Dual-Band Wireless A+G Notebook

Adapter

• Setup CD-ROM

•UserGuideonCD-ROM

• Quick Installation

• Registration Card

AInsert the Setup CD-ROM into

your CD-ROM drive. The Setup

Wizard should run automati-

cally, and the Welcome screen

should appear. If it does not,

click Start and choose Run. In

the field that appears, enter

D:\setup.exe (if “D” is the letter

of your CD-ROM drive).

Click the Install button.

BAfter reading the License

Agreement, click Next to con-

tinue the installation.

CNext you will choose your type

of wireless network. If you will

connect to both 802.11a and

54g networks, select 5GHz +

2.4GHz. If you will connect only

to 802.11a, select 5GHz. If you

will connect only to 54g, select

2.4GHz. Then click Next.

DNext you will choose a wireless

mode for your network. Click

the Infrastructure Mode radio

button if you want your wireless

computers to network with

computers on your wired net-

work using an access point.

Click the Ad-Hoc Mode radio

button if you want multiple

wireless computers to network

directly with each other.

In the SSID field, enter the SSID

of your wireless network. The

SSID must be identical for all

devices in the network. The

default setting is linksys (all low-

ercase). Click Next.

EIf you chose Infrastructure

Mode, go to Step F now. If you

chose Ad-Hoc Mode, select

the correct operating channel

for your network.

The Network Mode setting is

available only for 54g networks.

If you have Wireless-G

(802.11g) and Wireless-B

(802.11b) devices in your net-

work, then keep the default

Network Mode setting, Mixed

Mode. If you have only Wire-

less-G devices, select G-Only

Mode.

Click Next.

FThe Setup Wizard will ask you to

review your settings before it

starts to install files. Click Next if

you are satisfied with your set-

tings, or click Back to change

any settings.

GAfter the software has been

successfully installed, click Exit.

Installing the Dual-Band Wireless

A+G Notebook Adapter Software

Wireless A +G

Dual-Band

GHz

802.11a

5GHz

802.11g

NOTE: If you chose 5GHz + 2.4GHz in

Step C, then go to Step F now. The

Adapter will automatically select the

best channel for you.

ATurn off your notebook PC.

BLocate an available CardBus

slot on your notebook PC.

CWith the Adapter’s label facing

up, as shown in Figure C, slide it

completely into the CardBus

slot.

DTurn on your notebook PC.

EWindows will begin copying the

driver files to your computer. If

Windows asks you for the origi-

nal Windows CD-ROM, insert the

CD-ROM, and direct Windows

to its location (e.g., D:\).

FAfter installing the Adapter, the

Dual-Band Wireless A+G Note-

book Adapter WLAN Monitor

icon will appear in the system

tray, which is located at the

bottom right corner of your

screen.

If you want to use the WLAN

Monitor to check the link infor-

mation, search for available

wireless networks, or make addi-

tional configuration changes,

then double-click the icon.

Windows XP users: Proceed

to Step 3.

Windows 98, Me, and 2000 users:

Congratulations! The installation of

the Dual-Band Wireless A+G Note-

book Adapter is complete.

Windows XP has a built-in configura-

tion tool. To configure the Adapter

using the Dual-Band Wireless A+G

Notebook Adapter WLAN Monitor,

you need to disable Windows XP

Wireless Zero Configuration. Follow

the instructions in Steps A-C.

AThe Windows XP Wireless Zero

Configuration icon will appear

in your computer’s system tray.

Double-click the icon.

BThe screen that appears will

show any available wireless

network. Click Advanced.

COn the Wireless Networks

screen, uncheck the box next

to Use Windows to configure

my wireless network settings.

Then click OK.

Windows XP users: Congratulations!

The installation of the Dual-Band

Wireless A+G Notebook Adapter is

complete.

Model No.

Quick Installation

wpc55ag-QI-30912A BW

NOTE: If you are using 802.1x authentication, do not disable Windows XP Wireless

Zero Configuration because you must use it to configure the Adapter. You will be

able to use the WLAN Monitor for information purposes only.

For more information about wireless networking on a Windows XP computer, click

Start and then Help and Support. Enter the keyword wireless in the field pro-

vided, and press the Enter key.

2Installing the Dual-Band Wireless

A+G Notebook Adapter into Your PC

3Disabling Windows XP

Wireless Zero Configuration

For additional information or troubleshooting help, refer to the User Guide on the Setup CD-ROM. You

can also call or email for further support.

24-hour Technical Support 800-326-7114 (toll-free from US or Canada)

E-mail Support [email protected]

Website http://www.linksys.com or

http://support.linksys.com

RMA (Return Merchandise Authorization) http://www.linksys.com/support

FTP Site ftp://ftp.linksys.com

Sales Information 800-546-5797 (800-LINKSYS)

Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other
