Linksys PCMLM56 - EtherFast - 56 Kbps Network Manuel utilisateur

EtherFast®10/100 +

56K Modem PC Card

he EtherFast 10/100 + 56K Modem PC

Card will give your notebook computer

a simultaneous connection to any

10/100 Local Area Network and the Internet.

It’s two cards in one --the unique integrated

coupler is equipped with an auto-sensing

10/100 RJ-45 port and a standard RJ-11 tele-

phone port built right in. Just one integrated

unit takes up only one PCMCIA slot --plus

there’s no cables or dongles to lose!

Hotswapping technology lets you insert or

remove the EtherFast 10/100 + 56K Modem PC

Card while your computer is on, and a conven-

ient auto sleep mode turns the card off when it

isn’t being used to help preserve your notebook

PC’s battery life. Ready to run with all major

operating systems and fully compliant with all

major standards, the EtherFast 10/100 + 56K

Modem PC Card is guaranteed to help you stay

connected for years to come!

• Simultaneously Connect to the Internet and a

10Base/100BaseTX Network Through One

16-Bit PCMCIA PC Card

• Unique Design Takes Up Only One Card Slot

• Fully Integrated PC Card -- No Cable Coupler

to Break or Lose

• Runs with Windows 98, 95, NT 4.0 and Linux

• Type II PCMCIA 56Kbps Data Modem with

10/100 LAN and 14.4Kbps Send/Receive Fax

• Compatible with V.90 and K56Flex Standards

• Versatile Modem Runs with Regular

Telephone Lines

• Backward Compatible with Older V.x

Standards, Slower Dialups, ISPs, and Modems

• Fully Hotswappable

• Free Technical Support and Software

Upgrades

• 5-Year Limited Warranty

•Simultaneously Connect to the Internet

and a 10BaseT/100BaseTX Network

•Fully Integrated PC Card --No Dongle or

Cable Coupler to Lose or Break

• Surf the Web, Send Email and Share Files

OnYour Notebook PC at Up to 100Mbps

•Unique Design OnlyTakes Up One

PCMCIA Card Slot

•Free Software Driver Upgrades

•Free Technical Support

EEtthheerrFFaasstt1100//110000++5566KKMMooddeemmPPCCCCaarrdd

((PPCCMMLLMM5566))

Dual-Speed Networking and a 56K v.90 Modem

in an Integrated PC Card -- No Dongles or

Couplers to Lose or Break

NoDongle!

Features

Benefits

Specifications

Standards IEEE 802.3, IEEE 802.3u, V.90, K56Flex,

V.34bis, V.34, V.32bis, V.32, V.22bis, V.23,

V.22/Bell 212A, V.21/Bell 103

Topology Star

Protocol CSMA/CD

Ports 110BaseT/100BaseTX Dual-Speed

Auto-Sensing RJ-45 Port

1Standard RJ-11 Port

Speed LAN 10Mbps and 100Mbps

Modem 56Kbps Downstream

33.6Kbps Upstream

14.4Kbps Tx/Rx Fax

Card Type 16-Bit PCMCIA Type II

LEDs LAN Link, Activity, 10/100 (Lit

if 100Mbps)

Modem Carrier Detect, Transmit,

Receive

Environmental

Dimensions 4.4” x 2.3” x 0.65”

Unit Weight 2.0 oz.

Power 5v/260mA, 60mA Sleep

Certifications FCC Class A

CE Mark, Commercial

UL and CSA Listed

Operating Temp. 32ºF to 120ºF (0ºC to 49ºC)

Storage Temp. -40ºF to 158ºF (-40ºC to 70ºC)

Operating Hum. 10% to 85% Non-Condensing

Storage Hum. 5% to 90% Non-Condensing

Sales (800) 546-5797

Support (949) 261-1288

Fax (949) 261-8868

BBS (949) 261-2888

Email [email protected]

Web www.linksys.com

Package Contents

EtherFast 10/100 + 56K Modem

PC Card

• One EtherFast 10/100 + 56K

Modem PC Card

• One RJ-45 Network Cable

• One RJ-11 Telephone Cable

• Driver Diskette

• User Guide and Registration Card

(Model No.: PCMLM56)
