FALL RIVER, MASSACHUSETTS 02720

INSTRUCTION SHEET NO.

A0397 Page 1 of 2

IS:26650

Caution:

•Turn off power at fuse box before installing track.

•Instructions for grounding Feed-in Kit must be followed.

Failure to do so may result in a hazardous condition.

•Use only #12 ga. solid copper wire in connectors to

maintain proper track rating.

•Observe polarity, white (neutral) wire must be connected

to terminal marked "NEUT". Failure to observe Polarity may

result in an electrical hazard.

•Do not use Track as a conduit support. Independent conduit

supports (such as suitable conduit straps) must be used to

attach the conduit installation to the building structure.

INSTALLING CONNECTOR INTO TRACK SECTION

1. Remove Dead-End Cover if necessary by pulling it out of track

(save Dead-End Cover).

2. Push Connector into the track until there is no gap between the

track unit and connector. Ensure that the contact blades are

aligned with the copper wires in the track during assembly.

3. Tighten the locking screw(s).

4. Tighten Spline Screws.

POWER FEED TO THE CONNECTOR(S)

DIRECT POWER FEED

1. Remove the bottom cover (if required) by snapping it out of the

connector (save cover).

2. Remove K.O. plate from the connector.

3. Remove the K.O..

4. Attach the electrical connector onto the K.O. plate using the nut

provided. Align the electrical connector such that the connector is

hidden by the track width.

5. Attach the K.O. plate onto the connector using the screw that was

previously removed.

6. Pass cable or conduit through electrical connector and clamp cable

or conduit to electrical connector.

7. Form the wires to the appropriate screw terminals, cut and strip

wires and attach to the screw terminals (see wiring section of

instruction sheet).

8. Snap the bottom cover onto the connector.

The floating splice box may be used with this connector and the track.

The floating splice box can be mounted anywhere on the track (not on

the connector). The wires are passed along the top of the track and

into the connector. The floating splice box may only be used in

accessible installations. Floating Splice Box (cat no. 26660) sold

separately. See instructions supplied with 26660 for complete

installation details.

READ AND UNDERSTAND ALL TRACK, CONNECTOR, FEED-IN-KITS, AND ACCESSORY

INSTRUCTION SHEETS BEFORE INSTALLING ANY PROSPEC™ TRACK ITEM.

This fixture is intended for installation in accordance with the National Electrical Code and local or Federal

code specifications. To assure full compliance with codes and regulations, check with your local electrical

inspector before installation. To prevent electric shock, turn off electricity at fuse box before proceeding.

Retain these instructions for maintenance reference.

Fig. 3

Connector

Track Unit

BottomCover

Fig. 1

Fig. 2

Track Unit

Dead End

Knock Out

ElectricalConnector

(byOthers)

K.O. Plate

Nut

In-LineConnector

BottomCover

Dead End

Track Unit

Installation Instructions for Recessed ProSpec™, In-Line, "L", "T", and "X" Connectors

/Circuit Diagrams For use with Recessed ProSpec™Track System Only.

Locking Screw

SplineScrew

Track Unit

INSTRUCTION SHEET NO.

Typical Circuit

Identification

Circuit

Neutral Terminal

GND Ground

N-2Cir-2

N-1

Cir-1

GND

N-2Cir-2

N-1

Cir-1

GND

N-2Cir-2

N-1

Cir-1

GND

N-2Cir-2

N-1

Cir-1

IS:26650

A0397 Page 2 of 2

WIRING THE CONNECTOR(S)

Use 12 ga. solid copper wire when feeding the connector(s). Each

circuit is rated for 120V, 60Hz, 20 AMPs.

NOTE: The "L", "T", "X", and In-Line Connector allow for multiple

circuits to be introduced into them. The Connectors are not polarized

and can be installed into the track in any orientation. Therefore,

identification of the circuits during wiring needs to be controlled by

the installer or electrician. The brass screw terminals are for the hot

leads. The silver screw terminals are for the neutral leads, and the

terminals marked "GND" are for the ground. The individual circuit(s)

are arranged vertically. (See diagrams). The "L" and In-Line

Connectors are pre-wired. These wires may be removed if the wiring

needs to be different. Loosen the screw terminals and remove the

wires.

1. Form the wires to the screw terminals, strip the insulation

back 1/2".

2. Slip the wire under the terminal screw head. Tighten all screw

terminals when wiring is completed.

3. Snap bottom cover onto the connector to cover the wires.

Use 12 ga. solid copper wire

for feed connections

including ground.

.50

Ground Terminal

Power

Terminals

Neutral

Terminals

Two wires may be

attached to one

screwterminal.

"T" CONNECTORIN-LINE

Circuit 1

Circuit 2

"L" CONNECTOR

"X" CONNECTOR

FIG. 4

Installation Instructions for Recessed ProSpec™, In-Line, "L",

"T", and "X" Connectors /Circuit Diagrams

For use with Recessed ProSpec™Track System Only.

Circuit 2

Neutral 2

Circuit 1

Neutral 1
