Life Span TR1000B Manuel utilisateur

Treadmill Base

TR800B, TR1000B, TR1200B, TR5000B

Owner’s Manual

Welcome to LifeSpan Workplace!

Congratulations on stepping into the growing movement of workplace activity.

You’re joining an enthusiastic community, one that’s dedicated to a gentle pace

towards better living and more productive work environments.

You’ve picked the right partner. LifeSpan is the originator of active workstations

and the global leader in safe and efcient workplace motion. We trust our mission

will directly benet your own, a task we don’t take sitting down. With our company-

wide dedication to quality and reliability, we’re certain you’ll be satised with your

newfound health.

Before you assemble or operate your product, please read this manual thoroughly.

Important information regarding safety precautions, product maintenance,

assembly instructions, and proper operation are included.

If you need to contact LifeSpan customer service, please visit the customer service

section of www.LifeSpanFitness.com. Submitted service requests will be responded

to within one business day. Consumers in the United States and Canada can

also dial 801-973-9993, option 4.

We recommend you take a personal approach to adding movement to your day.

Begin slowly, gently increasing your activity in a way that is both comfortable and

enjoyable. We have a wealth of helpful information available on our website, feel

free to use us as a resource as you utilize your new product. We’d love to share our

strategies and provide you with proven methods for success.

Please thoroughly read this manual before you assemble or operate your treadmill.

Neither LifeSpan nor its representatives can accept responsibility for any damages

or injury incurred as a result of information presented in this manual except under

the terms of the product warranty.

LifeSpan Fitness • 801-973-9993 • LifeSpanFitness.com 3

Contents

Safety First . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Children and Pets

Safety Tips

Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

About Your Treadmill Base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Proper Grounding

Power Cord Options

Maintenance and Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-11

Belt Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Belt Tensioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Belt Alignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Moving the Treadmill Base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

When using active workstations, basic precautions

should always be followed, including:

• Never drop or insert any object into any opening. If an object falls into an opening, turn the power off

and unplug the power cord from the outlet.

• Remove the object or call customer service at 801-973-9993 option 4.

• Never operate this treadmill if it has been damaged or partially submersed in water.

• To reduce the risk of electric shock, unplug the treadmill from the wall outlet when not in use, before

performing any maintenance, or before moving the treadmill.

• Do not use outdoors or in areas of high humidity or extreme temperature changes.

• Do not operate where aerosol spray products are being used or where oxygen is being administered.

• Never place the power cord under carpeting or place any object on top of the cord, this may pinch or

damage the cord causing re damage or personal injury.

• Use this product for its intended use as described in this Owner’s Manual.

• Do not use attachments that are not recommended by LifeSpan.

• Do not leave your treadmill running while not in use.

Children and Pets

• Keep children from playing on your treadmill at all times.

• When in use children and pets should be kept at least 10 feet (3m) away.

• This treadmill should only be used by those 12 years of age and older. Users, especially those with

known health conditions, should consult a physician prior to beginning an activity program.

• Cleaning and user maintenance shall not be made by children without supervision.

Safety Tips While in Use

• Always consult a physician before beginning an exercise program.

• If you experience chest pains, nausea,

dizziness or shortness of breath, stop

exercising immediately and consult your

physician before continuing. Do not wear

clothing or jewelry that might catch on

any part of the treadmill.

• Wear shoes with high traction rubber

soles. Do not wear shoes with heels,

leather soles, cleats or spikes.

• Do not walk or run backwards on the

treadmill, always face forward.

• Allow the running belt to fully stop prior

to getting off the treadmill.

• Make sure the area behind the treadmill

remains completely clear during use. A

minimum of 3 feet (1m) of clearance is

required for safety reasons. There should

be a minimum of 2 ft. (.6 m) on at least

one side of the treadmill.

Safety First

3 Feet

(.9 m)

Min. 2 Feet

(.6 m)

3 Feet

(.9 m)

3 Feet

(.9 m)

Safety Clearance

LifeSpan Fitness • 801-973-9993 • LifeSpanFitness.com 5

Specications

TR800B

Walking Belt Size 18” x 45” (45.7 cm x 111.7 cm)

Drive Motor 2.0 HP Continuous Duty

Max User Weight 200 lbs. (136 kg)

Dimensions 60.5” L x 26” W (153.6 cm x 66 cm)

TR1000B

Walking Belt Size 20” x 45” (51 cm x 114.3 cm)

Drive Motor 2.25 HP Continuous Duty DC

Max User Weight 300 lbs. (136kg)

Dimensions 58.7” L x 28.7” W (149 cm x 73 cm)

TR12000B

Walking Belt Size 20” x 50” (51 cm x 127 cm)

Drive Motor 2.25 HP Continuous Duty DC

Max User Weight 350 lbs. (159 kg)

Dimensions 64” L x 29” W (160 cm x 73.7 cm)

TR5000B

Walking Belt Size 20” x 50” (51 cm x 127 cm)

Drive Motor 3.0 HP Continuous Duty

Max User Weight 400 lbs. (182 kg)

Dimensions 64” L x 29” W (160 cm x 73.7 cm)

All Treadmill Bases

Speed Range 0.4 - 4.0 mph (0.6 - 6.4 kph)

Roller Size Tapered Front 2.4” (6 cm), Rear 2.0” (5 cm)

Deck 1” (2.5 cm) Phenolic Deck

Deck Suspension 6 Independent Compression Shocks

Warranty

Your LifeSpan treadmill base comes with the following limited warranty valid in North America.

If you are outside of these areas contact your local distributor for warranty information or visit

www.LifeSpanFitness.com.

LifeSpan warrants the equipment it manufactures is free from defects in materials and workmanship

under normal use and services. The periods above are based on the date of purchase. During these

periods, LifeSpan will repair or replace any defective part. Free labor is included on all parts that are not

normally assembled or replaced by the customer within the labor period.

If within the time frames specied above, any part fails to operate properly, login to our website at www.

LifeSpanFitness.com, click on “Customer Service” and complete the form to request assistance or call

801-973-9993 option 4 for a Customer Service Agent (please note that certain kinds of service should only

be performed by a qualied service technician).

LifeSpan reserves the right to make changes and improvements to our products without incurring any

obligations to similarly alter any product purchased. In order to insure our product warranty and to ensure

the safe and efcient operation of your LifeSpan product, only authorized parts can be used. The warranty

is void if any parts other than those provided by LifeSpan are used.

Exclusions and Limitations:

• This warranty does not apply to any defects caused by negligence, misuse, improper assembly, or

maintenance, accident, or “act of God.”

• This warranty does not apply to discoloration of paints or plastics.

• LifeSpan shall not be responsible for incidental or consequential damages.

• This warranty is non-transferable from the original owner.

TR800B TR1000B TR1200B TR5000B

Labor 1 Year 1 Year 1 Year 1 Year

Parts 2 Years 2 Years 2 Years 2 Years

Treadmill Frame 10 Years 10 Years 10 Years 10 Years

LifeSpan Fitness • 801-973-9993 • LifeSpanFitness.com 7

Treadmill Outlet

Overload Switch Switch AC Power Power Socket

Power Cord Options

115V

NEMA 5-15 115V

NEMA 5-20 Euro Plug

CEE 7/7 208/220V

NEMA 6-15 230V

About Your Treadmill Base

Proper Grounding

LifeSpan equipment must be grounded. Improper connection of the equipment’s grounding conductor

can result in the risk of electric shock. Check with a qualied electrician or service person if you are in

doubt as to whether the outlet is properly grounded. Do not modify the plug provided with the product or

use a ground plug adapter to adapt to a non-grounded outlet. If the plug will not t in the outlet, have the

proper outlet installed by a qualied electrician.

Power Cord Options

This treadmill should only be used with the proper power cord and power outlet. Several power cord

options (shown below) are available from LifeSpan. We do our best to include the correct power cord with

the treadmill for your area. In the event that the correct power cord is not included in the packaging please

contact your local distributor.

Do not use extension cords between

the treadmill and power outlet.

Do not plug into a GFI outlet or circuit

as it may trip the breaker.

Maintenance and Tips

Belt Lubrication

Use only 100% silicone and avoid using aerosol silicone sprays which include additives and petroleum

distillates. One ounce of silicone should be used for each application. LifeSpan offers 100% silicone

lubricant that can be ordered at www.LifeSpanFitness.com.

The walking belt should be lubricated with one uid ounce every 50 hours of use or three months,

whichever comes rst.

To lubricate, unplug your treadmill.

1. Power off your treadmill and unplug it from the power outlet.

2. Starting toward the front (motor end) of your treadmill, slide your hand underneath the belt and create

separation between the deck and belt.

3. Slide the lube tube as close to the center of the deck as possible.

4. While gently applying controlled pressure to the squeeze bottle, apply approximately ½ oz (1/8 of

bottle) to the underside of belt. Apply as close to the middle of the belt as possible, since this is where

your feet make contact.

5. Move the belt with your hands or feet so that you apply a full ounce on the entire inner surface of the

belt.

6. Plug in treadmill, power it on, and run the belt without walking on it at 3 mph for 3 minutes to disperse

treadmill lubricant evenly.

Note:

When lubricating the belt, make sure

the treadmill is on a surface that can be

easily cleaned. After lubricating clean

any excess silicone off the walking

surface of the belt and side rails.

For a full video demonstration on

lubricating your treadmill, scan the

QR code to watch our YouTube video.

LifeSpan Fitness • 801-973-9993 • LifeSpanFitness.com 9

Maintenance and Tips

Daily Cleaning

It is recommended to wipe the treadmill down after each use to keep the treadmill clean and dry. A mild

detergent may be used at times to help remove all dirt and salt from the belt, painted parts and the

display.

Monthly Cleaning

This cleaning includes removing the motor cover and cleaning around the motor and electronics. It is

recommended to clean the motor compartment if the treadmill is in an area where there might be plush

carpet bers that could get pulled up into the motor compartment. It is a good idea at this time to tighten

all assembly hardware and check power cord for damage, or anything else that would indicate the need for

service.

Safety and Integrity

The safety and integrity designed into the machine can only be maintained when the treadmill is regularly

examined for damage and repaired. Worn or damaged components shall be replaced immediately or the

treadmill be removed from service until the repair is made. Pay special attention to components most

susceptible to wear.

WARNING: Keep treadmill stable on at ground.

WARNING: Unplug the power cord before removing the motor cover.

IMPORTANT: If service is required, turn the power off and remove the power cord to

ensure the unit cannot be used. Let all other users know the treadmill needs service.

CAUTION: Acidic cleaning detergents may damage painted or powder coated surfaces

and should not be used. Such cleaners may void the LifeSpan warranty.

Maintenance and Tips

Belt Tensioning

If the belt begins to slip and needs to be tensioned, tension bolts are accessible from the back of the

treadmill. Before tensioning the belt, start the treadmill and set the speed to 3 mph (5 kph).

Belt Alignment

A. Press Start, then increase the treadmill speed to 3 mph (5 kph).

B. Stand behind the treadmill to see which way the belt is drifting.

C. If the belt drifts to the left, turn the left adjustment bolt 1/4

turn clockwise and the right adjustment bolt 1/4 turn counter-

clockwise. (See Fig. 1)

D. If the belt drifts to the right, turn the left adjustment bolt 1/4

turn counter-clockwise and the right adjustment bolt 1/4 turn

clockwise. (See Fig. 2)

E. Observe the alignment for two minutes.

F. Repeat steps A-D as needed.

Visit https://www.lifespantness.com/support/frequently-

asked-questions for a full video demonstration on the aligning of

your treadmill belt.

A. Using a 6 mm Allen wrench,

included in your hardware bag,

turn the right and left tension bolts

1/2 turn clockwise.

B. Test to see if the slipping is

eliminated. If the belt slips repeat

step A and test again.

Turn both

clockwise to

tighten belt

Turn both

counter-clockwise

to loosen belt

Fig. 2

To move belt

to the left

To move belt

to the right

Fig. 1

CAUTION: DO NOT tighten more

than 2 full turns on each side.

Over tensioning the belt can

cause unnecessary friction and

wear and tear on the belt, motor

and electronics.

Adjusting one side more than the other

will cause the belt to drift to the side

of the treadmill and will require belt

alignment. Check to be sure the running

belt is still aligned. If belt alignment is

off refer to Belt Alignment section.

Note:

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Life Span tapis roulant

Life Span

Life Span TR3000i Manuel utilisateur

Life Span

Life Span TR1000-TV Manuel utilisateur

Life Span

Life Span BOOMER PLUS Manuel utilisateur

Life Span

Life Span NOVA Manuel utilisateur

Life Span

Life Span TORQUE III Manuel utilisateur

Life Span

Life Span TURBO PLUS Manuel utilisateur

Life Span

Life Span Everest 2 Manuel utilisateur

Life Span

Life Span Super Manuel utilisateur

Life Span

Life Span Pursuit Max Treadmill Manuel utilisateur

Life Span

Life Span TR2000i Touch Manuel utilisateur

Life Span

Life Span Dash Manuel utilisateur

Life Span

Life Span TR7000i Manuel utilisateur

Life Span

Life Span TR1200i Manuel utilisateur

Life Span

Life Span MyTread TR100 Manuel utilisateur

Life Span

Life Span Workplace DT-3 Manuel utilisateur

Life Span

Life Span PRO Series Manuel utilisateur

Life Span

Life Span Access Manuel utilisateur

Life Span

Life Span BOOST-R Manuel utilisateur

Life Span

Life Span TR2000e Manuel utilisateur

Life Span

Life Span PERFORMER II Manuel utilisateur

Life Span

Life Span Pursuit 2 Manuel utilisateur

Life Span

Life Span TR6000i Manuel utilisateur

Life Span

Life Span TR800B Manuel utilisateur

Life Span

Life Span TORQUE II Manuel utilisateur

Manuels tapis roulant populaires d'autres marques

Treadly

Treadly TREADLY 2 Manuel utilisateur

HEALTH ONE

HEALTH ONE Walk Ro Manuel utilisateur

NordicTrack

NordicTrack NTL12941 Manuel utilisateur

NordicTrack

NordicTrack T7.5 S Manuel utilisateur

Gold's Gym

Gold's Gym ADVANTAGE GGTL12920 Manuel utilisateur

Merax

Merax MS282992 Manuel utilisateur

FYTTER

FYTTER RU-2SX Manuel utilisateur

Precor

Precor 903 Manuel utilisateur

FitLogic

FitLogic freewill d225 Manuel utilisateur

HOP-SPORT

HOP-SPORT ESTIMA HS-3200LB Manuel utilisateur

Horizon Fitness

Horizon Fitness Adventure 5 Plus Manuel utilisateur

Stamia

Stamia InMotion II Manuel utilisateur

Smooth Fitness

Smooth Fitness EVO 3i Manuel utilisateur

NordicTrack

NordicTrack NETL81810.0 Manuel utilisateur

Schwinn

Schwinn 830/Journey 8.0 Manuel utilisateur

Keys Fitness

Keys Fitness HealthTrainer HT-740T Manuel utilisateur

Spirit

Spirit XT8 Manuel utilisateur

NordicTrack

NordicTrack T 14.0 Treadmill Manuel utilisateur
