LG LG-TD5130 Manuel utilisateur

LG-TD5130

UUsseerrGGuuiiddee

P/N : MMBB0129801(1.3)

TD5130cover 1/12/06 6:27 PM Page 1

Introduction |3

Important Information

Before You Start |4

Check Accessories

Safety Instructions

Chapter 1 Getting Started |8

Cautions ………………………………………… 8

Phone Components …………………………… 9

Phone Overview ……………………………… 10

Onscreen Icons … … … … … … … … … … … … … 11

Using the Battery and Charger …………… 12

Chapter 2 Basic Functions |15

Turning the Phone On and Off …………… 15

Making a Call … … … … … … … … … … … … … … 15

Receiving Calls … … … … … … … … … … … … … 16

Signal Strength … … … … … … … … … … … … … 16

About the antenna …………………………… 16

Quick Adjust …………………………………… 17

Call Waiting ……………………………………… 18

Mute ……………………………………………… 18

Redialing Calls ………………………………… 19

Speed Dialing … … … … … … … … … … … … … … 19

Caller ID ………………………………………… 19

Entering Information Using T9 Text Input 20

Examples Using T9 Text Input ……………… 22

Chapter 3 Phone Book |25

Phone Book Features ………………………… 25

LG-TD5130

Contents

*TD5130_eng 1/12/06 5:57 PM Page 1

Chapter 4 Menu Features |30

General Guidelines to Menu Access and

Settings ………………………………………… 30

Names …………………………………………… 30

Messages………………………………………… 34

Call History ……………………………………… 43

Profiles …………………………………………… 46

Display …………………………………………… 49

Game ……………………………………………… 51

Organizer ………………………………………… 53

Settings ………………………………………… 57

Chapter 5 Functions Used During a Call

In Call Memo …………………………………… 65

Mute/Unmute …………………………………… 65

Voice Privacy On/Off … … … … … … … … … … 65

Send My Number ……………………………… 65

Long DTMF/Short DTMF …………………… 66

Earpiece/Speaker Volume …………………… 66

Adjusting Speaker On………………………… 66

Chapter 6 Accessories |67

Chapter 7 Menu Tree |68

Chapter 8 Frequently Asked

Questions |70

Chapter 9 Safety Guidelines |74

TIA Safety Information ……………………… 74

FDA Consumer Update ……………………… 78

Consumer Information on SAR …………… 88

MANUFACTURER’S WARRANTY ………… 90

LG-TD5130

*TD5130_eng 1/12/06 5:57 PM Page 2

Congratulations on your purchase of the LG-TD5130 cellu-

lar phone that has been designed to operate with the latest

digital mobile communication technology, Code Division

Multiple Access (CDMA). The CDMA system has greatly

enhanced voice clarity and can provide various types of

advanced features.

This is an advanced and compact phone which has diverse

features as follows :

•Large, easy-to-read, 6-line, backlight LCD with status icons.

• Paging, Messaging, Voice mail, and Caller ID.

•18-key keypad(10 number keys / 2 function keys / 2 Soft keys /

1 clear key / 1 navigation key / 1 Call key / 1 End key).

•Long battery stand-by and talk time.

•Choice of 19 ring sounds.

•Menu-driven interface with prompt for easy operation and

configuration.

•Call privacy inherent with CDMA encoding.

•Any key answer, auto redialing, one touch and speed dial-

ing with 99 memory locations.

•Optional accessories with greater convenience and

enhanced functionality.

•You can hear the recipient’s voice louder with Speaker On

mode during a call.

Important Information

This user’s manual provides important information on the

use and operation of your phone. Please read all the infor-

mation carefully prior to using the phone for the best per-

formance and to prevent any damage or misuse of the

phone. Any unapproved change or modification will void

your warranty.

LG-TD5130

Introduction

*TD5130_eng 1/12/06 5:57 PM Page 3

Check Accessories

Your mobile phone comes with a AC Adaptor, recharge-

able battery and a handstrap. Please verify that these

accessories are included.

Safety Instructions

WARNING! To reduce the possibility of electric shock,

do not expose your phone to high humidity areas, such

as the bathroom, swimming pool, etc.

Use only LG-approved batteries and travel chargers to

avoid the damage to the phone. Using other batteries or

chargers voids your warranty and may cause the explo-

sion.

Do not use batteries and travel chargers for the other

purposes other than their original purpose of using for

the phone.

Always store your phone away from heat. Never

store your phone in settings that may expose it to tem-

peratures less than -20°C or greater than 50°C, such as

outside during a snowstorm or in your car on a hot day.

Exposure to excessive cold or heat will result in mal-

function, damage and/or catastrophic failure.

Use caution when using your phone near other

electronic devices. RF emissions from your mobile

phone may affect nearby inadequately shielded elec-

tronic equipment.You should consult with manufacturers

of any personal medical devices such as pacemakers

and hearing aides to determine if they are susceptible to

interference from your mobile phone. Turn off your

phone in a medical facility or at a gas station.

LG-TD5130

Before You Start

*TD5130_eng 1/12/06 5:57 PM Page 4

Never place your phone in a microwave oven as it will

cause the battery to explode.

IMPORTANT! Please read the TIA SAFETY INFOR-

MATION(on page 74) before using your phone.

FCC RF Exposure Information

WARNING! Read this information before operating the phone.

In August 1996, the Federal Communications

Commission (FCC) of the United States, with its action

in Report and Order FCC 96-326, adopted an updated

safety standard for human exposure to radio frequency

(RF) electromagnetic energy emitted by FCC regulated

transmitters. Those guidelines are consistent with the

safety standard previously set by both U.S. and interna-

tional standards bodies.

The design of this phone complies with the FCC guide-

lines and these international standards.

CAUTION

Use only the supplied and approved accessories. Use of

unauthorized accessories or modifications could impair

call quality, damage the phone, void your warranty.

Do not use the phone with a damaged accessories. If

the damaged accessories come into contact with the

skin, a minor burn may result. Contact your local dealer

for a replacement of accessories.

LG-TD5130

*TD5130_eng 1/12/06 5:57 PM Page 5

Body-worn Operation

This device was tested for typical body-worn operations

with the back of the phone kept 3/4 inch (2cm) from the

body. To comply with FCC RF exposure requirements, a

minimum separation distance of 3/4 inches (2cm) must

be maintained between the user’s body and the back of

the phone, including the antenna. Third-party belt-clips,

holsters, and similar accessories containing metallic

components should not be used. Body-worn acces-

sories that cannot maintain 3/4 inch (2cm) separation

distance between the user’s body and the back of the

phone, and have not been tested for typical body-worn

operations may not comply with FCC RF exposure lim-

its and should be avoided.

Vehicle Mounted External Antenna

(optional, if available)

A minimum separation distance of 8 inches (20 cm)

must be maintained between the user/bystander and

the vehicle mounted external antenna to satisfy FCC RF

exposure requirements.

For more information about RF exposure, visit the FCC

website at www.fcc.gov

LG-TD5130

*TD5130_eng 1/12/06 5:57 PM Page 6

FCC Part 15 Class B Compliance

This device and its accessories comply with part 15 of

FCC rules. Operation is subject to the following two con-

ditions: (1) This device and its accessories may not

cause harmful interference, and (2) this device and its

accessories must accept any interference received,

including interference that cause undesired operation.

Cautions for Battery

•Do not disassemble.

•Do not short-circuit.

•Do not expose to high temperature : 140°F(60°C)

•Do not incinerate.

Battery Disposal

•Please dispose of your battery properly or bring to your

local wireless carrier for recycling.

•Do not dispose of your battery in fire or with hazardous

or flammable materials.

Charger Cautions

•Using the wrong battery charger could damage your

phone and void your warranty.

•The charger is intended for indoor use only.

Do not expose the battery charger to direct sunlight or

use it in places with high humidity, such as the bath-

room.

LG-TD5130

*TD5130_eng 1/12/06 5:57 PM Page 7

Cautions

Only use the batteries and chargers provided by LG.The

warranty will not be applied to products provided by other

suppliers.

Using the phone in proximity to receiving equipment (i.e.,

TV or radio) may cause interference in this phone.

Keep your phone in a safe place when not in use.

Only authorized personnel should service the phone and

its accessories. Faulty installation or service may result in

accidents and consequently invalidate the warranty.

Do not hold the antenna while the phone is in use.

Use only the antenna provided or approved by LG.

Unauthorized antennas, modifications or attachments

may affect the quality of phone call, damage the phone

or result in a violation of FCC regulations.

Do not use the cellular phone if the antenna is damaged.

If the damaged antenna gets in contact with the skin, it

may cause a slight burn. Please contact LG Authorized

Service Center to replace the damaged antenna.

Do not use the cellular phone in areas where its use is

prohibited. (For example: aircrafts).

Do not expose the cellular phone to high temperature or

high humidity conditions.

Do not expose your cellular phone to water. If this hap-

pens, turn it off immediately and remove the battery. If the

phone does not work, bring it to an LG Authorized Service

Center.

Avoid shock or impact on the cellular phone.

LG-TD5130

Chapter 1 Getting Started

*TD5130_eng 1/12/06 5:57 PM Page 8

Phone Components

The following shows key components of your mobile

phone.

LG-TD5130

Headset Jack

Soft Key1

Clear Key

CALL Key

Vibrate Mode

Key

Data Port

Soft Key2

Navigation Key

LCD Screen

END / PWR Key

Alphanumeric

Keypad

Speaker On Key

Charger Port

“Key Guard” Key

Earpiece

Microphone

GETTING STARTED

*TD5130_eng 1/12/06 5:57 PM Page 9
