LevelOne KVM-0223 Manuel utilisateur

Ver. 1.0.0-0803

KVM-0223

2-Port USB Cable KVM Switch

LevelOne

User Manual

English

Package Contents

1. KVM-0223

2. User Manual

3. Quick Installation Guide

Requirements

Console

A VGA, SVGA, or Multisync monitor capable of the highest resolution that you will be using

on any computer in the installation

A USB Keyboard

A USB Mouse

Computers

The following equipment must be installed on each computer that is to be connected to the

system:

A VGA, SVGA or Multisync video port

A USB Type A port

Hardware Review

1. Port LEDs

2. KVM Cables

3. Speaker Jack

4. Console Port

5. USB keyboard/Mouse connector

6. Speaker Plug

7. Video Connector

Installation

Important

1. Before you begin, make sure that the power to all the devices you will be connecting has

been turned off. You must unplug the power cords of any computers that have the

Keyboard Power On function. Otherwise, the switch will receive power from the

computer.

2. To prevent damage to your equipment, make sure that all the devices you will be

connecting are properly grounded.

Installing your new KVM-0223 involves the following steps:

1. Plug your keyboard, monitor, and mouse into their ports on the KVM-0223. The keyboard

and mouse ports are labeled with an icon to distinguish them.

Plug the keyboard in before plugging in the mouse. When using a

wireless composite keyboard and mouse, its USB cable must plug into

the KVM-0223’s keyboard port for the Hotkeys to function.

The mouse connector is actually a USB port, and can accept any USB

compatible peripheral. You can even connect a hub to install multiple

USB devices.

2. Plug your speakers into the KVM-0223’s speaker jack. *This step is optional

3. Plug the USB, video, and speaker connectors of the attached KVM cables into their

respective ports on the computers you are installing.

4. Turn on the power to the computers.

Note: The KVM-0223’s Power On default is to link to the first computer you turn on.

Operation

Hotkey Port Selection

All hotkey port switches begin with tapping the Scroll Lock key twice.

[Scroll Lock] [Scroll Lock]

Invoking Hotkey Mode:

All Hotkey operations begin by invoking Hotkey Mode. Invoking Hotkey Mode takes three

steps.

1. Press and hold down the Num Lock key.

2. Press and release the minus [-] key.

3. Release the Num Lock key.

Hotkey Summary Table

Combination Function

[Port ID] + [Enter] Switches access to the computer that

corresponds to that Port ID (1 or 2).

[A]

Invokes Auto Scan Mode.

Note: The Auto Scan feature automatically

cycles through the two ports at regular

5-second intervals.

[Num Lock]

+ [-]

[Esc] or [Spacebar] Exits Hotkey, and Auto Scan Modes.

Skip Mode

Skip Mode is a shortcut method for port switching. To perform a skip, simply tap the Scroll

Lock key twice. When you do this, the KVM focus switches from its current port, to the other

one.

Hotkey Configuration

After invoking HSM, key in one of the following keys to perform the corresponding function:

Key Function

H Toggles between the default and alternate HSM invocation keys. The alternate

HSM invocation keys are [Ctrl] + [F12].

T Toggles between the default and alternate Skip Mode invocation keys. The

alternate Skip Mode invocation keys are [Ctrl] + [Ctrl].

F10 Auto detects the keyboard operating platform (for PC compatible systems).

F1 Sets the PC Compatible keyboard operating platform.

F2 Sets the Mac keyboard operating platform.

F3 Sets the Sun keyboard operating platform.

F7 Sets a Generic keyboard operating platform.

[F6] [nn]

[Enter]

Sets the keyboard language layout. Where nn is a two digit number that

represents the keyboard language code. (US English:33; French: 08;

Japanese: 15)

F4 Prints out the current hotkey, keyboard operating platform, and language code

settings.

F5 Performs a USB reset.

R [Enter] Resets the Hotkey settings to their default status.

Troubleshooting

Symptom Possible Cause Action

Keyboard / Mouse

needs to be reset. Unplug the keyboard / mouse from the Console

Keyboard Port, then plug it back in.

Hotkey sequence

input incorrectly. Resend the Hotkey command - press and

release each key in the sequence individually.

Keyboard

and/or

Mouse Not

Responding

Switch needs to be

reset. Turn off the computers; wait 5 seconds; turn the

computers back on.

Video

Problems Resolution and/or

Refresh rate set too

high. Select a lower resolution and/or bandwidth.

Specifications Function KVM-0223

Computer Connections 2

Port Selection Hotkey

Keyboard 1 x USB Type A Female (Black)

Video 1 x HDB-15 Female (Blue)

Mouse 1 x USB Type A Female (Black)

Console

Ports Speaker 1 x Mini Stereo Jack Female (Green)

Keyboard/ Mouse 2 x USB Type A Male (Black)

Video 2 x HDB-15 Male (Blue)

Connectors

KVM

Ports Speaker 2 x Mini Stereo Plug Male (Green)

LEDs Selected 2 (Green)

Cable

Length Computers 1.2m

Emulation Keyboard/ Mouse USB

Video 2048 x 1536; DDC2B

Scan Interval 5 Seconds

Operating Temp. 0-50°C

Storage Temp. -20-60°C

Environment Humidity 0-80% RH, Non-condensing

Housing Plastic

Weight 0.40 kg

Physical

Properties Dimensions

(L x W x H) 8.1 x 6.3 x 2.35 cm

Keyboard Emulation Mapping

The USB 101/104 key keyboard can emulate the functions of the Sun or Mac keyboard. The

corresponding functions are shown in the table below.

Sun Keyboard

Note: When using [Ctrl] combinations, press and release the Ctrl key, then press and release

the activation key.

PS/2 Keyboard Sun Keyboard

[Ctrl] [T] Stop

[Ctrl] [F2] Again

[Ctrl] [F3] Props

[Ctrl] [F4] Undo

[Ctrl] [F5] Front

[Ctrl] [F6] Copy

[Ctrl] [F7] Open

[Ctrl] [F8] Paste

[Ctrl] [F9] Find

[Ctrl] [F10] Cut

[Ctrl] [1]

[Ctrl] [2]

[Ctrl] [3]

[Ctrl] [4]

[Ctrl] [H] Help

Mac Keyboard

Note: When using key combinations, press and release the first key, then press and release

the second key.

PS/2 Mac Keyboard

[Shift] Shift

[Ctrl] Ctrl

[Win]

[Ctrl] [1]

[Ctrl] [2]

[Ctrl] [3]

[Ctrl] [4]

[Alt] L Alt/Option

[Prt_Sc] F13

[Scroll Lock] F14

[Desktop Menu] =

[Enter] Return

[Back Space] Delete

[Ins] Help

[Ctrl] [Win] F15
