Leica DVM6 Manuel utilisateur

Leica DVM6

User Manual

Leica DVM6 User Manual 2

Contents

General Instructions

General Instructions 5

Important Safety Notes 6

Symbols Used 7

Safety Instructions 8

Introduction

Congratulations! 11

Packing and Unpacking 12

Standard Delivery and Accessories 13

System Overview 15

Overview of the Instrument 16

Instrument Components 16

Leica DVM6C 17

Leica DVM6S 17

Leica DVM6A 18

Leica DVM6M 18

Objectives 19

Installation/Assembly

Setting up LeicaDVM6 21

Installing the PlanAPO Objective 22

Cables and Terminals 23

Optional Accessories 24

Polarizer 24

Diﬀuser 25

Side Light Adapter 26

Transmitted Light Stage 27

Leica LED5000SLI External Illumination 28

Personalizing the Computer and Installing Software 29

Instrument Setup

Leica DVM6 32

Switching on the LeicaDVM6 32

Switching on the Computer and Starting the LAS X Software 33

Placing the Sample and Positioning the Stage 34

Focusing 35

Changing the Magniﬁcation 37

Using a Tilting Stand 38

Application

Leica DVM6 Application Example 41

Leica DVM6 41

Changing the Objective 43

Coaxial Illumination 44

Using Accessories 47

Polarizer, Diﬀuser 47

Side Light Adapter, Transmitted Light Stage 48

Leica LED5000SLI External Illumination 49

Leica DVM6 User Manual 3

Contents (Continued)

Software Application

Leica LAS X Basic Functions 51

Service

Care, Maintenance, Contact Persons 54

Spare parts 57

Accessories 58

Speciﬁcations

Speciﬁcations 60

Dimensional Drawings 69

Objectives 69

LeicaDVM6C/S/A 70

Leica DVM6 M 71

Terms Used

Terms Used 73

Troubleshooting

Troubleshooting 77

Leica DVM6 User Manual General Instructions 4

General Instructions

Leica DVM6 User Manual General Instructions 5

General Instructions

Safety concept

Before using your Leica microscope for the ﬁrst

time, please read the "Safety Concept" brochure

included with your instrument. It contains addi-

tional information on handling and care.

Use in clean rooms

In general, the LeicaDVM6 digital microscope

can always be used in clean rooms.

Cleaning

ODo not use any unsuitable cleaning agents,

chemicals or techniques for cleaning.

ONever use chemicals to clean colored

surfaces or accessories with rubberized

parts. This could damage the surfaces,

and samples could be contaminated by

abraded particles.

Servicing

ORepairs may only be carried out by Leica

Microsystems-trained service technicians.

Only original Leica Microsystems spare

parts may be used.

Responsibilities of person in charge of

instrument

OEnsure that the Leica microscope is oper-

ated, maintained and repaired by autho-

rized and trained personnel only.

Leica DVM6 User Manual General Instructions 6

Important Safety Notes

User manual

The Leica DVM6C/S/A is a standalone product

and designed as a VDU workstation. It can be

conﬁgured with various objectives and a vari-

ety of accessories.

The LeicaDVM6M (zoom module and adapter)

can be conﬁgured within the Leica product

range in a wide variety of ways. You can ﬁnd

information on individual system components

on the interactive CD-ROM together with all

relevant user manuals in additional languages.

Keep this CD-ROM in a safe place, where it is

available to the user. User manuals and updates

are also available for you to download and print

from our website www.leica-microsystems.com.

This User Manual describes the special func-

tions of the Leica DVM6 digital microscope

system and contains important instructions

for its operational safety, maintenance and

accessories.

The "Safety Concept" booklet contains addi-

tional safety information regarding the service

work, requirements and the handling of the

microscope, accessories and electrical accesso-

ries as well as general safety instructions.

In order to maintain the instrument in its origi-

nal condition and to ensure safe operation,

the user must read and understand the User

Manual before assembly, instrument setup

and use. In particular, please follow all safety

instructions, notes and warnings.

Leica DVM6 User Manual General Instructions 7

Symbols Used

Warning! Safety hazard!

•This symbol indicates especially impor-

tant information that is mandatory to

read and observe.

Failure to comply can cause the following:

OHazards to personnel

OFunctional disturbances or damaged

instruments

Warning of hazardous electrical voltage

This symbol indicates especially impor-

tant information that is mandatory to

read and observe.

Failure to comply can cause the following:

OHazards to personnel

OFunctional disturbances or damaged

instruments

Danger due to hot surface

This symbol warns against touching hot

surfaces, e.g. those of light bulbs.

Important information

This symbol indicates additional infor-

mation or explanations that are intended

to provide clarity.

Leica DVM6 User Manual General Instructions 8

Safety Instructions

Description

The individual systems fulﬁll the highest

requirements for observation and documenta-

tion with the LeicaDVM6 digital microscope.

Intended use

Refer to "Safety Concept" booklet

Non-intended use

Refer to "Safety Concept" booklet

The Leica DVM6 and its components must

never be used for medical and/or IVD applica-

tions, because they are not intended for these

applications.

The instruments and accessory components

described in this User Manual have been tested

for safety and potential hazards. The respon-

sible Leica Microsystems aﬃliate must be

consulted whenever the instrument is altered,

modiﬁed or used in conjunction with non-Leica

components that are outside of the scope of

this manual!

Unauthorized alterations to the instrument or

non-compliant use shall void all rights to any

warranty claims.

Place of use

ORefer to "Safety Concept" booklet

OElectrical components must be placed at

least 10 cm away from the wall and from

ﬂammable substances.

OAvoid large temperature ﬂuctuations,

direct sunlight and vibrations. These condi-

tions can distort measurements and micro-

graphic images.

OIn warm and warm-damp climatic zones, the

individual components require special care

in order to prevent the build-up of fungus.

Responsibilities of person in charge of

instrument

Refer to "Safety Concept" booklet

Ensure that:

OThe Leica DVM6 digital microscope and

accessories are operated, maintained and

repaired by authorized and trained person-

nel only.

OAll operators have read, have understood

and observe this User Manual, and particu-

larly the safety regulations.

Leica DVM6 User Manual General Instructions 9

Safety Instructions (Continued)

Repairs, service work

Avoid contact with powered electrical circuits,

which can lead to injury.

Transport

OUse the original packaging for shipping or

transporting the LeicaDVM6 digital micro-

scope and the accessory components.

OIn order to prevent damage from vibrations,

disassemble all moving parts that (accord-

ing to the User Manual) can be assembled

and disassembled by the customer and

pack them separately.

Integration in third-party products

The LeicaDVM6 is not permitted for integration

in third-party products.

Disposal

Refer to "Safety Concept" booklet

Legal regulations

Refer to "Safety Concept" booklet

EC Declaration of Conformity

Refer to "Safety Concept" booklet

Health risks

Workplaces with microscopes facilitate and

improve the viewing task, but they also impose

high demands on the eyes and holding muscles

of the user. Depending on the duration of unin-

terrupted work, musculoskeletal problems may

occur. For this reason, appropriate measures for

reduction of the workload must be taken:

OOptimal arrangement of workplace, work

assignments and work ﬂow (changing tasks

frequently).

OThorough training of the personnel, giving

consideration to ergonomic and organiza-

tional aspects.

The ergonomic optics concept and the design

of the Leica DVM6 digital microscope aim to

limit the strain on the user to the lowest possi-

ble level.

•The microscope illumination is in risk

group 2 according to EN 62471:2008

when used according to its intended use.

Never look directly into the

LED beam of the illumination

equipment – either with or

without optical instruments. Failure to observe

this notice poses a risk of eye damage.
