La Crosse Technology Soluna C79141 Dimensions

La Crosse Technology, Ltd Page 1

C79141 FAQS

The links below will work in most PDF viewers and link to the topic area by clicking the

link. We recommend Adobe Reader version 10 or greater available at:

http://get.adobe.com/reader

CONTENTS

C79141 FAQS

............................................................................................................................. 1

Power......................................................................................................................................... 1

Alarm Clock Factory Restart ........................................................................................................ 2

Language................................................................................................................................ 2

12-Hour Time Format ............................................................................................................... 2

Does the clock have a backlight?............................................................................................. 2

What is Auto Dim backlight?..................................................................................................... 2

Glow Light Colors.................................................................................................................... 3

Time is inaccurate ................................................................................................................... 4

Daylight Saving Time............................................................................................................... 4

Program Menu......................................................................................................................... 5

Do I need to unplug the clock to change the time?................................................................... 6

Time Alarms ............................................................................................................................ 6

Light Alarm (light only, no sound).............................................................................................. 6

Will the light always start 30 minutes before the Light Alarm?.................................................... 7

Sound Alarm ........................................................................................................................... 7

Can I change sounds on my Sound Alarm ?.............................................................................. 7

USB Charge Port ..................................................................................................................... 8

Will not Charge my Phone ....................................................................................................... 8

Alarm Clock is dim................................................................................................................... 8

Alarm Clock is blank: No numbers or dashed lines ................................................................... 8

Power

•The design of this alarm clock is to use a power cord (5-volt) as the primary power

source.

•Replacement Power Cord: Look on the bottom of the clock for the appropriate Power

cord number. It is important to use the correct power cord on all electronic devices.

•The backlight will operate at five levels of intensity (including OFF) at your discretion

when using the power cable.

•The glow light will operate at five levels of intensity (including OFF) at your discretion

when using the power cable.

La Crosse Technology, Ltd Page 2

Battery Backup:

•CR2032 backup battery for time and alarm

When operating on battery only:

•LCD will not show but clock will keep time and both the Light Alarm & Sound Alarm

will buzz at the scheduled time each day if active.

Alarm Clock Factory Restart

Use a pen or paper clip to press the factory RESET button on the back of the clock.

Language

•This clock will show the weekday and directions in English (default), Spanish, French or

German.

•Use the program menu to select language.

12-Hour Time Format

•This clock only has 12-hour time format.

Does the clock have a backlight?

Yes, this alarm clock has a backlight.

•Tap the button to adjust the backlight 5 levels of intensity.

•Intensity Levels: 0FF | 1.5% | 20% | 50% | 100%.

LCD Backlight is not on:

Try this exercise in a dim room. The backlight will operate at five levels of intensity

(including OFF) at your discretion when using the power cable. Touch the DISPLAY button

a few times. Wait 15 seconds to see if backlight stays on. This will assure it is not in OFF

mode.

What is Auto Dim backlight?

You can set your backlight to automatically dim to level 1 at a set hour for sleeping, then

automatically return to full brightness when you wake.

Set Auto Dimming (Hour only).

Hold

the button 2 seconds to enter dimmer set mode.

AUTO DIM OFF

will show.

2. Tap the + or – buttons to turn dimmer (ON).

AUTO DIM ON

will show.

3. Tap the button to select start time (Hour) for dimmer.

START TIME

and the

hour

will

flash.

4. Tap the + or – buttons to change the hour for the dimmer to be low light level.

5. Tap the button to select start time for dimmer to be on High light level.

STOP TIME

and the

hour

will flash.

La Crosse Technology, Ltd Page 3

6. Tap the + or – buttons to change the hour for the dimmer to be high light level.

7. Tap the button to confirm and exit.

Glow Light Colors

Color Light Selection Order:

•COLOR CYCLE

•EVENING

•BREATHING

oEnergy

oWarmth

oCalm

•COMFORT METER

•PICK COLOR

oRed

oFire

oOrange

oSun

oYellow

oGarden

oGreen

oForest

oCyan

oOcean

oDark Blue

oNight

oPurple

oWhite

•

Tap

the button to move through light selection

•

Tap

+ or – button if adjustments need to be made to selection

•

Tap

the button to exit

Note:

During Light Settings, each selection will show at full intensity.

COLOR CYCLE:

When using the Color Cycle Mode, the light will gradually shift through all the glow

color options.

1. Tap the button

once

. CYCLE will show.

2. Tap the button to exit. The Light cycle will begin.

3. Tap the

–

button to adjust brightness (OFF, 1, 2, 3, 4, 5)

La Crosse Technology, Ltd Page 4

EVENING:

The Evening Mode is a 30-minute cycle designed to simulate the setting of the sun.

Simply start the mode before bed and the light will gradually dim and shift in color

while you fall asleep.

1. Tap the button

twice

. EVENING will show.

2. Tap the button to exit. The Evening light cycle will begin.

GUIDED BREATHING:

The Guided Breathing Mode will walk you through a 10-minute deep breathing

exercise. Simply inhale and exhale as the color change. To further assist you, the LCD

will also display your inhale and exhale times.

1. Tap the button

three times

. Breathing will show.

2. Tap the + or – button to choose

Energy, Warmth or Calm

3. Tap the button to exit. The Breathing light cycle will begin.

4. Tap button to cancel Breathing before 10 minutes has elapsed.

5. Tap the

–

button to adjust brightness (OFF, 1, 2, 3, 4, 5)

COMFORT METER:

In the Comfort Meter Mode, the color changes according to the current indoor

humidity level, so you can monitor the comfort of your room at a quick glance.

1. Tap the button

four times

. COMFORT will show.

2. Tap the button to exit.

3. Tap the + or – button to adjust brightness (OFF, 1, 2, 3, 4, 5)

COLOR SELECT:

Choose your favorite color: Red, Forest, Fire Orange, Cyan, Sun, Dark Blue, Yellow

Garden Green, Ocean, Night, Purple, White,

1. Tap the button

five times

. PICK COLOR will show.

2. Tap the + or – button to choose Red, Fire, Orange, Sunny, Yellow, Garden, Green,

Rainforest, Cyan, Ocean, Night, Purple or White.

3. Tap the button to exit. The light will stay on color selected.

4. Tap the

–

button to adjust brightness (OFF, 1, 2, 3, 4, 5)

Time is inaccurate

•This clock has manual set time. Use the program menu to set the time.

Daylight Saving Time

•This clock has manual set time. Use the program menu to change the time in the

spring to enter daylight saving time, and in the fall to return to Standard Time.

La Crosse Technology, Ltd Page 5

Program Menu

When the customer powers up the clock, there will be a greeting and the clock will go into

Settings automatically. If there is loss of power or customer unplugs and moves the clock,

the Greeting will appear.

•

Greeting:

HELLO

SET UP/ TIME

( Hello for 2 seconds, then 1 second each for SET UP

and TIME)

•Language flashes with no additional button press.

•Tap the +

buttons to adjust the values.

•Press the button to confirm adjustments and move to the next item.

•Tap the button at any time to exit settings.

•When customer exits with the button or after selecting the F/C, and presses the

button, clock will read THANK YOU for 2 seconds.

Settings Menu order:

•Greeting

HELLO

SET UP/ TIME

( Hello for 2 seconds, then 1 second each for SET UP

and TIME)

•Language: English, Spanish, French, German

•Hour

•Minutes

•Year

•Month

•Date

•Fahrenheit / Celsius

•Thank You

Power up clock.

HELLO /

SET UP /

TIME will show for 2 seconds (each frame). Then

ENGLISH

will flash. Tap the + or - button to select language.

2. Press to confirm and move to the hour. The

HOUR

will flash. Tap the + or - button to

choose the hour.

3. Press to confirm and move to the minutes. The

MINUTES

will flash. Tap the + or -

button to choose the minutes.

4. Press to confirm and move to the year. The

YEAR

will show and

2020

will flash. Tap

the + or - button to change the year.

5. Press to confirm and move to the month. The

MONTH

will show, and Month number

will flash. Tap the + or - button to change the month.

6. Press to confirm and move to the date.

DATE

will show and Date number will flash.

Tap the + or - button to change the date.

7. Press to confirm and move to the temperature unit.

TEMP

will show and F will flash.

Press the + or - button if you prefer °C (Celsius).

8. Press to confirm and exit.

THANK YOU

will show for 2 seconds.

La Crosse Technology, Ltd Page 6

Do I need to unplug the clock to change the time?

•No. To access the Program Menu, simply hold the button for 3 seconds. The

Greeting will not show. The Greeting will only show when clock is plugged in.

Time Alarms

There are 2 time alarms: LIGHT ALARM and SOUND ALARM. The LIGHT alarm and SOUND

alarm may be set to different times or be set to the same time.

The Light and Sound alarm can each be set to:

•DAILY ALARM (1-7) – Alarms 7 days per week when active.

•WEEKDAY M-F (1-5) – Alarms Monday through Friday only

•WEEKEND S-S (6-7) -Alarms on Saturday and Sunday only.

Light Alarm (light only, no sound)

•The Light Alarm is a silent alarm. There will be no Snooze feature for the Light Alarm.

•When the user sets the light alarm for 7:00am, the light should start at 6:30am and

gradually increase to full brightness at 7:00am.

Set Light Alarm:

1. Hold the button to enter the Alarm Setting Mode.

DA I LY

ALARM

will show.

Tap the + or – button to select Daily Alarm, Weekday M-F alarm, or Weekend S-S alarm.

2. Press the button. The Alarm Hour will flash. Tap the + or – button to adjust the hour.

3. Press the button. The Alarm Minutes will flash. Tap the + or – button to adjust the

minutes.

4. Press the button to confirm and exit.

5. The alarm is active when set.

Before the alarm time is reached

, the Light Cycle will begin to brighten, taking 30

minutes for full brightness. Full brightness will remain until the alarm is turned off. In the

rare chance that the user activates the light alarm, when there is less than 30 minutes

before the set alarm time, the light brightness will go from the brightness it should be at for

the time remaining before the alarm.

Activate/Deactivate Light Alarm:

•The alarm is active when set. The Light Alarm Icon and Alarm Type (1-5, 1-7, 6-7) will

show.

•Press the button once to deactivate. Alarm Time and Type (DAILY ON/OFF) will

show for 3 seconds.

•Press the button again to activate for the same time.

La Crosse Technology, Ltd Page 7

Will the light always start 30 minutes before the Light Alarm?

•In the rare chance that you set the light alarm, with less than 30 minutes before the

alarm time, the light brightness adjusts to the brightness level it should be at for the

time remaining before the alarm.

•This may cause you to see a “jump” in the light level when it adjusts.

Sound Alarm

The SOUND ALARM will wake you to gentle melody that will increase in loudness over a 5

minute period.

Set Sound Alarm:

1. Hold the button to enter the Alarm Setting Mode.

DA I LY

ALARM

will show. Tap

the + or – button to select Daily Alarm, Weekday M-F alarm, or Weekend S-S alarm.

2. Press the button. The Alarm Hour will flash. Tap the + or – button to adjust the hour.

3. Press the button. The Alarm Minutes will flash. Tap the + or – button to adjust the

minutes.

4. Press the button. The Snooze Duration will flash. Tap the + or – button to adjust the

Snooze Duration (5-120 minutes.

5. Press the button to confirm and exit.

6. The alarm is active when set.

Activate/Deactivate Sound Alarm:

•The alarm is active when set. The Sound Alarm Icon and Alarm Type (1-5, 1-7, 6-7) will

show.

•Press the button once to deactivate. Alarm Time and Type (WEEKEND ON/OFF) will

show for 3 seconds.

•Press the button again to activate for the same time.

Snooze:

•TAP the SNOOZE button to snooze the Sound Alarm for the selected 5-120 minutes.

•SNOOZE and minutes countdown will show in place of weekday

•When both the LIGHT and the SOUND ALARMS are set and active, the Alarm Icons

and day selection will show next to the date.

Gradual Wake Up:

The gentle Melody Sound Alarm will increase in volume over a 5-

minute period. Turn off a sounding alarm by pressing any button (except SNOOZE). After

the 5-minute time frame, the alarm will stop if not snoozed/deactivated.

Can I change sounds on my Sound Alarm ?

No. the only sound option is the melody.

La Crosse Technology, Ltd Page 8

USB Charge Port

There is a 1 Amp USB charging port on the side of the clock. The included power adapter

must be in use to charge a device with your cable.

•Connect your external device’s USB charging cable (not included) to the USB charging

port.

•Charging times will vary.

•USB Power Output: 1A maximum current.

•Charge 1A devices or devices that are self-regulating.

USB Output:

1 Amp output

Will not Charge my Phone

•Be sure your phone charge cord is attached correctly.

Alarm Clock is dim

•Tap the SNOOZE button to determine if the LCD backlight is on HIGH or LOW.

•Clock must operate on Power cord for backlight to stay on.

Alarm Clock is blank: No numbers or dashed lines

•Check that the Power cord. Is it correctly installed and connects to an active outlet.

•Press any button 20 times. Leave the alarm clock unpowered for 1-2 hours.

Autres manuels pour Soluna C79141

Table des matières

Autres manuels La Crosse Technology Réveil

La Crosse Technology

La Crosse Technology 616-1412v3 Manuel d'utilisation et d'entretien

La Crosse Technology

La Crosse Technology 617-1485Bv3 Manuel utilisateur

La Crosse Technology

La Crosse Technology Radio-Controlled Travel Alarm Clock WT-2160 Manuel utilisateur

La Crosse Technology

La Crosse Technology DCF-77 Manuel utilisateur

La Crosse Technology

La Crosse Technology 616-1412v2 Manuel d'utilisation et d'entretien

La Crosse Technology

La Crosse Technology WT-2191A Manuel utilisateur

La Crosse Technology

La Crosse Technology WT-5360U Manuel utilisateur

La Crosse Technology

La Crosse Technology WT-2171 Manuel utilisateur

La Crosse Technology

La Crosse Technology 616-146A Dimensions

La Crosse Technology

La Crosse Technology 616-143 Manuel utilisateur

La Crosse Technology

La Crosse Technology 617-2410V2 Dimensions

La Crosse Technology

La Crosse Technology C79141-UK Manuel utilisateur

La Crosse Technology

La Crosse Technology WT-5720 Manuel utilisateur

La Crosse Technology

La Crosse Technology WT-5432 Manuel utilisateur

La Crosse Technology

La Crosse Technology 602-249V2 Dimensions

La Crosse Technology

La Crosse Technology 433 MHz RADIO CONTROLLED PROJECTIONALARM... Manuel utilisateur

La Crosse Technology

La Crosse Technology WT-2171 Manuel utilisateur

La Crosse Technology

La Crosse Technology WW85760 Dimensions

La Crosse Technology

La Crosse Technology 616-1950V2 Manuel utilisateur

La Crosse Technology

La Crosse Technology WT-5721 Manuel utilisateur

La Crosse Technology

La Crosse Technology WT-5120 Manuel utilisateur

La Crosse Technology

La Crosse Technology K86326 Manuel utilisateur

La Crosse Technology

La Crosse Technology K84292 Manuel utilisateur

La Crosse Technology

La Crosse Technology RADIO CONTROLLED PROJECTION CLOCK WITH DIGITAL... Manuel utilisateur

Manuels Réveil populaires d'autres marques

Steren

Steren CLK-210 Manuel utilisateur

COP-USA

COP-USA ALCDVR32-SL Manuel utilisateur

Philips

Philips HF3505/70 Manuel technique

Casio

Casio PQ-70 Manuel utilisateur

iHome

iHome IA63 Manuel utilisateur

Coopers

Coopers 9765 Manuel utilisateur

ANJANK

ANJANK AC-190 Mode d’emploi

TFA

TFA 98.1075 Manuel utilisateur

Sharper Image

Sharper Image 204050 Manuel utilisateur

Lumie

Lumie Zest Manuel utilisateur

Dexford

Dexford RCT200 Manuel utilisateur

Philips

Philips AJL303/37B Manuel utilisateur

RST

RST Q754 Manuel utilisateur

iHome

iHome iKT50 Manuel utilisateur

Sony

Sony dash HID-B7 Manuel utilisateur

SVINZ

SVINZ SCC009 Manuel utilisateur

Clas Ohlson

Clas Ohlson 918863 Manuel utilisateur

IKEA

IKEA FNURRA Manuel utilisateur
