La Crosse Technology 617-148v2 Manuel utilisateur

SET UP GUIDE

MODEL NUMBER: 617-148v2

WIRELESS CHARGING

ALARM CLOCK

Table of Contents

BASICS

SUPPORT

Initial Setup

Buttons

LCD Display

Ports

LCD Display Brightness

Auto-Dim Settings

Display Modes

Display Mode Options

Support Information

Trademarks & Info

Stay in Touch

Use the +/- buttons on

the back of the clock to

adjust the values.

Initial Setup

Power Up

Settings Menu Order

Insert the 5V Power Adapter into an outlet, and then plug it into the Power Jack

on the bottom of the alarm clock.

A greeting will appear on the LCD display and then your clock will move into

the Settings Menu.

• Language •12/24 Format • Hour • Minutes •Year •Month •Date

• Month/Date or Date/Month • Fahrenheit/Celsius

You may exit the Settings

Menu at any time by tapping

the SNOOZE/LIGHT button.

APPENDIX

Speciﬁcations

Warranty

Recycling & Disposal

Cautions

Statement

ALARM

Setting the Alarm

Activate/Deactivate

Snooze Duration

GLOW LIGHT

Glow Light Selection

Glow Light Brightness

CHARGING

5W Wireless Charger

Phone Compatibility

Wireless Charging FAQs

Phone USB Charging Port

BASICS

Tap the SET button to

conﬁrm selection and

move to next step.

Language: Whichever language is selected, the following instructions and weekday

will be presented in that language.

Weekday: Weekday will set automatically after year, month, & date settings are

adjusted.

03 04

Buttons LCD Display

Ports

BASICS BASICS

1. GLOW

4. PLUS/MINUS (+/-)

2. SET

3. ALARM

6. RESET

Press to change the Glow

Light color. Hold to turn Glow

Light o.

Press to activate/deactivate or

hold to enter alarm settings.

Press to increase/decrease

Glow Light Brightness. Press

to increase/decrease values in

Settings Menu, hold to change

values quickly.

Tap to snooze sounding alarm,

adjust backlight, or hold for

Auto-Dim settings.

Press to change Display

Modes. Hold to enter

Settings Menu.

Note: To enter the Settings Menu after the initial setup, hold the SET button on the

back of the clock.

Top View

Back View

Press to factory reset

your clock

RESET

5. SNOOZE/BACKLIGHT

Right View

1 Amp USB

Charging Port

Bottom View

Power Jack

Snooze

Indicator

AM/PM

Indicator

Auto Dim

Indicator

Time

Alarm

Indicator

Weekday

Calendar or

Temperature

05 06

LCD Display Brightness Display Modes

Adjusting the LCD Display Brightness Selecting the Display Mode

Auto-Dim Settings

Press the SNOOZE/BACKLIGHT button on the top

of the clock to adjust the backlight intensity. There

are 4 brightness levels, plus an o option.

Press the SET button on the back of the clock

to select a display mode. Clock will stay on

selection.

Hold the SNOOZE/BACKLIGHT

button to enter the Auto-Dim

Settings Menu.

Program your LCD display to automatically dim during preselected times.

Press the +/- buttons to turn the

Auto-Dim feature on or o. Press

SNOOZE/BACKLIGHT to conﬁrm.

Press the +/- buttons to adjust

the starting hour. Press SNOOZE/

BACKLIGHT to conﬁrm.

Press the +/- buttons to adjust the

stopping hour. Press SNOOZE/

BACKLIGHT to conﬁrm and exit.

The icon will appear on the LCD when activated.

BASICS BASICS

Full Weekday

& Calendar

Full Weekday &

Indoor Temperature

Weekday, Month, Date

& Indoor Temperature

Display Mode Options

Time Alarm

Activating & Deactivating the Alarm

Time Alarm

Ascending Alarm

Snooze Duration Countdown

The alarm will increase in beep frequency over a 2-minute period. After the

2-minute time frame, the alarm will stop if not snoozed or turned o.

When your alarm sounds, Press the

SNOOZE/LIGHT button to snooze your

alarm for your preselected snooze

duration.

A countdown will appear on screen.

When the snooze time reaches “0,” the

alarm will sound again.

Setting the Alarm

ALARM ALARM

Your sound alarm is now activated,

indicated by the icon on the LCD.

Hold the button on the back

of the clock to enter the Alarm

Settings Menu.

Use the +/- buttons to set your

desired time. Press to conﬁrm.

Next, use the +/- buttons to set your

desired snooze duration (5 to 120

minutes). Press to conﬁrm and

exit the Alarm Settings Menu.

Press the button to activate/

deactivate the alarm and to view

your alarm time.

The icon will appear on the

LCD when the alarm is active.

Note: The snooze feature can be repeated as many times as desired.

1009

Glow Light Selection

Glow Light

Press the GLOW button to turn on the Glow Light and toggle

through the dierent light options.

Glow Light Color Selection Order:

Select Glow Light Color:

Press the SNOOZE/LIGHT to select an individual solid

color. When a single color is selected, it will remain

on that color. Select CYCLE to smoothly transition

between all of the colors.

Glow Light Brightness

Use the +/- buttons to adjust the Glow Light brightness. It has 4

intensity levels plus an OFF option. Holding the GLOW button will

also turn o the Glow Light.

CHARGING

5W Wireless Charger

Charging your Phone

Phone Compatibility

• Place your phone on the platform. Your

phone should sit ﬂush and centered on

the charging pad.

• The blue Charging Indicator Light below

the LCD will be solid when your phone is

successfully charging.

• The light will ﬂash slowly if your device is

not positioned properly or if your device is

not compatible with the wireless charging

technology. If this problem persists, try

removing any large/bulky cases.

Compatible with all Qi Enabled devices:

• iPhone 8 or newer

• Galaxy S8 or newer

• Galaxy Note 8 or newer

Compatibility may vary based on phone model and/or case selection.

This list is not comprehensive. Please check your phone’s manual for details

regarding wireless charging capabilities.

Glow Light

11 12

USB Charging Port

CHARGING

There is a 1 Amp USB Charging Port located on

the right side of your alarm clock.

• Connect your external device’s USB charging

cable (not included) into the USB Charging Port.

• Charging times may vary.

• USB Power Output: 1 Amp maximum current

Right View

1 Amp USB

Charging Port

For detailed product videos, manuals, and more, visit our support website:

www.lacrossetechnology.com/support

Make sure to have your model number handy (617-148).

If you need additional support, get in touch with our friendly customer

support team:

Online: bit.ly/contact_techsupport

Phone Number: 1.608.782.1610

Representatives are available Monday-Friday 8:00am to 6:00 pm CST.

CHARGING

Wireless Charging FAQs

Blue

LED Light

Q. Why is the blue light blinking?

A. Phone is not centered on the charging pad.

A. Your phone must be Qi Enabled to charge.

A. If the phone has a large/thick case, it may interfere with charging.

A. Foreign objects on the charging pad may make the light blink.

Q. Why is the table surface getting warm?

A. Ensure the clock is on a hard, clean surface.

A. Do not place on cloth, paper, or other items that may obstruct airﬂow.

A. Clear dust or other obstructions from the vents on the bottom of the clock.

Important:

Wireless charging uses magnetic induction to charge your compatible smartphone. Do not

place anything between your phone and the charging pad. Keep the charging pad clear of all

foreign objects. Magnetic mounts, magnetic cases, or other objects between your phone and

the wireless charger may reduce performance or damage magnetic strips or RFID chips found

in some credit cards, security badges, passports, and key fobs. If your phone case holds any

of these sensitive items, be sure to remove them before charging or make sure they are not

between the back of your phone and the charging pad.

Warranty

Recycling & Disposal Caution!

La Crosse Technology, Ltd. provides a 1-year limited time warranty (from date of purchase) on

this product, relating to manufacturing defects in materials and workmanship.

For full warranty details, you can visit: www.lacrossetechnology.com/support

Please consider the environment when

deciding to dispose of this product.

Although household electronics are

generally safe to use on a daily basis,

incorrect disposal can cause negative

and potentially irreversible impacts on

our environment.

Check with local donation centers to

see if your product can be donated for

future use. If disposal is the only option,

federal agencies, local governments, and

certiﬁed retailers may have electronic

recycling programs in place. Programs

may vary based on location.

Please Recycle

The manufacturer is not responsible for

any radio or TV interference caused by

unauthorized changes or modiﬁcations

to this equipment. Such changes or

modiﬁcations could void the user authority

to operate the equipment.

be reproduced in any form, even in part, or

duplicated or processed using electronic,

mechanical or chemical process without the

written permission of the publisher.

This booklet may contain errors or misprints.

The information it contains is regularly

checked and corrections are included

in subsequent editions. We disclaim any

responsibility for any technical error or

printing error, or their consequences. All

trademarks and patents are recognized.

La Crosse Technology, Ltd •2830 S. 26th Street •La Crosse, WI 54601

APPENDIX

Phone charging accessories not included.

Speciﬁcations

APPENDIX

Power Requirements: 5.0V Power Cord (Included)

HX13-0502500-AU-001

The plug on the power adapter is intended to serve

as the disconnect device, the socket-outlet shall

be installed near the equipment and shall be easily

accessible.

LCD Brightness: 4 Intensity Levels + OFF

(Programmable Auto-Dim Backlight Option)

Glow Light Brightness: 4 Intensity Levels + OFF

Programmable Snooze Duration: 5 to 120 Minutes

Indoor Temperature Range: 32°F to 99°F (0°C to 37°C)

Wireless Charger Power Output: 5 Watts

USB Charging Port: 1 Amp Maximum Current

(Charging Cord Not Included)

Settings Backup: The time and alarm settings will be

saved for 3 minutes in the event it loses power. Full

battery backup for extended times is not available.

Dimensions: 4.97” L x 5.34” W x 2.85” H

(12.62 cm L x 13.56 cm W x 7.24 cm H)

Factory Reset: If you’re experiencing issues with your

clock, use a pen or paper clip to press the factory RESET

button on the back of your clock.

Follow La Crosse Technology on Facebook,

Instagram, YouTube, and Twitter.

California Residents

This product can expose you to chemicals including

styrene, which is known in the State of California to

cause cancer. For more information, go to:

www.P65Warnings.ca.gov

WARNING:

FCC Statement

• This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant

to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception, which can

be determined by turning the equipment o and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

FCC Radiation Exposure Statement

This device complies with FCC radiation exposure limits set forth for an uncontrolled environment and

it also complies with Part 15 of the FCC RF Rules. This equipment must be installed and operated in

accordance with provided instructions and the antenna(s) used for this transmitter must be installed to

provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in

conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna

installation instructions and consider removing the no-collocation statement.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1 ) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may cause undesired

operation.

Caution!

Any changes or modiﬁcations not expressly approved by the party responsible for compliance could void

the user’s authority to operate the equipment.

Designed in La Crosse, Wisconsin • Made in China •Printed in China •DC 090821

APPENDIX

Autres manuels La Crosse Technology Réveil

La Crosse Technology

La Crosse Technology WT-2191A Manuel utilisateur

La Crosse Technology

La Crosse Technology WT-5350 Manuel utilisateur

La Crosse Technology

La Crosse Technology C86224 Manuel d'utilisation et d'entretien

La Crosse Technology

La Crosse Technology WT-5130 Manuel utilisateur

La Crosse Technology

La Crosse Technology C8929 Manuel utilisateur

La Crosse Technology

La Crosse Technology C86224 Dimensions

La Crosse Technology

La Crosse Technology WT-5442 Manuel utilisateur

La Crosse Technology

La Crosse Technology WT-2171U Manuel utilisateur

La Crosse Technology

La Crosse Technology WW85760 Dimensions

La Crosse Technology

La Crosse Technology WS-8017U Manuel utilisateur

La Crosse Technology

La Crosse Technology WT-2191A Manuel utilisateur

La Crosse Technology

La Crosse Technology 616-1412V3 Dimensions

La Crosse Technology

La Crosse Technology Soluna C79141 Dimensions

La Crosse Technology

La Crosse Technology 616-146v3 Manuel utilisateur

La Crosse Technology

La Crosse Technology W88723 Manuel utilisateur

La Crosse Technology

La Crosse Technology WS8010 Manuel utilisateur

La Crosse Technology

La Crosse Technology 617-89577V3 Manuel utilisateur

La Crosse Technology

La Crosse Technology WT-9300 Manuel utilisateur

La Crosse Technology

La Crosse Technology 617-1485v2 Manuel utilisateur

La Crosse Technology

La Crosse Technology WT-5130ER Manuel utilisateur

La Crosse Technology

La Crosse Technology 616-146A Dimensions

La Crosse Technology

La Crosse Technology 616-1412v3 Manuel d'utilisation et d'entretien

La Crosse Technology

La Crosse Technology 616-146A Manuel utilisateur

La Crosse Technology

La Crosse Technology 616-1412v2 Manuel d'utilisation et d'entretien

Manuels Réveil populaires d'autres marques

Steren

Steren CLK-210 Manuel utilisateur

COP-USA

COP-USA ALCDVR32-SL Manuel utilisateur

Philips

Philips HF3505/70 Manuel technique

Casio

Casio PQ-70 Manuel utilisateur

iHome

iHome IA63 Manuel utilisateur

Coopers

Coopers 9765 Manuel utilisateur

ANJANK

ANJANK AC-190 Mode d’emploi

TFA

TFA 98.1075 Manuel utilisateur

Sharper Image

Sharper Image 204050 Manuel utilisateur

Lumie

Lumie Zest Manuel utilisateur

Dexford

Dexford RCT200 Manuel utilisateur

Philips

Philips AJL303/37B Manuel utilisateur

RST

RST Q754 Manuel utilisateur

iHome

iHome iKT50 Manuel utilisateur

Sony

Sony dash HID-B7 Manuel utilisateur

SVINZ

SVINZ SCC009 Manuel utilisateur

Clas Ohlson

Clas Ohlson 918863 Manuel utilisateur

IKEA

IKEA FNURRA Manuel utilisateur
