Kyocera FS-1118MFP Manuel utilisateur

FS-1118MFP

KM-1820

ABB DD

CAUTION: Be sure to hold the machine as shown and do not carry it by holding

only the top portion.

Make sure the cassette does not come out and the original cover is closed when

holding or transporting the machine.

Remove the protective sheet (A) and the

packing tape (B).

Open the original cover.

Remove the packing tape (C), the protective packing (D) and the protective sheet (E).

Pull the cassette out of the machine.

Remove the protective packing (F) from

inside the cassette.

Turn the yellow transport pin (G) on the left side of the machine

counter-clockwise to remove it and remove the paper tag (H).

Store the pin for future use as shown in step 9.

Open the top cover.

Open the front cover.

Remove the Machine from the Box and Check Contents

Remove all Packing and Transport Materials

Place the machine in a stable position (refer to the Operation Guide).

Store the yellow transport pin (G). Be sure to save this pin as it is

essential that it is used whenever the machine is moved.

1. Toner Container 4. One-touch Key Sheet

2. Power Cord 5. Operation Guide and CD-ROM

3. Main Body 6. Cleaning Cloth

KM1820_ENG_IG 17_02_05.fm 1 ページ２００５年２月１７日　木曜日　午後７時３２分

5-6

A------

B------

C------

D------

E------

F------

G------

H------

Remove the process unit from the machine.

Install the Toner Container

Move the lock lever to the UNLOCK position.

Shake the toner container horizontally 5 or 6 times

so that the toner inside becomes evenly distributed.

Align the knob on the left side of the container

with the groove in the process unit and place the

toner container into the process unit.

Remove the orange protective seal.

Push on the PUSH HERE marks on the toner

container until the container clicks into place.

Push the lock lever back into its

LOCK position (away from you).

Align the pins on both sides of the process unit with

the guides inside the machine, and slide the

process unit into the machine until it stops.

Close the front cover and top cover.

Connect the Machine

Network Interface

When connecting to a network, plug the

network cable into the network interface

connector at the rear of the machine.

Connect the other end of the cable to your

network device.

Make network settings (refer to the

Operation Guide). 2.

Parallel and USB Interface

When connecting to the parallel and USB interfaces, plug one end into the appropriate port at the

rear of the machine and the other end to the appropriate port on your computer.

Connect the power cord to the machine

and the other end into a power outlet.

Turn the power switch to on ( | ).

The machine will begin replenishing the toner; this will take

approximately 15 minutes.

Once the toner has been replenished, Ready to copy will appear

on the message display and the Start key will light.

If the Welcome to the Found New Hardware Wizard is displayed on the PC click Cancel.

For more information on the machine, refer to the Operation Guide.

IMPORTANT: Place the process unit on a clean, level surface where it will not be

exposed to any sort of impact or shock. The drum in the process unit is sensitive to

light and should not be exposed to normal office lighting for more than five minutes.

Install the Software

Insert the CD-ROM in the PC. The opening screen is displayed.

Follow the instructions on the screen to install the software.

If the installation program fails to launch, use Windows Explorer

to access the CD-ROM and select Setup.exe.

The one-touch key sheet allows you to record destination

information registered under the one-touch keys. Place the

sheet next to the one-touch keys.

Enter the destinations onto the one-touch key sheet. (four

spare one-touch key sheets are included with the machine.)

Using the One-Touch Key Sheet

KM1820_ENG_IG 17_02_05.fm 2 ページ２００５年２月１７日　木曜日　午後７時３２分
