Kramer VP-444 Manuel utilisateur

KRAMER ELECTRONICS LTD.

USER MANUAL

MODEL:

VP-444

Presentation Switcher/Scaler

P/N: 2900-300305 Rev 1

VP-444 – Contents

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

2.2 Safety Instructions 3

2.3 Recycling Kramer Products 3

3Overview 4

3.1 Defining the VP-444 Presentation Switcher/Scaler 5

4Installing in a Rack 8

5Connecting the VP-444 9

5.1 Connecting the Balanced Stereo Audio Output 11

5.2 Microphone Pinout 11

6Controlling the VP-444 12

6.1 Controlling via the Front Panel Buttons 12

6.2 Using the OSD Menu 12

6.3 Connecting to the VP-444 via RS-232 15

6.4 Operating via Ethernet 15

6.5 Controlling via the Infrared Remote Control Transmitter 19

7Using the Embedded Web Pages 20

7.1 Browsing the VP-444 Web Pages 21

7.2 The Input Select Page 22

7.3 The Device Settings Page 24

7.4 The Output Settings Page 26

7.5 The HDCP Page 27

7.6 The EDID Page 28

7.7 The Audio Settings Page 31

7.8 The Advanced Page 31

7.9 The About Page 32

8Technical Specifications 33

8.1 Default Communication Parameters 34

8.2 Input Resolutions 34

9The VP-444 RS-232 Communication Protocol 35

9.1 Kramer Protocol 3000 Syntax 35

9.2 Kramer Protocol 3000 –Command List 38

9.3 Kramer Protocol 3000 –Detailed Commands 39

VP-444 - Introduction

Figures

Figure 1: VP-444 Presentation Switcher/Scaler Front Panel 6

Figure 2: VP-444 Presentation Switcher/Scaler Rear Panel 7

Figure 3: Connecting the VP-444 Presentation Switcher / Scaler 10

Figure 4: Connecting the Balanced Stereo Audio Output 11

Figure 5: Connecting an Unbalanced Stereo Audio Acceptor to the Balanced Output 11

Figure 6: Condenser Microphone Pinout 11

Figure 7: Dynamic Microphone Pinout 11

Figure 8: Local Area Connection Properties Window 16

Figure 9: Internet Protocol Version 4 Properties Window 17

Figure 10: Internet Protocol Version 6 Properties Window 17

Figure 11: Internet Protocol Properties Window 18

Figure 12: Infrared Remote Control Transmitter 19

Figure 13: The Input Select Page 22

Figure 14: Edit Input Buttons 23

Figure 15: The Device Settings Page 24

Figure 16: The Device Settings Page –Static IP Confirmation. 24

Figure 17: The Device Settings Page –Uploading the New Firmware File 25

Figure 18: The Device Settings Page –Uploading the New Firmware File 25

Figure 19: The Device Settings Page –New Firmware Updated 26

Figure 20: The Output Settings Page 26

Figure 21: The HDCP Page 27

Figure 22: The EDID Page 28

Figure 23: The EDID Page –Copying the Default 29

Figure 24: The EDID Page –The Copy EDID Results 30

Figure 25: The Audio Settings Page 31

Figure 26: The Advanced Page 32

Figure 27: The About Page 32

VP-444 –Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront video, audio, presentation, and broadcasting professionals

on a daily basis. In recent years, we have redesigned and upgraded most of our

line, making the best even better!

Our 1,000-plus different models now appear in 14 groups that are clearly defined by

function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11:

Sierra Video Products; GROUP 12: Digital Signage; GROUP 13: Audio; and

GROUP 14: Collaboration.

Congratulations on purchasing your Kramer VP-444 Presentation Switcher/Scaler.

This product, which incorporates HDMI™ technology, is ideal for:

Projection systems in conference rooms, boardrooms, hotels and churches

Home theater up-scaling

VP-444 - Getting Started

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Go to http://www.kramerelectronics.com/support/product_downloads.asp

to check for up-to-date user manuals, application programs, and to check

if firmware upgrades are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

Use only good quality connection cables (we recommend Kramer high-

performance, high-resolution cables) to avoid interference, deterioration in

signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

Do not secure the cables in tight bundles or roll the slack into tight coils

Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

Position your Kramer VP-444 away from moisture, excessive sunlight and

dust

This equipment is to be used only inside a building. It may only be

connected to other equipment that is installed inside a building.

VP-444 –Getting Started

2.2 Safety Instructions

Caution:

There are no operator serviceable parts inside the unit

Warning:

Use only the power cord that is supplied with the unit

Warning:

Do not open the unit. High voltages can cause

electrical shock! Servicing by qualified personnel only

Warning:

Disconnect the power and unplug the unit from the wall

before installing

2.3 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims

to reduce the amount of WEEE sent for disposal to landfill or incineration by

requiring it to be collected and recycled. To comply with the WEEE Directive,

Kramer Electronics has made arrangements with the European Advanced

Recycling Network (EARN) and will cover any costs of treatment, recycling and

recovery of waste Kramer Electronics branded equipment on arrival at the EARN

facility. For details of Kramer’s recycling arrangements in your particular country go

to our recycling pages at http://www.kramerelectronics.com/support/recycling/.

VP-444 - Overview

3 Overview

The VP-444 is a high−performance presentation scaler/switcher for HDMI and

computer graphics signals. The unit scales the video, embeds the audio, and

outputs the signal to two HDMI (with embedded audio) outputs (with S/PDIF and

balanced stereo audio) simultaneously.

The VP-444 features:

PixPerfect™scaling technology –Kramer’s precision pixel mapping and

high quality scaling technology. High-quality 3:2 and 2:2 pull down de-

interlacing and full up and down scaling of all video input signals

HDTV compatibility

HDCP compliance - The HDCP (High Definition Content Protection) license

agreement allows copy−protected data on the HDMI input to pass only to the

HDMI outputs

12 video inputs - 10 HDMI on HDMI connectors, 2 computer graphics video

on 15−pin HD connectors

Two HDMI scaled outputs

Up to UXGA/1080p output resolutions

Two microphone inputs that can be used by mixing, switching or talk-over

Companion AFV (Audio-Follow-Video) - stereo audio for every input (on

terminal blocks)

12 unbalanced stereo inputs on terminal blocks as well as embedded audio

for the HDMI inputs, each with individual level controls

Audio outputs –one S/PDIF on an RCA connector, one balanced stereo

audio on a terminal block as well as embedded audio on the HDMI outputs

Multiple aspect ratio selections - full, best fit, over scan, under scan, letter

box and pan scan

Powerful audio features via DSP technology including audio equalization,

mixing, delay and so on

Built-in ProcAmp - color, hue, sharpness, noise, contrast and brightness

VP-444 –Overview

Front panel control - audio mute and freeze frame

Front panel lockout

Non-volatile memory - saves final settings

Control your VP-444:

Directly, via the front panel push buttons

By RS-232 serial commands transmitted by a touch screen system, PC, or

other serial controller

Remotely, from the infrared remote control transmitter with OSD (on-screen

display)

Via the Ethernet with built-in Web pages

The VP-444 is housed in a 19” 1U rack mountable enclosure, with rack “ears”

included, and is fed from a 100-240 VAC universal switching power supply.

3.1 Defining the VP-444 Presentation Switcher/Scaler

This section defines the VP-444.
