Kramer WP-5VH2 Manuel utilisateur

PDF provided by Conference Room AV

Kramer WP-5VH2 HDMI and VGA w/ Audio Auto Switcher Wall Plate w/ Ethernet, HDBaseT Out

KRAMER ELECTRONICS LTD.

PRELIMINARY

USER MANUAL

MODEL:

WP-5VH2

Wall Plate

P/N: 2900-300386 Rev 1

WP-5VH2 – Contents

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

2.2 Safety Instructions 2

2.3 Shielded Twisted Pair/Unshielded Twisted Pair 3

2.4 Recycling Kramer Products 3

3Overview 4

3.1 About HDBaseT™ Technology 5

4Defining the WP-5VH2 Wall Plate 6

5Connecting the WP-5VH2 10

5.1 Connecting the Remote Control Switches 11

6Principles of Operation 13

6.1 Input Selection 13

6.2 Signal Loss and Unplugged Cable Timeouts 13

6.3 Audio Signal Control 14

6.4 VGA Phase Shift 14

7Operating the WP-5VH2 15

7.1 Selecting an Input Manually 15

7.2 Locking the EDID 15

7.3 Resetting the WP-5VH2 15

7.4 Analog Audio Output Volume Control 15

8Configuring the WP-5VH2 17

8.1 Setting the Configuration DIP-switch 17

8.2 Video Switching Timeouts 18

9Operating the WP-5VH2 Remotely Using the Embedded Web Pages 19

9.1 Browsing the WP-5VH2 Web Pages 19

9.2 The Switching Page 23

9.3 The Device Settings Page 23

9.4 The Video and Audio Settings Page 26

9.5 The Authentication Page 27

9.6 The EDID Page 28

9.7 The About Us Page 30

10 Wiring the Twisted Pair RJ-45 Connectors 31

11 Technical Specifications 32

11.1 Default IP Parameters 33

11.2 Default Logon Credentials 33

11.3 Supported Resolutions 33

12 Default EDID 35

12.1 HDMI 35

12.2 PC-UXGA 37

13 Protocol 3000 39

13.1 Kramer Protocol 3000 Syntax 39

13.2 Kramer Protocol 3000 Commands 42

WP-5VH2 - Introduction

Figures

Figure 1: WP-5VH2 and WP-5VH2E Wall Plate Front Panels 6

Figure 2: WP-5VH2 and WP-5VH2E Wall Plate Rear Panels 8

Figure 3: Connecting the WP-5VH2 Wall Plate 10

Figure 4: Remote Switches Terminal Block 11

Figure 5: The Configuration DIP-switch 17

Figure 6: Entering Logon Credentials 19

Figure 7: The Default Page 20

Figure 8: The Main Switching Page 21

Figure 9: The Switching Page 23

Figure 10: The Device Settings Page 24

Figure 11: The Video and Audio Settings Page 26

Figure 12: The Authentication Page 27

Figure 13: The EDID Page 28

Figure 14: The About Us Page 30

Figure 15: TP Pinout Wiring 31

WP-5VH2 - Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront video, audio, presentation, and broadcasting professionals

on a daily basis. In recent years, we have redesigned and upgraded most of our

line, making the best even better!

Our 1,000-plus different models now appear in 14 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:

Sierra Video Products; GROUP 12: Digital Signage; and GROUP 13: Audio, and

GROUP 14: Collaboration.

Thank you for purchasing the Kramer WP-5VH2 Wall Plate which is ideal for:

 Display systems requiring simple, automatic input selection

 Multimedia and presentation source selection

 Video distribution in hotel rooms and schools

Note: All mentions of the WP-5VH2 in this User Manual refer also to the

WP-5VH2E European version unless otherwise indicated.

WP-5VH2 - Getting Started

2 Getting Started

We recommend that you:

 Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

 Review the contents of this user manual

Go to http://www.kramerelectronics.com/support/product_downloads.asp

to check for up-to-date user manuals, application programs, and to check if

firmware upgrades are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

 Use only good quality connection cables (we recommend Kramer high-

resolution, high-quality cables) to avoid interference, deterioration in signal

quality due to poor matching, and elevated noise levels (often associated

with low quality cables)

 Do not secure the cables in tight bundles or roll the slack into tight coils

 Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

 Position your Kramer WP-5VH2 away from moisture, excessive sunlight and

dust

This equipment is to be used only inside a building. It may only be

connected to other equipment that is installed inside a building.

2.2 Safety Instructions

Caution:

There are no operator serviceable parts inside the unit

Warning:

Use only the Kramer Electronics input power wall

adapter that is provided with the unit

Warning:

Disconnect the power and unplug the unit from the wall

before installing

WP-5VH2 - Getting Started

2.3 Shielded Twisted Pair/Unshielded Twisted Pair

Kramer engineers have developed special twisted pair cables to best match our

digital twisted pair products; the Kramer BC-HDKat6a (CAT 6 23 AWG) HDBaseT

certified, and the Kramer BC-DGKat7a23 (CAT 7a 23 AWG) cables. These

specially built cables significantly outperform regular CAT 6 and CAT 7a cables.

2.4 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC

aims to reduce the amount of WEEE sent for disposal to landfill or incineration by

requiring it to be collected and recycled. To comply with the WEEE Directive,

Kramer Electronics has made arrangements with the European Advanced

Recycling Network (EARN) and will cover any costs of treatment, recycling and

recovery of waste Kramer Electronics branded equipment on arrival at the EARN

facility. For details of Kramer’s recycling arrangements in your particular country

go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.

WP-5VH2 - Overview

3 Overview

The WP-5VH2 accepts an HDMI and PC graphics video input, an Ethernet signal,

serial data, and an unbalanced stereo audio input (which is embedded into the

output signal), and transmits the signal via HDBaseT (Twisted Pair) cable to a

compatible receiver (for example, the TP-588D or the TP-580RXR). The

WP-5VH2 is a PoE (Power over Ethernet) receiver and can be powered by a

compatible PoE provider, (for example, the PSE-1).

The WP-5VH2 provides a range of up to 130m (427ft) in normal mode for

1080p@60Hz @36bpp. When using an extended range receiver and

BC−HDKat6a cables, the range is up to 180m (590ft) for 1080p@60Hz @24bpp.

To use the WP-5VH2 in extended range mode you must edit the EDID.

For optimum range and performance, use Kramer's BC−HDKat6a and

BC−DGKat7a23 shielded twisted pair (STP) cables. Note that the

transmission range depends on the signal resolution, graphics card and

display used. The distance using non-Kramer CAT 5, CAT 6, and CAT 7

cables may not reach these ranges.

In particular the WP-5VH2 features:

 Support for 4K, (a data rate of up to 10.2Gbps)

 Automatic input selection based on priority selection or last connected input

 Manual input selection

 Automatic live input detection based on video clock presence

 Automatic analog audio detection and embedding

 Power over Ethernet passes electrical power along with data on Ethernet

cabling. This allows a single cable to provide both data connection and

electrical power to compatible devices

 Control via Kramer Protocol 3000 and embedded Web pages over a LAN

 HDTV support

 HDMI with Deep Color, x.v.Color™ and 3D
