Kramer VP-772 Manuel utilisateur

USER MANUAL

MODEL:

VP-772

Presentation Matrix Switcher / Dual Scaler

P/N: 2900-300295 Rev 2 www.kramerAV.com

VP-772 –Contents

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

2.2 Safety Instructions 2

2.3 Recycling Kramer Products 3

3Overview 4

3.1 HDCP Compliance for HDMI inputs 6

3.2 Defining the VP-772 Presentation Matrix Switcher / Dual Scaler 6

4Installing in a Rack 9

5Connecting the VP-772 10

5.1 Wiring the RJ-45 Connectors 12

5.2 Connecting the Balanced Stereo Audio Input and Outputs 13

6The OSD Menu 14

6.1 OSD Menu Operation Example 14

6.2 The Input Menu 16

6.3 The Layout Menu 17

6.4 The Program / Preview Menus 19

6.5 The Misc Menu 22

7The Layout 24

7.1 The Transition Mode 24

7.2 The Overlay Mode 26

8Controlling the VP-772 29

8.1 Controlling via the Front Panel Buttons 29

8.2 Controlling via the OSD Menu 34

8.3 Controlling via the Infrared Remote Control Transmitter 39

9Firmware Upgrade 41

9.1 The Firmware Upgrade Process 41

9.2 Rollback 43

10 Technical Specifications 44

10.1 Default Communication Parameters 45

10.2 Input Resolutions 46

10.3 Output Resolutions 47

11 The VP-772 RS-232 Communication Protocol 48

11.1 Using the Communication Protocol 48

11.2 Communication Protocol: Mimicking OSD 48

11.3 Protocol Table: Mimicking Remote and Front Panel Buttons 56

11.4 The Protocol 3000 Common Operation Commands 57

VP-772 - Contents

Figures

Figure 1: VP-772 Presentation Matrix Switcher / Dual Scaler Front Panel 7

Figure 2: VP-772 Presentation Matrix Switcher / Dual Scaler Rear Panel 8

Figure 3: Connecting the VP-772 Presentation Matrix Switcher / Dual Scaler 11

Figure 4: TP PINOUT 12

Figure 5: Balanced Stereo Audio Connection 13

Figure 6: Unbalanced Stereo Audio Output Connection 13

Figure 7: Balanced Stereo Audio Input Connection 13

Figure 8: Unbalanced Stereo Audio Input Connection 13

Figure 9: OSD Menu Example 14

Figure 10: Input Menu 16

Figure 11: Layout Menu 17

Figure 12: Program/Preview Menus 19

Figure 13: Misc Menu 22

Figure 14: VGA superimposed over HDMI 27

Figure 15: RS-232 Connection 34

Figure 16: Local Area Connection Properties Window 35

Figure 17: Internet Protocol Version 4 Properties Window 36

Figure 18: Internet Protocol Version 6 Properties Window 37

Figure 19: Internet Protocol Properties Window 38

Figure 20: Infrared Remote Control Transmitter 39

Figure 21: Firmware Upgrade –list of Files to Upgrade 42

Figure 22: Firmware Upgrade –Upgrade Process 42

Figure 23: Firmware Upgrade –Upgrade Complete 42

Figure 24: Firmware Upgrade –list of Files to Rollback 43

VP-772 –Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront video, audio, presentation, and broadcasting professionals

on a daily basis. In recent years, we have redesigned and upgraded most of our

line, making the best even better!

Our 1,000-plus different models now appear in 14 groups that are clearly defined by

function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11:

Sierra Video Products; GROUP 12: Digital Signage; GROUP 13: Audio; and

GROUP 14: Collaboration.

Congratulations on purchasing your Kramer VP-772 Presentation Matrix Switcher /

Dual Scaler. This product, which incorporates HDMI™ technology, is ideal for:

Live events

Presentation applications that require a preview option

Projection systems in conference rooms, boardrooms, auditoriums, hotels

and churches, production studios, rental and staging

Any application where high quality conversion and switching of multiple and

different video signals to graphical data signals is required for projection

purposes

Presentations requiring seamless switching between inputs, using special

effects, cuts and fades

VP-772 - Getting Started

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Go to http://www.kramerav.com/downloads/VP-772 to check for up-to-date

user manuals, application programs, and to check if firmware upgrades are

available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

Use only good quality connection cables (we recommend Kramer high-

performance, high-resolution cables) to avoid interference, deterioration in

signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

Do not secure the cables in tight bundles or roll the slack into tight coils

Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

Position your Kramer VP-772 away from moisture, excessive sunlight and

dust

This equipment is to be used only inside a building. It may only be

connected to other equipment that is installed inside a building.

2.2 Safety Instructions

Caution:

There are no operator serviceable parts inside the unit

Warning:

Use only the power cord that is supplied with the unit

Warning:

Do not open the unit. High voltages can cause electrical

shock! Servicing by qualified personnel only

Warning:

Disconnect the power and unplug the unit from the wall

before installing

VP-772 –Getting Started

2.3 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims

to reduce the amount of WEEE sent for disposal to landfill or incineration by

requiring it to be collected and recycled. To comply with the WEEE Directive,

Kramer Electronics has made arrangements with the European Advanced

Recycling Network (EARN) and will cover any costs of treatment, recycling and

recovery of waste Kramer Electronics branded equipment on arrival at the EARN

facility. For details of Kramer’s recycling arrangements in your particular country go

to our recycling pages at http://www.kramerelectronics.com/support/recycling/.

VP-772 - Overview

3 Overview

The Kramer VP-772 is an eight input high quality dual scaler with special effect

transitions for the Rental and Staging and the Live Events market, and for other

applications where a dual scaler is needed. It features DVI-U inputs (including

analog, DVI and HDMI support) and stereo balanced audio signals. The VP-772

can also be configured as 4K single output scaler. The VP-772 scales and

processes the selected video and audio inputs, and outputs to 2 independent DVI-I

outputs (Program and Preview) together with two balanced stereo audio outputs.

The VP-772 features:

Pix Perfect™ Scaling Technology - Kramer’s extremely high performance,

State-of-the-Art scaling technology with extensive high-quality pull-down and

de-interlacing algorithms, and full up-and down-scaling of the video inputs

K-IIT XL™ Picture-in-Picture Image Insertion Technology for ultra-stable

picture−in−picture, picture−and−picture and split screen capability

Seamless video switching with cuts or built-in special effect transitions,

including horizontal, vertical, diagonal, circle, and chessboard wipes, cross-

fading, and more

Dual scalers—for “live” seamless transitions from one source to another—

with two independent outputs: a PREVIEW OUTPUT and a PROGRAM

OUTPUT. The PREVIEW output—including an OSD menu for making

adjustments—can be used to determine how the scaled output will look

before being displayed live during a presentation

Features 8 PREVIEW input buttons for switching a selected input to the

PREVIEW output and 8 PROGRAM input buttons for switching a selected

input to the PROGRAM output

Output Resolutions –UHD (3840x2160) resolution (in the Single Window

mode) as well as HDTV and computer graphics resolutions with selectable

refresh rates

Selectable HDMI, VGA, YUV or CV on each DVI-U input and VGA or HDMI

on each DVI-I output

Audio-Follow-Video (AFV) and breakaway options

VP-772 –Overview

Advanced deinterlacing functions - including 3D comb filtering, film mode,

diagonal correction and motion detection

Multiple Aspect Ratio Selections

Built-in Proc-Amp with enhanced functions such as color correction, gamma,

dither and noise reduction

Embedded HDMI audio support as well as eight balanced stereo audio

inputs and two balanced stereo outputs

Input and output audio level adjustment and audio DSP functions

HDCP Compliance

In addition, the VP-772:

Features luma- and chroma-keying

Includes built-in test patterns for screen setup and alignment

Analyses the connected output’s EDID for optimal scaling

Provides input and output color space control

Supports HDMI deep color for outputs

Comes with an On-Screen Display (OSD) for easy setup and adjustment

Has a non-volatile memory that retains the settings

Supports firmware upgrade via USB (via memory stick)

Control your VP-772:

Directly, via the front panel push buttons

Via the Ethernet

By RS-485 (allowing future optional T-bar control)

Remotely, from the infrared remote control transmitter

By RS-232 serial commands transmitted by a touch screen system, PC, or

other serial controller

The VP-772 is housed in a 19” 1U rack mountable enclosure, with handles and rack

“ears” included, and is fed from a 100-240 VAC universal switching power supply.
