USER MANUAL

Model:

VS-5x5

5x5 Video Audio Matrix Switcher

Contents

Introduction 1

Getting Started 1

Overview 2

Your VS-5x5 5x5 Video Audio Matrix Switcher 2

Connecting the VS-5x5 6

5.1

Connecting the VS-5x5 Rear Panel 6

5.2

Controlling via RS-232 (for example, using a PC) 7

5.3

Controlling via RS-485 8

5.4

Connecting the Balanced/Unbalanced Stereo Audio Input/Output 9

5.5

Setting the Dipswitches 10

5.5.1

Setting the MACHINE # 10

Controlling via RS-232 and RS-485 11

Operating the VS-5x5 13

7.1

Displaying Unit Characteristics 13

7.2

Choosing the Audio-Follow-Video or Breakaway Option 13

7.2.1

Setting the Audio-Follow-Video Option 14

7.2.2

Setting the Breakaway Option 14

7.3

Switching OUT-IN Combinations 14

7.4

Confirming Settings 14

7.4.1

Toggling between the AT ONCE and CONFIRM Modes 15

7.4.2

Confirming a Switching Action 15

7.5

Storing/Recalling Input/Output Configurations 16

7.5.1

Storing an Input/Output Configuration 16

7.5.2

Recalling an Input/Output Configuration 16

7.5.3

Deleting an Input/Output Configuration 17

7.6

Locking the Front Panel 17

7.7

Adjusting the Audio Gain Control 17

Flash Memory Upgrade 18

8.1

Downloading from the Internet 18

8.2

Connecting the PC to the RS-232 Port 18

8.3

Upgrading Firmware 19

Technical Specifications 23

Table of Hex Codes for Serial Communication 24

Tables of Hex Codes for Audio Input/Output Gain Control 24

11.1

Tables of Hex Codes for Audio Input Gain Control 24

11.2

Tables of Hex Codes for Audio Output Gain Control 26

Kramer Protocol 2000 28

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Contents

Figures

Figure 1: VS-5x5 5x5 Video Audio Matrix Switcher 3

Figure 2: VS-5x5 5x5 Video Audio Matrix Switcher Underside View 5

Figure 3: Connecting the VS-5x5 5x5 Video Audio Matrix Switcher 7

Figure 4: Connecting a PC without using a Null-modem Adapter 7

Figure 5: Controlling via RS-485 (for example, using an RC-3000) 8

Figure 6: Connecting the Balanced Stereo Audio Input/Output 9

Figure 7: Connecting the Unbalanced Stereo Audio Input 9

Figure 8: Connecting the Unbalanced Stereo Audio Output 9

Figure 9: Dipswitch Settings 10

Figure 10: Cascading Individual Units in a Control Configuration via RS-232 and RS-485 12

Figure 11: VS-5x5 Unit Characteristics 13

Figure 12: Storing and Recalling using the Input / Output Buttons 16

Figure 13: Splash Screen 19

Figure 14: Atmel – Flip Window 19

Figure 15: Device Selection Window 20

Figure 16: Device Selection window 20

Figure 17: Loading the Hex 21

Figure 18: RS-232 Window 21

Figure 19: Atmel – Flip Window (Connected) 22

Figure 20: Atmel – Flip Window (Operation Completed) 22

Tables

Table 1: Front Panel VS-5x5 5x5 Video Audio Matrix Switcher Features 4

Table 2: Rear Panel VS-5x5 5x5 Video Audio Matrix Switcher Features 5

Table 3: Dipswitch Settings 10

Table 4: Machine # Dipswitch Settings 10

Table 5: Technical Specifications of the VS-5x5 5x5 Video Audio Matrix Switcher 23

Table 6: VS-55 Hex Codes for Switching via RS-232/RS-485 24

Table 7: VS-55 Hex Codes for Audio Input Gain Control 25

Table 8: VS-55 Hex Codes for Audio Output Gain Control 27

Table 9: Protocol Definitions 28

Table 10: Instruction Codes for Protocol 2000 29

Introduction

1 Introduction

Welcome to Kramer Electronics (since 1981): a world of unique, creative and

affordable solutions to the infinite range of problems that confront the video,

audio and presentation professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better! Our

350-plus different models now appear in 8 Groups

, which are clearly defined

by function.

Congratulations on purchasing your VS-5x5 5x5 Video Audio Matrix

Switcher, which is ideal for the following typical applications:

 Professional display systems requiring true 5x5 matrix operation

 Multimedia and presentation source and acceptor selection, and remote

monitoring of computer activity in schools and businesses

The package includes the following items:

 VS-5x5 5x5 Video Audio Matrix Switcher

 Power cord

 Null-modem adapter

 Windows®-based Kramer control software

 Infra-red remote control transmitter (including the required battery and a

separate user manual

)

 This user manual

2 Getting Started

We recommend that you:

 Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

 Review the contents of this user manual

 Use Kramer high performance high resolution cables

1 GROUP 1: Distribution Amplifiers; GROUP 2: Video and Audio Switchers, Matrix Switchers and Controllers; GROUP 3:

Video, Audio, VGA/XGA Processors; GROUP 4: Interfaces and Sync Processors; GROUP 5: Twisted Pair Interfaces;

GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors

2 Downloadable from our Web

site at http://www.kramerelectronics.com

3 Download up-to-date Kramer user manuals from our Web

site at http://www.kramerelectronics.com

4 The complete list of Kramer cables is on our Web

site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Overview

3 Overview

The VS-5x5 is a true 5x5 matrix switcher for composite video signals and

balanced stereo audio signals. The high quality VS-5x5 lets you

simultaneously route any or all of the 5 inputs to any or all of the 5 outputs.

The VS-5x5 5x5 Video Audio Matrix Switcher includes:

 Video bandwidth of 70MHz that ensures transparent performance

 Easy-to-connect detachable terminal block connectors for the audio

signals

 Glitch-free transitions, which are produced when sources share a common

reference sync, as switching occurs during the vertical interval

. Any input or

special external sync input may be selected as the vertical interval source

 DC coupled inputs and outputs

 Audio-follow-video and breakaway options

 Storing and recalling setups

 “Take” button for precise switch control

 “Lock” button to prevent tampering with the front panel

 Gain control for all inputs and all outputs

 The ability to control via the front panel buttons, via the Infra-red remote

control transmitter, and remotely by RS-485 or RS-232 serial commands

transmitted by a touch screen system, PC, or other serial controller

To achieve the best performance:

 Connect only good quality connection cables, thus avoiding interference,

deterioration in signal quality due to poor matching, and elevated noise

levels (often associated with low quality cables)

 Avoid interference from neighboring electrical appliances that may

adversely influence signal quality and position your Kramer VS-5



5 away

from moisture, excessive sunlight and dust

4 Your VS-5x5 5x5 Video Audio Matrix Switcher

Figure 1, Table 1 and Table 2 define the VS-5x5 5x5 Video Audio Matrix

Switcher:

1 When one video signal replaces another video signal, the switching process causes a random interruption in the first video

signal (in the middle of a frame) and a random entrance into the second video signal (also in the middle of a frame). The

result is a visible jump in the edited tape. This deteriorates when the tape is copied, and the disturbance on playback is more

serious. Avoid this by switching at a very specific point during the vertical interval, allowing smooth replacement of a whole

frame by a second whole frame as long as the video sources are Genlocked to each other

Your VS-5x5 5x5 Video Audio Matrix Switcher

Figure 1: VS-5x5 5x5 Video Audio Matrix Switcher

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your VS-5x5 5x5 Video Audio Matrix Switcher

Table 1: Front Panel VS-5x5 5x5 Video Audio Matrix Switcher Features

# Feature Function

1 IR Receiver The red LED is illuminated when receiving signals from the Infra-red remote

control transmitter

2 Power Switch Illuminated switch for turning the unit ON or OFF

3 OUT Buttons Select the output to which the input is switched

4 IN Buttons Select the input to switch to the output

5 ALL Button Pressing ALL followed by an INPUT button, connects that input to all outputs

6 OFF Button An OFF-OUT combination disconnects that output from the inputs; an

OFF-ALL combination disconnects all the outputs

7 7-segment Display Displays the selected audio

or video

input switched to the output (marked

above each input)

8 VIDEO Button When pressed

actions relate to video

9 AFV Button When pressed

actions relate to video and audio channels. Audio channels

follow the video channels

AUDIO Button When pressed

actions relate to audio

STO (STORE) Button

Pressing STO followed by an output button stores the current setting

RCL (RECALL)

Button

Pressing the RCL button and the corresponding OUTPUT key recalls a

setup from the non-volatile memory. The stored status blinks. Pressing a

different OUTPUT button lets you view

another setup. After making your

choice, pressing the RCL button again implements the new status

TAKE Button Pressing TAKE toggles the mode between the CONFIRM mode

and the

AT ONCE mode (user confirmation per action is unnecessary)

LOCK Button Disengages the front panel switches

1 For example, press ALL and then Input button # 2 to connect input # 2 to all the outputs

2 When the Audio button illuminates, that is, when the audio breakaway mode is selected

3 When the Video button illuminates, that is, when the video breakaway mode is selected

4 Also displays the number of IN and OUT ports, the firmware version number, and the MACHINE #. Refer to section 7.1

5 The VIDEO button is illuminated when the video breakaway mode is selected

6 The AFV button is illuminated when the AFV mode is selected

7 The AUDIO button is illuminated when the audio breakaway mode is selected

8 For example, press STO and then the Output button # 3 to store in Setup # 3

9 Only view, nothing is implemented at this stage

10 When in Confirm mode, the TAKE button illuminates

Your VS-5x5 5x5 Video Audio Matrix Switcher

Table 2: Rear Panel VS-5x5 5x5 Video Audio Matrix Switcher Features

# Feature Function

1 LOOP BNC Connector For looping the inputs

2 EXT. SYNC BNC

Connector Connects to the external SYNC source

3 Composite BNC OUT

Connectors Connects to the composite video acceptors (from 1 to 5)

VIDEO

Composite BNC IN

Connectors Connects to the composite video sources (from 1 to 5)

5 INPUTS Terminal Block

Connectors Connect to the balanced stereo audio sources (from 1 to 5)

AUDIO

OUTPUTS Terminal

Block Connectors Connect to the balanced stereo audio acceptors (from 1 to 5)

7 RS-232 DB 9F Port Connects to the PC or the Remote Controller

8 RS-485 Terminal Block Port Pin G is for Ground connection; Pins B (-) and A (+) are for RS 485

9 FLASH PROG Button Push in

for “Program” to upgrade to the latest Kramer firmware

(see section 8), or release for Normal (the factory default)

Dipswitches Dipswitches for setup of the unit (1, 2, 3 and 4 are for setting the

Machine #; 5 is for the Vertical Interval Source; 8 is for RS-485

Termination)

Power Connector with Fuse AC connector enabling power supply to the unit

Figure 2 illustrates the VS-5x5 underside, including the Flash Program Reset

button (see section 8.2).

ENLARGED VIEW

Figure 2: VS-5x5 5x5 Video Audio Matrix Switcher Underside View

1 Using a screwdriver if required

2 Note that the FLASH PROG “Reset” button is located on the underside of the unit. Push in for “Reset”(Figure 2), or release

for Normal (see section 8)

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Connecting the VS-5x5

5 Connecting the VS-5x5

This section describes how to connect the VS-5x5. In particular, how to:

 Connect the VS-5x5 rear panel (see section 5.1)

 Control via RS-232, for example, using a PC (see section 5.2)

 Control via RS-485 (see section 5.3)

 Connect the audio inputs/outputs (see section 5.4)

 Set the dipswitches (see section 5.5)

5.1 Connecting the VS-5x5 Rear Panel

To connect the VS-5x5, do the following

1. Connect up to 5 composite video sources

to the 5 BNC input

connectors, and connect

up to 5 balanced stereo audio sources

to the

“AUDIO INPUTS” terminal block connectors.

2. Connect

the 5 composite video output connectors to up to 5 composite

video acceptors

and connect the corresponding “AUDIO OUTPUTS”

terminal block connectors to the balanced stereo audio acceptors

3. Set the dipswitches (see section 5.5).

4. Connect a PC and/or controller (if required) to the RS-232 port (see

section 5.2) and/or RS-485 port (see section 5.3).

5. Connect

the power cord

1 Switch OFF the power on each device before connecting it to your VS-5x5. After connecting your VS-5x5, switch on its

power and then switch on the power on each device. DO NOT push in the rear panel Flash Program “Program” button (item 9

in Table 2) and DO NOT push in the underside Flash Program “Reset” button. These are only used for upgrade to the latest

Kramer firmware (see section 8)

2 For example, VCR machines

3 See section 5.4 for a description of how to connect a balanced/unbalanced stereo audio input/output

4 Not illustrated in Figure 3

5 When less than five outputs are required, connect only those outputs of the VS-5x5 that are required, and leave the other

outputs unconnected

6 We recommend that you use only the power cord that is supplied with this machine

Connecting the VS-5x5

Figure 3: Connecting the VS-5x5 5x5 Video Audio Matrix Switcher

5.2 Controlling via RS-232 (for example, using a PC)

To connect a PC to the VS-5x5 unit, using the Null-modem adapter provided

with the machine (recommended):

 Connect the RS-232 DB9 rear panel port on the Master VS-5x5 unit to the

Null-modem adapter and connect the Null-modem adapter with a 9 wire

flat cable to the RS-232 DB9 port on your PC

To connect a PC to the VS-5x5 unit, without using a Null-modem adapter:

 Connect the RS-232 DB9 port on your PC to the RS-232 DB9 rear panel

port on the Master VS-5x5 unit, as Figure 4 illustrates

(depending on

whether the PC has a 9-pin or 25-pin connector)

Figure 4: Connecting a PC without using a Null-modem Adapter

Autres manuels pour VS-5x5

Table des matières

Autres manuels Kramer Commutateur matriciel

Kramer

Kramer VS-88UT Manuel utilisateur

Kramer

Kramer VS-88A Manuel utilisateur

Kramer

Kramer MTX3-16-M Manuel utilisateur

Kramer

Kramer VS-4216 Manuel utilisateur

Kramer

Kramer VS-42H Manuel utilisateur

Kramer

Kramer VS-44H2A Manuel utilisateur

Kramer

Kramer VS-42HC Manuel utilisateur

Kramer

Kramer 6464V5XL Manuel utilisateur

Kramer

Kramer VS-42HN Manuel utilisateur

Kramer

Kramer VS-61YC Manuel utilisateur

Kramer

Kramer VS-402XL Manuel utilisateur

Kramer

Kramer VS-88H2 Manuel utilisateur

Kramer

Kramer VS-44H2A Manuel utilisateur

Kramer

Kramer VS-1616D Manuel utilisateur

Kramer

Kramer VS-3232A Manuel utilisateur

Kramer

Kramer MTX3-16-M Manuel utilisateur

Kramer

Kramer VS-2516 Manuel utilisateur

Kramer

Kramer VS-88DTP Manuel utilisateur

Kramer

Kramer VP-4x4K Manuel utilisateur

Kramer

Kramer 3216HDS Manuel utilisateur

Kramer

Kramer XL 1616V4S Manuel utilisateur

Kramer

Kramer VS-44HDXI Manuel utilisateur

Kramer

Kramer Sierra Video 6448V5Sxl Manuel utilisateur

Kramer

Kramer VS-44HDCP Manuel utilisateur

Manuels Commutateur matriciel populaires d'autres marques

Broadcast Tools

Broadcast Tools SS 8.2 Manuel utilisateur

Altimium

Altimium MATF32 Manuel utilisateur

ALFAtron

ALFAtron ALF-MUK44N Manuel utilisateur

Monoprice

Monoprice Blackbird 15377 Manuel utilisateur

PTN

PTN FMX12 Manuel utilisateur

CYP

CYP nT15GX01 Manuel utilisateur

TESmart

TESmart HMA0402A40 Manuel utilisateur

Octava

Octava HD4XSTPMX Manuel utilisateur

Intelix

Intelix FLX-88 Mode d'emploi

Roland

Roland XS-1HD Manuel utilisateur

Atlona

Atlona AT-HDMI-22M Manuel utilisateur

Link

Link HD8X8 Manuel utilisateur

AMX

AMX AVS-OP-2020-117 Instructions et recettes

Lindy

Lindy 38042 Manuel utilisateur

Extron electronics

Extron electronics MTPX Plus Series Manuel utilisateur

Key Digital

Key Digital Champion KD-16x16CS Manuel utilisateur

Shinybow USA

Shinybow USA SB-8811 Manuel utilisateur

Optimus

Optimus Compact Manuel utilisateur
