Kodak LUMA 350 Manuel utilisateur
Quick Start Guide
Portable Smart Projector
KODAK LUMA 350
EN
INTRODUCTION
PRODUCT OVERVIEW
USING YOUR PHONE
CHARGING THE PROJECTOR
POWERING THE PROJECTOR ON/OFF
ADJUSTING THE FOCUS
ADJUSTING VOLUME
CONNECTING TO AN EXTERNAL DEVICE
CONNECTING TO A WIRELESS NETWORK
SCREEN MIRRORING (ANDROID/WINDOWS - MIRACAST®)
SCREEN MIRRORING (iOS)
CUSTOMER SERVICE CONTACT INFORMATION
FR
5
5-7
8
8
9
9
9
10-11
11
12-13
13
14
15
15-17
18
19
19
19-20
20
20-21
21
CONTENTS
INTRODUCTION
VUE D'ENSEMBLE DU PRODUIT
À L'AIDE DE VOTRE TÉLÉPHONE
CHARGER LE PROJECTEUR
ALLUMER/ÉTEINDRE LE PROJECTEUR
RÉGLAGE DE LA MISE AU POINT
RÉGLAGE DU VOLUME
CONNEXION À UN APPAREIL EXTERNE
CONNEXION À UN RÉSEAU SANS FIL
INTRODUCCIÓN
INFORMACIÓN GENERAL DEL PRODUCTO
USAR SU TELÉFONO
CARGAR EL PROYECTOR
ENCENDER/APAGAR EL PROYECTOR
AJUSTAR EL ENFOQUE
AJUSTAR EL VOLUMEN
INTRODUZIONE
PANORAMICA DEL PRODOTTO
UTILIZZO DEL TELEFONO
RICARICA DEL PROIETTORE
ACCENSIONE / SPEGNIMENTO DEL PROIETTORE
REGOLAZIONE DELLA MESSA A FUOCO
REGOLAZIONE DEL VOLUME
COLLEGAMENTO A UN DISPOSITIVO ESTERNO
CONNESSIONE A UNA RETE WIRELESS
MIRRORING DELLO SCHERMO (ANDROID / WINDOWS - MIRACAST®)
MIRRORING DELLO SCHERMO(iOS)
INFORMAZIONI DI CONTATTO PER IL SERVIZIO CLIENTI
FR
22-23
23-24
24
25
25-27
28
29
29
29-30
30
30-31
31
32-33
33-34
34
IT
35
35-37
38
39
39
39-40
40
ES
MISE EN MIROIR D'ÉCRAN (ANDROID/WINDOWS - MIRACAST®)
MISE EN MIRROIR D'ÉCRAN (iOS)
INFORMATIONS DE CONTACT DU SERVICE À LA CLIENTÈLE
CONECTARSE A UN DISPOSITIVO EXTERNO
CONECTARSE A UNA RED INALÁMBRICA
DUPLICACIÓN DE PANTALLA (ANDROID/WINDOWS - MIRACAST®)
DUPLICACIÓN DE PANTALLA (iOS)
INFORMACIÓN DE CONTACTO DE ATENCIÓN AL CLIENTE
ES
40-41
41
42-43
43-44
44
45
45-47
48
49
49
49-50
50
50-51
51-52
52-53
54
55
DE
EINLEITUNG
PRODUKTÜBERSICHT
NUTZUNG IHRES HANDYS
DEN BEAMER AUFLADEN
DEN BEAMER EIN- UND AUSSCHALTEN
DEN FOKUS EINSTELLEN
DIE LAUTSTÄRKE EINSTELLEN
MIT EINEM EXTERNEN GERÄT VERBINDEN
MIT DRAHTLOSEN NETZWERKEN VERBINDEN
BILDSCHIRMSPIEGELUNG (ANDROID/WINDOWS - MIRACAST®)
BILDSCHIRMSPIEGELUNG (iOS)
KONTAKTINFORMATIONEN FÜR DEN KUNDENDIENST
5 | EN
INTRODUCTION
Thank you for purchasing the KODAK LUMA 350 Portable Smart Projector.
This User Guide is intended to provide you with guidelines to ensure that
operation of this product is safe and does not pose risk to the user. Any use that
does not conform to the guidelines described in this User Guide may void the
limited warranty.
This product is covered by a limited one-year warranty. Coverage is subject to
limits and exclusions. See warranty for details.
Please make sure to view and download the full user guide at
https://www.kodakphotoplus.com/pages/luma-350-projector-support
PRODUCT OVERVIEW
1. Lens
2. Air Outlet
3. Up
4. Confirm/Back
(press more than 2 seconds)
5. Right / Fast Forward
6. Left / Rewind
7. Down
8. Power Indicator
1. Power
2. Speaker
3. Air Inlet
4. Tripod Dock
5. Rating Label
6. Non-slip Mat
7. Focus Wheel
8. Speaker
9. Audio Output (3.5mm)
10. USB Input / Power Out
11. HDMI Input
12. DC Input (15V/1.5A)
EN | 6
7 | EN
Within two (2) minutes of turning on the projector, press and hold both the Vol +
and Vol – keys for approximately three seconds. The remote’s indicator light will
flash quickly and then stop, indicating that the remote has successfully paired
with the projector.
NOTE: While the mouse button is activated, the Volume + or Volume - keys will
function as page up and down.
EN | 8
USING YOUR PHONE
CHARGING THE PROJECTOR
Before using the projector, connect it to the charger and allow it to fully charge.
Always use the original charger that was provided to ensure proper charging.
If the red indicator LED light is flashing, this means that the battery is low.
While the projector is charging, the indicator LED will be a solid red light. Once
charging completes, the indicator LED will change to a solid white light.
For greater ease of use and a more intuitive experience, you can control the
projector with the KODAK LUMA Companion App from the Apple App Store or
the Google Play store.
Once installed, you can use your phone as a remote to navigate through menus,
mirror your screen, easily input login information for apps, and control media
volume. Make sure to try out the reverse screen mirroring feature, which allows
you to view the LUMA interface directly on your phone, and navigate that way!
1. Search for the KODAK LUMA in your phone’s app store.
2. Download the app, and make sure that your phone is connected to
the same Wi-Fi network as the projector.
3. Open the app and follow the instructions to pair it with the
projector to enable remote functionality.
To turn the projector on or o, hold the power button on the side for three (3)
seconds. Once powered on, tap the power button lightly to display the
remaining battery percentage on the screen.
To adjust the device volume during playback, use the + and - buttons on
the remote control. There are also volume controls on the remote app for
your phone.
To adjust the volume without using the remote control, from the home screen,
select Settings > Sounds.
POWERING THE PROJECTOR ON/OFF
If the image on the screen appears fuzzy or unfocused when you turn the
projector on, use the focus wheel on the side to correct the image. Turn the
wheel up or down until the image appears sharp and clear.
NOTE: If a specific image or video remains fuzzy after adjusting the focus
wheel, try pressing and holding the confirm button to return to the main menu.
If the main menu graphics appear clear and the image is still fuzzy, the problem
may be the image or video quality.
ADJUSTING THE FOCUS
9 | EN
ADJUSTING VOLUME
CONNECTING TO AN EXTERNAL DEVICE
To access photos or videos stored on any USB drive, insert the drive into the
corresponding port on the side, then navigate to Source > File Browser. If you’re
using an HDMI compatible device, connect an HDMI cable from the device to
your projector to access and view images and pictures. An HDMI-to-HDMI cable
is included. If your device requires an adapter, you will need to purchase it
separately. For audio devices or headphones, there is an AUDIO OUT jack on
the left side.
NOTE: If you connect an HDMI device as well as a USB drive, the HDMI device
will take precedence over the USB drive and you will need to disconnect it to
access the other connected sources.
EN | 10
