Kodak FLIK X4 Manuel utilisateur
KODAK FLIK X4
HOME PROJECTOR
User Manual
6.3”H | 8.1”W | 2.9”D (15.9 cm | 20.5 cm | 7.5 cm)
Please read all directions before using the product and retain this guide for reference.
CONTENTS
INTRODUCTION
SPECIFICATIONS
BOX CONTENTS
SAFETY PRECAUTIONS
PRODUCT OVERVIEW
REMOTE CONTROL OVERVIEW
USING THE AUDIO OUT JACK
POWERING THE PROJECTOR ON/OFF
USING DIFFERENT MEDIA SOURCES
NAVIGATING YOUR PROJECTOR
MOVIES PAGE
PHOTOS PAGE
MUSIC PAGE
SETTINGS PAGE
INPUT SOURCE MENU
ADJUSTING FOCUS
ADJUSTING VOLUME
ADJUSTING PICTURE SETTINGS
SETTING THE SCREEN ORIENTATION
RESETTING THE PROJECTOR
CONNECTING EXTERNAL DEVICES
CUSTOMER SERVICE
WARRANTY
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
3
3
3
34
4
5
5
6
6
67
7
7
8
8
8
9
9
910
10
10
11
12
1214
3
Thank you for purchasing the KODAK FLIK X4 HOME PROJECTOR. This User Guide is intended to
provide you with guidelines to ensure that operation of this product is safe and does not pose risk to
the user. Any use that does not conform to the guidelines described in this User Guide may void the
limited warranty.
Please read all directions before using the product and retain this guide for reference. This product is
intended for household use only. It is not intended for commercial use.
This product is covered by a limited one-year warranty. Coverage is subject to limits and exclusions.
See warranty for details.
1. INTRODUCTION
Rated Input: 100 V – 220 V
Native Resolution: 800 x 480p
KODAK FLIK X4 HOME PROJECTOR
Remote Control
User Guide
Tabletop Tripod
Carrying Case
Charging Cable
2. SPECIFICATIONS
•Do not attempt to disassemble this device for any reason.
•Do not store the projector in areas where it will be exposed to high temperatures, humidity, or direct
sunlight. Exposure to any or all of these could permanently damage the projector.
•Never handle the projector with damp or wet hands. This could damage the projector or create the
risk of electric shock.
•Keep the projector out of the reach of children.
•Never point the projector at someone else’s face or look directly into the projector light. The light is
bright and could cause damage.
•Do not use products such as alcohol, gasoline, diluent, or any other organic solvent when cleaning or
attempting to clean this product.
•Do not use this device in an environment where it will be exposed to heavy dust or humidity/moisture.
•Never drop or shake the projector, as this could cause it to malfunction or permanently damage the
inside parts.
•Do not use the projector while bathing or in a shower.
•Do not place or store the projector where it can fall or be pulled into a tub or sink.
3. BOX CONTENTS
4. SAFETY PRECAUTIONS
4
•Do not place, drop, or submerge the projector in water or any other liquid.
•If the projector somehow falls into water despite you taking all of the above precautions, please do not
reach into the water to retrieve it. Unplug it immediately and then retrieve it.
•Take care that objects do not fall and liquids are not spilled onto the projector.
5. PRODUCT OVERVIEW
1. Power
2. Back
3. Left
4. Up
5. Right
6. Down
7. OK
8. Settings
9. Input Source
10. Lens
11. Focus Wheel
12. VGA Input
13. USB Input
14. HDMI Input
15. SD Card Input
16. AV Input
17. Audio Out Jack (3.5 mm)
18. Air Outlet
19. Air Intake
20. Power Input
21. Speaker
22. Adjustable Foot
23. Stationary Foot
24. Tripod Dock
5
6. REMOTE CONTROL OVERVIEW
7. USING THE AUDIO OUT JACK
1. Power
2. Mute
3. Rewind
4. Play/Pause
5. Fast Forward
6. OK
7. Up
8. Left
While the projector does include two (2) built-in speakers for regular use, you can also connect either
headphones or a portable speaker to the 3.5 mm Audio Out Jack as shown in the image below.
To adjust the volume or sound settings, navigate to the Settings menu from the home screen and press
OK to open the Settings Page. (You can also hit the Settings button on top of the projector to jump
straight to this page.) Use the right or left arrows to navigate to the Sounds Page, where you can adjust
the treble/bass or choose from three (3) presets for varying types of audio iles. You can also use the
remote to raise and lower the volume.
9. Right
10. Down
11. Back
12. Settings
13. Input Source
14. Volume –
15. Volume +
16. Two (2) AAA Batteries
6
You can use this projector with:
1. VGA Input
2. USB Input
3. HDMI® Input
4. SD™ Card Input
5. AV Input
To switch between source types, tap the Sources button on top of the projector and use the arrows to
highlight the source you want to use.
9. USING DIFFERENT MEDIA SOURCES
8. POWERING THE PROJECTOR ON/OFF
To turn the projector on or o, press the power button on top of the projector.
10. NAVIGATING YOUR PROJECTOR
MAIN PAGE:
• The Main Page is your start page for all
operations with your projector.
• When unit is powered on, the Main
Page will load automatically.
• To return to the Main Page at any time,
press the Back button until the Main
Page loads.
7
Your photo iles will be displayed. Navigate
to the ile you wish to open, and press the
OK button to open the desired ile. During
playback, navigate to the Control Bar at
the bottom of the screen and press the OK
button to select your desired option.
12. PHOTOS PAGE
Your video iles will be displayed. Navigate to
the ile you wish to open, and press the OK
button to begin playback. During playback,
navigate to the Control Bar at the bottom of
the screen and press the OK button to select
your desired option.
11. MOVIES PAGE
Movies : Navigate to this icon and press the OK button to select. This will access the Movies page,
where your video iles will be available for playback.
Photos : Navigate to this icon and press the OK button to select. This will access the Photos page,
where your photo iles will be available for playback.
Music : Navigate to this icon and press the OK button to select. This will access the Music page,
where your music iles will be available for playback.
Settings : Navigate to this icon and press the OK button to select. This will access the Settings page,
where you can adjust the settings for your projector, such as Contrast and Brightness.
8
Access the menu by pressing the Input
Source button. The menu will appear in
the top right corner of the screen. Use
the Up and Down buttons to navigate
through the options and ensure the
projector is receiving the signal from
your desired source. Once you’ve
navigated to your choice, press the OK
button to conirm your selection.
15. INPUT SOURCE MENU
Your music iles will be displayed. Navigate
to the ile you wish to open, and press
the OK button to begin playback. During
playback, navigate to the Control Bar at
the bottom of the screen and press the OK
button to select your desired option.
From the settings page, you can navigate
to other menus using the arrows on top
of the projector or on the remote. Adjust
the date/time, display size, picture mode,
volume and sound settings, and more
from these menus.
13. MUSIC PAGE
14. SETTINGS PAGE
9
If the image on the screen appears fuzzy or unfocused when you turn the projector on, use the focus
wheel on the top to correct the image. Move the wheel left or right until the image appears sharp and
clear. The dial behind the focus wheel allows you to adjust the viewing angle of the screen.
NOTE: For best performance, the projector must be located a minimum distance of 3.5
feet (1 meter) from the screen. If a speciic image or video remains fuzzy after adjusting
the focus wheel, try pressing the back button until you return to the Main Page. If the Main
Page graphics appear clear and the image is still fuzzy, the problem may be the image or
video quality.
16. ADJUSTING FOCUS
17. ADJUSTING VOLUME
To adjust the device volume during playback, use the < and > buttons on the top of the projector or the
volume buttons on the remote control.
18. ADJUSTING PICTURE SETTINGS
From the Main Page, navigate to Settings and press the OK button to select. Once you are on the
Settings Page, select the top option, “Picture Mode” and use the arrows to navigate through the preset
options. The inal option “User” allows you to personally customize the brightness and other
picture settings.
10
19. SETTING THE SCREEN ORIENTATION
From the Main Page, navigate to Settings and
press the OK button to select. Once you are on the
Settings Page, select the option that says “Rotate”
and press the OK button to cycle through the various
options until the screen matches your projector
orientation.
20. RESETTING THE PROJECTOR
From the Main Page, navigate to Settings and
press the OK button to select. Once you’ve loaded
the Settings Page, use the left arrow on top of the
projector to open the Options Menu. From here you
can adjust the software language, install irmware
updates, and reset the projector.
To reset the projector, use the down arrows to
highlight the second option, “Restore Factory
Defaults” and press the OK button. The projector will
give you a second popup window to conirm that
you really want to restore the default settings, and
you’ll need to select YES to proceed.
