c2007 KITCHENAID

2−07 Litho in U.S.A. (skr) Part No. W10122280 Rev. A

5 QT. STAND MIXER

ARTISAN TILT HEAD

MODELS:

KSM150PSOB1 (Onyx Black)

KSM150PSMY1 (Majestic Yellow)

KSM150PSGR1 (Imperial Grey)

KSM150PSGN1 (Empire Green)

KSM150PSER1 (Empire Red)

KSM150PSBU1 (Cobalt Blue)

KSM150PSAC1 (Almond Creme)

COLOR VARIATION PARTS

For Models: KSM150PS__1

W10122280

Illus. Part

No. No. DESCRIPTION

1 Motor Housing

240291−13

Onyx Black

240291−20

Majestic Yellow

240291−22

Imperial Grey

240291−10

Empire Green

240291−21

Empire Red

240291−7 Cobalt Blue

240291−16

Almond Creme

2 Trim Band

9706630 Black/Silver

9706632 Almond Creme

3 End Cover

240253−14

Onyx Black

240253−21

Majestic Yellow

240253−23

Imperial Grey

240253−11

Empire Green

240253−22

Empire Red

240253−8 Cobalt Blue

240253−16

Almond Creme

4 Planetary

240286−16

Onyx Black

240286−22

Majestic Yellow

240286−24

Imperial Grey

240286−13

Empire Green

240286−23

Empire Red

240286−10

Cobalt Blue

240286−18

Almond Creme

5 Lower Gearcase

240350−56

Onyx Black

240350−82

Majestic Yellow

240350−86

Imperial Grey

240350−46

Empire Green

240350−84

Empire Red

240350−31

Cobalt Blue

240350−62

Almond Creme

6 Pedestal

3179275 Onyx Black

9702303 Majestic Yellow

9702305 Imperial Grey

3179273 Empire Green

9702304 Empire Red

3179263 Cobalt Blue

3179277 Almond Creme

Colors Subject To Change.

Any Color Not Listed is

No Longer Available.

If Additional Colors Are Added,

This Page Will Be Updated.

BASE AND PEDESTAL UNIT

For Models: KSM150PS__1

W10122280

Illus. Part

No. No. DESCRIPTION

1 Literature Parts

9709785 Use & Care Guide

W10122280

Repair Parts List

2 4162529 Screw Cap Kit

3 Lever, Latch

9709280 Black

9709282 Buff

4 24450 Link, Latch

5 9709707 Foot, Base

6Pedestal

7 16910 Pin, Hinge

8 103993 Screw, Latch

Bearing

9 24452 Latch, Link &

Lever

10 9709055 Latch

11 3400020 Screw

12 110679 Screw, Pivot

13 116241 Washer, Spring

14 8533912 Washer

15 Beater, Flat

9708472 Coated, White

16 9706619 Bowl, 5 Qt.

17 9708471 Hook, Dough

18 9706446 Whip, Wire

19 9709923 Shield, Pouring

REFER TO PAGE 2.

CASE, GEARING AND PLANETARY UNIT

For Models: KSM150PS__1

W10122280

CASE, GEARING AND PLANETARY UNIT

For Models: KSM150PS__1

W10122280

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 Gearcase Motor

Housing

2 Cap, Attachment

Hub

242765−2 Chrome

242765−5 Almond Creme

3 Thumb Screw

9709194 Black

9709198 Buff

4Band, Trim

5 3180161 Washer

W10112253

Worm Gear

7 240308 Worm Gear Bracket

And Bearing

8 3400022 Screw

9 240210−2 Shaft & Pinion

10 9705444 Pin

11 240026 Shaft, Vertical

Center

12 9705130 Gear, Attachment

Hub Bevel

13 9709627 Bevel Pinion

Center Gear

14 240018−1 Pin (Vertical

Center Shaft)

15 3180163 Washer

16 9705443 Pin, Groove

17 4162324 Gasket,

Transmission

Case

18 Lower Gear Case

19 3180163 Washer

20 9703904 Gear, Internal

21 103994 Screw

22 Planetary

23 4176067 Agitator Shaft

24 240285 Ring, Planetary

Drip

25 9706090 Washer

26 9703903 Pinion, Gear

Agitator Shaft

27 89411 Screw, Adjusting

28 3400203 Screw, Set

29 3400025 Screw

30 67500−55 "O" Ring

31 311932 Screw

32 Cover, End

33 4162914 Screw

34 240309−2 Worm Gear Bracket

And Gear

35 4160474 Center Shaft

& "O" Ring

36 9703438 Ring

37 9704677 Pin, Groove

38 8533914 Washer, Spring

Lock

Refer to Page 2

MOTOR AND CONTROL PARTS

For Models: KSM150PS__1

W10122280

MOTOR AND CONTROL PARTS

For Models: KSM150PS__1

W10122280

Illus. Part

No. No. DESCRIPTION

1 110679 Screw, Pivot

2 116241 Washer, Spring

3 Lever, Speed

Control Assy

9709276 Black

9709278 Buff

4 3183680 Spring, Control

Plate

5 3184176 Speed Link & Cam

6 240205 Spring, Flat

7 240769 Screw

8 9702695 Field Assembly

W10068260

Screw

10 16998 Stud, Governor

Drive

11 3180162 Washer

W10068270

Washer

13 9704324 Washer, Ball

Bearing (Front)

14 240775−1 Seal, End

15 3180526 Bracket, Bearing

Asm.

16 3180238 Washer

17 8533905 Nut

18 240680 Insert, Brush

Holder

19 9706416 Brush, Carbon

20 9707926 Screw, Set

21 116286 Cap, Spring

Seat

22 116287 Spring, Cap

23 Cap, Brush Holder

3184212 Black

3184213 Almond Creme

24 17830 Governor Assembly

25 240904−2 Control Plate

Assembly

26 Power Cord

9701025 White

9701026 Black

27 9706595 Phase Control

Board

28 9708315 Armature &

Bearing

29 4162634 Sleeve, Motor

Stud

30 3184609 Screw, Self

Tapping

31 3179908 Housing, Brush

Holder

32 4162546 Brush Holder

ACCESSORY PARTS

For Models: KSM150PS__1

W10122280

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

FOLLOWING PARTS

NOT ILLUSTRATED

4164839 Speed Disc

(Service Tool)

4160588 Grease, Planetary

4164778 Mixer Attachment

Pak (Includes Food

Grinder (FGA),

Food Strainer

(FVSP), And

Vegetable Slicer,

(RVSA)

(FPPA)

4164749 Food Grinder

(FGA)

8211924 Grain Mill

(KGMA)

4164768 Pasta Maker And

Food Grinder

(Includes SNP

Pasta Maker

Plates)

(SNFGA)

4164775 Fruit/Vegetable

Strainer Parts

(Use With FGA

Model Only) (FVSP)

4164750 Rotor Slicer/

Shredder(With

4 Standard Cones)

Fine Shredder,

Coarse Shredder,

Thick Slicer,and

Thin Slicer

(RVSA)

9704568 Pouring Shield

(KPS2CL)

4164824 Pasta Maker Plates

(SNPA)

4164774 Fruit/Vegetable

Strainer and Food

Grinder (FVSFGA)

3180617 Cover, Decorative

(Cotton Polyester)

4162838 Food Tray (FT)

4164748 Juicer (JE)

4164747 Can Opener (CO)

4164803 Sausage Stuffer

Kit (SSA)

8212519 Ice Cream Maker

(KICA0WH0)

3177924 Bowl Cover,

Plastic Non−

Sealing

4163337 Bowl, Stainless

W/Handle, 4.5 QT

3180262 Bowl, 3 Qt.
