KitchenAid KSMSCA Manuel utilisateur

KSMSCA

Attachment main body

Thin blade

Thick blade

Food skewer

Food holder

Zucchini/Cucumber adapter (Gray)

Blade release lever

Blade carrier

PARTS AND FEATURES

PARTS AND ACCESSORIES

ENGLISH

VEGETABLE SHEET CUTTER SAFETY | 3

Blade release lever

VEGETABLE SHEET CUTTER SAFETY

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always

be followed, including the following:

1. Read all instructions.

2. To protect against risk of electrical shock, do not put Stand Mixer in water

or other liquid.

3. Be sure to turn the Stand Mixer off (and detach the Vegetable Sheet Cutter

attachment from Stand Mixer) after each use of the Vegetable Sheet Cutter

attachment and before cleaning. Make sure the motor stops completely

before disassembling.

4. Keep hands, utensils, or other objects away from the Vegetable Sheet Cutter

attachment, skewer, or moving parts while it is in operation to reduce the risk of

severe injury to persons or damage to the Vegetable Sheet Cutter attachment.

5. Never feed by hand. Always use the provided skewer, food holder, and

zucchini/cucumber adapter.

6. If food becomes lodged in any blade or the skewer, turn the motor off and

disassemble the Vegetable Sheet Cutter attachment to remove the

remaining food.

7. Avoid contacting moving parts.

8. The use of attachments not recommended or sold by KitchenAid may cause

re, electric shock, or injury.

9. Do not use outdoors.

10. Close supervision is necessary when any appliance is used by or near children.

11. Do not use the appliance if the driver mechanism or rotating parts are damaged.

Return appliance to the nearest Authorized Service Center for examination,

repair, or electrical or mechanical adjustment.

12. Do not let the Stand Mixer cord hang over the edge of table or counter.

13. Blades are sharp. Handle carefully when inserting or removing blades.

14. Do not remove food until Stand Mixer is off and skewer stops.

15. To avoid damaging the gear assembly, do not immerse the Vegetable Sheet

Cutter attachment main body in water or other liquids.

SAVE THESE INSTRUCTIONS

This product is designed for household use only.

4 | USING THE VEGETABLE SHEET CUTTER ATTACHMENT

USING THE VEGETABLE SHEET

CUTTER ATTACHMENT

Choose a blade based on your preference. Both blades work well for many types of

recipes — e.g., baked entrees, wraps, sushi. Experiment with both blades to identify the

thickness that you prefer.

FOR INSTRUCTIONAL VIDEOS, RECIPES AND OTHER INFORMATION ON USING THE

VEGETABLE SHEET CUTTER ATTACHMENT

Visit kitchenaid.com/quickstart for additional instructions with videos, inspiring recipes,

and tips on how to use your Vegetable Sheet Cutter attachment.

VEGETABLE SHEET CUTTER ATTACHMENT BLADE CHART

ICON USE THESE

PARTS WITH THESE PARTS SUGGESTED

FOODS SPEED

Thin blade* Attachment main body,

food holder,

food skewer,

and

zucchini/cucumber

adapter***

ZUCCHINI

POTATO

APPLE

SWEET POTATO

CUCUMBER

Stir

Speed

Thick blade**

*Approximate sheet thickness will be 1.3 mm.

**Approximate sheet thickness will be 1.8 mm.

***Zucchini/cucumber adapter should only be used with soft foods.

ENGLISH

USING THE VEGETABLE SHEET CUTTER ATTACHMENT | 5

USING THE VEGETABLE SHEET

CUTTER ATTACHMENT

FOOD TYPE

RECOMMENDED HOW TO PREP SKEWER USE

ADAPTER

Zucchini Firm and thick Cut off ends

(Max length 4.5"/11.4 cm )

Insert all the

way in Yes

Cucumber Firm and thick Cut off ends

(Max length 4.5"/11.4 cm )

Insert all the

way in Yes

Apple Firm and thick Leave ends on Insert to ﬁrst

mark No

Potato Round and symmetrical Cut off ends to be square

(Max length 5.5"/14 cm)

Insert to ﬁrst

mark No

Sweet

Potato Round and symmetrical Cut off ends to be square

(Max length 5.5"/14 cm)

Insert to ﬁrst

mark No

ATTACHING THE VEGETABLE SHEET CUTTER ATTACHMENT

TO THE STAND MIXER

2For Stand Mixers with a hinged power hub cover: Flip up to open.

For Stand Mixers with a removable power hub cover: Turn the attachment knob

counterclockwise to remove power hub cover.

1Turn the Stand Mixer off and unplug.

NOTE: For hard or tougher foods, such as jicama or yucca root, remove the skin

before processing.

FRUIT & VEGETABLE PREP CHART

NOTE: For best results, food should be 1.5-3.5"(3.8-8.9 cm) in diameter.

6 | USING THE VEGETABLE SHEET CUTTER ATTACHMENT

USING THE VEGETABLE SHEET

CUTTER ATTACHMENT

Insert the Vegetable Sheet Cutter

attachment into the power hub,

making certain that the power shaft

fits into the square hub.

Rotate the Vegetable Sheet Cutter

attachment back and forth if

necessary. The pin on the shaft

housing will slip fully into the notch

on the hub rim when it is in the

proper position.

Tighten the attachment knob

until the Vegetable Sheet Cutter

attachment is completely secured

to the Stand Mixer.

PREPARING TO PROCESS CUCUMBERS/ZUCCHINI

NOTE: Please refer to the “Fruit & Vegetable Prep”chart before processing.

TIP: The first mark on the food skewer

is 4.5"(11.4 cm) from the round

skewer base.

1Rotate lever clockwise to the

locked position. 2Cut cucumber or zucchini to a

maximum length of 4.5"

(11.4 cm).

ENGLISH

USING THE VEGETABLE SHEET CUTTER ATTACHMENT | 7

USING THE VEGETABLE SHEET

CUTTER ATTACHMENT

Insert the food holder into one end,

then the zucchini/cucumber adapter

into the other, using the markings to

align both holder and adapter. Make

sure the food holder and adapter are

centered.

4Place the food and food holder

onto the main body and twist

clockwise to lock into place.

Insert the food skewer into the

skewer support on the attachment,

making sure it goes all the way

through the vegetable. Make sure

there is no gap between the skewer

knob and the skewer support on the

main body.

6Once this is complete, begin on

Step 1 of the “Processing Fruits &

Vegetables” section.

8 | USING THE VEGETABLE SHEET CUTTER ATTACHMENT

USING THE VEGETABLE SHEET

CUTTER ATTACHMENT

NOTE: The food skewer may not need

to be fully inserted. For hard foods, insert

approximately 2"(5 cm), or to the first

mark on the food skewer.

3Insert the food holder all the way

into the center of the food. 4Place the food and food holder

onto the main body and twist

clockwise to lock into place.

Insert the food skewer into the

skewer support on the attachment

main body, making sure that it is

centered on the food.

PREPARING TO PROCESS OTHER VEGETABLES/FRUITS

1Rotate lever clockwise to the

locked position. 2

Cut the food to fit within the

attachment main body.

Maximum food size is approximately

3.5" (8.9 cm) diameter and 5.5"

(14 cm) long.

ENGLISH

USING THE VEGETABLE SHEET CUTTER ATTACHMENT | 9

NOTE: As the attachment cuts the

vegetable into sheets, it can either be

one continuous sheet or several sheets.

This is normal.

PROCESSING FRUITS & VEGETABLES

NOTE: When using the Vegetable Sheet Cutter attachment, do not wear ties, scarves,

loose clothing, long necklaces, or anything that could become entagled in the

attachment; gather long hair with a clasp.

USING THE VEGETABLE SHEET

CUTTER ATTACHMENT

Insert the desired blade into the

blade carrier at a 45 degree angle

to allow proper alignment with the

attachment main body. Allow the

blade cover to rest on the food.

Turn the Stand Mixer on to Stir speed.

For best results, start the Stand Mixer

before releasing the blade into

the food.

Pull toward Stand Mixer and lift up

on the blade release lever to unlock

the blade carrier and rotate the blade

carrier slowly until it comes into

contact with the food before

letting go.

4Once the food stops processing, turn

off the Stand Mixer.

10 | USING THE VEGETABLE SHEET CUTTER ATTACHMENT

Remove the food skewer, then

remove the food and adapter (if

necessary). To prevent breakage,

do not twist the skewer during food

removal. If food is difficult to remove

from food holder or skewer, slice into

the core lengthwise to help remove it.

FOR INSTRUCTIONAL VIDEOS, RECIPES AND OTHER INFORMATION ON USING THE

VEGETABLE SHEET CUTTER ATTACHMENT

Visit kitchenaid.com/quickstart for additional instructions with videos, inspiring recipes,

and tips on how to use your Vegetable Sheet Cutter attachment.

USING THE VEGETABLE SHEET

CUTTER ATTACHMENT

5Rotate lever clockwise to the

locked position. 6Remove the blade.
