KitchenAid KSBC1B0CU Manuel utilisateur

Orion Blender

KSBC1B0

W11593908B.indb 1W11593908B.indb 1 9/19/2022 9:47:19 AM9/19/2022 9:47:19 AM

PARTS AND FEATURES

1On/Off Switch (not shown)

2Base

3Cord Cleat (not shown)

4Power Cord Socket and Removable

Power Cord (not shown)

5Talon Blade

6Blender Jar

7Lid

8Ingredient Cap with Measuring Cup

9Open Handle for Easy Stackability

10 Removable Blender Jar Pad

11 Control Dial

12 Pulse Toggle Switch

13 Start/Stop Toggle Switch

14 Status Indicator Light

15 Flex Edge Tamper

121314

W11593908B.indb 2W11593908B.indb 2 9/19/2022 9:47:19 AM9/19/2022 9:47:19 AM

ENGLISH

PRODUCT SAFETY

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always

be followed, including the following:

1. Read all instructions.

2. To protect against risk of electrical shock, do not put Blender in water

or other liquid.

3. This appliance is not intended for use by persons (including children) with

reduced physical, sensory, or mental capabilities, or lack of experience and

knowledge, unless they are closely supervised and instructed concerning

use of the appliance by a person responsible for their safety. Close

supervision is necessary when any appliance is used by or near children.

Children should be supervised to ensure that they do not play with the

appliance.

4. Turn the appliance off (O), then unplug from the outlet when not in use,

before assembling or disassembling parts and before cleaning. To unplug,

grasp the plug and pull from the outlet. Never pull from the Power Cord.

5. Avoid contact with moving parts.

6. Do not operate the Blender with a damaged cord or plug or after appliance

malfunctions, or is dropped or damaged in any manner. Return appliance

to the nearest Authorized Service Center for examination, repair, or electrical

or mechanical adjustment. If the supply cord or plug is damaged, it must be

replaced by a special cord or assembly available from the manufacturer or

service agent.

7. Do not use outdoors.

8. Do not place on or near a hot gas or electric burner, or in a heated oven.

9. Do not let cord hang over edge of table or counter, or touch hot surfaces.

W11593908B.indb 3W11593908B.indb 3 9/19/2022 9:47:19 AM9/19/2022 9:47:19 AM

PRODUCT SAFETY

10. Keep hands and utensils out of container while blending to reduce the risk

of severe injury to persons or damage to the Blender. A spatula or scraper

other than the provided Flex Edge tamper may be used, but must be used

only when the Blender is not running.

11. Blades are sharp. Handle carefully.

12. The use of attachments, including canning blender jars, not recommended

by KitchenAid may cause a risk of injury to persons.

13. Do not use appliance for other than intended use.

14. Always operate Blender with cover in place.

15. When blending hot liquids or ingredients or operating in the heating mode,

Lid Center Cap should remain in place over the Lid opening. Always start on

lowest speed and slowly ramp to desired speed when blending hot liquids or

ingredients.

16. Allow the appliance to cool completely before putting on or taking off parts,

and before cleaning the appliance.

ELECTRICAL REQUIREMENTS

Voltage: 120 V~

Frequency: 60 Hz

Amps: 15.0 A

NOTE: If the plug does not fit in the

outlet, contact a qualified electrician. Do

not modify the plug in any way. Do not

use an adapter.

Do not use an extension cord. If the power

supply cord is too short, have a qualiﬁed

electrician or serviceman install an outlet

near the appliance.

This product is designed for commercial use.

SAVE THESE INSTRUCTIONS

W11593908B.indb 4W11593908B.indb 4 9/19/2022 9:47:19 AM9/19/2022 9:47:19 AM

ENGLISH

PRODUCT USAGE

The Blender has a preset recipe program: Icy Drinks. It also features Variable Times and

Pulse functions that allow you to customize your blending for any recipe you make.

To clean the Blender: Quick pulses of power and high speeds work to clean the Blender

Jar with just 2 cups of water and a drop of dish soap.

BLENDER FUNCTION GUIDE

SETTING DESCRIPTION BLENDING TIME

(in min:sec)

ICY DRINKS

Gradually ramp up to full power to completely blend

hard foods such as ice, whole fruits or vegetables, or

frozen fruits. This cycle is recommended for such drinks

as Margaritas, Daiquiris, and blended ice coffee drinks.

0:22

LOW

When Low speed is selected, the Blender will run

continuously on low until the Start/stop switch is

pressed, or after 6 minutes elapse.

N/A

MEDIUM

When Medium speed is selected, the Blender will run

continuously on medium until the Start/stop switch is

pressed, or until 6 minutes elapse.

N/A

HIGH

When High speed is selected the Blender will run

continuously on high until the Start/stop switch is

pressed, or after 6 minutes elapse.

N/A

PULSE H/L Alternatively, use Pulse during manual operation to add

a boost of power momentarily. N/A

VARIABLE

TIMES The timer function starts at a slow speed and ramps up

to a high speed for optimal blending results. 0:05-0:60

W11593908B.indb 5W11593908B.indb 5 9/19/2022 9:47:19 AM9/19/2022 9:47:19 AM

PRODUCT USAGE

Before ﬁrst use

Before using your Blender for the ﬁrst time,

wipe the blender base with a warm damp

cloth, then wipe clean with a damp cloth.

Dry with a soft cloth. Wash the Blender

Jar, Lid, and ingredient cup in warm, sudsy

water (see “Care and Cleaning” section).

Rinse parts and wipe dry.

PREPARING THE COMMERCIAL BLENDER FOR USE

NOTE: The Cord Cleat is not to be used

as a handle; the Cord Cleat is designed

to wrap the Power Cord around it for

storage only.

Before using the Blender, be sure the

countertop beneath the Blender and

surrounding areas are dry and clean. Be

sure the power switch on the back of the

blender base is in the OFF (O) position

and the cord is also fully plugged into

the back of the Blender. Then, plug the

Blender into a grounded 3 prong outlet.

The main power switch is on the back

of the Blender Base. Flip the POWER

switch to the ON (I) position. The Status

Indicator Light above the Start toggle

button will begin to flash, indicating that

the Blender is in Standby mode. The

Blender is now ready to operate.

W11593908B.indb 6W11593908B.indb 6 9/19/2022 9:47:20 AM9/19/2022 9:47:20 AM

ENGLISH

PRODUCT USAGE

ASSEMBLING AND RUNNING THE COMMERCIAL BLENDER

NOTE: Do not fill Blender Jar past the

top-most measurement mark, especially

when blending liquids.

NOTE: If you select a pre-programmed

cycle, you will need to ﬂip the

START/STOP toggle to begin operation.

Put the items to blend into the Blender

Jar. Add liquids first, then soft foods, then

leafy greens, and ice or frozen items last.

Make sure that the Lid is fully secured on

the Blender Jar; next, place the Blender

Jar on the base, making sure that it is fully

aligned on the jar pad.

3 4

Flip the START/STOP toggle switch up or

down to begin operation of the Blender.

The Status Indicator Light will now be

solid.

Turn the Control Dial to your desired

speed, time, or program. See the

“Blender Function Guide” for more

information.

W11593908B.indb 7W11593908B.indb 7 9/19/2022 9:47:20 AM9/19/2022 9:47:20 AM

PRODUCT USAGE

NOTE: The Pulse function may also

be used on its own as a separate

blending function while the Blender

is in Standby mode.

After blending, flip the START/STOP

toggle switch up or down. Allow the

Blender to come to a complete stop

before removing the Lid and pouring your

blended ingredients.

If the Blender remains in standby mode

for 10 minutes with no activity, the

Blender will enter sleep mode. To get

out of sleep mode, press the

START/STOP switch once to bring into

standby mode. Then, press

START/STOP once more to start the

Blender.

Utilize the Flex Edge tamper accessory

as needed for optimal blending

performance. Remove the

Ingredient-measuring Cap only, and leave

the Lid in place. Stir or press contents

down towards the blade. When you are

finished, replace the ingredient-measuring

cap in the Blender Jar Lid before

resuming blending.

If desired, use the Pulse function for

a momentary boost of speed while

blending on the variable speed settings.

PRESS AND HOLD the PULSE toggle

switch up for a faster pulse, or down for a

slower pulse.

W11593908B.indb 8W11593908B.indb 8 9/19/2022 9:47:21 AM9/19/2022 9:47:21 AM

ENGLISH

CARE AND CLEANING

CLEANING THE BLENDER AND ACCESSORIES

NOTE: To avoid damaging the Blender, do not immerse the blender base or cord in

water. To avoid scratching the Blender, do not use abrasive cleansers or scouring pads.

1 2

To clean the Blender Base and cord:

Unplug the Blender before cleaning.

Wipe the base and the cord with a warm,

damp cloth; wipe clean with a damp

cloth, and dry with a soft cloth.

Make sure to clean the Blender Jar,

Lid, and Ingredient Cap after each use.

Remove any remaining contents from the

Blender Jar. Fill the Blender Jar with 2

cups of warm water and 1 drop of liquid

detergent. Place the Lid on the Blender

Jar, and make sure the Blender Jar is fully

in place on the blender base.

IMPORTANT: Allow the appliance to cool completely before putting on or taking off

parts, and before cleaning the appliance.

Rotate the Control Dial to 30 seconds.

Flip the START/STOP toggle switch up or

down. When the timer finishes, pour out

the soapy water, and rinse the Blender Jar

with warm water.

Wash the Blender Jar, Jar Pad, Lid, Flex

Edge Tamper, and Ingredient Cap by

hand with a damp cloth and warm soapy

water; rinse with warm water, and dry

with a soft cloth.

W11593908B.indb 9W11593908B.indb 9 9/19/2022 9:47:21 AM9/19/2022 9:47:21 AM

CARE AND CLEANING

SANITIZING THE BLENDER

1. Remove any remaining contents from the Blender Jar.

2. Prepare a 200 ppm sodium hypochlorite solution* using 1.75 L of hot water in the

Blender Jar. Place the Lid on the Blender Jar, and make sure the Blender Jar is fully in

place on the Blender Base.

3. Run the Blender on the High Speed setting for 35 seconds. Flip the START/STOP

toggle switch up or down to start the Blender.

4. Turn off the Blender and let the sanitizing mix sit in the Blender Jar for an

additional 2 minutes.

5. Pour out the sanitizing solution mix. Do not rinse the Blender Jar.

6. Place the Lid on the Blender Jar. Make sure the empty Blender Jar is fully in place on

the blender base. Run the empty Blender for an additional 10 seconds. Do not rinse

the jar after sanitizing.

7. Allow the Blender Jar to air dry.

*To prepare a 200 ppm sodium hypochlorite solution: use 6.67 ml household bleach (with a 5.25% sodium

hypochlorite concentration) in 1.75 L of hot water.

TROUBLESHOOTING

WARNING

Electrical Shock Hazard

Plug into a grounded 3 prong outlet.

Do not remove ground prong.

Do not use an adapter.

Do not use an extension cord.

Failure to follow these instructions can result in death, fire, or

electrical shock.

PROBLEM SOLUTION

When the Blender is plugged in and

the main power On/Off (I/O) toggle

switch is on (I), the Blender will go

to Standby mode (flashing white

indicator light). However, after 10

minutes of no activity the Blender

will go into Sleep mode and the

indicator light will turn off:

To wake up the Blender simply ﬂip the

START/STOP toggle switch up or down. This will

put the Blender back into Standby mode.

If the Status Indicator Light flashes

an orange color, the Blender is in

error mode. This can be caused by:

using a spatula or any other utensil

that could obstruct the blade to

freely spin in the Blender Jar, or

having an ice cube or hard food in a

location that locks up the blade:

Correct the problem by turning off the Blender

using the dedicated On/Off Toggle Switch in the

back, or by unplugging the Blender.

Remove the Blender Jar from the base, and clear

the items. Place the Blender back on the base,

and then turn the

Blender back on to continue

regular use.

W11593908B.indb 10W11593908B.indb 10 9/19/2022 9:47:21 AM9/19/2022 9:47:21 AM

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels KitchenAid Mixer

KitchenAid

KitchenAid KSB40 Series Manuel utilisateur

KitchenAid

KitchenAid KSB60 series Manuel utilisateur

KitchenAid

KitchenAid KPCB348SPM0 Manuel utilisateur

KitchenAid

KitchenAid 5KSB555AAC Manuel utilisateur

KitchenAid

KitchenAid 5KSB1325A Series Manuel utilisateur

KitchenAid

KitchenAid 5KSB40 Series Manuel utilisateur

KitchenAid

KitchenAid KSB70DW Instructions d'installation

KitchenAid

KitchenAid KCB148 Manuel utilisateur

KitchenAid

KitchenAid 5KHB3583 Manuel utilisateur

KitchenAid

KitchenAid 5KSB8270 Manuel utilisateur

KitchenAid

KitchenAid KS8354 Manuel utilisateur

KitchenAid

KitchenAid KSB1575PK Manuel utilisateur

KitchenAid

KitchenAid 5KSB5553BOB Manuel utilisateur

KitchenAid

KitchenAid Pro Line KSB8270 Manuel utilisateur

KitchenAid

KitchenAid 4KPCB348PPM0 Manuel utilisateur

KitchenAid

KitchenAid KSB1570SL0 Manuel utilisateur

KitchenAid

KitchenAid 5KSB5080 Manuel utilisateur

KitchenAid

KitchenAid PROLINE KPCB148 Manuel utilisateur

KitchenAid

KitchenAid KSBR200 Manuel utilisateur

KitchenAid

KitchenAid 5 Speed Professional Blender Manuel utilisateur

KitchenAid

KitchenAid KHB100OB - 8" Immersion Blender Manuel utilisateur

KitchenAid

KitchenAid 5KSB1585 Manuel utilisateur

KitchenAid

KitchenAid KSB1575 Manuel utilisateur

KitchenAid

KitchenAid K400 Manuel utilisateur

Manuels Mixer populaires d'autres marques

ROTOR

ROTOR 1125.201 Manuel utilisateur

Braun

Braun Multiquick 5 Vario series Manuel utilisateur

ARENDO

ARENDO MIRA 305424 Manuel utilisateur

CHEF-BUILT

CHEF-BUILT CCB-3500 Manuel utilisateur

Viconte

Viconte VC-4406 Manuel utilisateur

Oster

Oster BLSTAB-CB0 Manuel utilisateur

HOFFEN

HOFFEN MC-3005 Manuel utilisateur

Black & Decker

Black & Decker BLC18750DM Manuel utilisateur

Sunbeam

Sunbeam 4182 Manuel utilisateur

Bialetti

Bialetti FMX35 Manuel utilisateur

Black & Decker

Black & Decker BL8000 Manuel utilisateur

Duronic

Duronic BL530 Manuel utilisateur

Exquisit

Exquisit MS 3002 wes Manuel utilisateur

Lumme

Lumme LU-KP1891A Manuel utilisateur

Binatone

Binatone HB-735 Manuel utilisateur

Moulinex

Moulinex LM936E10 Manuel utilisateur

Oster

Oster VERSA Manuel d'installation et d'exploitation

Ninja

Ninja NN210Q Manuel utilisateur
