FOREWORD

SIGNS DESCRIPTION

DANGER

WARNING

CAUTION

IMPORTANT

This mark indicates a hazardous situation which, if not observed, may result in death or

fatal injury.

This mark should be indicated for most dangerous situations only.

This mark indicates potentially hazardous situations which, if not observed, may result in

minor or moderate injury. And this mark can be used as a warning against unsafe

activities.

This mark indicates emphasis on notable characteristics in working procedures or infor-

mation on working procedures and technology for convenient use.

This mark indicates potentially hazardous situations which, if not observed, may result in

death or moderate injury.

NOTE: USA : only USA / EU : Europe / AU : Australia, New zealand, etc

Congratulations, and welcome to the fabulous world of KIOTI DK35/40/450L ownership,where serious work is

made fun again!

This versatile tractor is a culmination of the entire tractor and diesel knowledge gained by the Daedong

Industrial Co.,LTD over the years since 1947 and has been designed with the finest materials and under

rigid quality control standards set forth by the KIOTI Engineering Department.

Knowledge of tractor operation is essential for many years of dependable service and reliability. to help new

owners familiarize themselves with the KIOTI DK35/40/450L, it is the policy of KIOTI tractor to provide an

owner’s manual which includes helpful information about tractor safety, operation and maintenance. If the

information you seek is not found in this manual,your KIOTI tractor dealer will be happy to help you. please

feel free to contact DAEDONG-USA,INC. with your questions/concerns. Throughout this manual you will see

text in bold type, preceded by the words DANGER, WARNING, CAUTION or IMPORTANT.

Such text has the following significance.

ABBREVIATIONS LIST

Abbreviations

4WD

API

ASAE

ASTM

fpm

Hi-Lo

HST

m/s

P.T.O

RH/LH

ROPS

m-1(rpm)

S-1(r/s)

SAE

SMV

Definitions

Four Wheel Drive

American Petroleum Institute

American Society of Agricultural Engineers, USA

American Society of Testing and Materials, USA

Feet Per Minute

High Speed-Low Speed

Hydrostatic Transmission

Meters Per Second

Power Take OFF

Right-hand and Left-hand sides are determined by

facing in the direction of forward travel

Roll-Over Protective Structures

Revolutions Per Minute

Revolutions Per Second

Society of Automotive Engineers, USA

Slow Moving Vehicle

UNIVERSAL SYMBOLS

Various universal symbols have been used on the instruments and controls of your KIOTI tractor. Below is a list of the universal

symbols and their meanings.

Safety Alert Symbol

Fuel-Level

Engine Coolant-Temperature

Parking Brake

Battery Charging Condition

Engine Oil-Pressure

Turn Signal

Power Take-Off Clutch Control-

Off Position

Power Take-Off Clutch Control-

ON Position

Differential Lock

Position Control-Lowered

Position

Hazard Warning Lights

Headlight-Low Beam

Headlight-High Beam

Four-Wheel Drive-ON

Fast

Slow

High Range

Middle Range

Low Range

Neutral Position

Coolant

Preheat

1. SAFETY PRECAUTIONS ....................................................

2. SERVICING OF TRACTOR.................................................

3. SPECIFICATIONS ................................................................

4. DESCRIPTION OF OPERATING SYSTEM.......................

5. OPERATING .........................................................................

6. MAINTENANCE ....................................................................

7. STORAGE .............................................................................

8. TROUBLESHOOTING ........................................................

9. INDEX....................................................................................

CONTENTS

BEFORE OPERATING THE TRACTOR

OPERATING THE TRACTOR

DRIVING THE TRACTOR

PARKING THE TRACTOR

OPERATING THE P.T.O

USING 3-POINT HITCH

SERVICING THE TRACTOR

TRACTOR SAFETY LABELS

1SAFETY PRECAUTIONS

1-2 DK35/40/450L

615O102A615O101A

BEFORE OPERATING THE

TRACTOR

6. When getting on and off the tractor,

handholds and step plates should al-

ways be used. This will help to pre-

vent accidental slips trips and falls.

7. Be sure to scrape off mud or soil from

your shoes before mounting the tractor.

8. Watch where you are going at all times

so that you are able to avoid ob-

stacles that can cause injury or dam-

age to your tractor.

9. When startingthetractormake sure your

path is clear of people to avoid acci-

dents caused by sudden movements.

10.Before making reverse movements

with your tractor, you should always

check to see that the path is clear.

1. It is recommended that you read and

understand this entire manual before

operation of your new tractor. Failure

to do so could result in accidents or

injury.

2. Only persons who are properly trained

should be allowed to operate the

tractor.

3. Read and follow all warning labels and

decals affixed to the tractor.

4. Replace any missing or damaged de-

cals as soon as it is practical. A list of

decals is shown on page1-14~16

5. Keep safety decals clean from dirt and

debris.

A careful operator is the best operator.

Most accidents can be avoided by ob-

serving certain precautions. To help pre-

vent accidents, use these safety

precautions, and pay attention to the job

at hand. If you can prevent an accident,

your time will have been well spent.

SAFETY PRECAUTIONS 1-3

615O103A 615O104A

11.Never operate this tractor or any other

agricultural equipment while under the

influence of alcohol, drugs or while

fatigued.

12.While working in cooperation with

other tractors always communicate

your intentions.

13.Do not start your tractor by shorting

across the starter.

16.All persons using the tractor should

have knowledge of its proper opera-

tion and should read this manual

carefully.

17.Never get off the tractor without set-

ting the parking brake, lowering the

implement to the ground and shutting

of the tractor.

18.No alterations should be made to your

KIOTI tractor without first consulting

your KIOTI dealer.

14.Never start the engine while standing

on the ground.

15.Only the operator should ride on the

tractor unless a passenger seat is

installed. Keep bystanders away from

the tractor while in operation.

615O105B

1-4 DK35/40/450L

615O106A 615O107A

A ROPS should never be modified by

welding, grinding or cutting, as this can

weaken the ROPS structure. If any com-

ponents of the ROPS unit is damaged, it

must be replaced.

If the ROPS unit is removed or loosened

for any reason, the parts should be fit-

ted back to their original positions and all

bolts should be properly torqued.

NOTE

Always use seat belt when the trac-

tor is equipped with a ROPS. Never

use the seat belt when tractor is not

equipped with a ROPS.

(ROPS:Roll-OverProtectiveStructures)

21.Extra caution should be taken when

driving tractors with narrow tread

widths. For added stability you should

adjust your rear wheel tread width,

see page 8-3.

19.Before starting your tractor you

should disengage the clutch, and

make sure that all shift levers are in

the neutral position.

20.For your safety ROPS with a seat belt

is recommended for most applications.

(1) Max. tread width (2) Rear wheels

SAFETY PRECAUTIONS 1-5

615O108A 615O109A

1. Avoid accidental contact with gear

shift levers while the engine is

running. Unexpected tractor move-

ments can result in bodily injury.

2. Do not park your tractor on a steep

incline, and remember to shut off the

engine and P.T.O before dismounting

the tractor.

OPERATING THE TRACTOR

3. Do not operate your tractor in an en-

closed building without the proper

ventilation. Exhaust fumes can cause

serious injury or death.

615O110A
