Kioti CK20 Manuel utilisateur

Congratulations on being an owner of a versatile KIOTI CK20 tractor. This tractor has been designed with the

finest materials and under rigid quality control standards set forth by the DAEDONG engineering department.

Knowledge of tractor operation is essential for many years of dependable service and reliability. This manual

is given to help you familiarize yourself with the CK20 tractor and to give you helpful information about tractor

safety, operation and maintenance. It is the policy of KIOTI to provide each KIOTI tractor owner with a detailed

owner’s manual to help you answer many questions. If the information you are seeking is not found in this

manual, your KIOTI tractor dealer will be happy to help you.

Please feel free to contact DAEDONG IND.CO.,LTD.

Throughout this manual, you will see text in italics, preceded by the words DANGER, WARNING, CAUTION or

IMPORTANT.

Such text has the following significance.

Signs Description

DANGER

WARNING

CAUTION

IMPORTANT

This mark indicates hazardous situation which, if not observed, may result in death or

fatal injury.

This mark should be indicated for most dangerous situations only.

This mark indicates potentially hazardous situation which, if not observed, may result in

minor or moderate injury. And this mark can be used as a warning against unsafe

activities.

This mark indicates emphasis on notable characteristics in working procedures or infor-

mation on working procedures and technology for convenient use.

This mark indicates potentially hazardous situation which, if not observed, may result in

death or moderate injury.

FOREWORD

Abbreviations

4WD

API

ASAE

ASTM

fpm

Hi-Lo

HST

m/s

P.T.O

RH/LH

ROPS

m-1(rpm)

S-1(r/s)

SAE

SMV

Definitions

Four Wheel Drive

American Petroleum Institute

American Society of Agricultural Engineers, USA

American Society of Testing and Materials, USA

Feet Per Minute

High Speed-Low Speed

Hydrostatic Transmission

Meters Per Second

Power Take OFF

Right-hand and Left-hand sides are determined by

facing in the direction of forward travel

Roll-Over Protective Structures

Revolutions Per Minute

Revolutions Per Second

Society of Automotive Engineers, USA

Slow Moving Vehicle

ABBREVIATION LIST

Various universal symbols have been used on the instruments and controls of your KIOTI tractor. Below is a list of the universal

symbols and their meanings.

Safety Alert Symbol

Fuel-Level

Engine Coolant-Temperature

Parking Brake

Battery Charging Condition

Engine Oil-Pressure

Turn Signal

Power Take-OFF Clutch Control-OFF Position

Power Take-OFF Clutch Control-ON Position

Differential Lock

Position Control-Raised Position

Position Control-Lowered Position

Hazard Warning Lights

Master Lighting Switch

Position Lamps

Headlight-Low Beam

Headlight-High Beam

Audible Warning Device

Four-Wheel Drive-ON

Four-Wheel Drive-OFF

Fast

Slow

UNIVERSALSYMBOLS

1. SAFETYPRECAUTIONS .......................................................

2. SERVICING ............................................................................

3. SPECIFICATIONS ..................................................................

4. INSTRUMENT PANELAND CONTROLS ..............................

5. PRE-OPERATION CHECK.....................................................

6. OPERATING THE ENGINE ....................................................

7. OPERATING THE TRACTOR ................................................

8. THREE-POINT HITCH & DRAWBAR .....................................

9. HYDRAULIC UNIT..................................................................

10. TIRES,WHEELSANDBALLAST............................................

11. MAINTENANCE ......................................................................

12. PERIODIC SERVICE ..............................................................

13. STORAGE ..............................................................................

14. TROUBLESHOOTING...........................................................

15. OPTIONS ...............................................................................

16. INDEX.....................................................................................

CONTENTS

BEFORE OPERATING THE TRACTOR

OPERATING THE TRACTOR

DRIVING THE TRACTOR

PARKING THE TRACTOR

OPERATING THE P.T.O

USING 3-POINT HITCH

SERVICING THE TRACTOR

TRACTOR SAFETY LABELS

1SAFETY PRECAUTIONS

1-2 CK20

196O102A

A careful operator is the best operator.

Most accidents can be avoided by ob-

serving certain precautions. To help pre-

vent accidents, read and take these

safety precautions and pay attention to

the job at hand. If you can prevent an

accident in advance, your time will have

been spent well.

BEFORE OPERATING THE

TRACTOR

6. When getting on and off the tractor,

handholds and step plates should al-

ways be used. This will help to pre-

vent accidental slips trips and falls.

7. Be sure to scrape off mud or soil from

your shoes before mounting the tractor.

8. Watch where you are going at all times

so that you are able to avoid ob-

stacles that can cause injury or dam-

age to your tractor.

9. When starting thetractormake sure your

path is clear of people to avoid acci-

dents caused by sudden movements.

10.Before making reverse movements

with you tractor you should always

check to see that the path is clear.

196O101A

1. It is recommended that you read and

understand this entire manual before

operation of your new tractor. Failure

to do so could result in accidents or

injury.

2. Only persons who are properly trained

should be allowed to operate the

tractor.

3. Read and follow all warning labels and

decals affixed on the tractor.

4. Replace any missing or damaged de-

cals as soon as practical. A list on

decals is shown on page1-14.

5. Keep safety decals clean from dirt and

debris.

SAFETY PRECAUTIONS 1-3

196O104A196O103A

11.Never operate this tractor or any other

agricultural equipment while under the

influence of alcohol, drugs, or while

fatigued.

12.While working in cooperation with

other tractors always communicate

your intentions.

13.Do not start your tractor by shorting

across the starter.

196O105A

16.All persons using the tractor should

have knowledge of its proper

operation, and should read this manual

carefully.

17.Never get off the tractor without shut-

ting off the tractor, setting the park-

ing brake, and lowering the implement

to the ground.

18.No alterations should be made to your

KIOTI tractor without first consulting

you KIOTI dealer.

14.Never start the engine while standing

on the ground.

15.Only the operator should ride on the

tractor unless a passenger seat is

installed. Keep bystanderds away

from the tractor while in operation.

1-4 CK20

196O106A

A ROPS should never be modified by

welding, grinding, or cutting, as this can

weaken the ROPS structure. If any com-

ponents of the ROPS unit is damaged it

must be replaced.

If the ROPS unit is removed or loosened

for any reason, the parts should be fit-

ted back to their originals position and all

bolts should be properly torqued.

NOTE

Always use seat belt when the trac-

tor is equipped with a ROPS. Never

use the seat belt when tractor is not

equipped with a ROPS.

(ROPS:Roll-OverProtectiveStructures)

21.Extra caution should be taken when

driving tractors with narrow tread

widths. For added stability you should

adjust you rear wheel tread width,

see page 12-20.

196O132A

19.Before starting your tractor you

should disengage the clutch, and in-

sure that all shift levers are in the

neutral position.

20.For your safety ROPS with a seat belt

is recommended for most applications.

(1) Tread
