C rbon Monoxide Al rm

User Guide

Model: KN-COP-DP-B (900-0278)

AC Plug-in Operated with AA Battery Backup

ATTENTION: Please take a few minutes to thoroughly read this

user guide which should be saved for future reference and passed

on to any subsequent owner.

2551-7201-02_EN_V1.qxp__ 15-10-8 下午3:20 页 1

Welcome

Note: any times throughout this User Guide, we will refer to

Carbon onoxide as “CO”.

This Kidde carbon monoxide (CO) alarm is an important part of your

family’s home safety plan. This alarm has been designed and tested to

detect CO buildup in a residential environment. Your alarm is for use

specifically in the home, but not for use in a boat or recreational vehicle.

As an owner of a CO alarm, there are some basic facts you should know

about for your protection.

Many people think that CO alarms operate like smoke alarms. Like

smoke alarms, CO alarms monitor the air in your home and sound a

loud alarm to warn you of trouble. The way you respond to a CO alarm

is quite different than a smoke alarm. That’s because a house fire and a

CO problem are two distinctly different situations. If your smoke alarm

were to alarm, you would quickly be able to judge the level of danger

you were in with your senses. You can see and smell the smoke, feel the

heat, see, and possibly hear the fire burning. You can also readily see if

your smoke alarm is alarming in a non-emergency situation. Because

your sense of sight, smell, hearing and touch give you information, you

can almost instantly judge what action to take if you hear your smoke

alarm.

CO is an invisible, odorless, tasteless and non-irritating gas – completely

undetectable to your senses. That’s why it is important to your safety

that you have a CO alarm.

Important Warning Statements

I PORTANT: This carbon monoxide alarm is designed to detect

carbon monoxide from ANY source of combustion. It is NOT

designed to detect smoke, fire, or any other gas.

WARNING: Carbon monoxide alarms are not smoke alarms.

This carbon monoxide alarm is not a substitute for installing and

maintaining an appropriate number of smoke alarms in your

home.

This carbon monoxide alarm will not sense smoke, fire, or any

poisonous gas other than carbon monoxide even though carbon

monoxide can be generated by fire. For this reason you must

install smoke alarms to provide early warning of fire and to

protect you and your family from fire and its related hazards.

CAUTION: This alarm will only indicate the presence of carbon

monoxide at the sensor. Carbon monoxide may be present in

other areas.

2551-7201-02_EN_V1.qxp__ 15-10-8 下午3:20 页 3

Important Warning Statements

WARNING: This product is intended for use in ordinary indoor

locations of family living units, not for use in boats or

recreational vehicles. It is not designed to measure compliance

with commercial or industrial standards. It is not suitable for

installation in hazardous locations as defined in your local

building code.

The installation of this device should not be used as a substitute

for proper installation, use and maintenance of fuel burning

appliances, including appropriate ventilation and exhaust

systems. It does not prevent CO from occurring, nor can it solve

an existing CO problem.

WARNING: This device is designed to protect individuals from

acute effects of carbon monoxide exposure. It may not fully

safeguard individuals with specific medical conditions. If in doubt,

consult a medical practitioner.

Individuals with medical problems may consider using warning

devices which provide audible and visual signals for carbon

monoxide concentrations under 30 PP .

This carbon monoxide alarm requires a continuous supply of

electrical power – it will not work without power. odels

without battery backup will not operate during power failure.

This alarm has not been investigated for carbon monoxide

detection below 70 PP .

Contents of This User Guide

1. Information About Carbon onoxide

2. Product Features and Specifications

3. Installation Locations

4. Installation Instructions

5. Alarm Characteristics

6. Operating Characteristics

7. aintenance

8. Limited Warranty

2551-7201-02_EN_V1.qxp__ 15-10-8 下午3:20 页 4

1. Information About Carbon onoxide

Gener l C rbon Monoxide Inform tion

Carbon monoxide is a colorless, odorless and tasteless poison gas that

can be fatal when inhaled. CO inhibits the blood’s capacity to carry

oxygen.

Periodically review this alarm user guide and discuss your CO alarm

emergency procedure with all the members of your family. Never ignore

a CO alarm. A true alarm is an indication of potentially dangerous levels

of CO. CO alarms are designed to alert you to the presence of CO

before an emergency – before most people would experience symptoms

of CO poisoning, giving you time to resolve the problem calmly.

Determine if anyone in the household is experiencing symptoms of CO

poisoning. Many cases of reported CO poisoning indicate that while

victims are aware they are not well, they become so disoriented they are

unable to save themselves by either exiting the building or calling for

assistance. Also, young children and household pets may be the first

affected. You should take extra precautions to protect high-risk persons

from CO exposure because they may experience ill effects from CO at

levels that would not ordinarily affect a healthy adult.

Symptoms of CO Poisoning

The following common symptoms are related to CO poisoning and

should be discussed with ALL members of the household.

ild Exposure:

Slight headache, nausea, vomiting, fatigue (often described as “flu-like”

symptoms).

edium Exposure:

Severe throbbing headache, drowsiness, confusion, fast heart rate.

Extreme Exposure:

Unconsciousness, convulsions, cardio-respiratory failure, death.

If you experience even mild symptoms of CO poisoning, consult your

doctor immediately!

2551-7201-02_EN_V1.qxp__ 15-10-8 下午3:20 页 5

1. Information About Carbon onoxide

C rbon Monoxide PPM Levels

Model KN-COP-DP-B is equipped with a digital display that shows levels

of CO (displayed in PPM – parts per million). Learn the difference

between dangerous, high, mid and low levels.

Dangerous Levels:

When someone is experiencing symptoms of CO poisoning and CO

readings are generally above 100 PPM. Anytime someone is experiencing

the symptoms of CO poisoning this should be treated as an emergency.

See “What to do When the Alarm Sounds” (inside front cover).

High Levels:

Generally above 100 PPM, with no one experiencing symptoms. This

should be treated as an urgent situation. See “What to do When the

Alarm Sounds” (inside front cover).

id Levels:

Generally between 50 PPM to 100 PPM. This should be cause for

concern and should not be ignored or dismissed. See “What to do

When the Alarm Sounds” (inside front cover).

Low Levels:

Generally below 50 PPM. Kidde recommends you take action to

eliminate the source of CO. See “What to do When the Alarm Sounds”

(inside front cover).

Possible Sources of C rbon Monoxide

Inside your home, appliances used for heating and cooking are the most

likely sources of CO. Vehicles running in attached garages can also

produce dangerous levels of CO.

CO can be produced when burning any fossil fuel, such as gasoline,

propane, natural gas, oil and wood. It can be produced by any fuel-

burning appliance that is malfunctioning, improperly installed, or not

ventilated correctly, such as:

• Automobiles, furnaces, gas ranges/stoves, gas clothes dryers, water

heaters, portable fuel burning space heaters and generators,

fireplaces, wood-burning stoves and certain swimming pool heaters.

• Blocked chimneys or flues, back drafts and changes in air pressure,

corroded or disconnected vent pipes, loose or cracked furnace

exchangers.

• Vehicles and other combustion engines running in an open or closed

garage, attached or near a home.

• Burning charcoal or fuel in grills and hibachis in an enclosed area.

2551-7201-02_EN_V1.qxp__ 15-10-8 下午3:20 页 6

1. Information About Carbon onoxide

Conditions Th t C n Produce C rbon Monoxide

The following conditions can result in transient CO situations:

• Excessive spillage or reverse venting of fuel-burning appliances caused

by outdoor ambient conditions, such as, wind direction and/or

velocity, including high gusts of wind, heavy air in the vent pipes

(cold/humid air with extended periods between cycles).

• Negative pressure resulting from the use of exhaust fans.

• Simultaneous operation of several fuel-burning appliances competing

for limited internal air.

• Vent pipe connections vibrating loose from clothes dryers, furnaces, or

water heaters.

• Obstructions in, or unconventional, vent pipe designs which can

amplify the above situations.

• Extended operation of unvented fuel-burning devices (range, oven,

fireplace, etc.).

• Temperature inversions which can trap exhaust gases near the ground.

• Vehicle idling in an open or closed garage, or near a home.

To be safe, know the possible sources of CO in your home. Keep fuel-

burning appliances and their chimneys and vents in good working

condition. Learn the early symptoms of exposure, and if you suspect CO

poisoning, move outside to fresh air and get emergency help. Your first

line of defense is an annual inspection and regular maintenance of your

appliances. Contact a licensed contractor or call your local utility

company for assistance.

Inform tion About C rbon Monoxide Al rms –

Wh t They C n nd C nnot Do:

CO alarms provide early warning of the presence of CO, usually before a

healthy adult would experience symptoms. This early warning is possible,

however, only if your CO alarm is located, installed and maintained as

described in this guide.

Because carbon monoxide is a cumulative poison, long-term exposures to low

levels may cause symptoms, as well as short-term exposures to high levels.

This Kidde unit has a time-weighted alarm – the higher the level of CO

present, the sooner the alarm will be triggered.

2551-7201-02_EN_V1.qxp__ 15-10-8 下午3:20 页 7

1. Information About Carbon onoxide

This CO alarm can only warn you of the presence of CO. It does not prevent

CO from occurring, nor can it solve an existing CO problem. If your unit has

alarmed and you’ve provided ventilation by leaving your windows and doors

open, the CO buildup may have dissipated by the time help responds.

Although your problem may appear to be temporarily solved, it’s crucial that

the source of the CO is determined and that the appropriate repairs are made.

This CO alarm is designed to act as a monitor; it is not designed for use as a

short-term testing device to perform a quick check for the presence of CO.

CO alarms have limitations. Like any other electronic device, CO alarms are

not fool-proof. CO alarms have a limited operational life. You must test your

CO alarm weekly, because it could fail to operate at any time.

If your CO alarm fails to test properly, or if its self-diagnostic test reveals a

malfunction, immediately have the unit replaced. This alarm will not monitor

CO levels while in an error condition.

CO alarms can only sense CO that reaches the unit’s sensor. It’s possible that

CO may be present in other areas without reaching the alarm. The rate and

ability that which CO reaches the alarm may be affected by:

• Doors or other obstructions.

• resh air from a vent, an open window or other source.

• CO being present on one level of the home and not reach a CO alarm

installed on a different level. ( or example, CO in the basement may not

reach an alarm on the second level, near the bedrooms).

or these reasons, we recommend you provide complete coverage by placing

a CO alarm on every level of the home. Please carefully read all information

on properly installing this CO alarm.

CO alarms should not be used to detect the presence of natural gas

(methane), propane, butane, or other combustible fuels.

2551-7201-02_EN_V1.qxp__ 15-10-8 下午3:20 页 8

2. Product Features and Specifications

odel KN-COP-DP-B

Rotating

AC plug

Peak

Le el

Low B ttery W rning

If the battery power is low, the unit will chirp every 60 seconds,

and the display will show "Lb" to indicate the batteries must be

replaced. THE BATTERIES UST BE REPLACED I EDIATELY!

Low B ttery HUSH®CONTROL

When the unit produces a low battery warning, the Low Battery

Hush®feature allows you to press the Test/Hush button on the alarm

and disable the “chirp” for a period of approximately 10 hours. This

gives you a chance to replace the batteries at a more convenient

time without sacrificing your safety by disconnecting the alarm from

power. During this Low Battery HUSH®period, your alarm is

monitoring for CO.

If the alarm does not go into Low Battery Hush, the battery power is

below the Low Battery Hush threshold. REPLACE THE BATTERIES

I EDIATELY!

Ambient Light Sensor

This alarm includes a feature to determine dark or light conditions.

This feature will;

1. Help prevent low battery chirping at night, (when ambient

conditions are dark).

2. Dim the display in low light conditions, (night time and darker

rooms), and brighten the display in bright light conditions.

Battery

Compartment

Alarm

Sounder

Test/Hush

Button

Red Alarm

Light

Green

Operate

Light /

Ambient

Light Sensor

Digital

Display

2551-7201-02_EN_V1.qxp__ 15-10-8 下午3:20 页 9

2. Product Features and Specifications

End of unit life W rning

I PORTANT: Ten (10) years after the initial power up, this alarm

will “beep” two times every 30 seconds to indicate that it is time

to replace the alarm. Display will show "End".

To help identify the date to replace the alarm, a label has been affixed to

the side of the alarm. Write the “replace by” date (ten years from power

up) in a permanent marker on this label.

End of unit life Hush Control

The End of unit Life Hush feature allows you to silence End of Unit life

chirping, for a period of 3 days, by pressing the Test/Hush button. This

feature can be used 10 times within 30 days, allowing you to replace

the alarm at a more convenient time. After 30 days, the alarm will no

longer detect CO. RELACE ALAR I EDIATELY!

Temperature:

Operating Range: 4.4°C (40° ) to 37.8°C (100° )

Humidity:

Operating range: 10-95% relative humidity, non-condensing

Audible Alarm:

85+ dB at 10’ @ 3.4±0.5 KHz pulsing alarm

Sensor:

Electrochemical

Power:

120 volts AC, 60 Hz, 90 mA max, AA battery back-up

Alarm Response Times:

70 PPM = 60-240 min., 150 PPM = 10-50 min., 400 PPM = 4-15 min.

2551-7201-02_EN_V1.qxp__ 15-10-8 下午3:20 页 10

Recommended Inst ll tion Loc tions

CO alarms should be mounted in or

near bedrooms and living areas. It is

recommended that you install a Kidde

CO alarm on each level of your home.

When choosing your installation

locations, make sure you can hear the

alarm from all sleeping areas. If you

install only one CO alarm in your home,

install it near bedrooms, not in the

basement or furnace room.

• The CO alarm plugs into a wall socket. Children must be taught not to

handle the CO alarm.

Loc tions To Avoid

I PORTANT: Improper location can affect the sensitive electronic

components in this alarm. To avoid causing damage to the unit, to provide

optimum performance, and to prevent unnecessary nuisance alarms:

• Do not install in kitchens, garages or furnace rooms that may expose the

sensor to substances that could damage or contaminate it.

• Do not install in areas where the temperature is colder than 4.4°C (40° )

or hotter than 37.8°C (100° ) such as crawl spaces, attics, porches and

garages.

• Do not install within 5 ft. of heating or cooking appliances. (Kidde

recommends 15 ft. to prevent nuisance alarms).

• Do not install near vents, flues, chimneys or any forced/unforced air

ventilation openings.

• Do not install near ceiling fans, doors, windows or areas directly exposed

to the weather.

• Do not install in dead air spaces, such as peaks of vaulted ceilings or

gabled roofs, where CO may not reach the sensor in time to provide early

warning.

• Do not install this unit near deep-cell large batteries. Large batteries have

emissions that can cause the alarm to perform at less than optimum

performance.

• Do not obstruct the vents located on the alarm. Do not place the alarm

where drapes, furniture or other objects block the flow of air to the vents.

3. Installation Locations

DINING KITCHEN BEDROOM BEDROOM

BEDROOM

LIVING ROOM

Recommended Locations

2551-7201-02_EN_V1.qxp__ 15-10-8 下午3:20 页 11

Table des matières

Autres manuels Kidde Système de sécurité

Kidde

Kidde KN-COEG-3 (900-01 13) Manuel utilisateur

Kidde

Kidde 8LLCO Manuel utilisateur

Kidde

Kidde KN-COB-IC-CA Manuel d'instructions

Kidde

Kidde ZP885 Instructions de montage

Kidde

Kidde KN-COP-DP-10YL-AQ-WF Manuel utilisateur

Kidde

Kidde KN-COB-LP2 Manuel utilisateur

Kidde

Kidde WFPCO Manuel utilisateur

Kidde

Kidde KN-COB-DP-H) Manuel utilisateur

Kidde

Kidde FireBeta XT+ Manuel utilisateur

Kidde

Kidde Slick 1SF23/9HI Instructions de montage

Kidde

Kidde 900-CUAR-VCA Manuel utilisateur

Kidde

Kidde Fyrnetics Slick 1SFW Manuel utilisateur

Kidde

Kidde KN-COB-DP2CA Manuel utilisateur

Kidde

Kidde KN-COPE-DCA Manuel utilisateur

Kidde

Kidde P4010ACSCOAQ-WF Manuel utilisateur

Kidde

Kidde 4MCO Manuel utilisateur

Kidde

Kidde K5CO Instructions d'utilisation

Kidde

Kidde KF30 Manuel utilisateur

Kidde

Kidde P4010ACSCO-WF Manuel utilisateur

Kidde

Kidde 2030-DCR Instructions d'utilisation

Kidde

Kidde 7CO Manuel utilisateur

Kidde

Kidde P4010ACSCOAQ-WF Manuel utilisateur

Kidde

Kidde KN-COPP-B-LS Manuel utilisateur

Kidde

Kidde 4MCO Manuel utilisateur

Manuels Système de sécurité populaires d'autres marques

Inner Range

Inner Range Concept 2000 Manuel utilisateur

Climax

Climax Mobile Lite R32 Instructions de montage

CADDX

CADDX NX-6 Manuel utilisateur

FBII

FBII XL-31 Series Manuel utilisateur

Johnson Controls

Johnson Controls PENN Connected PC10 Manuel utilisateur

Aeotec

Aeotec Siren Gen5 Manuel utilisateur

Blaupunkt

Blaupunkt SA 2700 Manuel utilisateur

IDEAL

IDEAL Accenta Manuel du propriétaire

AJAX

AJAX DoubleButton Manuel utilisateur

Swann

Swann SW-P-MC2 Manuel utilisateur

Ecolink

Ecolink Siren+Chime Manuel utilisateur

Digital Monitoring Products

Digital Monitoring Products XR150 Manuel utilisateur

EDM

EDM Solution 6+6 Wireless-AE Manuel utilisateur

Highway Safety Group

Highway Safety Group EA401 Manuel utilisateur

Siren

Siren LED GSM Manuel utilisateur

Detection Systems

Detection Systems 7090i Instructions de montage

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manuel utilisateur

Siemens

Siemens FDM273 Manuel utilisateur
