Kidde KN-COB-IC Manuel utilisateur

Manual P/N 820-1685 Rev B 10/12 2512-7213-00

ATTENTION: Please take a few minutes to thoroughly read this

user’s guide which should be saved for future reference and

passed on to any subsequent owner.

Carbon Monoxide Alarm

User’s Guide

Models: KN-COB-IC and KN-COP-IC

KN-COB-IC

KN-COP-IC

with Digital Display

• 120V AC Wire-In

• 9V Battery Backup

• Interconnectable with other Kidde alarms

820-1685B_10Y_V2:_ 2012.9.14 10:25 AM Page 1

Welcome

Note: Many times throughout this User’s Guide, we will refer to

Carbon Monoxide as “CO”.

This Kidde carbon monoxide (CO) alarm is an important part of your

family’s home safety plan. This alarm has been designed and tested to

detect CO buildup in a residential environment. Your alarm is for use

specifically in the home. As an owner of a CO alarm, there are some

basic facts you should know about for your protection.

Many people think that CO alarms operate like smoke alarms. Like

smoke alarms, CO alarms monitor the air in your home and sound a

loud alarm to warn you of trouble. The way you respond to a CO alarm

is quite different than a smoke alarm. That’s because a house fire and a

CO problem are two distinctly different situations. If your smoke alarm

were to alarm, you would quickly be able to judge the level of danger

you were in with your senses. You can see and smell the smoke, feel the

heat, see, and possibly hear the fire burning. You can also readily see if

your smoke alarm is alarming in a non-emergency situation. Because

your sense of sight, smell, hearing and touch give you information, you

can almost instantly judge what action to take if you hear your smoke

alarm.

CO is an invisible, odorless, tasteless and non-irritating gas – completely

undetectable to your senses. That’s why it is important to your safety

that you have a CO alarm.

Important Warning Statements

IMPORTANT: This carbon monoxide alarm is designed to detect

carbon monoxide from ANY source of combustion. It is NOT

designed to detect smoke, fire, or any other gas.

WARNING: Carbon monoxide alarms are not smoke alarms.

This carbon monoxide alarm is not a substitute for installing and

maintaining an appropriate number of smoke alarms in your

home.

This carbon monoxide alarm will not sense smoke, fire, or any

poisonous gas other than carbon monoxide even though carbon

monoxide can be generated by fire. For this reason you must

install smoke alarms to provide early warning of fire and to pro-

tect you and your family from fire and its related hazards.

CAUTION: This alarm will only indicate the presence of carbon

monoxide at the sensor. Carbon monoxide may be present in

other areas.

820-1685B_10Y_V2:_ 2012.9.14 10:25 AM Page 3

Important Warning Statements

WARNING: This product is intended for use in ordinary

indoor locations of family living units. It is not designed to

measure compliance with Occupational Safety and Health

Administration (OSHA), commercial or industrial standards. It is

not suitable for installation in hazardous locations as defined in

the National Electric Code.

The installation of this device should not be used as a substitute

for proper installation, use and maintenance of fuel burning

appliances, including appropriate ventilation and exhaust sys-

tems. It does not prevent CO from occurring, nor can it solve an

existing CO problem.

WARNING: This device is designed to protect individuals from

acute effects of carbon monoxide exposure. It may not fully safe-

guard individuals with specific medical conditions. If in doubt,

consult a medical practitioner.

Individuals with medical problems may consider using warning

devices which provide audible and visual signals for carbon

monoxide concentrations under 30 PPM.

This carbon monoxide alarm requires a continuous supply of elec-

trical power – it will not work without power. Models without

battery backup will not operate during power failure.

This alarm has not been investigated for carbon monoxide detec-

tion below 70 PPM.

Contents of This User’s Guide

1. Information About Carbon Monoxide

2. Product Features and Specifications

3. Installation Locations

4. Installation Instructions

5. Alarm Characteristics

6. KN-COB-IC Operating Characteristics

7. KN-COP-IC (with digital display) Operating Characteristics

8. Maintenance

9. Limited Warranty

820-1685B_10Y_V2:_ 2012.9.14 10:25 AM Page 4

1. Information About Carbon Monoxide

General Carbon Monoxide Information

Carbon monoxide is a colorless, odorless and tasteless poison gas that

can be fatal when inhaled. CO inhibits the blood’s capacity to carry oxy-

gen.

Periodically review this user's guide and discuss your CO alarm emer-

gency procedure with all the members of your family. Never ignore a CO

alarm. A true alarm is an indication of potentially dangerous levels of

CO. CO alarms are designed to alert you to the presence of CO before

an emergency – before most people would experience symptoms of CO

poisoning, giving you time to resolve the problem calmly.

Determine if anyone in the household is experiencing symptoms of CO

poisoning. Many cases of reported CO poisoning indicate that while

victims are aware they are not well, they become so disoriented they are

unable to save themselves by either exiting the building or calling for

assistance. Also, young children and household pets may be the first

affected. You should take extra precautions to protect high-risk persons

from CO exposure because they may experience ill effects from CO at

levels that would not ordinarily affect a healthy adult.

Symptoms of CO Poisoning

The following common symptoms are related to CO poisoning and

should be discussed with ALL members of the household.

Mild Exposure:

Slight headache, nausea, vomiting, fatigue (often described as

“flu-like” symptoms).

Medium Exposure:

Severe throbbing headache, drowsiness, confusion, fast heart rate.

Extreme Exposure:

Unconsciousness, convulsions, cardio-respiratory failure, death.

If you experience even mild symptoms of CO poisoning, consult your

doctor immediately!

820-1685B_10Y_V2:_ 2012.9.14 10:25 AM Page 5

1. Information About Carbon Monoxide

Carbon Monoxide PPM Levels

(model KN-COP-IC with digital display only)

Model KN-COP-IC is equipped with a digital display that shows levels of

CO (displayed in PPM – parts per million). Learn the difference between

dangerous, high, mid and low levels.

Dangerous Levels:

When someone is experiencing symptoms of CO poisoning and CO

readings are generally above 100 PPM. Anytime someone is experiencing

the symptoms of CO poisoning this should be treated as an emergency.

See “What to do When the Alarm Sounds” (inside front cover).

High Levels:

Generally above 100 PPM, with no one experiencing symptoms. This

should be treated as an urgent situation. See “What to do When the

Alarm Sounds” (inside front cover).

Mid Levels:

Generally between 50 PPM to 100 PPM. This should be cause for

concern and should not be ignored or dismissed. See “What to do

When the Alarm Sounds” (inside front cover).

Low Levels:

Generally below 50 PPM. Kidde recommends you take action to

eliminate the source of CO. See “What to do When the Alarm Sounds”

(inside front cover).

IMPORTANT: Model KN-COB-IC does not have a digital display and

does not display carbon monoxide levels in PPM. If the alarm

sounds, it should be treated as a potentially serious condition. See

“What to do When the Alarm Sounds” (inside front cover).

Possible Sources of Carbon Monoxide

Inside your home, appliances used for heating and cooking are the most

likely sources of CO. Vehicles running in attached garages can also

produce dangerous levels of CO.

CO can be produced when burning any fossil fuel, such as gasoline,

propane, natural gas, oil and wood. It can be produced by any fuel-

burning appliance that is malfunctioning, improperly installed, or not

ventilated correctly, such as:

• Automobiles, furnaces, gas ranges/stoves, gas clothes dryers, water

heaters, portable fuel burning space heaters and generators,

fireplaces, wood-burning stoves and certain swimming pool heaters.

820-1685B_10Y_V2:_ 2012.9.14 10:25 AM Page 6

1. Information About Carbon Monoxide

• Blocked chimneys or flues, back drafts and changes in air pressure,

corroded or disconnected vent pipes, loose or cracked furnace

exchangers.

• Vehicles and other combustion engines running in an open or closed

garage, attached or near a home.

• Burning charcoal or fuel in grills and hibachis in an enclosed area.

Conditions That Can Produce Carbon Monoxide

The following conditions can result in transient CO situations:

• Excessive spillage or reverse venting of fuel-burning appliances caused

by outdoor ambient conditions, such as, wind direction and/or veloci-

ty, including high gusts of wind, heavy air in the vent pipes

(cold/humid air with extended periods between cycles).

• Negative pressure resulting from the use of exhaust fans.

• Simultaneous operation of several fuel-burning appliances competing

for limited internal air.

• Vent pipe connections vibrating loose from clothes dryers, furnaces, or

water heaters.

• Obstructions in, or unconventional, vent pipe designs which can

amplify the above situations.

• Extended operation of unvented fuel-burning devices (range, oven,

fireplace, etc.).

• Temperature inversions which can trap exhaust gases near the ground.

• Vehicle idling in an open or closed garage, or near a home.

To be safe, know the possible sources of CO in your home. Keep fuel-

burning appliances and their chimneys and vents in good working condi-

tion. Learn the early symptoms of exposure, and if you suspect CO poi-

soning, move outside to fresh air and get emergency help. Your first line

of defense is an annual inspection and regular maintenance of your

appliances. Contact a licensed contractor or call your local utility compa-

ny for assistance.

Information About Carbon Monoxide Alarms –

What They Can and Cannot Do:

CO alarms provide early warning of the presence of CO, usually before a

healthy adult would experience symptoms. This early warning is possible,

however, only if your CO alarm is located, installed and maintained as

described in this guide.

820-1685B_10Y_V2:_ 2012.9.14 10:25 AM Page 7

1. Information About Carbon Monoxide

Because carbon monoxide is a cumulative poison, long-term exposures

to low levels may cause symptoms, as well as short-term exposures to

high levels. This Kidde unit has a time-weighted alarm – the higher the

level of CO present, the sooner the alarm will be triggered.

This CO alarm can only warn you of the presence of CO. It does not

prevent CO from occurring, nor can it solve an existing CO problem. If

your unit has alarmed and you’ve provided ventilation by leaving your

windows and doors open, the CO buildup may have dissipated by the

time help responds. Although your problem may appear to be

temporarily solved, it’s crucial that the source of the CO is determined

and that the appropriate repairs are made.

This CO alarm is designed to act as a monitor; it is not designed for use

as a short-term testing device to perform a quick check for the presence

of CO.

CO alarms have limitations. Like any other electronic device, CO alarms

are not fool-proof. CO alarms have a limited operational life. You must

test your CO alarm weekly, because it could fail to operate at any time.

If your CO alarm fails to test properly, or if its self-diagnostic test reveals

a malfunction, immediately have the unit replaced. This alarm will not

monitor CO levels while in an error condition.

CO alarms can only sense CO that reaches the unit’s sensor. It’s possible

that CO may be present in other areas without reaching the alarm. The

rate and ability that which CO reaches the alarm may be affected by:

• Doors or other obstructions.

• Fresh air from a vent, an open window or other source.

• CO being present on one level of the home and not reach a CO alarm

installed on a different level. (For example, CO in the basement may

not reach an alarm on the second level, near the bedrooms).

For these reasons, we recommend you provide complete coverage by

placing a CO alarm on every level of the home. Please carefully read all

information in sections 2 and 3 on properly installing this CO alarm.

CO alarms should not be used to detect the presence of natural gas

(methane), propane, butane, or other combustible fuels.

Instruct children never to touch, unplug or otherwise interfere with the

alarm. Warn children of the dangers of CO poisoning.

820-1685B_10Y_V2:_ 2012.9.14 10:25 AM Page 8

2. Product Features and Specifications

Red,

Alarm LED

Green,

Power LED

Amber, Initiating

Alarm LED

AC Connector

Pins

Tamper Resist

Feature

Battery

Compartment

Test/Reset

Button

Red,

Alarm

LED

Green,

Power LED

Amber, Initiating

Alarm LED

Peak Level

Button

Test/Reset Button

Digital

Display

IMPORTANT: Ten (10) years after the initial power up, this alarm

will “beep” two times every 30 seconds to indicate that it is time

to replace the alarm. Replace the alarm immediately! It will not

detect CO in this condition. See Maintenance Section for more

information regarding End of Life Notification.

To help identify the date to replace the alarm, a label has been affixed to

the side of the alarm. Write the “replace by” date (ten years from power

up) in a permanent marker on this label.

Model KN-COB-IC

Model KN-COP-IC

with digital display

820-1685B_10Y_V2:_ 2012.9.14 10:25 AM Page 9

Temperature:

Operating Range: 40°F (4.4°C) to 100°F (37.8°C)

Humidity:

Operating range: 10-95% non-condensing

Audible Alarm:

85+ dB at 10’ @ 3.4±0.5 KHz pulsing alarm

Sensor:

Electrochemical

Power:

120 volts AC, 60 Hz, 60 mA max, 9 volt battery back-up

Accuracy of Digital Display (Model KN-COP-IC only):

30-999 PPM +/-30% when measured in conditions of 80° F (+/- 10° F),

atmospheric pressure +/- 10% and 40% +/- 3% relative humidity.

Display readings may vary slightly depending on changes in the ambient

condition (temperature, humidity) and the condition of the sensor.

Alarm Response Times:

70 PPM = 60-240 min., 150 PPM = 10-50 min., 400 PPM = 4-15 min.

Interconnection with Other Alarms:

This Kidde CO alarm can be used as a single-station alarm or intercon-

nected with other Kidde alarms. This alarm can be interconnected direct-

ly with these Kidde models:

Ion smoke alarm models:

1235, 1235CA, 1275, 1275CA, 1276,1276CA, 1285, 1285CA,

i12020, i12040, i12060, i12080, i12020CA, i12040CA, i12060CA

Photo smoke alarm models:

PE120, PE120CA,

Photo Ion combination alarms:

PI2010, PI2010CA

Heat alarm models:

HD135F, HD135FCA

Carbon monoxide/Ion smoke alarm models:

KN-COSM-IB, KN-COSM-IBCA

Carbon monoxide alarm models:

KN-COB-IC, KN-COP-IC, KN-COB-ICB, KN-COP-ICB

Relay models:

CO120X, SM120X

Strobe Light models:

SL177I

2. Product Features and Specifications

820-1685B_10Y_V2:_ 2012.9.14 10:25 AM Page 10

Recommended Installation Locations

CO alarms should be mounted in or

near bedrooms and living areas. It is

recommended that you install a Kidde

CO alarm on each level of your home.

When choosing your installation loca-

tions, make sure you can hear the

alarm from all sleeping areas. If you

install only one CO alarm in your

home, install it near bedrooms, not in the basement or furnace room.

• When wall mounting, place out of reach of children. Under no cir-

cumstances should children be allowed to handle the CO alarm.

• Placing the alarm at eye level allows for optimum monitoring of the

digital display.

Locations To Avoid

IMPORTANT: Improper location can affect the sensitive electronic com-

ponents in this alarm. To avoid causing damage to the unit, to provide

optimum performance, and to prevent unnecessary nuisance alarms:

• Do not install in kitchens, garages or furnace rooms that may expose

the sensor to substances that could damage or contaminate it.

• Do not install in areas where the temperature is colder than 40°F

(4.4°C) or hotter than 100°F (37.8°C) such as crawl spaces, attics,

porches and garages.

• Do not install within 5 ft. of heating or cooking appliances. (Kidde

recommends 15 ft. to prevent nuisance alarms).

• Do not install near vents, flues, chimneys or any forced/unforced air

ventilation openings.

• Do not install near ceiling fans, doors, windows or areas directly

exposed to the weather.

• Do not install in dead air spaces, such as peaks of vaulted ceilings or

gabled roofs, where CO may not reach the sensor in time to provide

early warning.

• Do not install on a switched or dimmer-controlled outlet.

• Do not install this unit near deep-cell large batteries. Large batteries

have emissions that can cause the alarm to perform at less than opti-

mum performance.

3. Installation Locations

Recommended Locations

820-1685B_10Y_V2:_ 2012.9.14 10:25 AM Page 11

Autres manuels pour KN-COB-IC

Table des matières

Autres manuels Kidde Système de sécurité

Kidde

Kidde WFPCO Manuel utilisateur

Kidde

Kidde 10LLDCO Manuel utilisateur

Kidde

Kidde Fyrnetics Slick 1SFW Manuel utilisateur

Kidde

Kidde SLED177iCA Manuel utilisateur

Kidde

Kidde P4010ACSCO-WF Manuel utilisateur

Kidde

Kidde 4MCO Manuel utilisateur

Kidde

Kidde KF30 Manuel utilisateur

Kidde

Kidde KN-COPE-D Manuel utilisateur

Kidde

Kidde KN-COP-DP-10YB Manuel utilisateur

Kidde

Kidde P4010ACSCOAQ-WF Manuel utilisateur

Kidde

Kidde 2030-DCR Instructions d'utilisation

Kidde

Kidde 4MCO Manuel utilisateur

Kidde

Kidde Truesense Combo Manuel utilisateur

Kidde

Kidde SLED177i Manuel utilisateur

Kidde

Kidde KN-COB-LP2 Manuel utilisateur

Kidde

Kidde KN-COB-IC-CA Manuel d'instructions

Kidde

Kidde SLICK RF-SFTP Manuel utilisateur

Kidde

Kidde KN-COPE-DCA Manuel utilisateur

Kidde

Kidde 123I Instructions de montage

Kidde

Kidde K5CO Instructions d'utilisation

Kidde

Kidde KF10 Manuel utilisateur

Kidde

Kidde ZP885 Instructions de montage

Kidde

Kidde KN-COB-B Manuel utilisateur

Kidde

Kidde KN-COB-IC Manuel utilisateur

Manuels Système de sécurité populaires d'autres marques

Inner Range

Inner Range Concept 2000 Manuel utilisateur

Climax

Climax Mobile Lite R32 Instructions de montage

CADDX

CADDX NX-6 Manuel utilisateur

FBII

FBII XL-31 Series Manuel utilisateur

Johnson Controls

Johnson Controls PENN Connected PC10 Manuel utilisateur

Aeotec

Aeotec Siren Gen5 Manuel utilisateur

Blaupunkt

Blaupunkt SA 2700 Manuel utilisateur

IDEAL

IDEAL Accenta Manuel du propriétaire

AJAX

AJAX DoubleButton Manuel utilisateur

Swann

Swann SW-P-MC2 Manuel utilisateur

Ecolink

Ecolink Siren+Chime Manuel utilisateur

Digital Monitoring Products

Digital Monitoring Products XR150 Manuel utilisateur

EDM

EDM Solution 6+6 Wireless-AE Manuel utilisateur

Highway Safety Group

Highway Safety Group EA401 Manuel utilisateur

Siren

Siren LED GSM Manuel utilisateur

Detection Systems

Detection Systems 7090i Instructions de montage

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manuel utilisateur

Siemens

Siemens FDM273 Manuel utilisateur
