Keysight Technologies X Series Manuel utilisateur

Functional

Tests

Keysight X-Series Signal Analyzers

This manual provides documentation for the following

Analyzers:

PXA Signal Analyzer N9030A

Notices

2006-2015

No part of this manual may be

reproduced in any form or by any

means (including electronic storage

and retrieval or translation into a

foreign language) without prior

agreement and written consent from

Keysight Technologies, Inc. as

governed by United States and

international copyright laws.

Trademark Acknowledgments

Manual Part Number

N9030-90018

Print Date

January 2015

Published in USA

Keysight Technologies

1400 Fountaingrove Parkway

Santa Rosa, CA 95403

Warranty

THE MATERIAL CONTAINED IN THIS

DOCUMENT IS PROVIDED “AS IS,”

AND IS SUBJECT TO BEING

CHANGED, WITHOUT NOTICE, IN

FUTURE EDITIONS. FURTHER, TO

THE MAXIMUM EXTENT PERMITTED

BY APPLICABLE LAW, KEYSIGHT

DISCLAIMS ALL WARRANTIES,

EITHER EXPRESS OR IMPLIED WITH

REGARD TO THIS MANUAL AND

ANY INFORMATION CONTAINED

HEREIN, INCLUDING BUT NOT

LIMITED TO THE IMPLIED

WARRANTIES OF

MERCHANTABILITY AND FITNESS

FOR A PARTICULAR PURPOSE.

KEYSIGHT SHALL NOT BE LIABLE

FOR ERRORS OR FOR INCIDENTAL

OR CONSEQUENTIAL DAMAGES IN

CONNECTION WITH THE

FURNISHING, USE, OR

PERFORMANCE OF THIS

DOCUMENT OR ANY INFORMATION

CONTAINED HEREIN. SHOULD

KEYSIGHT AND THE USER HAVE A

SEPARATE WRITTEN AGREEMENT

WITH WARRANTY TERMS

COVERING THE MATERIAL IN THIS

DOCUMENT THAT CONFLICT WITH

THESE TERMS, THE WARRANTY

TERMS IN THE SEPARATE

AGREEMENT WILL CONTROL.

Technology Licenses

The hardware and/or software

described in this document are

furnished under a license and may be

used or copied only in accordance

with the terms of such license.

Restricted Rights Legend

If software is for use in the

performance of a U.S. Government

prime contract or subcontract,

Software is delivered and licensed as

“Commercial computer software” as

defined in DFAR 252.227-7014 (June

1995), or as a “commercial item” as

defined in FAR 2.101(a) or as

“Restricted computer software” as

defined in FAR 52.227-19 (June

1987) or any equivalent agency

regulation or contract clause. Use,

duplication or disclosure of Software

is subject to Keysight Technologies’

standard commercial license terms,

and non-DOD Departments and

Agencies of the U.S. Government will

receive no greater than Restricted

Rights as defined in FAR

52.227-19(c)(1-2) (June 1987). U.S.

Government users will receive no

greater than Limited Rights as

defined in FAR 52.227-14 (June

1987) or DFAR 252.227-7015 (b)(2)

(November 1995), as applicable in

any technical data.

Safety Notices

CAUTION

A CAUTION notice denotes a hazard. It

calls attention to an operating

procedure, practice, or the like that,

if not correctly performed or adhered

to, could result in damage to the

product or loss of important data. Do

not proceed beyond a CAUTION

notice until the indicated conditions

are fully understood and met.

WARNING

A WARNING notice denotes a hazard.

It calls attention to an operating

procedure, practice, or the like that,

if not correctly performed or adhered

to, could result in personal injury or

death. Do not proceed beyond a

WARNING notice until the indicated

conditions are fully understood and

met.

Where to Find the Latest Information

Documentation is updated periodically. For the latest information about these products, including instrument software

upgrades, application information, and product information, browse to one of the following URLs, according to the name

of your product:

http://www.keysight.com/find/pxa

To receive the latest updates by email, subscribe to Keysight Email Updates at the following URL:

http://www.keysight.com/find/MyKeysight

Information on preventing analyzer damage can be found at:

www.keysight.com/find/PreventingInstrumentRepair

Is your product software up-to-date?

Periodically, Keysight releases software updates to fix known defects and incorporate product enhancements. To search

for software updates for your product, go to the Keysight Technical Support website at:

http://www.keysight.com/find/techsupport

Contents

Table of Contents

1. Functional Tests

Functional Test Versus Performance Verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Contents of this Document. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Before Performing a Functional Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Test Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2. Displayed Average Noise Level (DANL)

Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

3. Frequency Readout Accuracy

Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

4. Second Harmonic Distortion (SHD)

Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

5. Amplitude Accuracy at 50 MHz

Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Testing Preamp Option (P03, P08, P13, P26, P43, P44, P50) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

6. Frequency Response (Flatness)

Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

7. Frequency Response (Flatness), Preamp On

Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

8. Scale Fidelity

Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

9. BBIQ Input Frequency Response

(Option BBA only)

Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Contents

Keysight X-Series Signal Analyzers

PXA N9030A

Functional Tests

1 Functional Tests

Functional tests are tests of various instrument parameters that give a high

degree of confidence that the analyzer is operating correctly. They are

recommended as a check of analyzer operation for incoming inspection or after

a repair. Measurement uncertainty analysis is not available for functional tests,

and the analyzer is checked against limits that are wider than the published

specifications. The functional tests are designed to test an analyzer operating

within the temperature range defined by the analyzer specifications using a

minimum set of test equipment. If a test does not pass, performance

verification tests must be run to determine whether a problem exists.

4 Chapter 1

Functional Tests

Functional Test Versus Performance Verification

Functional tests use a minimum set of test equipment to check a much smaller

range of parameters (and a limited number of data points for each parameter)

than do performance verification tests. Functional tests use limits that are

wider than the published specifications; measurement uncertainty analysis is

not available for functional tests.

NOTE If a functional test does not pass, you must run performance verification tests

to determine whether a problem exists.

Performance verification tests span a wide range of instrument parameters and

provide the highest level of confidence that the instrument conforms to

published specifications. These tests can be time consuming and require

extensive test equipment.

Chapter 1 5

Functional Tests

Contents of this Document

This chapter includes the following:

—“Before Performing a Functional Test” on page 6 (what to do first).

—“Test Equipment” on page 7 (a list of the equipment required for all of the

tests).

Subsequent chapters describe the following Functional Tests:

—“Displayed Average Noise Level (DANL)” on page 11

—“Frequency Readout Accuracy” on page 15

—“Second Harmonic Distortion (SHD)” on page 19

—“Amplitude Accuracy at 50 MHz” on page 23

—“Frequency Response (Flatness)” on page 29

—“Frequency Response (Flatness), Preamp On” on page 35

—“Scale Fidelity” on page 41

Each functional test includes:

— Test limits (pass/fail criteria)

— A description of the test

— The equipment required for the test

— A figure showing how to connect the equipment

— Step-by-step instructions

— One or more tables in which to record the measurement results

6 Chapter 1

Functional Tests

Before Performing a Functional Test

1. Ensure that you have the proper test equipment.

2. Switch on the unit under test (UUT) and let it warm up (in accordance with

warm-up requirements in the instrument specifications).

3. Allow sufficient warm-up time for the required test equipment (refer to

individual instrument documentation for warm-up specifications).

4. Ensure that the analyzer’s frequency reference is set to Internal:

a. Press the Input/Output, More, Freq Ref In keys.

b. If the Freq Ref In softkey does not show Internal, press the Freq Ref

In softkey and select Internal.

5. Following instrument warm-up, perform the auto align routine:

Press System, Alignments, Align Now, All.

NOTE Functional test accuracy depends on the precision of the test equipment

used. Ensure that all of the test equipment is calibrated before running a

functional test.
