Keysight Technologies M9485A Guide de l'utilisateur

Startup Guide

Keysight M9485A PXIe

Multiport Vector Network

Analyzer

M9300A, Frequency Reference

M9389A, PXIe Vector Network Analyzer Source

M9309A, PXIe Vector Network Analyzer Synthesizer

M9340A, PXIe Vector Network Analyzer RF Distributor

M9376A, PXIe Vector Network Analyzer Receiver

M9377A, PXIe Vector Network Analyzer Direct Access Receiver

M9378A/B, PXIe Vector Network Analyzer Directional Coupler

Notices

2015-2016

No part of this manual may be

reproduced in any form or by any

means (including electronic storage

and retrieval or translation into a

foreign language) without prior

agreement and written consent from

Keysight Technologies, Inc. as

governed by United States and

international copyright laws.

Trademark Acknowledgments

Manual Part Number

M9485-90020

Print Date

November, 2016

Published in Malaysia

Published by

Keysight Technologies

International Japan G.K,

1-3-3 Higashikawasaki-cho

Chuo-ku

Kobe-shi, Hyogo, Japan

Warranty

THE MATERIAL CONTAINED IN THIS

DOCUMENT IS PROVIDED “AS IS,”

AND IS SUBJECT TO BEING

CHANGED, WITHOUT NOTICE, IN

FUTUREEDITIONS.FURTHER,TOTHE

MAXIMUM EXTENT PERMITTED BY

APPLICABLE LAW, KEYSIGHT

DISCLAIMS ALL WARRANTIES,

EITHER EXPRESS OR IMPLIED WITH

REGARD TO THIS MANUAL AND ANY

INFORMATION CONTAINED HEREIN,

INCLUDINGBUTNOTLIMITEDTOTHE

IMPLIED WARRANTIES OF

MERCHANTABILITY AND FITNESS

FOR A PARTICULAR PURPOSE.

KEYSIGHTSHALL NOT BE LIABLEFOR

ERRORS OR FOR INCIDENTAL OR

CONSEQUENTIAL DAMAGES IN

CONNECTION WITH THE

FURNISHING, USE, OR

PERFORMANCE OF THIS DOCUMENT

OR ANY INFORMATION CONTAINED

HEREIN.SHOULDKEYSIGHTANDTHE

USER HAVE A SEPARATE WRITTEN

AGREEMENT WITH WARRANTY

TERMS COVERING THE MATERIAL IN

THIS DOCUMENT THAT CONFLICT

WITHTHESETERMS,THEWARRANTY

TERMS IN THE SEPARATE

AGREEMENT WILL CONTROL.

Technology Licenses

The hardware and/or software

described in this document are

furnished under a license and may be

used or copied only in accordance

with the terms of such license.

Restricted Rights Legend

If software is for use in the

performance of a U.S. Government

prime contract or subcontract,

Software is delivered and licensed as

“Commercial computer software” as

defined in DFAR 252.227-7014 (June

1995), or as a “commercial item” as

defined in FAR 2.101(a) or as

“Restricted computer software” as

definedinFAR52.227-19(June1987)

oranyequivalentagencyregulationor

contract clause. Use, duplication or

disclosure of Software is subject to

Keysight Technologies’ standard

commercial license terms, and

non-DOD Departments and Agencies

oftheU.S.Governmentwillreceiveno

greater than Restricted Rights as

defined in FAR 52.227-19(c)(1-2)

(June 1987). U.S. Government users

will receive no greater than Limited

Rights as defined in FAR 52.227-14

(June 1987) or DFAR 252.227-7015

(b)(2)(November1995),asapplicable

in any technical data.

Safety Notices

CAUTION

ACAUTIONnoticedenotesahazard.It

calls attention to an operating

procedure,practice,orthe like that, if

notcorrectlyperformedoradheredto,

couldresultindamage to theproduct

or loss of important data. Do not

proceed beyond a CAUTION notice

untiltheindicatedconditionsarefully

understood and met.

WARNING

A WARNING notice denotes ahazard.

It calls attention to an operating

procedure,practice,orthe like that, if

notcorrectlyperformedoradheredto,

could result in personal injury or

death. Do not proceed beyond a

WARNING notice until the indicated

conditions are fully understood and

met.

Contents

1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Getting Started

Introduction 5

Related Documentation

You can find all M9485A PXIe network analyzer module documentation and

other resources at: http://www.keysight.com/find/m9485A 

or at the respective product pages on www.keysight.com (go to Document

Library > Manuals).

Getting Started

STEP 1. Unpack and Inspect the Network Analyzer Modules

CAUTION Thenetworkanalyzermodulesareshippedinmaterialswhichpreventdamagefromstatic.

The modules should only be removed fromthe packaging in an anti-static area ensuring

that correct anti-static precautions aretaken. Store all modules in anti-static envelopes

when not in use.

Electrostatic discharge (ESD) can damage or destroy electronic components.

Use a static-safe work station to perform all work on electronic assemblies.

Figure 1-1 shows a static-safe work station using two types of ESD protection:

conductive table-mat and wrist-strap combination, and conductive floor-mat

and heel-strap combination. Both types, when used together, provide a

significant level of ESD protection. Of the two, only the table-mat and

wrist-strap combination provides adequate ESD protection when used alone.

To ensure user safety, the static-safe accessories must provide at least 1

meg-ohm of isolation from ground.

WARNING DoNOT usethese techniquesfora static-safeworkstation whenworkingoncircuitrywith

a voltage potential greater than 500 volts.

Figure 1-1 ESD protection setup

Getting Started

STEP 1. Unpack and Inspect the Network Analyzer Modules

Unpack the network analyzer modules from the shipping containers. Keep the

black plastic port protector and the shipping containers for possible reuse.

Inspect for Damage

After unpacking a network analyzer module, inspect it for any shipping

damage. Report any damage to the shipping agent immediately, as such

damage is not covered by the warranty.

CAUTION To avoid damage when handling the network analyzer modules, do not touch exposed

connector pins.

How to Return an Instrument for Service

Should it become necessary to return a network analyzer module for repair or

service, follow the steps below:

1. Review the warranty information shipped with your product.

2. Contact Keysight to obtain a Return Material Authorization (RMA) and

return address. For assistance finding Keysight contact information, go to

www.keysight.com/find/assist (worldwide contact information for repair

and service).

3. Write the following information on a tag and attach it to the network

analyzer module:

• Name and address of owner. A P.O. box is not acceptable as a return

address.

• Network analyzer module serial numbers. The serial number label is

located on the side panel of the module. The serial number can also be

read from the Soft Front Panel (SFP) interface, after the hardware is

installed.

• Description of the service required or the failure.

4. On the shipping label, write ATTENTION REPAIR DEPARTMENT and the

RMA number.

5. Ship the analyzer module using the original packaging materials. Shipping

the analyzer module in anything other than the original packaging may

result in non-warranted damage.

NOTE In your correspondence, refer to the network analyzer module by serial number and by

model number.

Getting Started

STEP 2. Check the Shipment

The M9485A consists of several modules, cables and dividers. Use the

Contents List in the shipping container to verify the completeness of your

shipment. If not complete, refer to “Contacting Keysight” on page 44.

Getting Started

STEP 3. Install the Network Analyzer Modules

NOTE These modules can be used in a chassis with a PXIe, or PXI-H chassis slots.

Recommended Best Practices to Ensure Proper and Safe Module Operating

Conditions

• Ensure proper chassis air flow is maintained.

• The use of a Keysight M9018A chassis is recommended for optimum

temperature control. If a different chassis is used, make sure it provides

thermal protection if fans become inoperable or forced air cooling is

obstructed.

— If using the Keysight M9018A PCIe Cable Interface, download the

Keysight Multiple PXIe and AXIe Chassis System Configuration Tool.

Save the file to your local hard drive; do not try to open the file from the

Internet location.

• Use slot blockers and EMC filler panels in empty module slots to ensure

proper operating temperatures. Keysight chassis and slot blockers optimize

module temperature performance and reliability of test.

• Set chassis fans to high or auto. Do not disable fans.

• Position chassis to allow plenty of space around chassis air intake and fan

exhaust.

• At ambient temperatures above 45° C (113° F) set the chassis fan to high.

Figure 1-2 M9485A chassis air flow

Tools Required for the Installation Procedure

• Phillips #1 torque driver, set to 4 in-lb (0.45 N.m) - not supplied.

Getting Started

STEP 3. Install the Network Analyzer Modules

• Socket adapter (part number M9485-23001) - supplied.

• Torque driver (for use with socket adapter), set to 8 in-lb (0.91 N.m) - not

supplied.

• Cable removal tool (part number 5002-3361) - supplied.

• Torque Wrench for SMA, set to 8 in-lb (0.91 N.m) - not supplied.

• 5.5 mm open end wrench - not supplied.

Installation Procedure

CAUTION PXI hardware does not support “hot-swap” (changing network analyzer modules while

power is applied to the chassis) capabilities. Before installing or removing a module

to/from thechassis, power-off the chassis to prevent damage to the module.

1. Make sure that the line cord is plugged in to establish earth ground and that

the chassis power switch is Off (see callouts 1 and 3 in Figure 1-3 on

page 11).

2. Wear a grounded wrist strap for this procedure (see callout 2 in Figure 1-3

on page 11).

3. If the chassis has multiple fan speed settings, ensure that the fan switch is

set to high or auto.

4. Position the chassis to provide ample space between the chassis fan intake

and exhaust vents. Blockage by walls or obstructions affects the air flow

needed for cooling. (Refer to the chassis documentation for more

information about cooling.)

5. Before inserting the network analyzer module into the chassis, back-out the

top mounting screw (see callout 7 in Figure 1-3 on page 11) on the module

to ensure that there is no interference between the screws and the

mounting rails.

6. Holding the module by the injector/ejector handle, slide it into a slot, as

shown in callouts 4 – 6 in Figure 1-3 on page 11.

a. Install the module into the slot of the chassis by placing the module card

edges into the front module guides (top and bottom).

The network analyzer module can be installed in any PXIe or hybrid PXI

slot marked with a peripheral slot compatibility image (solid black

circle fro PXIe, or solid black circle with the letter “H” for hybrid.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Keysight Technologies Instrument de mesure

Keysight Technologies

Keysight Technologies B2900A Series Manuel utilisateur

Keysight Technologies

Keysight Technologies N524 A Series Manuel d'installation et d'exploitation

Keysight Technologies

Keysight Technologies U2000 Series Manuel utilisateur

Keysight Technologies

Keysight Technologies E2655C Manuel utilisateur

Keysight Technologies

Keysight Technologies FieldFox N9913A Manuel utilisateur

Keysight Technologies

Keysight Technologies 34420A Manuel utilisateur

Keysight Technologies

Keysight Technologies N4373E Manuel utilisateur

Keysight Technologies

Keysight Technologies N2750A Manuel utilisateur

Keysight Technologies

Keysight Technologies X-Series Manuel utilisateur

Keysight Technologies

Keysight Technologies N9040B Manuel d'installation et d'exploitation

Keysight Technologies

Keysight Technologies P50 B Series Manuel utilisateur

Keysight Technologies

Keysight Technologies E5061B ENA Series Manuel utilisateur

Keysight Technologies

Keysight Technologies BT2152B Manuel de service

Keysight Technologies

Keysight Technologies N5221A Manuel utilisateur

Keysight Technologies

Keysight Technologies N9000A Manuel d'installation et d'exploitation

Keysight Technologies

Keysight Technologies U8903B Manuel utilisateur

Keysight Technologies

Keysight Technologies N9000A Manuel utilisateur

Keysight Technologies

Keysight Technologies N9030A Manuel d'installation et d'exploitation

Keysight Technologies

Keysight Technologies M9203A Guide rapide

Keysight Technologies

Keysight Technologies B2980A Series Manuel utilisateur

Keysight Technologies

Keysight Technologies N5224/5A Manuel utilisateur

Keysight Technologies

Keysight Technologies FieldFox Manuel utilisateur

Keysight Technologies

Keysight Technologies N5221B Manuel utilisateur

Keysight Technologies

Keysight Technologies 34136A Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
