Jura IMPRESSA XF70 Manuel utilisateur

IMPRESSA X

Short operating instructions

Art. 65478 – XF70 GB – 12/2005

Control elements Control elements

11 22

15/16

33 45678

Rotary Switch

1. Rotary Switch

2. Illuminated ring

3. ON/OFF key

4. Programming key

5. Draw-off key 1 cup

6. Draw-off key 2 cups

7. Maintenance key

8. Steam pre-selection key

9. Display dialog system

10. Water tank with carrying handle

11. Filler funnel for pre-ground coffee

12. Bean tank cover

13. Aroma preservation cover

14. Steam/hot water draw-off valve

15. Replaceable 2-stage frothing jet

16. Replaceable hot water nozzle mounted in illustration

17. Height-adjustable coffee spout

18. Coffee grounds container

19. Drip grate

20. Drip tray

21. Power Switch

22. Metal shelf

(1)

(2)

First use

Press power switch (I) (on rear)

Fill bean tank

Touch symbol

Display text: SPRACHE - DEUTSCH

Turn the Rotary Switch until the required language is displayed

Confirm selected language by pressing the Rotary Switch

Lift out water tank

Fill water tank and place back into the machine

Display text: OPEN TAP

Place a receptacle (ca. 1 litre) under the hot water nozzle

Turn tap to position

Turn it back to the initial position when display prompts you to

do so

Display text: PRESS - MAINT.

Place receptacle under height-adjustable coffee spout

Touch symbol when display prompts you to do so

The machine is ready for use

Insert filter (first use)

Remove water tank and empty it

Flip up cartridge (1) holder

Insert filter cartridge (2) into water tank, applying slight

pressure

Close cartridge holder (1) (engages audibly)

Fill water tank and insert

Hold Rotary Switch down until the display shows FILTER

Confirm setting by pressing the Rotary Switch

Turn Rotary Switch until the display shows YES

Confirm setting by pressing the Rotary Switch

Place a receptacle (ca. 1 litre) under the hot water nozzle

Turn tap to position

Turn it back to the initial position when display prompts you to

do so

The machine is ready for use

(1)

(2)

Cleaning (duration: approx. 15 minutes)

Display text: READY - CLEAN

Touch the maintenance symbol until the display shows

EMPTY - TRAY

Empty drip and grounds tray and place back into the machine

Remove drip tray

Place a receptacle (ca. 1 litre) under the coffee spout

Touch the maintenance symbol

Drop an original JURA cleaning tablet into the filler funnel for

ground coffee when display prompts you to do so

Close lid

Touch the maintenance symbol

Empty drip and grounds tray and place back into machine when

display prompts you to do so

Wipe out filler funnel for ground coffee with a dry cloth after

the cleaning program has finished.

The machine is ready for use

Changing the filter

Display text: READY - FILTER

NOTE:

After having used 50 litres of water or after two months at the

latest, the filter cartridge will be used up.

Touch symbol to switch machine off

Touch maintenance symbol until the display shows

CHG FILTER - OPEN TAP

Remove and empty water tank

Flip up cartridge holder (1)

Remove old CLARIS plus filter cartridge from the tank

Place new filter cartridge (2) into water tank, applying slight

pressure

Close cartridge holder (1) (engages audibly)

Fill water tank and place back into machine

Place a receptacle (ca. 1 litre) under the hot water nozzle

Turn tap to position

Turn it back to the initial position when display prompts you to

do so

The machine is ready for use

Display text: READY - DECALCIFY

Touch symbol to switch machine off

Touch maintenance symbol until the display shows

EMPTY - TRAY

Empty drip and grounds tray and place back into machine

Remove 2-stage frothing jet or hot water nozzle

Remove water tank and empty it

Completely dissolve contents of a blister (3 tablets) in 0.6 litres

of water

Pour solution into the empty water tank

Place water tank back into machine

Place a receptacle (ca. 1 litre) under the spout

Turn tap to position

Turn it back to the initial position when display prompts you to

do so

Decalcifying (duration: approx. 40 minutes)

Empty drip and grounds tray and place back into machine when

display prompts you to do so

Rinse water tank well, fill with cold, fresh tap water and place it

back into the machine

Place receptacle under spout

Turn tap to position

Turn it back to the initial position when display prompts you to do

Empty drip and grounds tray and place back into machine when

display prompts you to do so

Fit 2-stage frothing jet or hot water nozzle

Shift receptacle under height-adjustable coffee spout

Touch maintenance symbol when display prompts you to

do so

The machine is ready for use

Decalcifying (continuation)

Cleaning the 2-stage frothing jet

TIP:

To ensure perfect operation of the 2-stage frothing jet, we

recommend you clean it regularly.

Hold the nozzle at the top and at the bottom end or use a 7 mm

open-ended spanner

Screw the nozzle apart

Thoroughly rinse the 3 parts under running water

NOTE:

The display will not prompt you to clean the 2-stage frothing jet

Notes
