Juniper CTP2000 Series Manuel utilisateur

CTP2000 Series

Circuit to Packet Platform

Quick Start Guide

February 2017

Part Number: 530-033822

Revision 01

This document describes how to install the Juniper Networks

CTP2000 Series Circuit

to Packet Platform.

Contents CTP2000QuickStartDescription.......................................3

Step1:PreparetheSite...............................................3

BeforeYouUnpackthePlatform....................................3

UnpackthePlatform..............................................3

Inspect the Components and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

IfYouDetectorSuspectDamage...................................4

Step2:InstallthePlatform............................................4

BeforeYouBeginInstallation.......................................5

Option: Install the Platform in Freestanding Mode . . . . . . . . . . . . . . . . . . . . . . 5

Option: Install the Platform in a Rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Step 3: Install Modules and Other Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

ModuleInstallationOverview.......................................6

ProtectModulesandSlots.........................................6

Required Tools and Safety Items for Installation . . . . . . . . . . . . . . . . . . . . . . . . 7

Safety Guidelines for Installing Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Install a CTP Interface Module, Processor Module, or Clock Module . . . . . . . . 8

InstallaCompactFlashCard.......................................9

InstallaPMCModule............................................10

Install SFPs ....................................................12

Step4:ConnectCables..............................................13

CablingOverview................................................13

Required Tools and Wires for Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

ConnectManagementPorts.......................................14

ConnectanInterfaceModule......................................15

CablethePlatformforPower......................................15

Step 5: Set Up Access to the CTP Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

ConsoleAccess.................................................16

Direct Access ...................................................17

HyperTerminalAccess............................................17

SSHAccess....................................................18

Step6:PowerOn...................................................18

Safety Warnings ....................................................21

Compliance Statements.............................................22

Federal Communications Commission (FCC) Statement . . . . . . . . . . . . . . . . 22

FCC Requirements for Consumer Products . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Food and Drug Administration, Center for Devices and Radiological

Health.....................................................23

Canadian Department of Communications Radio Interference

Regulations ................................................23

IndustryCanadaNoticeCS-03.....................................23

DOC Explanatory Notes: Equipment Attachment Limitations . . . . . . . . . . . . 23

ECDeclarationofConformity......................................24

CTP Documentation and Release Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

RequestingTechnicalSupport........................................26

Self-Help Online Tools and Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

OpeningaCasewithJTAC........................................26

Revision History ....................................................27

CTP2000 Series Platform Quick Start

CTP2000 Quick Start Description

This Quick Start contains information you need to install and access the CTP2000 series

platform. For complete installation instructions, see the CTP2000 Series Platform

Hardware Documentation at https://www.juniper.net/documentation/.

WARNING: This Quick Start contains a summary of safety warnings in “Safety

Warnings” on page 21. For a complete list of warnings for this router, including

translations, see the CTP2000 Series Platform Hardware Documentation at

https://www.juniper.net/documentation/.

Juniper Networks Circuit to Packet (CTP) products provide advanced technology and

features required to reliably transport legacy time-division multiplexing (TDM) and other

circuit-based applications across next-generation IP networks. CTP platforms create an

IP packet flow from a serial data or analog voice connection at one end and provide the

necessary processing to re-create the serial bit stream or analog signal from the received

packet flow at the other end.

CTP platforms provide compact and lightweight chassis, high port density, and multiple

Ethernet interfaces. Each CTP platform runs the CTP operating system (CTPOS) and

can be managed by CTPView, a secure Web-based management tool for provisioning,

managing, running diagnostics, monitoring, and reporting on all CTP devices and circuits

in the network.

Step 1: Prepare the Site

•Before You Unpack the Platform on page 3

•Unpack the Platform on page 3

•Inspect the Components and Accessories on page 4

•If You Detect or Suspect Damage on page 4

Before You Unpack the Platform

Before you begin unpacking the platform, be sure you have the following tools:

•No. 2 Phillips screwdriver

•Utility knife

•Mechanical lift, or at least two people to assist in lifting

Unpack the Platform

Depending on the platform, it may be delivered boxed, bolted, and strapped to a skid.

For your convenience, we recommend that you unpack the device in the location where

you want to install it.

CTP2000 Quick Start Description

WARNING: Three people are required to install the device in a rack: two to

lift the device into position and one to screw it to the rack.

To unpack the device:

1. Cut the two straps that secure the carton to the skid, open the carton from the top,

and remove the box of accessories that sits on top of the device.

2. Unlock the four plastic clips that hold the box to the skid by squeezing them in their

center and pulling out, and then lift the carton off the device.

3. Remove the three screws that attach each of the two L-brackets to the device.

4. To avoid scratching the device when removing it from the skid, detach one of the

L-brackets from the skid by removing the three screws.

Inspect the Components and Accessories

After you remove the equipment from the shipping containers:

•Confirm the contents of each container.

•Inspect all external surfaces and external connectors for visible signs of damage.

•Inspect all accessories shipped with each unit.

•Document any damage noted during your inspection.

•Confirm that the device has the correct number and type of modules for your ordered

configuration.

If You Detect or Suspect Damage

If you detect or suspect damage to any equipment:

•Contact the shipper responsible for delivery, and formally report the damage.

•Contact your Juniper Networks sales representative or reseller.

Step 2: Install the Platform

•Before You Begin Installation on page 5

•Option: Install the Platform in Freestanding Mode on page 5

•Option: Install the Platform in a Rack on page 5

CTP2000 Series Platform Quick Start

Before You Begin Installation

Before installing the device:

•Have a plan for installing the device that takes into consideration future expansion.

•Have the tools and accessories needed to complete the installation.

•Be sure that the space requirement of 3 feet (90 cm) behind the device or rack is met.

Do not block air vents on the front or back of the router.

•Prepare the equipment racks by measuring and marking space for each device and

plenum you plan to install.

•See the “Safety Warnings” on page 21.

Option: Install the Platform in Freestanding Mode

When installing the device on a table top or in any other freestanding mode, be sure to

leave enough space around the device for adequate ventilation. Position the chassis with

easy access to the connections that it needs for power, local communications, and remote

communications.

WARNING: Two people are required to lift the device.

CAUTION: To prevent electrostatic damage to the device and its components,

make sure persons handling the device wear an antistatic device.

Option: Install the Platform in a Rack

To install the device in a rack, you need:

•Phillips screwdriver

•Four 10-32 x 3/8 Phillips screws for each device to be installed

Before installing the devices in a rack, consider the following guidelines:

•You can install up to four CTP2056 chassis in a single 7-ft. (2.1-m) rack. Installing

multiple devices in a single rack enables you to maximize your available space.

•Install heavier devices, such as a CTP2056 chassis, on the bottom of the rack. Mount

lighter devices higher in the rack.

Following your installation plan, use a tape measure and marking pen to measure and

mark space on each equipment rack for each device component. For horizontal spacing,

follow Network Equipment Building System (NEBS) requirements.

Step 2: Install the Platform

To install the device in the rack:

1. With one person standing on the left side of the device and another standing on the

right side, lift the device into the rack.

2. Position the device in its designated location in the equipment rack. Make sure the

holes of the mounting brackets align evenly with the holes of the equipment rack on

both sides.

3. Starting at the bottom of the device, have the third person secure the device in the

equipment rack by using the 10-32 x 3/8 Phillips screws.

Step 3: Install Modules and Other Components

•Module Installation Overview on page 6

•Protect Modules and Slots on page 6

•Required Tools and Safety Items for Installation on page 7

•Safety Guidelines for Installing Modules on page 7

•Install a CTP Interface Module, Processor Module, or Clock Module on page 8

•Install a CompactFlash Card on page 9

•Install a PMC Module on page 10

•Install SFPs on page 12

Module Installation Overview

In CTP2000 series platforms, interface modules can be installed in the front and rear of

the device. Rear transition modules (RTMs) are located in the rear of the device.

Interface modules are not hot-swappable.

In CTP2000 series platforms, slot numbering starts at the top of the chassis with slot 0.

Protect Modules and Slots

The CTP2056 has an ESD (electrostatic discharge) grounding jack located in the rear

lower-left corner of the chassis near the power switch. To prevent damage from

electrostatic discharge, wear an antistatic wrist strap and connect it to one of the jacks

when handling components. There are no ESD jacks on the other CTP platforms, so you

must use another grounding device.

To protect the modules, components, and slots when installing components, observe

the following guidelines:

CAUTION: When handling components, use an antistatic wrist strap

connected to an appropriate grounding device. This action helps to protect

the module from damage by electrostatic discharge.

CTP2000 Series Platform Quick Start

CAUTION: Always handle a module by its edges. Do not touch the

components, pins, leads, or solder connections.

CAUTION: If you meet strong resistance when attempting to seat a module

using the ejectors, remove it from the chassis and confirm that the slot is

designed to hold the module. Also, be sure that you have aligned the left and

right edges in the correct matching module guides.

CAUTION: Be sure to cover every empty slot with a blank filler panel to protect

the device from dust or other foreign substances and to ensure proper device

cooling.

CAUTION: Do not discard the antistatic bag. When a module is not in use,

store it in an antistatic bag.

Required Tools and Safety Items for Installation

You need the following tools to install a CTP module:

•Phillips screwdriver

•Flathead screwdriver

•ESD wrist strap or other grounding device

Safety Guidelines for Installing Modules

Before and during the installation process, observe the following warnings:

WARNING: Do not work on the device or connect or disconnect cables during

lightning activity.

WARNING: Be sure circuit breakers for the power source are in the OFF

position before attaching power cables.

WARNING: Remove jewelry (including rings, necklaces, and watches) before

working on equipment that is connected to power lines. Metal objects heat

up when connected to power and ground and can cause serious burns or

become welded to the terminals.

Step 3: Install Modules and Other Components

WARNING: Do not insert any metal object, such as a screwdriver, into an

open slot or the midplane. Doing so can cause electric shock and serious

burns.

WARNING: Never attempt to repair parts of modules yourself. Only trained

customer service personnel are authorized to service parts. Call Juniper

Networks Customer Service to make arrangements to return defective

modules for repair.

Install a CTP Interface Module, Processor Module, or Clock Module

To install a module:

1. Ground yourself by using an antistatic wrist strap or other device, and connect it to

one of the ESD grounding jacks.

2. Choose the slot where you want to insert the module.

3. With a Phillips screwdriver, loosen the screws that secure the blank filler panel covering

the empty chassis slot, if present, and remove the filler panel.

4. Remove the module from its antistatic bag, being careful not to touch module

components, pins, leads, or solder connections.

5. Verify that the ejectors are in the open position (facing outward).

6. Guide the module into the chassis by placing it between the guides of the selected

slot and pushing the module until it stops.

The module stops sliding when the ejectors make contact with the chassis.

CAUTION: If you meet strong resistance when attempting to seat the

module using the ejectors, remove it from the chassis, and confirm that

the slot is designed to hold the component. Also, be sure that you have

aligned the left and right edges in the correct matching tracks.

7. Insert the module into the midplane by simultaneously pressing both ejectors inward

and exerting forward pressure on the module. The small red release buttons should

click into place.

8. Tighten the module's captive screws using a Phillips screwdriver.

CTP2000 Series Platform Quick Start

NOTE: Tighten the captive screws completely before installing an adjacent

module so that proper electromagnetic interference (EMI) gasket

compression occurs. Failure to do this can make it difficult to install

adjacent modules.

Install a CompactFlash Card

On the CTP2000 series devices with the new PP833 processor, the CompactFlash card

is installed on the processor itself (which may be located under an installed PMC card),

which prevents insertion or removal of the CompactFlash card until the PMC card is

removed. On the CTP2000 series devices with the PP310 and PP332 processors, the

CompactFlash card is installed on the processor rear transition module (RTM). Some

CTP devices may ship with a CompactFlash card already installed.

To remove or install the CompactFlash card for the CTP2000 series devices with the

new PP833 processor (see Figure 1 on page 9):

1. Power off the unit.

2. If installed, remove the PP833 PMC card by unscrewing the retaining screws and

pushing the extractors outward with the latching buttons depressed.

3. You can then remove or install the CompactFlash card in the flash socket.

4. If being used, reinstall the PP833 PMC card into the chassis, and secure the retaining

screws.

Figure 1: Installing CompactFlash on the PP833 processor

Step 3: Install Modules and Other Components

To remove and reinstall the CompactFlash card for the CTP2000 series devices with the

PP310 and PP332 processors:

1. Power off the unit.

2. Remove the RTM by unscrewing the retaining screws and pushing the extractors

outward with the latching buttons depressed.

3. Verify that the CompactFlash card is installed.

4. Remove the CompactFlash card–retaining screw and nut. You can then remove or

install the CompactFlash card in the flash socket.

5. Reinstall the CompactFlash card–retaining screw and nut.

6. Reinstall the processor RTM into the chassis, and secure the retaining screws.

Figure 2: CompactFlash Card on the RTM

IIIIIIIIIIIIIIIIIIIIIIIIIIIII

CompactFlash card

CompactFlash

locking screw

g015386

Install a PMC Module

The PMC module is mounted onto the processor module and can be installed or replaced

in the field. Figure 3 on page 11 displays the location of the PMC module.

CTP2000 Series Platform Quick Start

Autres manuels pour CTP2000 Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Juniper Matériel réseau

Juniper

Juniper NetScreen-5GT Wireless Manuel utilisateur

Juniper

Juniper MX150 Manuel utilisateur

Juniper

Juniper SSR1500 Manuel utilisateur

Juniper

Juniper JATP700 Instructions d'installation

Juniper

Juniper CTP2000 Series Guide de démarrage rapide

Juniper

Juniper SSR1400 Instructions d'installation

Juniper

Juniper QFX10016 Manuel utilisateur

Juniper

Juniper WX 15 Manuel utilisateur

Juniper

Juniper SRX300 Series Manuel utilisateur

Juniper

Juniper ACX7100-32C Manuel utilisateur

Juniper

Juniper CSE2000 Manuel

Juniper

Juniper PTX10004 Instructions d'installation

Juniper

Juniper SRX Series Manuel utilisateur

Juniper

Juniper Day One Plus SRX380 Manuel utilisateur

Juniper

Juniper SSR1300 Manuel utilisateur

Juniper

Juniper CTP2000 Series Instructions d'installation

Juniper

Juniper Junos Space JA1500 Manuel utilisateur

Juniper

Juniper JSA1500-BSE Manuel utilisateur

Juniper

Juniper MX480 Instructions d'installation

Juniper

Juniper Junos Space JA2500 Instructions d'installation

Juniper

Juniper SSR1400 Manuel utilisateur

Juniper

Juniper MX SERIES - FAN TRAY UPGRADE REV1 4-2010 Manuel utilisateur

Juniper

Juniper JSA7800 Manuel utilisateur

Juniper

Juniper CTP1000 Series Instructions d'installation

Manuels Matériel réseau populaires d'autres marques

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manuel utilisateur

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manuel utilisateur

Yudor

Yudor YDS-16 Manuel utilisateur

D-Link

D-Link ShareCenter DNS-320L Manuel utilisateur

Samsung

Samsung ES1642dc Instructions d'utilisation

Honeywell Home

Honeywell Home LTEM-PV Instructions de montage

evertz

evertz 7700 Series Manuel utilisateur

D-Link

D-Link ShareCenter DNS-343 Manuel utilisateur

Asante

Asante AsanteBridge 1012 Manuel utilisateur

FireBrick

FireBrick FB2700 Manuel utilisateur

Audiovox Electronics

Audiovox Electronics ARWH2T Manuel utilisateur

ADC

ADC DSX-1 Manuel

NetComm

NetComm NF2 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 5620 Manuel utilisateur

Dell EMC

Dell EMC XC6420 Series Manuel utilisateur

Lanner

Lanner NCA-1020A Manuel utilisateur

Allied Telesis

Allied Telesis AT-TN121-A Manuel utilisateur

Arista

Arista CCA-ETM-Q12 Manuel utilisateur
