Route Insight Manager Quick Start

Overview

The Route Insight Manager Appliance Quick Start Guide contains the following topics:

■About the Route Insight Manager Appliance on page 3

■Front and Back Panel Overview and Features on page 3

■Route Insight Manager Platform Hardware Specifications on page 4

About the Route Insight Manager Appliance

Route Insight Manager is a route analytics tool that provides insight into real-time

routing topology and monitors vital service parameters such as network churn and

prefix flaps, alerting you to potential problems and allowing before and after

comparisons and event analysis.

Route Insight Manager appliances are easy to deploy. The appliances physically

connect to the network directly to one of the routers or through a switch or hub. The

appliances establish communication with several routers in the network through the

routing protocol over the single physical connection. Link-state routers send periodic

update messages that communicate network information to each other, and to the

appliance.

You can monitor and record network events in different parts of the network with

multiple route recorder units. The distributed recorders collect routing data locally,

from the area where they are installed, through generic route encapsulation (GRE)

tunnels, or both. A centralized Management Console retrieves the data from each

recorder. For a description of recorder configuration, see the “Configuration and

Management”chapter in the Route Insight Manager Administrator’s Guide.

Front and Back Panel Overview and Features

The Route Insight Manager appliance is shown in Figure 1 on page 3 and has a 2U

rack-mountable chassis with optional redundant AC and DC power supplies, a 2U

hot-swappable mirrored RAID1 array, 12 GB of memory, and a Gigabit Ethernet

controller.

Figure 1: Front Panel View

The following tables describe the features of the front panel for the Route Insight

Manager appliance. The chassis, hard drive, and LAN LEDs are described in Table 1

on page 4.

Overview ■3

Overview

Table 1: Appliance Front Panel LEDs

Description

Chassis LEDs

■Power (green) - When lit, indicates that the appliance is powered on

■Hard disk (yellow) - When lit, indicates the hard disk is in use (writing or reading data)

■Hardware (red) - When lit, indicates that a fan, power supply, or temperature alarm has

occurred

LAN LEDs

■Left LED (green) - When lit, indicates that the link is active

■Right LED - Indicates the link speed:

■off -10 Mbps

■green - 100 Mbps

■yellow - 1 Gbps

Hard drive tray LEDs

■Left (green) - For disk activity

■Right (red) - For disk failure

Route Insight Manager Platform Hardware Specifications

The appliance has the following ports:

■Serial Console—One RJ45 serial port.

■Network ports—Four RJ45 10/100/1000 Ethernet ports.

■USB interface for Flash drive.

The appliance chassis front panel has LEDs as described in Table 2 on page 4.

Table 2: Route Insight Manager Appliance Chassis LEDs

MeaningLED

When lit, indicates power is applied to the appliance.Power

When lit, indicates a hardware problem on the appliance.HW Warning

4■Route Insight Manager Platform Hardware Specifications

Route Insight Manager Quick Start

Route Insight Manager FRUs

The following sections describe the field replaceable units (FRUs) in the Route Insight

Manager appliance chassis.

■Hard Drive on page 5

■Power Supply on page 5

■Fans on page 6

Hard Drive

The Route Insight Manager appliance ships with hot-swappable hard disks to offer

component redundancy. The appliance has a RAID10 configuration of six 500 GB

SAS drives (5001) or four 1TB SAS drives (5002). Redundant disks maintain a copy

of the software image and configuration information as it is on working drives. If the

working drive fails, the redundant drive immediately assumes responsibility for Route

Insight Manager operations. You can hot-swap the disk if any one of the disk drives

fails. The drives are externally accessible.

Redundant array of independent disk (RAID) is an organization of multiple disks to

enhance fault tolerance and performance. It is used in the servers for data storage

and to replicate data among multiple hard disk drives. There are different RAID levels

designed to increase data reliability and increased I/O performance. In RAID10,

drives are striped for performance, and all striped drives are duplicated for fault

tolerance.

The key concepts in RAID are:

■Mirroring - copy data to more than one disk

■Striping - split data across more than one disk

■Error correction - redundant data storage to detect and resolve problems

The hard drive LEDs are described in Table 3 on page 5.

Table 3: Hard Drive LEDs

MeaningLED

When lit, indicates drive activity.LED 1

When lit, indicates drive failure.LED 2

Power Supply

The appliance has a dual hot swap redundant 560W AC power supply module, and

can support additional redundant power supply modules. If one power supply fails,

an optional second power supply can assume responsibility for the entire power

load. The appliances also have a hot swap dual redundant 560W DC power supply

Route Insight Manager Platform Hardware Specifications ■5

Route Insight Manager Platform Hardware Specifications

option if you need DC power. You can have both AC and DC power supplies in the

same chassis.

Fans

The Route Insight Manager platform appliance contains three hot-swappable

redundant cooling fans.

Installation Environment Setup

This section contains the following topics:

■Rack Requirements and Specifications for a Route Insight Manager

Appliance on page 6

■Environmental Requirements for a Route Insight Manager Appliance on page 7

■Power Requirements for a Route Insight Manager Appliance on page 8

Rack Requirements and Specifications for a Route Insight Manager Appliance

The Route Insight Manager appliance can be installed in many types of racks, including

four-post Telco racks and open-frame racks. Table 4 on page 6 lists the rack

requirements.

Table 4: Route Insight Manager 500 Rack Requirements

GuidelinesRack Requirement

Use a front mount rack, four-post rack (Telco), or a

center-mount rack.

Rack type

■Ensure that the rack complies with one of these

standards:

■A 19-in. rack as defined in Cabinets, Racks,

Panels, and Associated Equipment (document

number EIA-310–D) published by the Electronics

Industry Association (http://www.eia.org).

■A 600-mm rack as defined in the four-part

Equipment Engineering (EE); European

telecommunications standard for equipment

practice (document numbers ETS 300 119-1

through 119-4) published by the European

Telecommunications Standards Institute

(http://www.etsi.org).

The horizontal spacing between the rails in a rack

that complies with this standard is wider than

the appliance’s mounting brackets, which

measure 19 in. (48.2 cm) from outer edge to

outer edge. Use approved wing devices to narrow

the opening between the rails as required.

■Ensure that the spacing of rails and adjacent racks

allow for the proper clearance around the appliance

and rack.

Rack size and strength

6■Installation Environment Setup

Route Insight Manager Quick Start

Table 4: Route Insight Manager 500 Rack Requirements (continued)

GuidelinesRack Requirement

■Secure the rack to the building structure.

■If earthquakes are a possibility in your geographical

area, secure the rack to the floor.

■Secure the rack to the ceiling brackets as well as wall

or floor brackets if maximum stability is required.

Rack connection to building

structure

One pair of mounting brackets is supplied with the appliance. The holes in the

mounting brackets are spaced at 1 U (1.75 in. or 4.445 cm), so the appliance can be

mounted in any rack that provides holes spaced at that distance.

The outer edges of the mounting brackets extend the width of the chassis to 19 in.

(48.2 cm), and the front of the chassis extends approximately 0.5 in. (1.27 cm)

beyond the mounting brackets. The spacing of rails and adjacent racks must also

allow for the clearances around the appliance and rack.

Environmental Requirements for a Route Insight Manager Appliance

The appliance must be installed in a rack or cabinet housed in a dry, clean,

well-ventilated, and temperature-controlled environment.

Ensure that these environmental guidelines are followed:

■The site must be as dust-free as possible, because dust can clog air intake vents

and filters, reducing the efficiency of the appliance cooling system.

■Maintain ambient airflow for normal appliance operation. If the airflow is blocked

or restricted, or if the intake air is too warm, the appliance might overheat.Table

5 on page 7 provides the required environmental conditions for normal

appliance operation.

Table 5: Environmental Requirements for Appliance Operation

ToleranceDescription

No performance degradation to 10,000 feet (3048 meters)Altitude

Normal operation ensured in relative humidity range of

8% to 90%, non-condensing

Relative Humidity

Normal operation ensured in temperature range of 41° F

to 104° F (5° C to 40° C)

Temperature

The operational environment must also be able to withstand the heat and noise

generation shown in Table 6 on page 8.

Environmental Requirements for a Route Insight Manager Appliance ■7

Environmental Requirements for a Route Insight Manager Appliance

Table 6: Appliance Heat and Noise Dissipation

OutputDescription

With a single power supply:

■323 BTU/hr (94.67 W) typical

■413 BTU/hr (121 W) maximum

With dual power supplies:

■413BTU/hr (121 W) typical

■499 BTU/hr (146.26) maximum

Thermal dissipation

■Front/rear with 1 power supply xx/xx DB.

■Front/rear with 2 power supplies xx/xx DB.

Acoustic noise from approximately

3 feet

Table 7 on page 8 lists the environmental requirements for storing the appliance

while non-operational.

Table 7: Environmental Requirements for Appliance Storage

ToleranceDescription

The appliance can be stored safely up to an altitude of

40,000 feet (12,192 meters)

Altitude

The appliance can be stored safely in relative humidity

range of 5% to 95%, non-condensing

Relative Humidity

The appliance can be stored safely in temperature range

of –40° F to 158° F (-40° C to 70° C)

Temperature

Power Requirements for a Route Insight Manager Appliance

A Route Insight Manager appliance can be powered by either an AC or DC electrical

supply, depending on the power modules that shipped in your appliance. Table 8 on

page 8 shows the electrical power requirements for a Route Insight Manager

appliance with AC power modules.

Table 8: Power Requirements for Route Insight Manager Appliances with AC Power

Modules

RequirementItem

90 to 264 VACAC input voltage

50 to 60 HzAC input line frequency

25 A (low appliance)

60 A (mid appliance)

AC current rating

8■Power Requirements for a Route Insight Manager Appliance

Route Insight Manager Quick Start

Table 8: Power Requirements for Route Insight Manager Appliances with AC Power

Modules (continued)

RequirementItem

400 W (low appliance)

700 W (mid appliance)

Maximum output power

Table 9 on page 9 shows the electrical power requirements for a Route Insight

Manager appliance with DC power modules.

Table 9: Power Requirements for Appliances with DC Power Modules

RequirementItem

-48 VDCDC input voltage

60 ADC input current rating

710 WMaximum output power

Safety

This section contains the following topics:

■General Safety Guidelines and Warnings for Route Insight Manager

Appliances on page 9

■Fire Safety Requirements for the Route Insight Manager Appliance on page 10

■Route Insight Manager Appliance Agency Approvals on page 11

General Safety Guidelines and Warnings for Route Insight Manager Appliances

The following guidelines help ensure your safety and protect the appliance from

damage. The list of guidelines might not address all potentially hazardous situations

in your working environment, so be alert and exercise good judgment at all times.

■Perform only the procedures explicitly described in the hardware documentation

for this product. Make sure that only authorized service personnel perform other

system services.

■Keep the area around the chassis clear and free from dust before, during, and

after installation.

■Keep tools away from areas where people could trip over them while walking.

■Do not wear loose clothing or jewelry, such as rings, bracelets, or chains, which

could become caught in the chassis.

■Wear safety glasses if you are working under any conditions that could be

hazardous to your eyes.

Safety ■9

Safety

■Do not perform any actions that create a potential hazard to people or make the

equipment unsafe.

■Never attempt to lift an object that is too heavy for one person to handle.

■Never install or manipulate wiring during electrical storms.

■Never install electrical jacks in wet locations unless the jacks are specifically

designed for wet environments.

■Operate the appliance only when it is properly grounded.

■Ensure that the separate protective earthing terminal provided on this product

is permanently connected to earth.

■Replace fuses only with fuses of the same type and rating.

■Do not open or remove chassis covers or sheet-metal parts unless instructions

are provided in the hardware documentation for this product. Such an action

could cause severe electrical shock.

■Do not push or force any objects through any opening in the chassis frame. Such

an action could result in electrical shock or fire.

■Avoid spilling liquid onto the appliance. Such an action could cause electrical

shock or damage the appliance.

■Avoid touching uninsulated electrical wires or terminals that have not been

disconnected from their power source. Such an action could cause electrical

shock.

■Always ensure that all modules, power supplies, and blanks are fully inserted

and that the installation screws are fully tightened.

Fire Safety Requirements for the Route Insight Manager Appliance

In the event of a fire emergency involving switches and other network equipment,

the safety of people is the primary concern. You should establish procedures for

protecting people in the event of a fire emergency, provide safety training, and

properly provision fire control equipment and fire extinguishers.

In addition, you should establish procedures to protect your equipment in the event

of a fire emergency. Juniper Networks products should be installed in an environment

suitable for electronic equipment. We recommend that fire suppression equipment

be available in the event of a fire in the vicinity of the equipment, and that all local

fire, safety, and electrical codes and ordinances be observed when installing and

operating your equipment.

Fire Suppression

In the event of an electrical hazard or an electrical fire, you should first turn power

off to the equipment at the source. Then use a Type C fire extinguisher, which uses

noncorrosive fire retardants, to extinguish the fire.

Fire Suppression Equipment

Type C fire extinguishers, which use noncorrosive fire retardants such as carbon

dioxide and Halotron™, are most effective for suppressing electrical fires. Type C fire

10 ■Fire Safety Requirements for the Route Insight Manager Appliance

Route Insight Manager Quick Start

Table des matières

Autres manuels Juniper Matériel réseau

Juniper

Juniper SRX5600 Manuel utilisateur

Juniper

Juniper Junos Space JA2500 Manuel utilisateur

Juniper

Juniper SSR130 Instructions d'installation

Juniper

Juniper SSR1400 Instructions d'installation

Juniper

Juniper PTX3000 Manuel utilisateur

Juniper

Juniper IDP 800 Manuel utilisateur

Juniper

Juniper MX480 Instructions d'installation

Juniper

Juniper NetScreen-IDP 3.0 Manuel utilisateur

Juniper

Juniper CTP2000 Series Guide de démarrage rapide

Juniper

Juniper WXC 590 Manuel utilisateur

Juniper

Juniper CTP2000 Series Instructions d'installation

Juniper

Juniper 16-PORT GIGABIT ETHERNET XPIMS Manuel utilisateur

Juniper

Juniper STRM 500 II Manuel

Juniper

Juniper Junos Space JA1500 Manuel utilisateur

Juniper

Juniper SSR130 Manuel utilisateur

Juniper

Juniper WX 100 Manuel utilisateur

Juniper

Juniper NETSCREEN-5XP Manuel utilisateur

Juniper

Juniper MX SERIES - FAN TRAY UPGRADE REV1 4-2010 Manuel utilisateur

Juniper

Juniper SRX320 Manuel utilisateur

Juniper

Juniper SRX300 Series Manuel utilisateur

Juniper

Juniper TCX1000 Manuel utilisateur

Juniper

Juniper CSE2000 Manuel

Juniper

Juniper STRM 5000 Manuel

Juniper

Juniper SSR1500 Instructions d'installation

Manuels Matériel réseau populaires d'autres marques

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manuel utilisateur

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manuel utilisateur

Yudor

Yudor YDS-16 Manuel utilisateur

D-Link

D-Link ShareCenter DNS-320L Manuel utilisateur

Samsung

Samsung ES1642dc Instructions d'utilisation

Honeywell Home

Honeywell Home LTEM-PV Instructions de montage

evertz

evertz 7700 Series Manuel utilisateur

D-Link

D-Link ShareCenter DNS-343 Manuel utilisateur

Asante

Asante AsanteBridge 1012 Manuel utilisateur

FireBrick

FireBrick FB2700 Manuel utilisateur

Audiovox Electronics

Audiovox Electronics ARWH2T Manuel utilisateur

ADC

ADC DSX-1 Manuel

NetComm

NetComm NF2 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 5620 Manuel utilisateur

Dell EMC

Dell EMC XC6420 Series Manuel utilisateur

Lanner

Lanner NCA-1020A Manuel utilisateur

Allied Telesis

Allied Telesis AT-TN121-A Manuel utilisateur

Arista

Arista CCA-ETM-Q12 Manuel utilisateur
