BCM™ Motherboard BIOS

Upgrade Instructions

Digital Vision Network

5000 Series

October, 2011

24-10129-128 Rev. –

Johnson Controls, Inc.

(805) 522-5555

www.johnsoncontrols.com

No part of this document may be reproduced without the prior permission of Johnson Controls, Inc.

Cardkey P2000, BadgeMaster, and Metasys are trademarks of Johnson Controls, Inc. All other company and product

names are trademarks or registered trademarks of their respective owners.

These instructions are supplemental. Some times they are supplemental to other manufacturer’s documentation.

Never discard other manufacturer’s documentation. Publications from Johnson Controls, Inc. are not intended to

duplicate nor replace other manufacturer’s documentation.

Due to continuous development of our products, the informationin this document is subject to change without notice.

Johnson Controls, Inc. shall not be liable for errors contained herein or for incidental or consequential damages in

connection with furnishing or use of this material. Contents of this publication may be preliminary and/or may be

changed at any time without any obligation to notify anyone of such revision or change, and shall not be regarded as

a warranty.

If this document is translated from the original English version by Johnson Controls, Inc., all reasonable endeavors

will be used to ensure the accuracy of translation. Johnson Controls, Inc. shall not be liable for any translation errors

contained herein or for incidental or consequential damages in connection with the furnishing or use of this translated

material.

24-10129-128 Rev. – 1

This document contains confidential and proprietary information of Johnson Controls, Inc.

DVN 5000 BCM™ MOTHERBOARD BIOS

UPGRADE INSTRUCTIONS

This document describes how to update the DVN 5000 Rackmount Series BCM™

motherboard BIOS using the DVN-BIOS upgrade package to help prevent potential hard

drive failures resulting from the following power issues:

Brown out conditions causing power management issues

Improper shutdown (for example, switching off the DVN using the power supply

switch)

NOTE

Perform this upgrade only on DVN 5000 Rackmount Series servers

running software Version 2.9 or earlier. DVN 5000 servers running Version

2.10 do not require the BIOS patch. Version 2.10 is scheduled for release

in late 2011.

Upgrading the BCM motherboard BIOS consists of the following series of steps:

Identifying the motherboard manufacturer (see page 1)

Installing the BIOS patch (see page 2)

Verifying the BIOS patch was successfully installed (see page 4)

MOTHERBOARD MANUFACTURER IDENTIFICATION

Determine whether the DVN 5000 has a BCM or Intel® motherboard. To do this, on the

back of the DVN, verify the number of network ports.

A DVN 5000 with two network ports has a BCM motherboard.

A DVN 5000 with one network port has an Intel motherboard.

NOTE

Do not attempt to install the patch on DVN 5000 servers with an Intel

motherboard. Install the patch only on DVN 5000 servers with a BCM

motherboard.

DVN 5000 BCM Motherboard BIOS Upgrade Instructions

2 24-10129-128 Rev. –

This document contains confidential and proprietary information of Johnson Controls, Inc.

BIOS PATCH INSTALLATION

To install the BCM motherboard BIOS patch:

1. On the DVN 5000 RemoteControl Main screen, click Shutdown.

The Shutdown button only appears when running RemoteControl locally at

the server.

2. Click Ye s when the warning message appears.

3. Once the DVN shuts down, insert the USB flash drive into one of the

DVN5000’s available USB ports.

4. Restart the DVN.

5. During the boot up process, press and hold the <Delete> key on your

keyboard to enter the BCM motherboard BIOS.

6. When prompted to enter the BIOS password, enter P001 and press <Enter>.

The password is case sensitive.

7. Use the arrow keys to select Advanced BIOS Features and press <Enter>.

Upgrade Instructions DVN 5000 BCM Motherboard BIOS

24-10129-128 Rev. – 3

This document contains confidential and proprietary information of Johnson Controls, Inc.

8. Select Hard Disk Boot Priority and press <Enter>.

9. Confirm that the USB flash device is the first device the DVN uses to boot,

and press <F10>.

If the BIOS does not list the USB flash device in the first position, use the (+)

and (-) keys on your keyboard's numeric keypad to move it to the first

position. Then, press <F10>.

DVN 5000 BCM Motherboard BIOS Upgrade Instructions

4 24-10129-128 Rev. –

This document contains confidential and proprietary information of Johnson Controls, Inc.

NOTE

The USB flash drive description may vary.

10. Press <Enter> when asked to Save to CMOS and exit (Y/N)? Y.

The BIOS update selection screen appears.

11. Press 3on your keyboard.

12. When the confirmation message appears, press any key to continue.

IMPORTANT

Do not switch off the DVN while the system installs the BIOS patch.

Once the system completes the BIOS patch installation, the DVN

automatically restarts.

13. Remove the flash drive from the DVN.

14. Click the Login button when it becomes highlighted and verify that you can

successfully log on to the DVN.

BIOS PATCH INSTALLATION VERIFICATION

To verify the patch was successfully installed:

1. Restart the DVN.

2. During the boot up process, press and hold the <Tab> key on your keyboard.

The current BCM motherboard BIOS version appears briefly.

3. Verify the system displays BIOS Version 2.10C.
