AP130

SOLDER FEED IRON

www.jbctools.com

2

AP130 / SOLDER FEED IRON

AP130-A

SOLDER FEED IRON

INSTALLATION

AP130-A

SOLDER FEED IRON

MANUAL0002801

Reel

0006559

Feeding Tube

DD-2B /DD-1B/DD-9B

CONTROL UNIT

AP-SC

SOLDER FEED STAND

Power cord

switch

Equipotential

connection

AP130

SOLDER FEED IRON

ww w.j bc too ls.co m

3

CHANGING THE CARTRIDGE

- Loosen the cartridge screw (1) to release the

cartridge.

- Place the new cartridge in the solder feed handle.

Important: It is essential to insert the cartridge till

the end for a good connection.

Use the mark as reference (2).

- Align the tip of the cartridge with the solder guide

tube (3). Tighten the cartridge screw (1).

Warning: It is esential to tighten the cartridge screw for the tool to function.

3

1 2

Guide tube screw

Cartridge screw

Alignment

4

REPLACING THE REEL

Before ﬁtting a new reel, pull out the solder remaining inside the solder direction tube.

Always use 0.8 to 1.0 mm diameter solder wire.

Insert the solder into its hole checking that the wire becomes straight. Pull the trigger intermittently until the solder feed

system works by itself.

1

2

3

Press

5

BE-SA

Solder reel stand

For production-line purposes we recommend

using our BE-SA holder which allows for solder

reels of sizes up to 2.5 Kg to be used.

Simply wrap a couple of turns of the solder wire

around an empty reel as shown.

SOLDER REEL HOLDER

6

ACCESSORIES

F1204

FUME EXTRACTOR

Suction pump

and ﬁlter

7

All the cartridges shown are actual size.

Consult our wide range of cartridges with more than 250 references in www.jbctools.com.

For special cartridges contact with our distributor.

C130 CARTRIDGE RANGE

ø 0,6

ø 3

ø 0,8

2,2x1

ø 4

ø 1,7

3,2x1,5

4,8x1,5

ø 1

1,2x0,7

1,8x0,8

ø 2,2

C130-401

C130-405

C130-416C130-402 C130-403

C130-406

C130-417

C130-409

C130-418 C130-419

C130-404

C130-410

WARRANTY

JBC’s 2 years warranty guarantees this equipment against all manu-

facturing defects, covering the replacement of defective parts and

all necessary labour.

Warranty does not cover product wear due to use or mis-use.

In order for the warranty to be valid, equipment must be returned,

postage paid, to the dealer where it was purchased enclosing this

fully ﬁlled in, sheet.

www.jbctools.com

SERIAL Nº

STAMP OF DEALER

DATE OF PURCHASE

0008861-0912

This product should not be

thrown in the garbage.
