Jacuzzi NOVA 6 Manuel utilisateur

nova™ 6 pure air®II bath

nova—a brightly burning star. the nova™ pure air®II bath—a rejuvenating point of light in your day, your night, your routine.

Clean lined and classic, the Nova™ whirlpool

is versatility deﬁned.

features:

• Exclusive 360º Balanced Airﬂow™ system

• 600 watt variable speed heated air blower

• Thermal Lumbar Comfort (TLC)™

• Safely use salts and aromatic oils

• PrO

™

Ozone Sanitation System standard

nova™ 6 pure air®II bath

model number: EA10 – LH

exterior dimensions:

72" long x 42" wide x 20½" high

interior dimensions (bottom):

50" long x 28" wide(mid) x 21" wide (end)

operating gallons:

67 gallons

Nova™ 6 Pure Air® II Bath

Model: EA10

Installation Notes

Refer to installation instructions included with ﬁxture before beginning installation.

Please conﬁrm product availability and speciﬁcations before commencing with any

installation work.

PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT TO CHANGE

WITHOUT NOTICE.

Electrical Components and Electrical Speciﬁcations do not apply to non-jetted baths.

Ordering Information

Product Code:

EA10 Nova™ 6 Pure Air II Bath

Left Hand

• Left Hand Drain Location

• Accessories / Hardware:

Trip-Lever Drain Kit #X559

Rotary Drain Kit, 26” Cable #8730

• Trim Kit Finishes Available:

(827) – Chrome

(898) – Brushed Chrome

(815) – Satin Nickel

(829) – Bright Brass

(805) – Platinum

(826) – Brushed Nickel

(849) – Oil Rubbed Bronze

Technical Speciﬁcations

Dimensions

72” L x 42” W x 20-1/2” H

(1829 mm) L x (1067 mm) W x (521 mm) H

Drain/Overﬂow

A: 14-3/4” (375 mm) B: 8-1/2” (216 mm)

Cutout

70” x 40” (1778 mm x 1016 mm)

Total Weight

1026.4 lb (466 kg)/48.9 lb/ft2(239 kg/m2)

Operating Gallonage

67 U.S. Gal. (30 Liters)

Min. 56 U.S. Gal. (212 Liters)

Max. 77 U.S.Gal. (292 Liters)

Product Weight

135 lb (61 kg)

Skirt Mounting

Optional, U-Frame

Electrical Speciﬁcations

Requires a dedicated GFCI protected separate circuit.

Blower: 120 VAC, 15 AMP, 60 Hz.

Heater

No water heater is available on this unit. Blower has integral air heater.

*72"

21"

42"

14" x 4"

8-1/2"

6-7/8"

Blower

12" H x 18" L

Service Access

Opt. Service Access

NOVA® 6, RIGHT HAND PURE AIR II BATH

END VIEW

20-1/2"

42"

SIDE VIEW

72"

(51 mm) (Blower)

#FQ96 12/06

DRAIN/OVERFLOW

Product Shown: Nova™ 6 Pure Air II Bath Left Hand Model: EA10

* Measurements inside unit represent cutout in ﬂoor to allow for drain/overﬂow.

Minimum Service Access dimensions given.
