Operating instructions
Website:www.jtechdigital.com
TollFree:1-888-610-2818
Email:[email protected]
USER MANUAL
J-Tech Digital® 492Ft/150M HDBaseT 4K Extender
Supports 4K/60Hz 4:4:4 HDR
Model: JTECH-UHDT150
JTD-ID: 614
Thank you for purchasing this product
For optimum performance and safety, please read these instructions carefully
before connecting, operating or adjusting this product. Please retain this manual
for future reference.
Surge protection device recommended
This JTD-614 contains sensitive electrical components that may be damaged
by electrical spikes, surges, electric shock, lighting strikes, etc. Use of surge
protection systems is highly recommended in order to protect and extend the
life of your equipment.
Table of Contents
1. Introduction............................................................................................
2. Features..................................................................................................
3. Package Contents................................................................................
4. Specifications........................................................................................
5. Operation Controls and Functions......................................................
5.1 Transmitter Panel.............................................................................
5.2 Receiver Panel................................................................................
5.3 IR Pin Definition................................................................................
6. Application Example............................................................................
1
1
2
2
4
4
5
6
8
1. Introduction
2. Features
☆HDCP 2.2 / HDCP 1.4 and DVI 1.0 compliant
☆Supports 18Gbps video bandwidth
☆The maximum extended transmission distance via a single Cat5e/6 cable:
394 feet / 120 meters for 4K2K signal;
492 feet / 150 meters for 1080P signal
☆Supports one HDMI loop output on the transmitter
☆Sends de-embedded audio signal to analog stereo output on receiver
☆With bi-directional IR, RS-232 and CEC pass-through
☆HDR, HDR10+, Dolby Vision and HLG functions supported
☆Supports PoC (Power over Cable) function
☆Compact design for easy set-up and installation
1 / 9
This 18Gbps HDMI Extender transmitter receiver set lets you "extend" the
distance between your HDMI source and display devices by up to 492ft./
150m via a single Cat 5e/6 Ethernet cable. Integrated HDBaseT technology
maintains signal stability and quality, reducing signal loss and latency.
HDMI 2.2 and HDCP 1.4 compliant, this HDMI extender set supports a wide
range of video resolutions (up to 4Kx2K@50/60Hz 4:4:4) and HD audio
formats (including LPCM 2.0, Dolby Digital, Dolby TrueHD, Dolby Digital Plus,
and DTS). RS-232 port and bi-directional IR controls let you easily operate
your connected devices. A HDMI out port on the transmitter lets you add a
second, local, HDMI display to the mix.
Easy to set up, and useful for a wide range of home, office, school, and retail
applications - perfect for any situation where you need to send a HDMI signal
from a HDMI source to a HDMI display that's located outside the transmission
range of HDMI cables.
3. Package Contents
4. Specifications
Human body model — ±8kV (Air-gap discharge) &
±4kV (Contact discharge)
ESD Protection
Technical
HDCP Compliance HDCP 2.2 / HDCP 1.4
Video Bandwidth 18Gbps
Video Resolution
4K2K 50/60Hz 4:4:4
4K2K 50/60Hz 4:2:2
4K2K 50/60Hz 4:2:0
4K2K 30Hz 4:4:4
1080p, 1080i, 720p, 720i, 480p, 480i
All HDMI 3D TV formats
All PC resolutions including 1920 x 1200
Color Space RGB / YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0
Color Depth
8/10/12-bit (1080P60Hz, 4K30Hz, 4K60Hz YCbCr
4:2:2/4:2:0)
8-bit (4K60Hz 4:4:4 )
HDMI Audio Formats
LPCM 2.0/2.1/5.1/6.1/7.1, Dolby Digital, Dolby
TrueHD, Dolby Digital Plus(DD+), DTS-ES, DTS
HD Master, DTS HD-HRA, DTS-X
Qty Item
1 18Gbps HDMI over HDBaseT Extender (Transmitter)
1
1 IR Blaster cable (1.5 meters)
1 20~60KHz IR Receiver cable (1.5 meters)
4 Mounting Ears
3-pin Phoenix connectors2
1 24V/1A Locking Power adapter
1 User Manual
L/R Audio Formats PCM 2.0
2 / 9
18Gbps HDMI over HDBaseT Extender (Receiver)
Resolution /
Cable Length
Power Supply Input: AC 100 - 240V 50/60Hz
Output: DC 24V/1A (Locking connector)
Operating
Temperature
9.36 W
Storage Temperature
32 - 104°F / 0 - 40°C
Relative Humidity
-4 - 140°F / -20 - 60°C
Power Consumption
20 - 90% RH (no condensation)
Dimensions
BlackColor
Transmitter / Receiver:
140mm [W] x 65mm [D] x 18mm [H]
Metal EnclosureHousing
Weight Transmitter: 160g, Receiver: 155g
4K2K
HDMI IN / OUT
492ft / 150M
16ft / 5M
Receiver
The use of “Premium High Speed HDMI” cable is highly recommended.
Input: 1x HDBT IN [RJ45, 8-pin female]
Outputs: 1x HDMI Type A [19-pin female]
1x AUDIO OUT [3.5mm Stereo Mini-jack]
Controls: 1x IR IN [3.5mm Stereo Mini-jack]
1x IR OUT [3.5mm Stereo Mini-jack]
1x RS-232 [Phoenix jack]
1x SERVICE [Mini-USB, Update port]
Mechanical
4K60 -
Feet / Meters
4K30 -
Feet / Meters
1080P60 -
Feet / Meters
32ft / 10M 50ft / 15M
Connection
Transmitter
Input: 1x HDMI Type A [19-pin female]
Outputs: 1x HDMI Type A [19-pin female]
1x HDBT OUT [RJ45, 8-pin female]
Controls: 1x IR IN [3.5mm Stereo Mini-jack]
1x IR OUT [3.5mm Stereo Mini-jack]
1x RS-232 [Phoenix jack]
1x SERVICE [Mini-USB, Update port]
394ft / 120M
1080P
3 / 9
Resolution / Distance
5. Operation Controls and Functions
5.1 Transmitter Panel
DC 24V/1A power supply input port.
Note that the extender supports PoC function, it means that either
transmitter or receiver is powered on by 24V/1A power adapter, the
other one doesn’t need power supply.
HDMI loop output for display.
SERVICE
IR IN IR OUT
HDMI OUT HDMI IN
HDBT OUT
DC 24V
Name Function Description
Power LED Red LED indicates that the transmitter is powered on.
SERVICE port Firmware update port.
DC 24V
HDBT OUT
Connection
Signal
Indicator lamp
▪ Illuminating: Transmitter and Receiver are in good
connection status.
▪ Flashing: Transmitter and Receiver are in poor connection
status.
▪ Dark: Transmitter and Receiver are not connected.
Data Signal
Indicator lamp
▪ Illuminating: HDMI signal with HDCP.
▪ Flashing: HDMI signal without HDCP.
▪ Dark: No HDMI signal.
HDMI OUT
HDMI IN HDMI source input.
IR IN IR input port for receiving the signal of IR remote.
IR OUT IR output port for control of source device. This IR output signal
is from the IR IN port of receiver.
RJ45 connector for connecting the HDBT IN port of receiver
with a CAT 5e/6 cable.
4 / 9
1 2
3 4 7 8 9 10 115 6
No.
1
2
3
4
5
6
7
8
9
10
RS-232
3-pin Phoenix connector for RS-232 command transmission.
The RS-232 command will pass-through from transmitter to
receiver or from receiver to transmitter.
5.2 Receiver Panel
SERVICE
IR IN IR OUT
HDMI OUT
DC 24V
HDBT IN
AUDIO OUT
DC 24V/1A power supply input port.
Note that the extender supports PoC function, it means that either
transmitter or receiver is powered on by 24V/1A power adapter, the
other one doesn’t need power supply.
HDMI output for display.
Name Function Description
Power LED Red LED indicates that the receiver is powered on.
SERVICE port Firmware update port.
DC 24V
HDBT IN
Connection
Signal
Indicator lamp
▪ Illuminating: Transmitter and Receiver are in good
connection status.
▪ Flashing: Transmitter and Receiver are in poor connection
status.
▪ Dark: Transmitter and Receiver are not connected.
Data Signal
Indicator
▪ Illuminating: HDMI signal with HDCP.
▪ Flashing: HDMI signal without HDCP.
▪ Dark: No HDMI signal.
HDMI OUT
AUDIO OUT 3.5mm stereo connector for analog audio output.
RJ45 connector for connecting the HDBT OUT port of
transmitter with a CAT 5e/6 cable.
5 / 9
1 2
3 4 7 8 9 10 115 6
11
No.
1
2
3
4
5
6
7
8
5.3 IR Pin Diagrams
IR RECEIVER IR BLASTER
IR Blaster
IR Receiver
IR Blaster Signal
Power
NC
IR Signal
Power
Grounding
IR IN IR input port for receiving the signal of IR remote.
IR OUT IR output port for control of display device. This IR output signal
is from the IR IN port of transmitter.
RS-232
3-pin Phoenix connector for RS-232 command transmission.
The RS-232 command will pass-through from transmitter to
receiver or from receiver to transmitter.
6 / 9
9
10
11
Bi-directional IR control system diagram:
Note: When the angle between the IR receiver and the remote control is ± 45 °, the
transmission distance is 0-5 meters; when the angle between the IR receiver and the
remote control is ± 90 °, the transmission distance is 0-8 meters.
IR IN IR OUT
HDMI OUT HDMI IN
HDBT OUT
DC 24V
IR IN IR OUT
HDMI OUT
DC 24V
HDBT IN
AUDIO OUT
LAN
LAN
TV
DVD
DVD remoteTV remote
CAT 5e/6 cable
IR Receiver cable
IR Blaster cable
7 / 9
ReceiverTransmitter
6. Transmitter/Receiver Connection and Set Up
Diagram:
DVD or Blu-ray Player
IR Receiver
Power Supply
UHDTV
IR Blaster
IR IN IR OUT
HDMI OUT HDMI IN
HDBT OUT
DC 24V
IR IN IR OUT
HDMI OUT
DC 24V
HDBT IN
AUDIO OUT
LAN
LAN
2.0 Speakers
UHDTV
IR Receiver
IR Blaster
Receiver
Transmitter
CAT 5e/6 cable
8 / 9
RX
RS-232 DC 12VUSBUSBLAN
